Windsor SENSOR SR18 User manual

Picture 1 - Figura 1
1
Handle grip
2
On/Off switch
3
Handle assembly
4
Retaining ring
5
Cover release
6Dust
.bag housing
7
Cover
8Housing release
9
Brush/suction Head
10 Cable
11
Telescopic handle grip
12 Hose
13
Carrying handle
14
Cable hook
15
Attachment tube
16
Crevice nozzle
17
Upholstery nozzle
18
Foot pedal
Preparation
Place the brush/suction head on a flat surface
with the neck (20) and the support lever (21)
upright. Hold the dust bag housing vertically
and place over neck and support lever. Push
firmly down so that the housing release (8)
snaps closed.
Lift the catch (22) then slot the handle
assembly into the top of the dust bag housing
(6) and push firmly down.
When the handle has been pushed down as
far as it will go press catch (22) down. If the
handle is not pushed fully down the machine
will not work.
Insert attachment tube (15) into the channel at
the back of the machine. Locate the handle
grip (11) on the holder (24).
Push the black end of the hose into the
connecting tube (26) so that it clicks into
place.
Insert crevice nozzle and upholstery nozzle
into the recesses in the back of the machine.

Functions of the display:
Green light (a) : Brush lowers
Green light (b) : Brush raises
Red light
(c) : Continous-change brush
Red light
(c) : Flashing and motor off-
Brushjammed-clear
Red light (c) : Flashing and motor on
(when machine is upright
position)-Take care: Brush
in contact with carpet.
Red light (d) : Continuous-change paper
bag or clear blockage
Red light (d) : Flashing
- motor switched
off due to full paper bag or
blockage.
On hard floors the adjustment wheel (41)
moves upwards into the machine so that the
brush becomes flush with the floor.
Therefore, the WINDSOR “SENSOR” can
also be used to vacuum hard floors.
On carpeted floors the adjustment wheel (41)
moves downwards out of the machine so that
the brush rises. The adjustment wheel (41)
rises and lowers to adjust the brush to the
optimal setting. This combines effective, gentle
brushing with a smooth easy action.
When the machine is switched on in the up-
right position the brush automatically rises
from the carpet. To release the machine from
the upright position, press down the foot pedal
(18). The brush will automatically lower. The
handle can be lowered to an intermediate stop
position in order to lift up the brush head. T O
lower the handle to a horizontal position, the
foot pedal must be pressed a second time. The
stop position can be closed off by a slider on
the swivel neck (19) so that the handle will go
from vertical to horizontal in one movement.
To vacuum in corners etc.,
take hold of the telescopic handle grip, lift it
away from the machine and stretch out the
hose. After use insert the telescopic
attachment tube into the back of the
machine. Raise the handle of the machine
and the hose will automatically retract. To
use the hose without the tube as shown in
the right hand picture, the hose will pull out
of the tube while the tube is fitted to the
machine. Alternatively, press the release
catch (27) on picture 2.
To vacuum under beds etc., the
WINDSOR “SENSOR” can be fitted with an
additional straight tube and the floor nozzle.
The machine will then perform as a cylinder
vacuum.
Never run over the cable with the brush/
suction head.
Always carry the machine over steps and sills.

Maintenance
CAlJTlON -Always unplug machine at mains
outlet before dismantling any part of machine
If red light (d) shows, change paper filter bag.
To do this first pull cover release (5) picture 1
forward and lift the cover from the dust bag
housing. Slide the dust bag sealing plate (28)
from the holder (29). Slide the sealing plate
(28) of a new bag into the holder and push
firmly in. Insert cover into dust bag housing,
push it forward then lock it in place by pushing
down the cover release (5).
The micro hygiene filter (30) needs to be
changed when it becomes clogged with dust
or after approximately 20 paper bags have
been used. To change the hygiene filter first
remove the cover then slide the filter out at the
bottom. To replace lift the lever and slide the
new filter in.
After 20 paper bags have been used also
change the exhaust filter (32). To remove the
exhaust filter push the catch (33) backward
and remove the filter cover (34) and filter.
Insert the new filter and replace the filter cover.
To change the brush roller (35) and the edge
brush (35a) press the release knobs (36 or
36a), pull the bearing block (37) or the brush
cover (37a) outwards. Turn the brush roller
(35) clockwise, and the edge brush (35a) in the
direction of the arrow marked on the end of
the brush, and pull each brush out of the
channel. The new brushes are fitted back into
the channel and onto the drive shafts, both are
turned until they snap into position, then
replace bearing block (37) and brush cover
(37a).
Underneath the machine is an inspection door
to check for blockages (38).
Blockages-in the neck (20 - picture 2) can be
checked by first lifting off the dust bag housing
by pressing the catch (8). Then release the foot
pedal, lower the neck and check into the tube
next to the pedal.
Blockages in the hose can cleared by taking
the hose off the machine and replacing it the
wrong way round in the connecting tube (26)
holding it upright with one hand blocking the
top and switching on the machine. (If
necessary quickly lift your hand on and off the
end of the hose.)
The guarantee is invalidated if take out
parts not approved by WINDSOR. eg. bags,
filters, brush roller, etc. are fitted!

120 V GREY
Pos. Pmduct-
Code
101 5346 UL
102 5006 bl
103 5007 BL
104 5143
105 5257 hg
106 5256 UL
107 0102
108 2494
109 5101
110 5178
111 5177
112 5203ER
113 5205
114 5102 bl
115 5103
116 5051 hg
117 5059dg
118 5053
119 5055hg
120 2010
121 2014
122 5287 bl
123 5276 WI
124 5231 hg
125 5155 hg
126 5172HG
127 5303
128 5304
129 5154hg
130 0100
131 0176 TL
132 5174 hg
133 5060 ER
134 5415 hg
135 5416hg
136 5400-3
137 5401
138 5402
139 0197
141 5322 UL
142 0511
5272 UL
143 5100
144 5117
145 5129
146 5107
147 5112sw
148 5278 ER
149 0107
150 0143
151 5173 SW
152 5383
153 0104
154 5379
155 5110
158 5242 hg
157 5243 hg
158 5236
159 5327
160 5179
161 0103
182 0141
163 5018UL
184 5239 bl
185 5244 hg
166 5288 bl
167 5250
168 5246
Description
PowerheadcoverSR18
Exhaust filter catch
Exhaustfiltercover
Exhaust filter
Swivelneckassembly
(incl. Pos.106)
Malecontactholder
Screw F 3.9 x 13
Cableclamp
Swivelneckbearing
Swivelnecksupportrighthand
Swivelnecksupportlefthand
PCB 12 V power supply
Ribbon cable
Brush roller release
Spring
Axleassembly
Footpedal
Axle
Wheel
Axle spring
Axleclamp
Bearingblockrighthand
Brushrollerset (incl. Pos. 167)
Bumper, set
Rubbingplate
Access door (incl. Pos.127+128)
Accessdooraxle
Access door spring
Hinge
screw c 2,9 x 9,5
Screw AM 4 x 30,
Pile adjustment wheel
Servomotorwithgearbox
Frontbottomplate,cpl.
Rearbottomplate,cpl.
(incl. Pos.136+139)
Sealing strip
Wire tie
Wire tie
screw
Chassis, complete
Carbonbrushvacuummotor
Motor 850 W / 120 V
Rubber mounting
Motorpulley
Supportlever
Supportspring
Motorpulleycover
Computercontroller120V
Screw C 2,9 x 13
Washer 3,2
Coverforairchannel
Sensor (with blue ring)
ScrewC3.9x25
Belt 312 3M-HDTII-8
Belt 219 3M-HDTII-6
Bearingblocklefthand,cpl.
Bearingblocklefthand
Drive shaft
Bushing
Clutch
ScrewC3,9x16
Lockingwasher
Motorcover
Brush roller release
Seal bearing
Brush cover
Edge brush
Shaftextension. cpl.
164
165

SENSOR SR 18
