Winlong Industrial SCC-RF-MI-C40 User manual

JIANGMEN WINLONG INDUSTRIAL ROBOT CO.,LTD
SMART CARD READER
SCC-RF-MI-C401 User Manual

Make sure USB port (1) connects to PC ,another port (2)
connects to reader port (3), check the white LED
models (4)， the status indicato (5)
reading and writing area（6）
First ,Driver installation process
1.1,At this point you will see in the lower right corner of the Windows
Found New Hardware prompt, Eject Hardware Update Wizard

1.2,Select "setup from listed or specified location" , click "Next" then
1.3,Select "Search for the best driver in these locations" and then
"Include this location in the search" tick, click Browse, select the
folder to ccid driver, click Next
1.4,Click Browse, select the ccid driver folder, click OK, immediately
after the completion of
1.5,After installing the device driver in the Device Manager can be seen
inside the device is smart USB Smart Card Reader Card reader under

Second, Device Test
2.1,After the device driver is installed, open the demo folder, open
demo.exe, under normal circumstances it should appear directly like below
shown.

2.2,Click “select reader”，the reader will be able to detect the card
reader in a column reader

2.3,Follow the instructions on the card reader logo, placed on reading
and writing area (6), the white status indicator (5) bright green, the
reader buzzer sounds, will appear in the ATR column card information, as
shown below.

2.4,Click on a column "reader", reader information below, then "OK"

2.5,In the "Connection Protocol" select "T1", then click on "2, connect",
properly connected, the following "3, transmit" will become available
from gray.

2.6, the message to enter the card's box "ffca000000", then "3, transmit",
will appear the following answer from reader M1 UID numbers (before 8
digits), and finally the bit for 900

2.7,Finally, the card reader scored from the reader buzzer beep, white
status indicator (5) lights red.
Three, card reader and card use
3.1, The card reading device and a computer connected, open the TXT text,
the consumer card is placed on the card reader, whether to hear "drop"
sound or read card device lights, if heard to "drop" sound or read card
device lamp in the bright flash, and TXT text in a consumer card
information appears, indicating that the normal
3.2, If you can not hear the "drops" or card reader lights flashing, and
no consumer card information appears in the TXT text, then it is not normal,
you can check the connection between the card reader and the computer is
normal. Can also check whether the IC card into the correct. Otherwise
you will fail to read the card.

Four, read card applications
4.1, SCC-RF-MI-C401Rev1.0 card reader is a development of smart card
application and system integration of terminal equipment, identity
authentication, e-commerce, financial institutions, information
security, access control and identity and other security applications,
the ideal solution.
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for
a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to pro-vide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equip-ment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the inter-ference at his own expense.
