Winmate M101BC User manual

Getting Started
Congratulations on purchasing this rugged Tablet Computer. The rugged design allows you to
use it in harsh outdoor environments.
This quick start guide tells you step by step how to get the Tablet Computer up and running. You
will find instructions for the following procedures:
•Unpacking
•Description of Parts
•First Time Operations
•Turning On/Off
Unpacking
Check and identify the supplied accessories:
•Tablet Computer
•Standard Battery
•Driver CD
•Power Adapter (19 V)
•Power Cord and Plugs
•Quick Start Guide
•Capacitive Touch Stylus with
tether
•Standard I/O Cover
•Rubber tip for Capacitive touch
stylus
•Screw driver tool
10.1” Bay Trail Tablet PC Quick Start Guide 1

Description Of Parts
Front:
Right:
No
Item
Description
1
Front Camera
2 Megapixel Webcam
2
LED Indicators:
Show the current status of
the Tablet Computer
RF
Green - WiFi/BT/3G/GPS
ON
No light - None of
WiFi/BT/3G/GPS is ON
HDD
Green - Harddrive Activity
No light - Harddrive Idling
Battery
Orange – AC adapter is
plugged in and charging
Green – AC adapter is
plugged in and battery is
completely charged
Solid Red - Low battery
(<10%)
Blinking Red – Battery is
being hot swapped.
Not lit – Battery is in use
and more than 10%
Power
Blue – Tablet is ON
No light – Tablet is OFF
3 Touch Screen
Displays and act as one of
the inputs for the Tablet
Computer
4 Fn1 Button
Programmable function
key configured by HotTab
Utility. Default: Web
Browser
5
Menu Button
HotTab Quick Access
6
Power Button
Turns on/off tablet
Front LED Indicators Detail:
No
Item
Description
7
I/O Cover
Protects I/O ports
8 Micro HDMI
HDMI output to external
display
9 LAN/RS232
Adapter port for
LAN/RS232 connector
10 USB 3.0
High speed USB port
connects to USB
devices, such as USB
flash drive, mouse,
keyboard, printer, etc.
11 Mic In/Line Out
Headset or headphone
can be connected (Mic
is only supported with
3.5mm 4-pin headset)
12
Power Jack
DC-IN power input jack
13
MicroSD Card
Reader
Memory card reader
port for MicroSD Card
14
Reset Button
Hardware reset button
Side I/O Details:
Front Buttons Details:
2 10.1” Bay Trail Tablet PC Quick Start Guide

Rear:
Bottom:
No
Item
Description
15
Kensington
Lock Port
Provides lock access for
Kensington Lock.
16 Optional
Barcode
Barcode Scanner for
reading of 1D/2D
barcode.
17 Optional RFID
RFID reader for reading
of RFID tags.
18 Rear Camera 5MP Autofocus Camera.
Captures photos and
videos.
19 Camera Flash LED camera flash to
provide flash lighting
when camera is in use.
20 Fn2 Button
Programmable function
key configured by
HotTab Utility. Default:
Camera
21 Volume Buttons Volume Control.
(+) Raises volume,
(-) Lowers volume.
22 Battery Lock
Latch
Latch to lock the battery
in place once battery is
inserted. Not spring-
loaded.
23
Battery Release
Slider
Spring-loaded slider that
latches the battery in.
24 Touch Pen Slot
Pen holder slot to store
touch pen
25 3G Module/SIM
card slot
Service window to insert
Micro SIM card. Also
provide access to 3G
Module.
26
Speakers
Emits sounds.
No
Item
Description
27 Docking
Connector
Port to docking solutions
such as vehicle docking
to provide power and
external antenna
Docking Connector Detail:
Rear Buttons
Detail:
Battery Lock Latch
Detail:
10.1” Bay Trail Tablet PC Quick Start Guide 3

Combination Keys (Keyboard Key Emulation)
For the physical buttons on the 10.1” Bay Trail tablet computer, in addition to their dedicated
functions detailed in the previous section, they can also be used to emulate commonly used
keyboard key strokes. Under different scenario, a single physical button or a combination of
physical buttons provide different keyboard key strokes, which are specified below:
Under POST (before Windows boots up):
Buttons
Keystroke
Menu
F7
Fn1
Recovery Menu
Fn2
ESC
Volume Up
Up
Volume Down
Down
Menu + Fn1
Enter
Menu + Volume Up
Right
Menu + Volume Down
Left
Under Windows:
Buttons
Keystroke
Volume Up + Volume Down
Ctrl + Alt + Del
4 10.1” Bay Trail Tablet PC Quick Start Guide

First-time Operation
Insert SIM card (For Optional 3G/LTE equipped device)
The Tablet Computer supports data connection using 3G/LTE SIM cards and fits a Micro-SIM
card. (Note: 3G/LTE feature is optional). Perform the following to install the SIM card into your
Tablet Computer:
Caution •Please perform this action in the safe zone
1. Remove the service window in the rear by unscrewing the four screws.
2. Remove the screw that is securing the 3G/LTE module.
3. Carefully lift the 3G wireless module up, and be careful not to damage the connected
cable.
4. Make sure the SIM card IC contact patch is faced down; the notch is in the direction of
insertion (towards right).
5. Insert the 3G SIM card into the slot located near the right side of the service window.
6. Reposition the removed 3G/LTE module screw to secure the 3G/LTE module.
7. Reposition the removed service window screw to secure the service window.
Step 1
Step 2
Step 3
Step 4
10.1” Bay Trail Tablet PC Quick Start Guide 5

Inserting Battery Pack
To insert the included standard battery pack into the Tablet Computer:
Caution •Please perform this action in the safe zone
1. Disconnect any cords connected to the tablet computer.
2. Turn the tablet computer over, back facing up.
3. Locate the Battery Lock Latch and push it to the “Unlocked” position.
4. Locate the Battery Release Slider that is spring-loaded. Pull back and hold.
5. Insert the battery with the connector-pins side first, and then lower the battery into the
battery compartment. Continue to hold the Battery Release Slider until the battery is fully
inserted.
6. Make sure the battery is completely lowered into the compartment before letting go of the
Battery Release Slider. Battery will be flat against the housing once fully inserted
Removing the Battery Pack
1. Shut down the tablet computer (or put it to sleep). Disconnect any cords connected to the
computer.
2. Turn the tablet computer over, back facing up.
3. Locate the Battery Lock Latch and push it to the “Unlocked” position.
4. Locate the Battery Release Slider that is spring-loaded. Pull back and hold.
5. Lift the battery out using the opening on side of battery compartment.
Connecting to Power Supply
The Tablet Computer operates either on external AC power or internal battery power. It is
recommended to use AC power when you start up the Tablet Computer for the first time. In this
C1D2 version, the I/O connector is only accessible by tooling (screwdriver). To connect the tablet
computer to AC Power, user needs to remove the I/O Cover.
Caution •Please remove the I/O cover in the safe zone
6 10.1” Bay Trail Tablet PC Quick Start Guide

Perform the following to remove the I/O Cover:
1. Turn the tablet computer over, back facing up
2. Remove the I/O Cover on the side by unscrewing the three screws
3. Remove the screw that is securing the I/O Cover
4. Carefully lift the I/O Cover
Caution
•Use only the AC adapter included with your Tablet Computer. Using
other AC adapters may damage the Tablet Computer and the Battery.
•
Please perform this action in safe zone
Perform the following to connect the Tablet computer to AC Power:
1. On the side of the Tablet computer, lift the I/O protective cover by pulling on the latch
2. Plug the DC cord of the AC adapter into the Power Jack of the tablet computer.
3. Plug the AC power cord into the AC adapter.
4. Finally, Plug the AC power cord into the electrical outlet.
When the AC Adapter is connected, the battery pack starts charging. The battery LED indicator
on the tablet computer will show different states. Please refer to description of the LED indicator
in the Description of Parts.
Caution •Please perform this action in the safe zone
10.1” Bay Trail Tablet PC Quick Start Guide 7

When the LED indicator turns green, this indicates the device is fully charged and User needs to
perform the following to reinstall the I/O Cover:
1. Turn the tablet computer over, back facing up
2. Reposition the I/O Cover on the side by placing the three screws into the screws hole
3. Carefully insert the three screws until it covers the I/O
Note: User can also use standard I/O Covers for device deployment in the safe zone; perform the
following to install the standard I/O Covers:
1. Place the seal mounting plate into the inset of the I/O seal
2. Insert the three screws into the plate, making sure not to over tighten them
3. Make sure the I/O seal is properly aligned and the port is correctly sealed
8 10.1” Bay Trail Tablet PC Quick Start Guide

Turning On / Off
Turning On
Press and hold the power switch for 3 seconds until the blue LED power indicator light is lit up.
Note:
•Do not press the power switch repeatedly.
•Do not perform the following operations until the hard drive indicator turns off
oConnecting or disconnecting the AC adapter
oPressing the power switch
oTouching the tablet buttons, screen, or external keyboard/mouse
Turning Off
Perform the following procedure to shutdown the Tablet Computer:
1. Make sure you have closed any programs that are open on the Desktop. Start Screen
apps don’t need to be closed.
2. Open the Charms Bar by swiping your finger from the far right of the screen towards the
middle of the screen.
3. Tap on the Settings charm.
4. Tap on Power.
5. Tap on Shut Down.
6. Wait for the Tablet Computer to power off.
Note:
•The computer will forcefully be turned off if the power switch is pressed and held for six
seconds or longer.
10.1” Bay Trail Tablet PC Quick Start Guide 9
