Wirata WF-160 User manual

MODEL NO.
WF-160
POWER
50W
VOLTAGE
220-240V
FAN SIZE
16” (400mm)
FREQUENCY
50Hz
NO. OF BLADE
5
FAN SPEED
3
INSTRUCTION MANUAL
Model No.:
WF-160
Please read Instruction Manual before use
& follow ALL the instructions carefully.

WHAT’S IN THE BOX
PARTS DESCRIPTION
1: Front grill 9: Switch housing
2: Fan Blade nut 10: 3 Speed pull control
3: Fan Blade 11: Oscillation pull control
4: Rear Grill Screw 12: Wall mounting bracket
5: Rear Grill 13: Wall Plugs
6: Motor Shaft 14: Fixing screw
7: Motor Housing 15: Grill screw
8: Tilt neck
1. Wall Fan –1set
2. Instruction Manual–1 set
MAIN COMPONENT：
(Product may vary slightly from what is illustrated)

When using the electrical appliance, the following basic
safety precautions should always be followed.
Please read these instructions carefully. Pay your special
attention to important safety instructions. Keep this
“Instructions for use” for future reference.
WARNING - To reduce the risk of fire, electric shock or injury to persons
or property:
1. Always operate the product from a power source of the
same voltage, frequency and rating as indicated on the
product identification plate.
2. Do not use this fan with any solid-state speed control
device to reduce the risk of electric shock.
3. The appliance is not intended for use by persons
(including children) with reduced physical, sensory,
mental capabilities or lack of experience and
knowledge, unless they have been given supervision or
instructions concerning use of the appliance by a
person responsible by their safety.
4. Children should be supervised to ensure that they do
not play with the appliance.
5. Do not leave the fan running unattended.
6. Do not operate the product if it is dropped, damaged or
showing signs of product malfunction. Do not operate
the product with a damaged plug or cord. Return the
complete product to the place of purchase for
inspection, refund or replacement.
7. If it is not working properly, contact a qualified
electrician or service centre for examination and repair,
never try to dismantle it by yourself.
GENERAL INSTRUCTION
SAFETY INSTRUCTIONS

8. Do not immerse or expose the product or flexible cord
to rain, moisture or any other liquid.
9. This product should not be used in the immediate
vicinity of water, such as bathtubs, washbowls,
swimming pools etc. where the likelihood of immersion
or splashing could occur.
10. Never install the unit where it could be subject to:
•Heat sources such as radiators, heat registers, stoves
or other products that produce heat
•Direct sunlight
•Mechanical vibration or shock
•Excessive dust
•Lack of ventilation, such as a cabinet or bookcase
•Uneven surface
11. Switch off and unplug from outlet when the product is
not in use, before assembling or disassembling parts
and before cleaning. Fully assemble the fan before
switching on.
12. Avoid contact with moving parts. Do not insert any
body parts (e.g., finger) or objects through the grill
when the fan is operating.
13. Do not cover the grille, or operate in close proximity to
curtains, etc.
14. This product is intended for normal domestic/household
use only.
15. Always disconnect the fan when moving it from one
location to another.
16. The use of attachments or accessories not
recommended or sold by the product distributor may
cause personal or property hazards or injuries.
17. Be sure fan is on a stable surface when operating to
avoid overturning.
18. Do not immerse in water.
19. If the supply cord is damaged, it must be replaced by
the manufacturer or its service agent, or similarly
qualified person, in order to avoid a hazard.

1. Remove the rear grill lock nut (4) from the motor shaft
spindle (6).
2. Fill the rear grill (5) by positioning it on the location
pins. Secure the grill to the motor body with the grill
lock nut (4).
3. Push the fan blade (3) onto the motor shaft (6) until
the fan blade is appropriately fitted. For models with
shaft pins, push the fan blade onto the motor shaft by
matching the slots on the base of the blade with the
shaft pin.
4. Secure the blade with the blade nut (2) by turning it
COUNTER - CLOCKWISE. Check that the fan blade
rotates freely by turning it with your hand.
5. Open securing clips around the front grill (1) and
loosen the clip screw at the bottom of the front grill.
Position the top clip on the uppermost part of the rear
grill. Push the top clip down and press rim of the front
grill onto the rear grill. Close all clips around and
tighten the safety screw.
6. Select an appropriate location and fix the mounting
bracket (12) onto a strong wall (or locate a stud behind
plaster boards) with three wall plugs (13) and screws
(14) supplied.
Note: Consider a location within a distance of 0.8m radius from
a wall power outlet to make sure you can plug the unit into the
power point easily.
7. Mount the wall fan on the mounting hook and plug in
the unit.
8. If the power cord is hanging loosely between the fan
and the power outlet, make sure it will not touch or
obstruct fan blade rotation or fan oscillation in any
way.
WARNING: Do not use the device near water, over the bath tub,
pool or other water basin.
*Observe the above-mentioned rules in order to avoid burning,
electric shock or fire hazard. Make sure you understand the
instructions.
ASSEMBLY INSTRUCTION

1. Plug the fan into an electrical socket and switch on at
the wall.
2. You can control your wall fan either with the twist
knob, or with pull cords.
3. Pull on the cord to switch the fan on. At first start-up
the fan will operate at low speed.
4. Pull on the same cord a couple of times to reach
desired fan speed. Choose between Low (1), Medium
(2) and High (3) fan speed.
5. Pull on the other cord to switch on the oscillation mode.
Caution: The fan should always be switched off when making
this adjustment.
1. Switch off and unplug from the power supply before
assembling or disassembling and cleaning.
2. Keep the air vents at the rear of the main body free
from dust or fluff- use a vacuum cleaner to remove
these when necessary. Do not probe any opening to
remove fluff.
3. Fan component parts should be cleaned using mild
soap and a damp cloth or sponge. Do not allow any
water or other liquid to enter the motor housing
4. Thoroughly remove soap film with clean water.
CAUTION: Do not use harsh detergents, chemical cleaners or solvents as
they may damage the surface finish of the fan components.
ENVIRONMENT PROTECTION
Dispose the appliance according to the local garbage
regulations. Never throw it away to the rubbish, so you will
help to the improvement of the environment.
HOW TO OPERATE
CLEANING INSTRUCTION
