Wittco 1826-7-DBL Installation and operation manual

OPERATIONS
MAINTENANCE
MANUAL
FOOD HOLDING & TRANSPORT CABINETS
WITTCO MODEL NUMBERS
1826-7-DBL
1826-7-DBL-IS

LIMITED WARRANTY
Wittco warrants the Products that it manufactures to be free from defects in materials and workmanship, under normal use and
service, for the periods indicated below from the date of purchase when installed and maintained in accordance with Wittco's written
instructions. Buyer must establish the "Products" purchase date by returning Wittco's Warranty registration Card or by other means
satisfactory to Wittco in its sole discretion.
Wittco warrants its Products to be free from defects in materials and workmanship from the date of purchase (subject to the
foregoing conditions) for the period(s) of time and on the conditions listed below:
a) Ninety (90) days Labor Warranty
b) One (1) Year Parts Warranty
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ANY OTHER WARRANTY. EXPRESSED OR IMPLIED.
INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE OR PATENT OR OTHER INTELLECTUAL PROPERTY RIGHT INFRINGEMENT. Without limiting the generality of the
foregoing, SUCH WARRANTIES DO NOT COVER: Coated incandescent light bulbs or heat lamps, all glass components. Product
misuse, tampering, misapplication, application of improper voltage, or recalibration of thermostats or high limit switches.
LIMITATION OF REMEDIES & DAMAGES
Wittco's liability and Buyer's exclusive remedy hereunder will be limited solely, at Wittco's option, to repair or replacement by a
Wittco authorized service agency (other than where Buyer is located outside of the United States or Canada, in which case Wittco's
liability and Buyer's exclusive remedy hereunder will be limited solely to replacement of part under warranty) with respect to any
claim made within the applicable warranty period referred to above. Without limiting the generality of the foregoing, all portable
Products, as defined by Wittco, shall be delivered by Buyer, at its sole expense, to the nearest Wittco authorized service agency for
replacement or repair. Wittco reserves the right to accept or reject any such claim in whole or in part. Wittco will not accept the
return of any Product without prior written approval from Wittco, and all such approved returns shall be made at Buyer's sole
expense. WITTCO WILL NOT BE LIABLE. UNDER ANY CIRCUMSTANCES, FOR CONSEQUENTIAL OR INCIDENTAL
DAMAGES, INCLUDING BUT NOT LIMITED TO LABOR COSTS OR LOST OF PRODUCTS AND LOSS OF PROFITS
RESULTING FROM THE USE OF OR INABILITY TO USE THE PRODUCTS.

WITTCO TECHNICAL & PRODUCT SUPPORT
TECHNICAL SUPPORT & SERVICE INQUIRES MAY BE DIRECTED TO WITTCO BY:
1. CALLING DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT TECHNICAL & SERVICE DEPARTMENT - (800)
367-8413
8:00 AM - 4:30 PM (CENTRAL TIME)
2. FAX1NG DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT TECHNICAL & SERVICE DEPARTMENT - (414)
354-2821
DAILY 24 HOURS
3. MAILING DIRECTLY TO:
WITTCO FOODSERVICE EQUIPMENT INC.
7737 NORTH 81ST. STREET
MILWAUKEE, WISCONSIN 53223 USA
WHEN DIRECTING INQUIRIES TO WITTCO PLEASE HAVE THE FOLLOWING INFORMATION AVAILABLE TO AVOID DELAYS
1. Wittco model number indicated on the equipment serial data plate located at the electrical connection.
2. Wittco serial number indicated on the equipment serial data plate. The equipment serial number will also have
two (2) alpha characters immediately following the serial number. These alpha characters are part of the serial
number.

INTRODUCTION
The 1826 DBL and 1826 DBL IS series of commercial and institutional cabinets from Wittco Foodservice Equipment
provide an efficient and sanitary method of holding and transporting prepared food products. Because these cabinets
provide individual controls for each of the two compartments, the operator is able to hold two different products at two
different temperatures in separate sections of the same unit. They have found wide acceptance in all types of food
service operations. Schools, hospitals, restaurants, and correctional facilities are all users of these dependable and
useful cabinets.
This manual has been produced to provide persons responsible for the operation and maintenance of the equipment
with a simple but comprehensive understanding of its proper use. We recommend that this manual be read and
understood prior to placing the cabinet in operation.
As with any piece of food service equipment, this holding and transport cabinet will require a minimum amount of care
and maintenance. Suggestions for this procedure are contained in this manual and should become a regular part of the
operation of the unit.
NOTE: The holding and transport cabinet should be cleaned in accordance with the instructions contained in
this manual.
It is recommended that prior to placing the holding and transport cabinet into operation that it be pre-heated at the
highest temperature setting for a period of 30-45 minutes.
Should repair or adjustment of the unit become necessary, we suggest that procedures described in this manual be
followed. The operator may also contact the authorized Wittco dealer who sold the product or an authorized Wittco
service agency. If the needed repair occurs during the warranty period, prior authorization is required from Wittco by
the service company before the work is done.
It is our sincere desire that you obtain the maximum benefit from your Wittco heated holding and transport cabinet. If
at any time questions arise or additional information is required, contact Wittco at 800 367-8413.
DESCRIPTION
The Wittco 1826 DBL series cabinets provide an efficient means of holding and transporting bulk prepared foods at
proper serving temperatures. The 1826 DBL commercial series cabinets will accommodate 7 each 18 X 26 sheet pans,
7 each 12 X 20 X 2 1/2 steam table pans, or a combination of both by utilizing the adjustable universal tray slides. The
1826 institutional series will accommodate 7 each 18 X 26 sheet pans, 14 each 12 X 20 X 2 1/2 steam table pans, or a
combination of both. It will also accommodate 1/1 or 2/1 gastronome pans.
UNCRATING

Each Wittco Foodservice Equipment cabinet is packed in a cardboard carton which, in turn, is banded to a wooden
pallet. When the cabinet is received by the operator, the carton should immediately be inspected for any sign of visible
exterior damage. If carton is punctured or dented, it may be an indication that the cabinet has sustained concealed
freight damage.
It is very important that any evidence of damage be noted on the Bill of Lading at the time of receipt.
UNPACKING THE CABINET
1. Remove the banding material holding the carton to the pallet.
2. Remove the cardboard carton and the plastic bag covering the cabinet.
3. Carefully move the cabinet off the carton bottom and pallet.
4. Open the cabinet doors and remove the boxes containing the adjustable tray slides and upright tray slide side
supports.
5. Remove the cardboard element cover protector from the bottom of the cabinet.
6. Open the boxes and install the tray slide supports in each compartment. To install the supports, hook the openings
in flat flange of the support over two vertical carriage bolts on the interior of the cabinet. Make sure that all
flanges on the four supports are facing the door opening. Remove the adjustable tray slides from the box and
install them in the cabinet. The hook on the end of the slide must be up in order for slides to be properly installed.
7. Pre-heat the cabinet for 30-45 minutes before using.
ELECTRICAL REQUIREMENTS
The 1826 series of holding and transport cabinets are factory wired for either 110/120 volt or 208/240 volt, single
phase operation. All 110/120 volt units are equipped with an 8 foot cord and NEMA 5-15 plug as standard equipment.
All 208/240 volt units are equipped with an 8 foot cord and NEMA 6-15 plug.
CAUTION: Verify that the power source matches the data plate on the lower rear of the cabinet and the plug
configuration before the connection is made.
OPERATION
The control panel of the 1826 DBL series cabinets contains a dual indicator operating light with both amber and red
lamps, a dial thermometer, and a full range thermostat.
After the cabinet is connected to an appropriate power source, the operator will notice that the red indicator lights are
illuminated. These lights will continue to be on as long as the cabinet is connected to the power source.
Rotate the thermostat knobs so that they point to the number 5. This will cause the heating elements to start heating.
When this occurs, the amber indicator lights will be illuminated. These lights will stay on as long as the heating
elements are engaged. Once the predetermined temperature is achieved, the heating elements will begin to cycle.
During this period, the amber lights will turn on and off.

As the elements are heating, the thermometers will begin to move and indicate the interior temperature of the
compartments. At the number 5 setting the thermometer should indicate an average temperature of approximately 150
degrees0F.
NOTE: The temperature in any heated cabinet will fluctuate as the heating elements cycle on and off. The
thermostat setting will provide an average air temperature in the cabinet. However, the operator should always
monitor the food product to insure that it remains at proper temperatures.
REMEMBER - THE GREATER THE THERMOSTAT NUMBER SETTING THE HIGHER THE CABINET
TEMPERATURE AND THE LOWER THE THERMOSTAT NUMBER SETTING THE LOWER THE
CABINET TEMPERATURE.
CLEANING
The interior of the compartments should be cleaned whenever a food spill occurs. Use a mild soap and water to clean.
The tray slides should be removed and cleaned in a sink if necessary. Never use harsh chemicals or abrasive pads to
clean the cabinet.
REPLACEMENT OF ELECTRICAL COMPONENTS
It is highly recommended that only Wittco Foodservice Equipment replacement parts be used to insure compatibility of
component parts in the operation of holding and transport
cabinet.
The controls of the lower compartment are accessed by opening the door and removing the door gasket from the top of
that compartment. Two screws are then visible and when they are removed, the control panel will tip forward allowing
access to the compartment controls.
THERMOSTAT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the cover off the cabinet to expose the
thermostat.
3. Remove the black thermostat knob from the control panel by loosening the "L-end" screws that holds it to the
thermostat stem.
NOTE: PRIOR TO LOOSENING THE "L-END" SCREWS, TURN THE BLACK THERMOSTAT
KNOB SO THAT THE ARROW ON THE KNOB IS IN THE "OFF" POSITION
4. Notice the arrangement and connection of all electrical leads and refer to the wiring diagrams for reference.

THERMOSTAT REPLACEMENT (CON'T)
5. Disconnect the wire leads connected to the thermostat.
6. Loosen the screws holding the temperature sensing bulb and remove it from the interior of the cabinet. The
temperature sensing bulb must be replaced whenever the thermostat is replaced.
7. Remove the two screws on the front of the control panel that hold the thermostat in place and remove it.
8. Install the replacement thermostat and temperature sensing probe following the reverse of the above procedure.
9. Reinstall the cabinet top cover and screws.
10. Reconnect the cabinet to the power source and test.
INDICATOR LIGHT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the cover off the cabinet to expose the
indicator light.
3. Notice the arrangement and connection of all electrical leads and refer to the wiring diagrams for reference.
4. Disconnect the wire leads connected to the indicator light
5. Depress the side mounted retaining clips on the indicator housing and remove the light from the front on the
control panel.
6. Install the replacement indicator light by pushing it into the control panel until the retaining clips snap into place.
7. Reconnect the electrical leads to the indicator light.
8. Reinstall the cabinet top cover and screws.
9 Reconnect the cabinet to the power source and test.

HEATING ELEMENT REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Open the door to the cabinet.
3. Remove the bottom mounted element cover.
4 Remove the retaining screws securing the element to the interior rear of the cabinet.
5. Gently pull the element from is housing until the electrical lead wire connectors are exposed.
6. Disconnect the defective element at the electrical lead wire connectors.
7. Connect the element lead wires to the cabinet lead wires by reinstalling the wire connectors.
8. Tuck the residual wire back through the wire housing hole until the replacement element is against the interior
rear wall.
9. Reinstall the element retaining screws.
10. Reinstall the protective element cover.
11. Reconnect the cabinet to the power source and test.
THERMOMETER REPLACEMENT
1. DISCONNECT THE CABINET FROM ITS POWER SOURCE.
2. Remove the top cover by removing the retaining screws and lifting the top cover off the cabinet to expose the
thermometer.
3. Identify and remove the thermometer sensing bulb screws and retaining clips located in the interior top of the
cabinet. Pull the thermometer sensing bulb through the access hole located in the top of the cabinet.
4. Remove the retaining nuts which secure the thermometer to the housing located on the back of the control panel.
5 Remove the thermometer by pushing it from the rear through the control panel.
6. Install the replacement thermometer following the reverse of the above procedure.
7. Reconnect the cabinet to its power source and test.

DRAWING TITLE
1826-7-DBL
WIRING DIAGRAM
120V. 1PH. 60 HZ

WITTCO FOODSERVICE EQUIPMENT INC.
REPLACEMENT PARTS LIST
WTTTCO SERIES - HOLDING/TRANSPORT CABINETS 6/18/98
MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
1826-7-DBL
WP-113-E BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-113-V BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-079 CARD HOLDER 3"x 5" 1
WP-114-4R CASTER 4" HEAVY DUTY RIGID 2
WP-114-4S CASTER 4" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-5R CASTER 5" HEAVY DUTY RIGID 2
WP-114-5S CASTER 5" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-6R CASTER 6" HEAVY DUTY RIGID 2
WP-114-6S CASTER 6" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-6HR CASTER 6" HI-MODULUS RIGID 2
WP-114-6HS CASTER 6" HI-MODULUS SWIVEL W/BRAKE 2
WP-178-1 CONTROL PANEL DECAL (BLUE) 2
WP-247 CORD, 10' HEAVY DUTY 1
AD-650 CORD WRAP 1
WP-063-DBL DOOR, (NO HARDWARE) 2
WP-107 DOOR LATCH COMPLETE W/CATCH 2
WP-104-1 ELEMENT, 600 WATT 120 VOLT 4
WP-104-2 ELEMENT, 600 WATT 208-240 VOLT 4
WP-182 ELEMENT CLIP 4
WP-284 ELEMENT COVER 2
WP-090-7 GASKET, DOOR ALUMINUM EXTRUSION 2
WP-302 GASKET, DOOR (BLACK) BY THE FT. 16'
WP-117 HANDLE, PUSH/PULL 2
WP-31U HANDLE, PUSH/PULL DECAL 2
WP-111 HINGE, DOOR 4
WP-103 HUMIDITY PAN (W/SPONGE) 2
WP-099 HUMIDITY PAN SPONGE (ONLY) 2

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
1826-7-DBL
WP-174 INSPECTION CAP, CHROME 2
WP-106-1 LIGHT, INDICATOR DUAL 125 VOLT (AMBER/RED) 2
WP-106-2 LIGHT, INDICATOR DUAL 250 VOLT (AMBER/RED) 2
WP-302-7L RACKS, INT. SIDE UPRIGHT (LEFT) 4
WP-302-7R RACKS, INT. SIDR UPRIGHT (RIGHT) 4
WP-305 RACK, SIDE RETAINING BOLTS 16
WP-006-1 STRAIN RELIEF AT POWER CORD 1
WP-109 THERMOMETER, DIAL TYPE 2
WP-093 THERMOMETER BULB HOLDER 2
WP-110 THERMOSTAT W/OUT KNOB 2
AD-242 THERMOSTAT KNOB 2
WP-089 THERMOSTAT BULB HOLDER 4
WP-308-C7 TOP COVER 1
WP-121 TRAY SLIDES (SET OF 2) 14

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
1826-7-DBL-IS
WP-113-EI BUMPER, ALUMINUM EXTRUSION ONLY (NO VINYL) 1
WP-113-VI BUMPER, BLACK VINYL ONLY (NO EXTRUSION) 1
WP-079 CARD HOLDER 3" x 5" 1
WP-114-4R CASTER 4" HEAVY DUTY RIGID 2
WP-114-4S CASTER 4" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-5R CASTER 5" HEAVY DUTY RIGID 2
WP-114-5S CASTER 5" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-6R CASTER 6" HEAVY DUTY RIGID 2
WP-114-6S CASTER 6" HEAVY DUTY SWIVEL W/BRAKE 2
WP-114-6HR CASTER 6" HI-MODULUS RIGID 2
WP-114-6HS CASTER 6" HI-MODULUS SWIVEL W/BRAKE 2
WP-178-2 CONTROL PANEL DECAL (BLUE) 2
WP-247 CORD, 10' HEAVY DUTY 1
AD-650 CORD WRAP 1
WP-063-DBL 1 DOOR, (NO HARDWARE) 2
WP-107 DOOR LATCH COMPLETE W/CATCH 2
WP-104-1 ELEMENT, 600 WATT 120 VOLT 4
WP-104-2 ELEMENT, 600 WATT 208-240 VOLT 4
WP-182 ELEMENT CLIP 4
WP-284 ELEMENT COVER 2
WP-090-7 I GASKET, DOOR ALUMINUM EXTRUSION 2
WP-302 GASKET, DOOR (BLACK) BY THE FT. 16'
WP-117 HANDLE, PUSH/PULL 2
WP-310 HANDLE, PUSH/PULL DECAL 2
WP-111 HINGE, DOOR 4
WP-103 HUMIDITY PAN (W/SPONGE) 2
WP-099 HUMIDITY PAN SPONGE (ONLY) 2

MODEL NUMBER AND QUANTITY REQUIRED
WITTCO
PART NO. PART DESCRIPTION
1826-7-DBL-IS
WP-174 INSPECTION CAP, CHROME 2
WP-106-1 LIGHT, INDICATOR DUAL 125 VOLT (AMBER/RED) 2
WP-106-2 LIGHT, INDICATOR DUAL 250 VOLT (AMBER/RED) 2
WP-316-L RACKS, INT. SIDE UPRIGHT (LEFT) 4
WP-316-R RACKS, INT. SIDE UPRIGHT (RIGHT) 4
WP-305 RACK, SIDE RETAINING BOLTS 16
WP-006-1 STRAIN RELIEF AT POWER CORD 1
WT-109 THERMOMETER, DIAL TYPE 2
WP-093 THERMOMETER BULB HOLDER 2
WP-L10 THERMOSTAT W/OUT KNOB 2
WP-242 THERMOSTAT KNOB 2
WP-089 THERMOSTAT BULB HOLDER 4
WP-308-C7I TOP COVER 1
WP-275 TRAY SLIDES (SET OF 2) 14
