WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
1
WT-1672D
GSM Remote Monitor and
Remote Control Switch
USER MANUAL
VERSION: 1.2
UPDATED: AUG 2013

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
2
INTRODUCTION
The WT-1672D GSM Remote Monitoring & Remote Control Switch is capable of monitor 2 digital inputs, 1 x
20A relay output, 1 timer input, and power outages notification function. One of the digital inputs can turn
to pulse counter input.
The unit can monitor 2 digital inputs. A call and SMS alarm message will sent when inputs triggered. The
system is able to load up to 5 numbers in the white list as authorised users. One of the digital inputs can be
pulse counter alarm input. The input alert message can be edited and programmed up to 40 characters long.
User can change the display text by sending the SMS text commands to the units.
The unit also has 1 x 20A heavy duty relay output can be used to switch on any application like lamps, pumps,
heaters, motor etc. Output relay can be switched ON or OFF by calling its cell phone number or by sending an
SMS command, there is no call charges incurred when dialling the unit as it will recognize an authorised
telephone number calling it and reject the call without answering. One Call to the SIM Card Number will switch
the device OFF permanently. Another Call to the SIM Card will switch the device ON permanently.
The GSM Remote Control system supports timer function, the user can set schedule to turn on / off the switch.
For example, put your pump, motor on a schedule. “Turn off in 5 minutes”, “turn on at 17:00, “turn on 1 year
later”
This function is important to use in the renting and leasing industry of electrical appliances, heavy vehicle, and
rental of site equipment to turn off the machines when off hire time completed
This function also important as the reminder to the owner to monitor the SIM Card expiry date. User can
instruct the unit to trigger the relay in the specified times and sent the SMS to the user to keep the SIM card
active when expiry dates.
The unit equips 1 pulse counter input, the range is 00000~59999. The user can setup start value, interval alert
value alert, interval time to alert, total value to alarm, when total value alarm occurrence, it can active the
relay outputs and sent SMS or dial to authorize phone number.
The unit detect loss of power. Once power outage is detected, the unit will call and SMS to your cell phone
and / or sound an auditable alert to make you aware of the power failure. The system using CE and FCC
approved industry internal power supply connected on board. A backup lithium battery can power up at least
8 hours and will sent a power down or power restored alerts in the event of power failure

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
3
SETTING UP AND PROGRAMMING
When first booting up the system you will see Green LED Lights on the side of the Enclosure and it should light
up when the Network is applied to the unit.
The Green LED is the network Indicator and this will light up when attempting to log on to the network flash
inconsistently until it locates the network.
A Phone Call to the SIM Card Number will now Latch the Relay permanently ON and Switch the device being
Controlled On.
The Status of the Relay will remain as on, until the unit receives a second Call to the Unit of which will now
Latch the Relay Permanently off.
Both Calls used to Latch the Relay either on or off are automatically disconnected, once the relays are
activated and never incur any Network Call Costs.
Beside calls to switch off or on, the unit also can be permanently switch off and on by sending the unit a text
message command

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
4
Step 1 - The simplest set up methods to set up Administrator number
Applied the “KISS Principle”, keep it simple, stupid.
The GSM Remote Control Switch is easy to setup and use. Insert the SIM card, simply use your mobile phone
call to the unit, your mobile phone number will automatically register as the 1st Administrators
You will receive the following SMS message from the unit –
Administrator:
1: 18617185300 (your phone number)
2:
3:
4:
5:
You already finish the set up. Now, you can use your mobile phone call to the SIM Card number switch the
device on permanently. Another call to the SIM Card will switch the device off permanently.
If you do not required to go through details setting, please process to STEP3 –Final Installation and Wiring

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
5
Factory Reset
If you required to change the administrator number in the future, simply press the button “FACTORY” at the
mother board until you hear the “du~” . This means the unit back to the factory default
This means you already reset the unit to factory default. Now you can start to call again to set the
administrator.
This method of setting is only allowed to set 1 administrator number. If you wish to set more administrators,
please go to Step 3 –Installation and set up
Step 2 - Advance Set Up
NO.
Description
Programming Code
SMS Texts Respond
Function
1
First Step of programming, you must
enter the factory passwords of 1234
and go inside the programming
mode.
You only can perform the next
commands after enter into
programming mode
*0*1234#
You get administrator
privileges!
2013-10-09 00:33
Wed
When you enter *0*1234#, you
enter into the programming
mode. You must perform the
next command in 10 minutes. If
you did not do anything, the
system will exit from
programming mode.
2
Change Password
*0*1234*new password#
For example if you need to
change to the new PW of 1212.
*0*1234*1212#
New password<1212>
2013-10-10 16:07 Thu
Maximum 4 digits of passwords
If you decide to protect your
privacy, you can change the
factory password to your new
password.
Enter the factory password
follow by your new password.

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
6
3
Add telephone number into the
admin list.
*1*1*telephone number#
For example set Admin number
18617185300 into admin 2
*1*2*18617185300#
Administrator:
1: 15989427391
2: 18617185300
3:
4:
5:
2013-10-10 16:08 Thu
Set Admin Numbers ;
*1*1* - set 1st admin
number
*1*2* - set 2nd admin
number
*1*3* - set 3rd admin
number
*1*4* - set 4th admin
number
*1*5* - set 5th admin
number
Only the number in the list can
receive alarm texts message
and active the relay output.
You can add up to 5 telephone
number into the admin list.
4
Check phone number you
program in the list
*2*
Administrator:
1: 15989427391
2: 18617185300
3:
4:
5:
2013019019 16:09
Thu
5
Delete the admin number in the list.
*3*N#
N = Admin number 1- 5
For example, if you want to
delete admin no 2.
just enter *3*2#
Administrator:
1: 15989427391
2:
3:
4:
5:
2013019019 17:16
Thu
Delete Admin Number
Delete 1st admin *3*1#
Delete 2nd admin *3*2#
Delete 3rd admin *3*3#
Delete 4th admin *3*4#
Delete 5th admin *3*5#
6
Check the relay status in ON or OFF
Mode.
*4*
Master relay <ON>
2013-10-10 16:10 Thu
The unit will return Master
relay <ON> if the relay is on.
The unit will return Master
relay <OFF> if the relay is off.

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
7
7
Check Signal Strength
*5*
CSQ<28>
2013-10-10 16:11 Thu
You must confirm the signal
strength at site before you
install the unit.
If the signal too weak, the unit
will not function properly.
CSQ 5 –12 Signal too weak,
system not function
CSQ 13 - 24 Signal Good. System
function well
CSQ 25 –32 Signal Excellent.
System working well
8
Setting the year, month, day, hours,
minutes, week
*12*YYYYMMDDHHMMX#
Time change OK!
2013-10-10 16:05 Thu
YYYY=4 digit for Year
MM = 2 digit for Month
DD = 2 digit for Date
HH = 2 digit for Hour
MM = 2 digit for Minutes
X = 1-7 (Day of the Week)
Example set as
*12*2013101016054# which
means 2013-10-10 16:05 Thu
If reprogram the date, it will
take the last as the accurate
date. The date have to be
correct (if setting 2014-2-29 or
2013-11-31) this is the incorrect
date which is not occur, the
system will verify the date,
time, day if correct, the date
have to be after year 2013

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
8
9
Schedule the ON/OFF for the
Master Relay
*13*N*YYYYMMDDHHMM#
Master relay off time:
2013-10-10 16:33
2013-10-10 16:31 Thu
When the
programmed time is
reach, the relay is
either on or off, all the
admin will get the
reply SMS as per
below.
Since time is up!
Master relay<OFF>
2013-10-10 16:33 Thu
N=0 (Switch Off the Master
Relay)
N=1 (Switch On the Master
Relay)
YYYY=4 digit for Year
MM = 2 digit for Month
DD = 2 digit for Date
HH = 2 digit for Hour
MM = 2 digit for Minutes
Example set as
*13*0*201310101633# which
means 2013-10-10 16:33 to
switch off the master relay
If reprogram the date, it will
take the last as the correct date.
If you program the date that
already past, the system will
alert you
11
Checking the schedule time for
Master Relay ON/OFF
*14*
Master relay on time:
Master relay off time:
2013-10-10 16:33
2013-10-10 16:35 Thu
Checking the schedule time for
Master Relay ON/OFF, when
the time reach, the system will
operate and it will delete the
schedule time automatically.
12
Delete the schedule time for the
Master Relay ON/OFF
*15*N#
Master relay on time:
Master relay off time:
2013-10-14 11:08
Mon
N=0 (Delete schedule of Relay
OFF Time)
N=1 (Delete schedule of Relay
ON Time)
14
SMS Reply Message when the
system ON/OFF
*21*N#
Message switch <ON>
2013-10-10 17:06 Thu
N=0 means SMS Reply Message
when the system OFF
N=1 means SMS Reply Message
when the system ON
Factory Default as SMS Reply
Message when the system ON
If setting to not receive SMS
Reply Message when the
system OFF, the unit will return
a message indicate successful
setting for the command and it
will no longer sending SMS
reply until the setting of SMS
Reply Message when the
system ON is done. When the
system having the temperature
alert, wireless alarm alert, it will
automatically sending the alert
message to the Admin

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
9
15
To receive SMS Reply Message or
not to receive SMS Replay Message
when the system trigger by phone
call
*22*N#
After sending
command *22*0#
Status switch <OFF>
2013-10-10 17:10
Thu：
After sending
command *22*1#
Master relay <OFF>
2013-10-10 17:08
Thu：
N=1 means after make the
phone call to the system, it will
return the SMS for the status to
the caller
N=0 means after make the
phone call to the system, it will
not return the SMS for the
Status to the caller
Factory Default as return SMS
for the status after make the
phone call
** If you decide not to allow the
system to
text you for any
acknowledgement after you
call to the unit. You can switch
OFF the text message. Some
Customer request
this function because texts
reply involved call
cost
18
Security mode/ Open Mode
*23*N#
When Setting as
Security Mode *23*1#
Mode switch <ON>
2013-10-10 17:13 Thu
When Setting as Open
Mode *23*0#
Mode switch <OFF>
2013-10-10 17:13 Thu
N=1 means in security mode.
Only allow the number in the
list can text to the unit to
control the system.
N=0 means in open mode.
Anybody can call to the unit to
control the system. Please take
note that the Privacy and
Security before you decide to
use the Open Mode
Factory Default is N=1 for
Security Mode
20
SMS Text Message to Switch On/Off
Relay
*24*N#
When Setting as
*24*1#
Master relay <ON>
2013-10-10 17:13 Thu
When Setting as
*24*0#
Master relay <OFF>
2013-10-10 17:13 Thu
N=1 means switch on the relay
by SMS Message
N=0 means switch off the relay
by SMS Message

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
10
21
SMS Text Message to Switch On/Off
Relay
*24*N#
When Setting as
*24*1#
Master relay <ON>
2013-10-10 17:13 Thu
When Setting as
*24*0#
Master relay <OFF>
2013-10-10 17:13 Thu
N=1 means switch on the relay
by SMS Message
N=0 means switch off the relay
by SMS Message
22
Call alert to the First Admin Number
when turn on / off the alarm
equipment
*25*N#
When Setting as
*25*5#
Call switch: wireless
alarm
2013-10-10 17:18 Thu
N=0 means switch off all alarm
alert, which means any alarm
alert from the equipment, it will
not call the first admin number
N=1 means when the
equipment is switch on, it will
call the first admin number
N=2 means when the
equipment is power outage, it
will call the first admin number
N=3 means when the
equipment is line cut trigger, it
will call the first admin number
N=4 means when over the high
or low limit of temperature, it
will cal the first admin number
N=5 means when the 9 channel
wireless alarm having the alarm
alert, it will call the first admin
number
N only can set for either one
between 0 to 5 which means
only can set either 1 function. If
there is a repeat setting, it will
overwrite the before setting
and take the last setting.
Factory Default as N=0 which
means any alarm alert from the
equipment, it will not call the
first admin number

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
11
23
Edit Input Messages for the system
and 9 Channels Wireless Alarm
Alert Messages
*26*N*XXXXXXXX#
When Setting as
*26*0*The equipment
has already started!#
Startup user defined
information: The
equipment has
already started!
2013-10-10 17:24 Thu
When Setting as
*26*1*The door
closed!#
Wireless 1 defined
information: The door
closed!
2013-10-10 17:21 Thu
N=0 means Edit for Input
Messages for the system when
switch on
N=1 -9 means Edit for Input
Alert Message for which
channel of Wireless Alarm
Equipment that connected
N=10 means Edit for Input Alert
Message for line cut alert
N=11 means Edit for Input Alert
Message for pulse counter
when it reach the value set.
XXXXXXX is the text messages
content which can up to 70
alphabet. When the text
message content successfully
programmed, it will overwrite
the system default text
messages
24
Check input messages programmed
in the system and the 9 channels
wireless alarm alert messages
*27*N#
When Setting as
*27*0#
Startup user defined
information: The
equipment has
already started!
2013-10-10 17:36 Thu
When Setting as
*27*1#
Wireless 1 defined
information: The door
closed!
2013-10-10 17:40 Thu
N=0 means Check the Input
Messages for the system when
switch on
N=1 -9 means Check the Input
Alert Message for which
channels of Wireless Alarm
Equipment that connected
N=10 means Check Input Alert
Message for line cut alert
N=11 means Check Input Alert
Message for pulse counter
when it reach the value set.
If there is no text message
programmed, it will return a
SMS with Blank Message

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
12
25
Delete input messages programmed
in the system and the 9 channels
wireless alarm alert messages
*28*N#
When Setting as
*28*0#
Delete OK!
2013-10-10 17:42 Thu
After delete success,
when system restart,
admin will receive the
default text message
System startup!
Master relay <OFF>
2013-10-10 17:45 Thu
When Setting as
*28*1#
Delete OK!
2013-10-10 17:42 Thu
After delete success,
when the 1st channel
wireless alarm trigger,
admin will receive the
default text message
Alarm 1.Please timely
processing!
2013-10-10 17:45 Thu
N=0 means Delete the Input
Messages for the system when
switch on
N=1 -9 means Delete the Input
Alert Message for which
channels of Wireless Alarm
Equipment that connected
N=10 means Delete Input Alert
Message for line cut alert
N=11 means Delete Input Alert
Message for pulse counter
when it reach the value set.
If there is no text message
programmed, it will return a
SMS with Blank Message
26
Setting Pulse Counter
*29*XXXXX#
When Setting as
*29*00030#
Overplus: 30 PCS
2013-10-10 17:42 Thu
XXXXX = 00000 to 59999 means
the pulse counter value
After setting the pulse counter
value, when there is pulse
situation, the system will
calculate the total number of
pulses, and sending the text
messages to the Admin. The
message will include the total
pulse counter value within 1
minute and the remaining value
of the pulse counter value.
(which means the total pulse
counter value deduct the pulse
counter value)
27
Check Remaining Pulse Counter
Value
*30*
When sending *30*
Overplus: 30 PCS
2013-10-10 17:27 Thu
Checking the remaining pulse
counter value

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
13
28
This command is setting of high or
low voltage level output.
Low voltage level output connects
J16 connector (0V or GND). Setting
is *31*0#
High voltage level output connect
the J16 connector (5V or GND) and
set the *31*1#
*31*N#
*31*0#, low voltage level output
connection
*31*1#, High voltage level output
connection
When sending *31*1#
Line alarm: High level
2013-11-30 09:42 Sat
N=0 means low voltage alarm
(which means connect the 2PIN
at the J16 port)
N=1 means high voltage alarm
(which means disconnect the
2PIN at the J16 port)
Factory Default as N=0 where
the 2PIN at the J16 port
connected
29
This commands is to set either relay
should trigger manually by user or
automatically by unit
Factory default: User manually
active the relay when input alarm
trigger.
If user required the relay trigger
automatically when input alarm
trigger, they can perform this
commands
32*N#
*32*0# - The unit will latch the
relay when input trigger. (Default
Setting)
*32*3# - When input trigger,
latch the relay automatically
*32*4# - When alarm (input)
back to normal, trigger relay OFF
automatically
*32*5# - When Pulse counter
reaching the limit, trigger relay
When sending *32*1#
Linkage: High
temperature.
2013-11-30 09:44 Sat
N=0 means when the system
have alarm alert, it will not
switch on the relay (the relay
will not action if there is any
alarm alert)
N=1 mean when high
temperature will switch on
relay, when low temperature
will switch off relay
N=2 means high temperature
will switch off relay, when low
temperature will switch on
relay N=3 means line cut alert
will switch on relay
N=4 means line recover will
switch off relay
N=5 means when reach the
pulse counter value will switch
on relay
N=6 means any channels of
wireless alarm will switch on
relay
Default as N=0 which when
reach the pulse counter value
will switch on relay
** This command only can
operate when the Master Relay
under Open Mode (which
mean the command *23*0#). If
it is under Security Mode, the
Master Relay will no function

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
14
Step 3 - Installation
Insert the SIM card, to access the SIM card carrier gently push the button adjacent to it, insert the SIM card
and carefully close the carrier
Connect the cable to terminals 220V & N ensuring positive is connected to terminal 200V, switch on the power
supply , the red power LED will light indicating power is present, the blue network LED indicator will initially
flash quickly, once logged onto the network , it will flash more slowly approximately one every 3 -4 seconds
It is recommended that the GSM Remote Control Switch be programmed to operate as required before final
installation.

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
15
Connection Details
If you are unsure how to connect the device you wish to control refer to a qualified person
Connector
1
2
3
1
2
3
4
5
Description
Digital/Analogue Input
Relay Connection
110V-240V
Industry Power
Supply
Digital or
Pulse
Counter
Digital Or
Analogue
Temperature
Input
NO
NC
COM
L
N
Note:
1. The Temperature Input is only work with Witura Temperature Sensors
2. The Connect 4 and 5 is inside the Industry Power Supply
Example Wiring Diagram For Digital And Analogue Input

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
16
Example Wiring Diagram For Pulse Counter
Example Connection with Washing Machine

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
17
Example Connection with Coffee Machine
Example Connection with Catering Equipment

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
18
Example Connection with Freezer
Production Specifications
Operation Voltage
12 volts DC
Operating Current
Maximum 500mA, typically 55mA
Relay Contacts
1 x Normally Open and Normally Closed Contacts
maximum switching capacity 20 amps @230v ac per relay
GSM Frequency MHz
GSM 850, GSM 900, GSM 1800, GSM 1900
Humidity
Less Than 80% RH
Operating Temperature
-20c to 55c
Physical Size
130 x 100 x 50mm
Protection
IP 65 Weather Proof Casing
Approvals
C.E, FCC, ETSI

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
19
Preparing the SIM card
All new SIM cards have to be registered with the network provider before they can be used, usually by calling
the network provider or registering on their website please refer to the instructions supplied with your SIM
card.
During the registration procedure a confirmation code or text message is usually sent to the SIM cards
telephone number, to be able to read and react to the message you will need to insert the SIM card into an
unlocked mobile phone.
After successfully registering the SIM card, ensure there is sufficient credit on the card for programming
confirmation texts to be sent from the GSM Remote Control Switch.
You MUST ensure that the PIN request is disabled from the SIM card before inserting it into the GSM Remote
Control Switch. If you do not disable the PIN request the GSM Remote Control Switch will not work. If the PIN
request is not disabled and the unit is switched on more than 3 times you will have to reset the PIN using the
PUK code which will have to be obtained from the service provider.
To check the PIN request status of your SIM card, place the card in an unlocked mobile phone, switch the
phone on. If you are able to make calls without entering a PIN number the PIN request is disabled. If a PIN
number is requested refer to the instructions supplied with the SIM card and then look through the phones
options for the ‘disable PIN request’ and disable it.
You MUST disable any voicemail that is set up on the SIM card; the codes shown below are for UK networks
only, please refer to your network operator if outside the UK
Vodafone: 1210 >Send - you will hear ‘order is accepted and confirmed’
O2 - Call 1760 >Send - you will hear ‘order is accepted and confirmed’
T-Mobile - Call 222 and follow instructions
Orange - Call 450 and follow instructions
The SIM card is now ready to use
We recommend that if you are using a ‘pay as you go’ (PAYG) SIM card that you choose to automatically ‘Top-
Up’ when the cards credit falls below a certain limit please contact your network provider or visit their website
for more details.
Most but not a using post-paid SIM cards will be de-activated by the network if not used to make an outgoing
voice call or send an SMS text message within a specific period. To prevent this simply send the GSM Remote
Control Switch a text command *0*PW#, then *2*, it will reply by text message, do this once a month to keep
the SIM card active.

WITURA TECHNOLOGY SDN BHD |
WT-1672D GSM Remote Monitor & Remote Control Switch User Manual V1.4
20
Troubleshooting
1. Red power LED not alight
Ensure that your DC power supply is connected
correctly, positive (+) to terminal 220v and negative (-)
to terminal N. Verify 12 volts is present using a volt
meter
2. Blue network LED flashing every one second
and not every 3 seconds
Ensure your SIM card has been activated and that the
PIN request has been disabled. If the unit is in a low
signal strength area consider using an external GSM
antenna or changing to another network provider
3. I am not receiving confirmation test messages
when program the administrators number
Ensure your telephone number is in the Administrator
list and that sending text messages to your number is
enabled.
4. I am not receiving any text messages when
initially programming the unit
Ensure the unit is connected to the GSM network by
observing the blue network LED; it should be flashing
once every 3 seconds (see 2 above). Ensure the SIM
card has credit
5. The unit has been working for several months
and has now stopped responding to calls and
text commands
Most but not all PAY SIM cards will be de-activated by
the network if not used to make an outgoing voice call
or send an SMS text message within a specific period.
To prevent this simply send a txt command *0*PW#,
then *2*, it will reply by text message, do this once a
month to keep the SIM card active
