FOR-A MFR-3000 User manual

MFR-3000
Multi Format Routing Switcher
MFR-30FP
MFR-GPI
MFR-TALM
6th Edition - Rev. 2
OPERATION
MANUAL

2
Edition Revision History
Edit.
Rev.
Date
Description
Section/Page
1
-
2015/02/27
2
-
2015/05/27
MFR-30FP added.
Sec. 4
2
1
2015/09/16
Switcher's AUX Crosspoints Switching
Sec. 3-4
3
-
2015/11/19
MFR-18/39RUA supported.
4
-
2016/06/17
Audio cards supported.
(MFR-8AAI/8AAO/8AESI/8AESO)
Secs. 1, 2-1-1,
2-3, 2-5, 9-1
5
-
2016/08/18
MFR-16MV supported.
Page button operation added
Secs. 2, 7, 10
Appendix
6
-
2017/03/01
12G-SDI (MFR-8SDIGB / 8SDOGB) supported.
2-1, 2-3, 2-4, 8
6
1
2017/12/19
Available Conversions
System Size Request Command added.
AC adapters from consumable lists deleted.
7-2
8-3
11-1-3, 11-1-4
6
2
2019/02/14
Payload ID and other Section added.
Channel Name Import Command added.
Video Format Commands added.
MFR-RU Series to separate operation manual
deleted.
7-3-5, 7-3-6
8-3-6
8-3-8
Throughout
Firmware / Software Versions and Supported Hardware / Features
Main Unit Firmware Version (*1)
GUI Version
(*2)
Supported
Hardware
Supported Feature
MFR-3000
1.79 or higher
1.86 or higher
-
Switcher's AUX
Crosspoints Switching
1.83 or higher
2.01 or higher
MFR-8SDIGB
MFR-8SDOGB
Gearbox feature
(*1) Click [Primary CPU] in the [Web-based Control: System Settings- MU Info page] to see your version number
under Firmware Version.
(*2) The GUI (Web-based control software) version is displayed on the browser's title bar.

3
Precautions
Important Safety Warnings
[Power]
Caution
Operate unit only at the specified supply voltage.
Disconnect the power cord via the power plug only. Do not pull on the cable portion.
Stop
Do not place or drop heavy or sharp-edged objects on the power cord. A damaged
cord can cause fire or electrical shock hazards. Regularly check the power cord for
excessive wear or damage to avoid possible fire / electrical hazards.
Caution
Ensure the power cord is firmly plugged into the AC outlet.
[Grounding]
Caution
Ensure the unit is properly grounded at all times to prevent electrical shock.
Hazard
Do not ground the unit to gas lines, units, or fixtures of an explosive or dangerous
nature.
[Operation]
Hazard
Do not operate the unit under hazardous or potentially explosive atmospheric
conditions. Doing so could result in fire, explosion, or other hazardous results.
Hazard
Do not allow liquids, metal pieces, or other foreign materials to enter the unit. Doing
so could result in fire, other hazards, or a unit malfunction.
If a foreign material does enter the unit, turn the power off and immediately
disconnect the power cord. Remove the material and contact an authorized service
representative if damage has occurred.
[Transportation]
Caution
Handle with care to avoid impact shock during transit, which may cause
malfunction. When you need to transport the unit, use the original or suitable
alternative packing material.

4
[Circuitry Access]
Do not remove covers, panels, casing, or access the circuitry with power applied to
the unit. Turn the power off and disconnect the power cord prior to removal. Internal
servicing / adjustment of unit should only be performed by qualified personnel.
Stop
Do not touch any parts / circuitry with a high heat factor.
Capacitors can retain enough electric charge to cause mild to serious shock, even
after the power has been disconnected. Capacitors associated with the power
supply are especially hazardous.
Hazard
Unit should not be operated or stored with cover, panels, and / or casing removed.
Operating the unit with circuitry exposed could result in electric shock / fire hazards
or a unit malfunction.
[Potential Hazards]
Caution
If abnormal odors or noises are noticed coming from the unit, immediately turn the
power off and disconnect the power cord to avoid potentially hazardous conditions.
If problems similar to the above occur, contact an authorized service representative
before attempting to operate the unit again.
[Rack Mount Brackets, Ground Terminal, and Rubber Feet]
Caution
To rack-mount or ground the unit, or to install rubber feet, do not use screws or
materials other than those supplied. Doing so may cause damage to the internal
circuits or components of the unit. If you remove the rubber feet that are attached to
the unit, do not reinsert the screws that secure the rubber feet.
[Consumables]
Caution
Consumable items that are used in the unit must be periodically replaced. For
further details on which parts are consumables and when they should be replaced,
refer to the specifications at the end of the Operation Manual. Since the service life
of the consumables varies greatly depending on the environment in which they are
used, such items should be replaced at an early date. For details on replacing
consumable items, contact your dealer.

5
Upon Receipt
Unpacking
MFR-3000 units and their accessories are fully inspected and adjusted prior to shipment.
Operation can be performed immediately upon completing all required connections and
operational settings.
Check your received items against the packing lists below. Check to ensure no damage has
occurred during shipment. If damage has occurred, or items are missing, inform your supplier
immediately.
Main Unit
ITEM
QTY
REMARKS
MFR-3000
1
AC Cord
1 set
AC cable and retaining clip
Rack Mount Brackets
1 set
EIA standard type (Attached to unit.)
Rubber Feet
4
CD-ROM
1
Operation manual (PDF)
Notes on serial port setting
1
Quick Setup Guide
1
Input / Output Cards
ITEM
QTY
REMARKS
MFR-8SDI
1 - 8 *
8 SDI input card
MFR-8SDO
1 - 8 *
8 SDI output card
MFR-8AAI
1 - 8 *
Analog audio input card with A/D converter
(Analog 8 stereo pairs)
MFR-8AAO
1 - 8 *
Analog audio output card with D/A converter
(Analog 8 stereo pairs)
MFR-8AESI
1 - 8 *
AES audio input card
(AES/EBU 8 stereo pairs)
MFR-8AESO
1 - 8 *
AES audio output card (AES/EBU 8 stereo
pairs)
MFR-16MV
1 - 4 *
16 SDI output card with multiviewer function.
MFR-8SDIGB
1 - 8 *
SDI input card (Gearbox 2ch built-in)
MFR-8SDOGB
1 - 8 *
SDI output card (Gearbox 2ch built-in)
* The number of installed cards varies depending on the system configuration. See the Matrix Size Chart
on page 11
Options (for MFR-3000)
ITEM
QTY
REMARKS
MFR-30CPU
1
Redundant CPU card *
MFR-30PS
1 set
Redundant power supply unit (with AC cord
and AC cord retaining clip.)
MFR-30FP
1
Front control panel
MFR-18RUA/39RUA
MFR-39RU/40RU/18RU
MFR-16RU/16RUD/16RUTA
MFR-16/32/64RUW
1
Remote Control Unit

6
Interface Expansion Unit
ITEM
QTY
REMARKS
MFR-GPI
1
AC Adaptor *
1
With DC lock plug
AC cable
1
Rack Mount Brackets
1 set
EIA standard type
LAN Cable (straight)
1
* Depending on the production date, AC adapter is supplied without DC lock plug, but with a DC cable
retaining clip.
Tally Manager Unit
ITEM
QTY
REMARKS
MFR-TALM
1
AC Adaptor *
1
With DC lock plug
AC cable
1
Rack Mount Brackets
(optional)
1 set
Single- or Dual-unit type, EIA standard type
* Depending on the production date, AC adapter is supplied without DC lock plug, but with a DC cable
retaining clip.
Font Conventions
The following conventions are used throughout this manual:
Shaded text (such as ON) indicates parameter values in the menu.
Text enclosed by a square (such as ALARM, MODE) indicates front panel buttons on the
MFR-3000 or Remote Control Units.
References to the MFR Series Web-based Control Software are indicated by [Web-based
Control: XXX page].

7
Table of Contents
1. Prior to Starting..........................................................................................................................10
1-1. Welcome ............................................................................................................................10
1-2. Features.............................................................................................................................10
2. Panel Descriptions ....................................................................................................................11
2-1. MFR-3000 Front Panel.......................................................................................................11
2-1-1. Matrix Size Chart.........................................................................................................11
2-2. MFR-30FP Front Panel......................................................................................................13
2-3. MFR-3000 Rear Panel.......................................................................................................14
2-3-1. Interfaces.....................................................................................................................16
2-3-2. SDI Input/Output Cards...............................................................................................18
2-3-3. CPU Card Installation and Removal...........................................................................18
2-3-4. Changing the Interface from RS-422 to RS-232C......................................................20
2-4. SDI Input / Output Cards....................................................................................................21
2-4-1. MFR-8SDI...................................................................................................................21
2-4-2. MFR-8SDO .................................................................................................................21
2-4-3. MFR-16MV..................................................................................................................22
2-4-4. MFR-8SDIGB..............................................................................................................22
2-4-5. MFR-8SDOGB............................................................................................................23
2-5. Audio Input / Output Cards.................................................................................................24
2-5-1. MFR-8AAI (Analog Input)............................................................................................24
2-5-2. MFR-8AAO (Analog Output).......................................................................................25
2-5-3. MFR-8AESI (AES Input).............................................................................................27
2-5-4. MFR-8AESO (AES Output).........................................................................................27
2-6. MFR-GPI............................................................................................................................28
2-6-1. Front Panel..................................................................................................................28
2-6-2. Rear Panel..................................................................................................................29
2-6-3. Interfaces (MFR-GPI)..................................................................................................30
2-6-4. Switches on the Card..................................................................................................32
2-7. MFR-TALM.........................................................................................................................33
2-7-1. Front Panel..................................................................................................................33
2-7-2. Rear Panel..................................................................................................................34
3. System Configuration Example.................................................................................................35
3-1. Basic Configuration............................................................................................................35
3-2. Main Unit Linking................................................................................................................36
3-2-1. Parallel Link System Example ....................................................................................36
3-2-2. Expanded Matrix System Example.............................................................................37
3-3. Signal Name and Tally Link System..................................................................................38
3-3-1. Standard Configuration...............................................................................................38
3-3-2. If Configuring an MFR-TALM......................................................................................40
3-4. Switcher's AUX Crosspoints Switching System.................................................................43
3-4-1. Switching an AUX Bus Signal.....................................................................................43
3-4-2. Synchronous Crosspoints Switching ..........................................................................45
4. Front Panel (MFR-30FP) Operation..........................................................................................46
4-1. Functions and Operations..................................................................................................46
4-2. Basic Operation on the Front Panel...................................................................................47

8
4-2-1. Buttons........................................................................................................................47
4-2-2. Page Function.............................................................................................................47
4-2-2-1. Group Page Changes..........................................................................................47
4-3. Function Buttons................................................................................................................49
4-4. Operation Using the Menu Display....................................................................................50
4-4-1. Destination Menu........................................................................................................50
4-4-2. Source Menu...............................................................................................................51
4-4-3. Crosspoint Menu.........................................................................................................51
4-4-4. Button Assign Menu....................................................................................................52
4-4-5. Button Group Menu.....................................................................................................53
4-4-6. Setting Menu...............................................................................................................53
4-4-6-1. BRIGHTNESS......................................................................................................54
4-4-6-2. MFR-LAN.............................................................................................................54
4-4-6-3. PC-LAN................................................................................................................55
4-4-6-4. ALARM.................................................................................................................55
5. Crosspoint Control.....................................................................................................................56
5-1. One Crosspoint Switching..................................................................................................56
5-1-1. One Crosspoint Switching by X-Y Setting..................................................................56
5-1-2. Crosspoint Switching Using Bus Buttons ...................................................................56
5-1-3. CHOP Function...........................................................................................................57
5-1-4. Crosspoint Switching Using TAKE Function...............................................................57
5-2. Simultaneous Crosspoint Switching...................................................................................58
5-2-1. Main Unit Stored Salvos .............................................................................................58
5-2-2. Front Panel Stored Salvos..........................................................................................59
5-2-3. Simultaneous Switching Using Take Function ...........................................................59
5-2-4. Simultaneous Switching by Link Function..................................................................59
5-3. Lock....................................................................................................................................60
5-3-1. LOCK LOCAL..............................................................................................................60
5-3-2. LOCK OTHER / LOCK ALL ........................................................................................61
5-4. Preview Function................................................................................................................63
5-5. Level Control......................................................................................................................63
6. Multiview Output........................................................................................................................64
6-1. Multiviewer Specifications..................................................................................................64
6-2. FS Mode.............................................................................................................................65
6-3. Displaying Multiview Images..............................................................................................66
6-4. Basic Rules for Creating Multiview Layouts.......................................................................67
6-5. Clocks.................................................................................................................................67
6-6. Available Window Objects..................................................................................................68
7. Gearbox Feature (MFR-8SDIGB/8SDOGB).............................................................................69
7-1. MFR-8SDIGB / 8SDOGB Cards........................................................................................69
7-2. Available Conversions........................................................................................................70
7-3. Conversion Settings...........................................................................................................70
7-3-1. Converting 3G SQD Input to 2SI (MFR-8SDIGB) ......................................................70
7-3-2. Converting 2SI to SQD Output (MFR-8SDOGB)........................................................71
7-3-3. Converting 12G-SDI Input to 3G-SDI 2SI (MFR-8SDIGB).........................................72
7-3-4. Converting 3G-SDI SQD to 12G-SDI Output (MFR-8SDOGB)..................................72
8. Serial / LAN Command Control.................................................................................................75

9
8-1. Serial Interface...................................................................................................................75
8-2. LAN Interface .....................................................................................................................75
8-3. Control Command..............................................................................................................76
8-3-1. Command Responses (Commands 1-6)....................................................................77
8-3-2. Receiving Responses (Commands 1-6).....................................................................79
8-3-3. Channel Name Request Commands (7).....................................................................82
8-3-4. CPU Status Request Command (8)............................................................................86
8-3-5. Destination Lock Status Request Command (9)........................................................87
8-3-6. Channel Name Import Commands (10)......................................................................88
8-3-7. System Size Request Command (11) ........................................................................88
8-3-8. Video Format Commands (12) ...................................................................................89
9. Troubleshooting.........................................................................................................................90
10. Specifications and Dimensions...............................................................................................91
10-1. Unit Specifications............................................................................................................91
10-1-1. MFR-3000.................................................................................................................91
10-1-2. MFR-30FP.................................................................................................................93
10-1-3. MFR-GPI...................................................................................................................93
10-1-4. MFR-TALM................................................................................................................93
10-2. External Dimensions........................................................................................................94
10-2-1. MFR-3000.................................................................................................................94
10-2-2. MFR-GPI...................................................................................................................95
10-2-3. MFR-TALM................................................................................................................96

10
1. Prior to Starting
1-1. Welcome
Congratulations! By purchasing an MFR-3000 Multi Format Routing Switcher (hereafter called
MFR main unit) you have entered the world of FOR-A and its many innovative products. We
thank you for your patronage and hope you will turn to FOR-A products again and again to
satisfy your video and audio needs.
FOR-A provides a wide range of products, from basic support units to complex system
controllers, which have been increasingly joined by products for computer video-based systems.
Whatever your needs, talk to your FOR-A representative.We will do our best to be of continuing
service to you.
1-2. Features
The MFR-3000 is a multi-format routing switcher that supports 12G-SDI, 3G-SDI, HD-SDI,
SD-SDI, ASI, AES and Analog audio signals. Inside the 4U case a matrix of up to 64 inputs/64
outputs can be configured. And by linking multiple units, they can be used as a large-scale
routing switcher. It supports various functions such as the capability of linking multiple cases,
tally connections with peripheral devices, and automatic source name tracking, to allow the
units to be the core product in small to medium size systems.
Support for 3G-SDI, HD-SDI, SD-SDI, and ASI signals with automatic signal recognition that
enables operation without concern for the type of signal. 12G-SDI, AES and analog audio
input/output and multiview output are also supported by installing optional input/output
cards.
By linking multiple units, they can be used as a large-scale routing switcher.
Up to 8 units can be linked together for expansions of up to 128 x 64 –192 x 21.
One routing switcher can be virtually partitioned to build any theoretical hierarchy, which
creates possibilities for use in various operating forms.
Various crosspoint control functions such as Salvo, Take, Link, Level operation, and Chop
Tally linking with FOR-A’s video switchers (HANABI Series) and multi viewers. Source
name displays on video switchers and multi viewers can be switched in conjunction with
switchings controlled in the main unit. MFR routers support TSL and Harris protocol,
enabling linkage to other companies' products.
Built-in web server for remote control through a web browser
SNMP support enabling SNMP monitoring system configuration
Status monitoring for power supply, fan, CPU, etc.
CPU board redundancy allowing monitoring of primary CPU board operation via the
secondary board. Immediate and smooth switch over to the secondary board without down
time in case of irregularities, as well as stable remote control operation supported by the
network redundancy
Power unit redundancy for stable power supply against power unit failure or power supply
troubles
Matrix partition and level setting capabilities support a flexible control environment
(maximum of 128 units in total including the main unit)
Remote control panel connectivity for configuring a huge control panel
Interface expansion unit (MFR-GPI) for additional 128 (32 x 4) GPI/O and 4 serial ports
(9-pin D-sub, male)
MFR-TALM Tally Manager Unit is designed specifically to manage tally and signal name
data in the MFR system and the exchange of this data with external devices such as a video
switcher, multiviewer etc.. The unit performs the task of tally data computation, which is
ordinarily undertaken by the MFR main unit, to accelerate the task.
Front control panel option (MFR-30FP)
Conversions between 12G-SDI and Quad Link 3G-SDI and between 2SI and SQD available
by installing optional MFR-8SDIGB and MFR-8SDOGB (Gearbox feature built-in) cards.

11
2. Panel Descriptions
2-1. MFR-3000 Front Panel
POWER 2
ROUTING SWITCHER
ON
OFF
OFF
ON
ALARM
ALARM
MFR-3000
POWER 1
No.
Name
Description
A
POWER1
Power switch 1 (standard equipment)
(1) Switch to turn unit power On/Off.
(2) DC power supply voltage indication LED
(Normal: lit green / Error: unlit)
(3) Alarm indication LED
(Normal: unlit / Power or fan error: lit,
Secondary CPU active: flashing )
B
POWER2 (*1)
Power switch 2 (optional equipment) (1) (2) and (3) the same as
POWER1.
(*1)The LED lights up if a power/fan error and CPU changeover occur simultaneously.
2-1-1. Matrix Size Chart
Standard SDI Signal Routing
Matrix size varies depending on the number of installed MFR-8SDI and MFR-8SDOcards as
shown below. (64 x 64 to 8 x 8)
Number of cards: MFR-8SDO
8
7
6
5
4
3
2
1
Number of
cards:
MFR-8SDI
8
64 x 64
64 x 56
64 x 48
64 x 40
64 x 32
64 x 24
64 x 16
64 x 8
7
56 x 64
56 x 56
56 x 48
56 x 40
56 x 32
56 x 24
56 x 16
56 x 8
6
48 x 64
48 x 56
48 x 48
48 x 40
48 x 32
48 x 24
48 x 16
48 x 8
5
40 x 64
40 x 56
40 x 48
40 x 40
40 x 32
40 x 24
40 x 16
40 x 8
4
32 x 64
32 x 56
32 x 48
32 x 40
32 x 32
32 x 24
32 x 16
32 x 8
3
24 x 64
24 x 56
24 x 48
24 x 40
24 x 32
24 x 24
24 x 16
24 x 8
2
16 x 64
16 x 56
16 x 48
16 x 40
16 x 32
16 x 24
16 x 16
16 x 8
1
8 x 64
8 x 56
8 x 48
8 x 40
8 x 32
8 x 24
8 x 16
8 x 8
A single MFR-16MV card provides 16 outputs (using two slots) and supports two multiview
channels.
A
B
(1)
(2)
(3)

12
12-SDI Signal Routing
12G-SDI signal routing is enabled by installing MFR-8SDIGB and MFR-8SDOGB cards and
using them for 12G-SDI input/output. (If using MFR-8SDIGB and MFR-8SDOGB them for
3G-SDI input/output, the “Standard SDI Signal Routing” table in the previous page applies.)
Matrix size varies depending on the number of installed MFR-8SDIGB and MFR-8SDOGB
cards as shown below.
(16 x 16 to 2 x 2)
Number of cards: MFR-8SDOGB (12G-SDI output)
8
7
6
5
4
3
2
1
Number of cards:
MFR-8SDIGB
(12G-SDI input)
8
16 x 16
16 x 14
16 x 12
16 x 10
16 x 8
16 x 6
16 x 4
16 x 2
7
14 x 16
14 x 14
14 x 12
14 x 10
14 x 8
14 x 6
14 x 4
14 x 2
6
12 x 16
12 x 14
12 x 12
12 x 10
12 x 8
12 x 6
12 x 4
12 x 2
5
10 x 16
10 x 14
10 x 12
10 x 10
10 x 8
10 x 6
10 x 4
10 x 2
4
8 x 16
8 x 14
8 x 12
8 x 10
8 x 8
8 x 6
8 x 4
8 x 2
3
6 x 16
6 x 14
6 x 12
6 x 10
6 x 8
6 x 6
6 x 4
6 x 2
2
4 x 16
4 x 14
4 x 12
4 x 10
4 x 8
4 x 6
4 x 4
4 x 2
1
2 x 16
2 x 14
2 x 12
2 x 10
2 x 8
2 x 6
2 x 4
2 x 2
AUDIO Signal Routing
Matrix size varies depending on the number of installed MFR-8AAI, MFR-8AAO,
MFR-8AESI and MFR-8AESO cards as shown below. (1 stereo pair = 2 channels)
MFR-8AAO or MFR-8AESO (number of cards)
8
7
6
5
4
3
2
1
MFR-8AAI
or MFR-8AESI
(number of
cards)
8
64 x 64
64 x 56
64 x 48
64 x 40
64 x 32
64 x 24
64 x 16
64 x 8
7
56 x 64
56 x 56
56 x 48
56 x 40
56 x 32
56 x 24
56 x 16
56 x 8
6
48 x 64
48 x 56
48 x 48
48 x 40
48 x 32
48 x 24
48 x 16
48 x 8
5
40 x 64
40 x 56
40 x 48
40 x 40
40 x 32
40 x 24
40 x 16
40 x 8
4
32 x 64
32 x 56
32 x 48
32 x 40
32 x 32
32 x 24
32 x 16
32 x 8
3
24 x 64
24 x 56
24 x 48
24 x 40
24 x 32
24 x 24
24 x 16
24 x 8
2
16 x 64
16 x 56
16 x 48
16 x 40
16 x 32
16 x 24
16 x 16
16 x 8
1
8 x 64
8 x 56
8 x 48
8 x 40
8 x 32
8 x 24
8 x 16
8 x 8

13
2-2. MFR-30FP Front Panel
POWER 2
ROUTING SWITCHER
ON
OFF
OFF
ON
ALARM
ALARM
MFR-3000
POWER 1
DEST SRC
CANCEL
ASSIGN SETTINGGROUP
LOCK
BUTTON
No.
Name
Description
A
Buttons
User assignable buttons. (LED: 1 color, green)
B
MENU
Displays setting menus and status.
C
DEST
Shows destination assignments on the display.
D
SRC
Shows source assignments on the display.
E
BUTTON
ASSIGN
Opens the Button Assign screen.
F
BUTTON
GROUP
Opens the Button Group screen.
G
SETTING
Opens the Setting screen.
H
CONTROL
Used to enter menu settings.
I
CANCEL
Used to cancel menu settings.
J
LOCK
Lock function assignable button
Changing Button Labels
Button labels can be changed on user-assignable buttons. Utilize button label templates in the
FOR-A web site. To remove button caps, use an optional tool.
Go to the MFR-RU Series page in the FOR-A site and download the following files:
“MFR-16RUW_32RUW_4ChrOneLine.pdf”
“MFR-16RUW_32RUW_8ChrTwoLine.pdf.”
URL: https://www.for-a.com/products/mfr_ru_series/
A
J
C
D
E
F
G
I
B
H

14
2-3. MFR-3000 Rear Panel
91 2 3 45 6 7 8 1 2 3 4 5 6 78
INPUT OUTPUT
SERIAL
ALARM
REF IN
SET
SLOT OUTPUTINPUT 98765432187654321
OFF
ON
MFR-LAN1PC-LAN
RATINGLABEL
AC100-240V50/60HzINAC100-240V50/60HzIN
PS2
PS1
SLOT
91 23 4 5 6 7 8 12 3 4 5 67 8
INPUT
ON
SET
POWER
OFF
MFR-LAN2
IN
1
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
1
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
2 3 4 5 6 7 8 2 3 4 5 6 7 8
OUT OUT OUT OUT OUT OUT OUT OUT
OUTPUT
SERIAL
ALARM
MFR-30CPU
ACTIVE
REF IN
SET
SLOT OUTPUTINPUT 98765432187654321
OFF
ON
MFR-LAN1PC-LAN
RATINGLABEL
AC100-240V50/60HzINAC100-240V50/60HzIN
PS2
PS1
SLOT
* The above figure shows an MFR-3000 with MFR-8SDI and MFR-8SDO cards installed.
No.
Name
Description
A
MFR-LAN
Ethernet ports for connection to MFR Remote Control Units and MFR-GPI
(10/100/1000BASE-T, RJ-45)
(1) For MFR-3000
(2) For MFR-30CPU
B
PC-LAN
Ethernet ports for connection to PC or other external unit
(10/100BASE-TX RJ-45)
C
ALARM
Used for alarm output
►See Sec. 2-3-1. "Interfaces."
D
SERIAL
Used for control via a serial interface. RS-232C or RS-422 selectable.
►See Sec. 2-3-1. "Interfaces."
The SERIAL connector is set to RS-422 as factory default. Consult your
FOR-A reseller if you wish to change the setting.
E
AC IN1
Used to connect Power Supply Unit 1 (standard equipment) to an AC
power source
F
AC IN2
Used to connect Power Supply Unit 2 (optional) to an AC power source
G
INPUT
Used for installing input cards
H
OUTPUT
Used for installing output cards
I
REF IN
Used to input a reference signal (BB or Tri-level sync)
(with loop-through. Terminate with 75Ω terminator, if unused.)
J
MFR-30CPU
CPU option card
K
I/O card power
switches
(1) Input card power switches
(2) Output card power switches
L
NC
Not used
A
(1)
E
D
C
K
(1)
B
K
(2)
I
L
M
H
G
O
N
J
A
(2)
F
P
Q
01 02 03 04 05 06 07 08 09 10 11 12 13 14 15 16
Slot No.

15
M
SET
Used to insert / remove input / output cards with MFR-3000 powered on.
N
CPU card
power switch
Used to replace an MFR-30CPU card.
O
SET
Used to manually activate an installed MFR-30CPU.
P
ACTIVE
Displays the MFR-30CPU status.
Lit: MFR-30CPU is active.
Unlit: MFR-3000 CPU is active.
Flashing: MFR-30CPU manual activation is disabled.
Q
OUTPUT9
Reserved slot
IMPORTANT
After installing an MFR-30CPU, MFR-LAN 1, MFR-LAN 2 and PC-LAN connectors
must be connected to their respective devices to enable CPU redundancy. MFR-LAN
and PC-LAN must be located on different LAN segments. Do not connect them to
existing LAN networks.
Input /output cards and Slots
No.
Slot
Video card
Audio card
G
INPUT1-8
(No. 01-08)
8SDI / 8SDIGB: Max. 8 cards
8AAI, 8AESI: Max 8 cards
H
OUTPUT1-8
(No. 09-16)
8SDO / 8SDOGB: Max. 8 cards
16MV: Max. 4cards *
8AAO, 8AESO: Max. 8 cards
* Available slot pairs are No. 09-10, 11-12, 13-14, and 15-16.
Cooling fans
Four cooling fans are installed in MFR-3000 units: FAN 1 and 2 are on the rear panel and
FAN 3 and 4 are on the front panel as shown below.
Rear Panel
Front panel inside
MFR-30PS
91 2 3 45 6 7 8 1 2 3 4 5 6 78
INPUT OUTPUT
SERIAL
ALARM
REF IN
SET
SLOT OUTPUTINPUT 98765432187654321
OFF
ON
MFR-LAN1PC-LAN
RATINGLABEL
AC100-240V50/60HzINAC100-240V50/60HzIN
PS2
PS1
SLOT

16
2-3-1. Interfaces
SERIAL Connector (9-pin D-sub, male)
RS-232C or 422 interface can be selected via the CPU card DIP switches.
(See Sec. 2-3-4. "Changing the Interface from RS-422 to RS-232C."
RS-422 connector pin assignment (Factory default settings)
Pin No.
Signal Name
Description
1
FG
Frame Ground
2
T-
Transmit data (-)
3
R+
Receive data (+)
4
SG
Signal Ground
5
NC
Unused
6
SG
Signal Ground
7
T+
Transmit data (+)
8
R-
Receive data (-)
9
FG
Frame Ground
* The maximum cable length is 100 m.
RS-232C Connector Pin Assignments
Pin No.
Signal Name
Description
1
NC
Not used
2
RxD
Received Data
3
TxD
Transmitted Data
4
DTR
Data Terminal Ready
5
SG
Signal Ground
6
DSR
Data Set Ready
7
RTS
Request To Send
8
CTS
Clear To Send
9
NC
Not used
* The maximum cable length is 10 m.
* DTR/DSR and RTS/CTS are internally connected respectively.
9-pin D-sub, male

17
ALARM Connector (9-pin D-sub, female)
Alarm 1 Out:
Under normal operation:
Pins 1 and 6 are open.
In a malfunction or power-off state:
Pins 1 and 6 are closed.
Alarm 2 Out:
Under normal operation:
Pins 2 and 7 are open.
In a malfunction or power-off state:
Pins 2 and 7 are closed.
Reset:
To reset the unit externally, short Pin 5 and a signal ground pin (8 or 9).
ALARM Connector Pin Assignments
Pin No.
Signal Name
Description
1
ALARM 1 OUT
Alarm 1 output (Default setting: Fan)
2
ALARM 2 OUT
Alarm 2 output (Default setting: Power)
3
NC
Unused
4
NC
Unused
5
RESET IN
Reset in, active low
6
ALARM 1 COMMON
Alarm 1 output, common
7
ALARM 2 COMMON
Alarm 2 output, common
8
GND
Signal ground
9
GND
Signal ground
The following items can be set for ALARM1 OUT and ALARM2 OUT. The alarms can be
assigned in the Web-Based Control.
Available alarm signals
Fan (including power unit cooling fans)
Power
Secondary CPU error
CPU Changeover (issued when the secondary CPU is activated to change over the
operation)
Crosspoint Error
9-pin D-sub, female

18
2-3-2. SDI Input/Output Cards
MFR-3000 units allow Input/Output cards to be installed into slots on the rear panel.
Removing input /output cards
(1)To remove an installed card while the MFR-3000 power is on, turn OFF the
corresponding I/O card power switch (set the switch to down). *
(2)Press SET for a second, then remove the card.
Installing input /output cards
(1)To install a card while the MFR-3000 power is on, MFR-3000, verify that the
corresponding I/O card power switch is turned OFF (the switch is down). *
(2)Press SET for a second, then insert the card.
(3)Turn ON the I/O card power switch (set the switch up). *
(4)Press SET for a second.
* To power off an installed MFR-16MV card using I/O card power switches, two power
switches (for two slots) must be turned off.
Card power shutdown can be performed in the Slot Status page on the Web-based
Control.
2-3-3. CPU Card Installation and Removal
CPU cards can be installed or removed with the MFR-3000 power turned on as shown
below.
IMPORTANT
Do not touch any other parts on the card. Static electricity may damage sensitive
electrical components on the card.
Removing an installed MFR-30CPU card
SET
POWER MFR-LAN2
IN
1
1
2
IN
1
2
IN
1
2
IN
1
2
IN
1
2
IN
1
2
IN
1
2
IN
1
2
1
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
2 3 4 5 6 7 8 2 3 4 5 6 7 8
OUT OUT OUT OUT OUT OUT OUT OUT
MFR-30CPU
ACTIVE
REFIN
SET
SLOT OUTPUTINPUT
MFR-LAN1PC-LAN
(1)Turn OFF the power switch on the MFR-30CPU rear panel.
(2)Release the screws on the both sides of the MFR-30CPU rear panel.
(3)Grasp the handle and the card gently straight out of the slot.
91 2 3 45 6 7 8 12 3 4 5 67 8
INPUT
ON
SET
POWER
OFF
MFR-LAN2
IN
1
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
IN
1
2
3
4
5
6
7
8
1
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
2 3 4 5 6 7 8 2 3 4 5 6 7 8
OUT OUT OUT OUT OUT OUT OUT OUT
OUTPUT
SERIAL
ALARM
MFR-30CPU
ACTIVE
REF IN
SET
SLOT OUTPUTINPUT 98765432187654321
OFF
ON
MFR-LAN1PC-LAN
RATINGLABEL
AC100-240V50/60HzIN AC100-240V50/60HzIN
PS2
PS1
SLOT
(1)
(2)
(3)

19
Inserting an MFR-30CPU card
(1)Verify that the power switch on the card rear panel is turned OFF.
(2)Align both edges of the MFR-30CPU with the guide rails in the slot and insert the card.
(3)Verify that the MFR-30CPU is inserted properly, and secure both screws on the rear of
the MFR-30CPU.
(4)Connect MFR-LAN2 to the same network as MFR-LAN1.
(5)If the power of the MFR-3000 is turned off, turn on the power and wait more than one
minute.
(6)Turn on the Power switch on the rear of the MFR-30CPU and wait about 5 minutes.
Manually activating the MFR-30CPU
Once an MFR-30CPU is installed, it is NOT automatically activated. Follow the procedure
below to manually activate the MFR-30CPU.
(1)After installing an MFR-30CPU, press the SET button on the rear of the MFR-30CPU
(2)Verify that the ACTIVE lamp is lit green. If the ACTIVE lamp flashes green, wait until it
stops flashing and press the SET button again.

20
2-3-4. Changing the Interface from RS-422 to RS-232C
IMPORTANT
Note that internal switch settings should only be performed by qualified technical
personnel.
(1)Remove the 6 screws on the MFR-3000 top panel to remove the panel.
(2)The MAIN card factory default settings are as shown below.
Switch settings
Switch
Settings
S1, S2
Used to select RS-232C or
RS-422. Make your selection
referring to the right figures. Both
switches must be set the same.
Switch settings
RS-232C
RS-422
(Factory default)
IMPORTANT
Do not change other switches
Front
422
422
232C
232C
S1
S2
