Wizard Lion User manual

Instructions manual
Ozone generator
Lion model

2
3
3
3
4
5
5
8
8
8
8
9
9
10
10
11
11
11
Index
1. Introduction ...............................................................................
1.1. Operating principle .......................................................................................
1.2. Manufacturer ..................................................................................................

2. Product operation ..................................................................
2.1. Manual operation .........................................................................................
3. Machine components ...........................................................
3.1. Button panel......................................................................................................

3.3 Air circulation ..................................................................................................
3.4 Ozone generator.............................................................................................
3.5 Ozone gauge sensor ...................................................................................
4. Maintenance .............................................................................
5. Product applications .............................................................
6.Safety recommendations.
indications and warnings .........................................................



3
1.1 Operating principle

types of microorganisms.It is the most active form of oxygen, capable of
deactivating viruses, bacteria, parasites, fungi,molds, spores and many other


disinfectants.
The use of ozone for air disinfection is much more recommended than
the use of otherdisinfectants, apart from its effectiveness and its rapid

the most ecological and sustainable disinfection.
This ozone generator uses a high-frequency system to turn the surrounding
oxygen molecules into ozone by micro-discharge. Once the ozone is



1.2 Manufacturer
Ozone generator manufactured by LEMAR LEBEN GROUP S.L.
Contact address:
Pol. Industrial nº2 – C/ En proyecto, s/n

Teléfono ([phone]


4
1.3 Technical specications
Ozone output Flow
Ozone generator Treated zone
Voltage +- 10% Weight
Power Dimensions
20g/h
Corona discharge 0-300m2
AC220v 50Hz 12kg
250w390x250x595mm
2250l/min
Estandard programs:
Rooms up to 30m2
Pr.1 – 82min
Rooms up to 80m2
Pr.2 – 172min
Rooms up to 150m2
Pr.3 – 280min
Rooms up to 300m2
Pr.4 – 420min
- Programs type: ozone + oxygenation cycle
- App programming by volume: Calculation according to the space to be
disinfected


to use

- Operation light sign.


material have been found.


5
2. Product operation
2.1. Manual operation
Connect the machine to the electrical current 

connection cable. Preferably place in the center of the cabin or room to be
disinfected.
Press the power switch. 


Select the desired program pushing the Program button (consult section 3.1).
Push the Run button to start the operating cycle (consult section 3.1).
The ozonation process will start 10 seconds later. This security time is used


Be careful, ozone generator cannot be used in the presence
of people or animals.

6
Program 1
rooms up to 30m2.
Cycle time: 82 minutes.



Air out the room after disinfection
Program 2
rooms up to 80m2.
Cycle time: 172 minutes.



Air out the room after disinfection.

7
Program 3
150 m2.
Cycle time: 280 minutes.



Air out the room after disinfection.
Program 4
rooms up to 300 m2.
Cycle time: 420 minutes.



Air out the room after disinfection.
Program error


restart the process. If you notice a strong ozone odor, air out the room
immediately.
If the error persists, consult the manufacturer

8
RUN
1 2 3 4PROG
3. Machine components
3.1 Button panel
3.2 Active carbon lter

ozone molecules (O3) once the disinfection process has been completed, to

3.3 Air circulation

ozonization and oxygenation processes.
Led indicators
for the selected
program
Pogram start
button
Program selection button

9
RUN
1 2 3 4PROG
3.4 Ozone generator

corona effect. Ozone is produced from an electrical discharge, commonly

ambient air into elemental oxygen (O). These oxygen atoms


in an air space

produce ozone. In

through this gap to

3.4 Ozone gauge sensor
This ozone generator has an ozone gauge sensor that can measure the
amount of this gas throughout the process. When access to the vehicle or

The disinfected area must be properly ventilated before use

10
4.Maintenance






It is recommended to inspect it periodically and change it in case of
deterioration.

Any damaged part should only be replaced by the manufacturer.


The ozone gauge sensor should be replaced after 5 years of use.
To do this, consult themanufacturer
The ozone generator should be replaced after 5 years of use.
To do this, consult themanufacturer.
5. Product applications
This ozone generator is useful for the disinfection of viruses and bacteria and
the elimination of odors from all types of vehicles (cars, vans, buses, etc.) and
rooms up to 300m.
Suitable for hospitals, clinics, laboratories, residences, shops, restaurants,
coffee shops, hotels,spas, beauty centers, hairdressers, gyms and sports
centers.
5
5

11
6. Safety recommendations.
Indications and warnings.
6.1. Specic warnings

the maximum value recommended by the WHO and therefore, according to

It cannot be used in the presence of people, animals and / or living

in operation, it must be carried out observing the adequate protective
measures against irritating gases.


accessible under normal conditions once it indicates that the ozonation +
oxygenation cycle has ended (programs 1, 2, 3 or 4, times in
section 2.1). The disinfected area must be properly ventilated before use.

differential of at least 30 mA.
6.2. General warnings



those indicated in this manual.

MAL20201003
