WMF coffeemachines
WMF Heated Thermal Container 20 liter planning
information for WMF 9000 F
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 |73312 Geislingen (Steige)
On site
3x1mm2,
length appr.
1.5 m
Optional:
Area for counter cut out for
connection
Optional feet
Ø 40 mm
Connection plug

µ
WMF coffeemachines
WMF Heated Thermal Container 20 liter planning
information for WMF 9000 F
Dimensions
and empty
weight
Width
Height
Depth
Clearance heights
Weight
355mm
583mm with insulated lid
446mm with carry handles
473mm with tap
Approx. 11.2kg
Use at
elevation
above sea level
<2000m
Electrical data Nominal power
rating
0.1 kW
Power supply 220- 240V
50 / 60 Hz (1 / N / PE)
Degree of protection IP X0
Protection Class I
Installation
Clearance
For operating, service, and safety reasons the machine should be installed with a clearance
from the building or non-WMF components of not less than 50 mm at the sides and 60 mm
at the back. A minimum working space of 800 mm in front of the coffee machine is
recommended. Clearance of at least 200 mm above the product hopper is recommended. The
height of the installation surface above the floor is at least 850 mm. If the coffee machine
connections are to be run downwards through the counter, please make space for the lines,
which can reduce the usable space below the machine. Additional space for grounds through
counter need to be considered on site if necessary.
Installation
surface /
water spray
The device must be placed and leveled on a horizontal, sturdy, water-resistant, and heatproof
base. The device must not be cleaned using a water jet. The device must be installed where it
is protected against water spray. The device must not be located on a surface that is sprayed
or cleaned with a water hose, steam jets, steam cleaner, or similar devices.
Conditions for usage and installation
Any necessary on-site preparatory work for electricity, water and drainage connections at the customer‘s premises
is to be arranged by the machine owner / operator. The work must be carried out by authorised installation
technicians in compliance with general, country-specific and local regulations. The WMF service engineers may
only connect the coffee machine to existing prepared connection points. WMF Service is neither authorised nor
responsible for carrying out any on-site installation work prior to connection.
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 |73312 Geislingen (Steige)

µ
WMF coffeemachines
WMF Heated Thermal Container 20 liter planning
information for WMF 9000 F
http://www.wmf-kaffeemaschinen.de/fachplaner
WMF Group GmbH | Eberhardstraße 35 |73312 Geislingen (Steige)
For more information as the instruction manual , safety data sheets and certificates , see:
http://mediacenter.wmf.com/servicecenter/
All information refers to coffee machines/ equipment as standard version. Individual solutions can differ from the
standard version.
Electrical
connection
These specifications for the electrical connection and the standards quoted apply for
connecting the coffee machine in EU countries. It may be necessary to also observe additional
country-specific regulations. Outside the EU countries acceptance of the standards quoted is
to be checked by the legal entity or natural person who wishes to use the coffee machine.
The customer's on-site electrical system must be designed to meet countryspecific regulations
per IEC 60364 and must match the information on the rating plate.
An isolated ground socket or a country-specific single-phase socket for single-phase
connection, or a 5-pole CEE / CEKON socket per DIN EN 50310 VDE 0800–2-310 or a country-
specific multi-pole socket for a three-phase connection, must be available near the machine.
The sockets are part of the customer‘s on-site installation. The mains cable must not come
into contact with hot surfaces. If the mains cable for this device is damaged then it must be
replaced by our service personnel or a similarly qualified person, in order to prevent
hazards.
In order to avoid possible faults from arising in our shielded data lines due to
potential equalisation currents between the devices, an additional potential equalisation unit
should be planned for devices connected to the vending system (see DIN EN 50310 VDE 0800–
2-310). If the machine is intended to be installed in a large kitchen, it is recommended
that it be equipped with a ground potential bonding conductor. The potential equalisation
terminal is installed by WMF Service if needed.
Miscellaneous Ambient
temperature
+5 °C to maximum +35 °C
(empty the water system in case of frost).
Maximum
humidity
80 % relative humidity without condensation. Do not use device outdoors.
