WobbiTech HKV-001 User manual

WobbiTech
HKV-00
HKV-00
HKV-00
HKV-00
1
1
1
1
Internet
Internet
Internet
Internet
Radio
Radio
Radio
Radio
User Guide

1 WobbiTech HKV-001 internet radio user guide
Overview
Overview
Overview
Overview
HKV-001 provides easy access to a wide selection of radio stations and
audio files on the Internet. Before enjoying your Internet Radio, make
sure that you have access to a wired network
Main
Main
Main
Main
features
features
features
features
Cable connectable for home or office LAN without any setup
Low power consumption(<0.8Watt at standby mode)
Support multiple internet audio streaming protocol(HTTP web, RTSP, Icecast and
SHOUTcast)
Support LAN MyCast, BiCast POD protocol
built-in 1Mbit RAM to support buffer size up to 8 seconds for 128kbps stream
Built-in speaker, external sub speaker for stereo channels
Output power upto 2 x 2-Watt THD+N=1% with two 4 OHM speakers
Station channel display
8 preset station buttons
Sleep timer
InfraRed remote controller
FM transmitter option
Support by HKV-001 Manager Software(HKV-001MS): Manager Software for
staion management and setup
Support by Andriod app: Remote control, radio staion management and setup

WobbiTech HKV-001 internet radio user guide 2
Specifications
Specifications
Specifications
Specifications
Network
Network
Network
Network
connectivity
connectivity
connectivity
connectivity
10/100Mbits Ethernet
Audio
Audio
Audio
Audio
decoder
decoder
decoder
decoder
format
format
format
format
MP3/WMA/AAC/AAC+/Ogg/WAV
Radio
Radio
Radio
Radio
stream
stream
stream
stream
protocol
protocol
protocol
protocol
HTTP WEB, RTSP, Icecast, SHOUTcast ,
Mycast, BiCast
Output
Output
Output
Output
Headphone jack ( Φ 3.5mm)
Sub speaker jack ( Φ 3.5mm)
Ethernet (RJ45)
DC power jack (Mini USB)
Speaker
Speaker
Speaker
Speaker
Built-in 5 Watt / 4 Ohm
FM
FM
FM
FM
transmitter
transmitter
transmitter
transmitter
Modulation: Stereo
Frequency: 70MHz~108MHz
Specification: ALC / SN > 66dB
AC
AC
AC
AC
power
power
power
power
adaptor
adaptor
adaptor
adaptor
Input: AC 100 ~ 240V(50/60Hz)
Output: DC 5V/2A
Remote
Remote
Remote
Remote
control
control
control
control
infraRed 21 keys

3 WobbiTech HKV-001 internet radio user guide
Front
Front
Front
Front
view
view
view
view
standby / on button , press to turn radio on or off.
mode button, press to change mode between Volume control , FM
frequency setting , FM in/off setting and channel control , wile select the
mode, press button to change the current setting .
Dimension
Dimension
Dimension
Dimension
110 (L) x110 (W) x170 (H)mm
Application
Application
Application
Application
software
software
software
software
Win - 32 manager software /Android app

WobbiTech HKV-001 internet radio user guide 4
display on/off button , press to turn the display on or off .
sleep timer button , press to display sleep timer ( minute ), press
again to reset the timer ; press button can change sleep time (5
minutes/step ).
radio station channel buttons , act as [+/-] button when change
mode and sleep time setup .
volume buttons , change volume level and resume from mute
mode .
preset station buttons,
While listen one radio station, press and hold one button until display
[PS_*] can save the current channel as preset station * ; press the preset
button to listen the radio station at once if there station channel is saved
to the preset station .

5 WobbiTech HKV-001 internet radio user guide
infraRED receiver
LED indicator
Rear
Rear
Rear
Rear
view
view
view
view
power switch , turn on/off the power of unit
external sub speaker jack
ethernet jack
headphone jack
DC power socket

WobbiTech HKV-001 internet radio user guide 6
Remote
Remote
Remote
Remote
control
control
control
control
Using the remote control to control the unit, refer the following table for
detailed operation and functions .

7 WobbiTech HKV-001 internet radio user guide
Button
Function
Operations
Standby/On button
turn radio on or off
Mode button
change mode between
Volume control , FM
frequency setting , FM in/off
setting and channel control ,
wile select the mode, press
button to change
current setting .
display button
Press to turn display on or
off
Sleep timer button
press to display sleep
timer ( minute ), press again
to reset the timer ; press
button can change sle

WobbiTech HKV-001 internet radio user guide 8
ep time (5 minutes/step )
Preset station button
preset station buttons,
While listen one radio
station, press and hold one
button until display [PS_*]
can save the current channel
as preset station * ; press the
preset button to listen the
radio station at once if there
station channel is saved to
the preset station .
Volume button
Press to change volume
level
Mute button
Press the button to mute ,
press again to unmute , or
press to unmute

9 WobbiTech HKV-001 internet radio user guide
Turn
Turn
Turn
Turn
on
on
on
on
the
the
the
the
device
device
device
device
Connect the power adaptor to DC power jack, and the CAT5 cable is
connected to Ethernet, set power switch to [ON] position , the running
LED indicator for connecting in progress, and the display will show [- - - -]
Channel number
mode button
Press to change one or two
digit mode, display [CH0_]
or [CH_ _]
Radio channel entry
button
Select radio channel entry ,
for one digit mode (CH01 ~
CH09), press one number to
change channel; two digit
mode(CH10 ~ CH99) need
input two digits to change
the channel
Radio channel [+]/[-]
button
Press to change channel , or
act as [ +/- ] button in sleep
timer setting mode and
mode change setting mode

WobbiTech HKV-001 internet radio user guide 10
that means the device is connected to LAN and is in standby mode, user
can control the device using remote control, Android app and Win32
application .
Using
Using
Using
Using
Win32
Win32
Win32
Win32
manager
manager
manager
manager
application
application
application
application
This untility can connect to your HKV-001 device in same LAN, with its
powerful functions, you can manage your own station list, search on-line
for preference station, edit the staion information, listen station for
testing and even add your own station. Also you can manage your
playback list for the audio file in PC, and HKV-001 can be configed as your
LAN speaker.
For Windows 7/Vista/XP/2000
Main
Main
Main
Main
functions
functions
functions
functions
:
:
:
:




Multiple
Multiple
Multiple
Multiple
language
language
language
language
support
support
support
support
English
Chinese(tranditional, simplified)

11 WobbiTech HKV-001 internet radio user guide
user self - defined




Stat
Stat
Stat
Stat
i
i
i
i
on
on
on
on
list
list
list
list
management
management
management
management
Search internet radio station on-line (by location, language,
genre or key words)
favorite station list: upload, download, save and load function
new radio station add feature
internet radio station test feature




LAN
LAN
LAN
LAN
Speaker
Speaker
Speaker
Speaker
support audio format(WAV, WMA, MP3, AAC+, OGG)
playlist management(add, delete)
play on e or play all functions
auto repeat playback option




Setup
Setup
Setup
Setup
check HKV-001 network parameters
setup parameter for HKV-001 as working channel, volume,
buffer size,FM transmitter etc.

WobbiTech HKV-001 internet radio user guide 12
Screenshot
Screenshot
Screenshot
Screenshot
connected to HKV-001

13 WobbiTech HKV-001 internet radio user guide
Setup
LAN speaker

WobbiTech HKV-001 internet radio user guide 14
Radio station search and management

15 WobbiTech HKV-001 internet radio user guide
Using
Using
Using
Using
Android
Android
Android
Android
app
app
app
app
This app can connect to your HKV-001 device in same LAN, with its
powerful functions, you can manage your own station list, search on-line
for preference station, display radio station information and control HKV-
001 device etc.
Main
Main
Main
Main
functions
functions
functions
functions
Auto connect HKV-001 radio in LAN
Display radio information
Volume control, Channel change
Display favourate station list
Select radio station to play directly
Support english and chinese
Search radio station on-line
Play back the audio file s in phone to HKV-001
Limited internet radio function without HKV-001 device connected
Support auto-connect station function when using the limited internet radio
function
Operation
Operation
Operation
Operation
[
[
[
[
Settings
Settings
Settings
Settings
]
]
]
]
Press [Menu] from main page to open the setting page, use
can change settings of language, app notification in Android, current
location and HKV-001 device settings(built-in FM transmitter parameters

WobbiTech HKV-001 internet radio user guide 16
and the default settings such as working channel, volume level and
playback buffer size).
main settings
HKV-001 device settings

17 WobbiTech HKV-001 internet radio user guide
[
[
[
[
Working
Working
Working
Working
with
with
with
with
HKV-001
HKV-001
HKV-001
HKV-001
device
device
device
device
]
]
]
]
If
the app is connected to HKV-001
device
press [ON]/[OFF] button to
turn off or turn on HKV-001
press [FM] button to turn off
or turn on built-in FM transmitter
press [Display] button to turn
off or turn on the LED display
press [Play] button to connect and listen the radio station which
indicate CHxx
press [Stop] button to disconnect the station
press [CH-] or [CH+] button for last or next radio station
press [VOL-] or [VOL+] button to adjust volume step by step
Slide or click the volume bar to adjust volume at any level

WobbiTech HKV-001 internet radio user guide 18
[
[
[
[
LAN
LAN
LAN
LAN
speaker
speaker
speaker
speaker
]
]
]
]
If the app is connected to HKV-001 device, user can play
the audio files in phone to HKV-001 device( support audio file format as
WAV, MP3, WMA, AAC, OGG), press [LAN speaker] button to go to the
operation page.
press [Menu]->[Settings] to select
working folder(default: Sounds)
working status

19 WobbiTech HKV-001 internet radio user guide
[
[
[
[
Favourate
Favourate
Favourate
Favourate
station
station
station
station
function
function
function
function
]
]
]
]
The app can connect to [Wobbi Portal] for the updated internet radio
station information, user can manage one's own favourate station list,
press [Station] button to go to the operation page.
station list
long press the selected station for
more functions
