Wolf cinema DCX-500FD User manual

Digital Cinema Three Chip DLP™ Projectors
DCX-500FD
DCX-500i
DCX-1000FD
DCX-1000i
DCX-1500FD
DCX-1500i
Wolf Cinema • 2431 Fifth Street •Berkeley •CA 94710 •Tel: [phone] •Fax: [phone] •www.wolfcinema.com

DCX-500FD DCX-500i DCX-1000FD DCX-1000i DCX-1500FD DCX-1500i
Light Engine Cinema Contrast three chip DLP™
light engine Cinema Contrast three chip DLP™ light engine Cinema Contrast three chip DLP™ light engine Cinema Contrast three chip DLP™ light engine Cinema Contrast three chip DLP™ light engine Cinema Contrast three chip DLP™ light engine
Color Filter Filmic Color Correction Filter Filmic Color Correction Filter Filmic Color Correction Filter Filmic Color Correction Filter Filmic Color Correction Filter Filmic Color Correction Filter
Lamp Xenon lamp 500W Xenon lamp 500W Xenon lamp 1000W Xenon lamp 1000W Xenon lamp 1225W Xenon lamp 1225W
Lens System VariScope constant height lens
system VariScope constant height lens system VariScope constant height lens system VariScope constant height lens system VariScope constant height lens system VariScope constant height lens system
Lens Options †.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
.67:1** RP lens
1.1:1** FP lens
1.4-1.8:1*
1.8-2.6:1*
2.6-4.1:1*
4.1-6.9:1*
Gamma
Correction Film 1 Correction Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Film 1 Correction
Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Film 1 Correction
Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Film 1 Correction
Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Film 1 Correction
Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Film 1 Correction
Film 2 Correction
B&W Film Correction
Incandescent Light Correction
Fluorescent Light Correction
Sunlight Correction
Picture Quality Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Multi Standard Color Management
and Calibration Control
White Field Uniformity/Correction
Communications RS232 in and out
IR input
Wolf Sentry IP monitoring and control
RS232 in and out
IR input
Wolf Sentry IP monitoring and control
RS232 in and out
IR input
Wolf Sentry IP monitoring and control
RS232 in and out
IR input
Wolf Sentry IP monitoring and control
RS232 in and out
IR input
Wolf Sentry IP monitoring and control
RS232 in and out
IR input
Wolf Sentry IP monitoring and control
Inputs 6 HDMI 1.3 inputs (1 on front panel), 2
Component, 1 S-Video, 1 Composite 6 HDMI 1.3 inputs (1 on front panel), 2 Component, 1 S-Video, 1 Composite 6 HDMI 1.3 inputs (1 on front panel), 2 Component, 1 S-Video, 1 Composite 6 HDMI 1.3 inputs (1 on front panel), 2 Component, 1 S-Video, 1 Composite 6 HDMI 1.3 inputs (1 on front panel), 2 Component, 1 S-Video, 1 Composite 6 HDMI 1.3 inputs (1 on front panel), 2 Component, 1 S-Video, 1 Composite
Outputs 1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
1 HDMI 1080P Video (set to native
rate of display)
1 HDMI audio loop out with delay
Contrast Ratio 2,500- 50,000:1 full on/off *** 2,500- 50,000:1 full on/off *** 2,500- 50,000:1 full on/off *** 2,500- 50,000:1 full on/off *** 2,500- 50,000:1 full on/off *** 2,500- 50,000:1 full on/off ***
Lumens 2500*** 2500*** 5500*** 5500*** 7250*** 7250***
Lamp Life 2500 to 4000 depending on lamp
power setting 2500 to 4000 depending on lamp power setting 2500 to 4000 depending on lamp power setting 2500 to 4000 depending on lamp power setting 2500 to 4000 depending on lamp power setting 2500 to 4000 depending on lamp power setting
Power 100 VAC to 240 VAC ± 10% @
50/60 Hz, Power consumption: 900W
maximum, Thermal dissipation: 3000
BTU/hr, Operating current: 9.5A @
100V/5A@ 200V
100 VAC to 240 VAC ± 10% @
50/60 Hz, Power consumption: 900W
maximum, Thermal dissipation: 3000
BTU/hr, Operating current: 9.5A @
100V/5A@ 200V
100 VAC to 240 VAC ± 10% @ 50/60
Hz, Power consumption: 1500W
maximum, Thermal dissipation: 5460
BTU/hr, Operating current: 10.4A @
100V/8A@ 200V
100 VAC to 240 VAC ± 10% @ 50/60
Hz, Power consumption: 1500W
maximum, Thermal dissipation: 5460
BTU/hr, Operating current: 10.4A @
100V/8A@ 200V
200 VAC to 240 VAC ± 10% @ 50/60
Hz, Power consumption: 2000W
maximum, Thermal dissipation: 6825
BTU/hr, Operating current: 10A @
200V
200 VAC to 240 VAC ± 10% @ 50/60
Hz, Power consumption: 2000W
maximum, Thermal dissipation: 6825
BTU/hr, Operating current: 10A @
200V
Dimensions Length: 41 5/8
Width: 29 7/8
Height: 12 1/8
Length: 21 1/2
Width: 28 1/4
Height: 11 1/2
Length: 41 5/8
Width: 29 7/8
Height: 12 1/8
Length: 21 1/2
Width: 28 1/4
Height: 11 1/2
Length: 41 5/8
Width: 29 7/8
Height: 12 1/8
Length: 21 1/2
Width: 28 1/4
Height: 11 1/2
Dimensions with
VariScope 2.35 Length: 41 5/8 Width: 29 7/8
Height: 12 1/8
Length: 31 3/4
Width: 28 1/4
Height: 11 1/2
Length: 41 5/8
Width: 29 7/8
Height: 12 1/8
Length: 31 3/4
Width: 28 1/4
Height: 11 1/2
Length: 41 5/8
Width: 29 7/8
Height: 12 1/8
Length: 31 3/4
Width: 28 1/4
Height: 11 1/2
Options VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
VariScope 2.35
Automated 2.35 lens and motor for
use with VariScope lenses
Wolf Warp
Geometric distortion correction for
more exible installation solutions
† Preliminary Lens Options
* Use of VariScope features does not allow for full zoom range of lens. Please see manual for details
** VariScope feature not available with this lens option.
*** Depending on lamp power setting, installed iris and iris setting.
