Planning Information
60" (1524) Dual Fuel Ranges
MODELS DF606DG, DF606F, DF606CG, DF604CF AND DF604GF
1
Dimensions in parentheses are in
millimeters unless otherwise specified.
9/07
The Wolf 60" (1524) dual fuel range
is available in natural or LP gas, with your
choice of several top configurations.
Model numbers indicate the features;
(C) charbroiler, (G) griddle, (DG) double
griddle and (F) French top. The model
number followed by (-LP) denotes an LP
gas model.
With Wolf's dual fuel ranges you have state-of-the-art
cooking expertise in any number of sizes to meet the
discriminating consumers' precise needs. Patented
features ensure that this range stands out from the rest
in performance and also beauty.
Wolf dual fuel ranges offer a wide variety of top configu-
rations and standard dual-stacked sealed surface
burners. Optional infrared charbroiler, infrared griddle and
French Top give you the freedom to customize your
range.
The electric ovens feature the Wolf exclusive dual
convection system that delivers even temperature and
airflow throughout. Its two convection fans and four
heating elements give the user convenience and superior
control over ten different cooking modes. Brilliant
halogen lights illuminate the beautiful cobalt blue oven
interiors.
Let Wolf, the corporate companion and kitchen soul
mate of Sub-Zero, fuel your passion for cooking and
kitchen design.
Model DF604CF shown.
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.
Model DF606DG
Model DF606F
Model DF606CG
Model DF604CF
Model DF604GF
Continuous cast
iron top grates
Location of
rating plate
Coaxial oven
selector knobs
Dual halogen
oven lighting
Pivoting hidden
control panel
Blue porcelain
oven interiors
Dual-stacked,
sealed burners
French top (optional) Infrared charbroiler
(optional)
Adjustable front legs
and rear casters
Stainless steel
exterior finish
Stainless steel
island trim
Spring/damper
door system
Control knobs with
platinum bezels
Dual convection
ovens

Planning Information
60" (1524) Dual Fuel Ranges
MODELS DF606DG, DF606F, DF606CG, DF604CF AND DF604GF
2
601/8" (1527)
OVERALL WIDTH
417/8"
(1064)
WITH 5"
RISER
467/8"
(1191)
WITH 10"
RISER
567/8"
(1445)
WITH 20"
RISER
47" (1194)
241/4"
(616)
271/2" (699)
91/4"
(235)
291/2" (749)
OVERALL DEPTH
LEGS AND CASTERS ALLOW
21/8" (54) HEIGHT ADJUSTMENT
357/8"
(911)
367/8"
(937)
OVERALL
HEIGHT TO
COOKING
SURFACE
OVERALL DIMENSIONS
FEATURES
Natural or LP gas rangetop with two large-
capacity dual convection electric ovens
Optional infrared charbroiler, infrared griddle
and French Top configurations
Classic stainless steel exterior finish with
island trim included
Distinctive red or black control knobs
Platinum bezels surround all knobs—chrome
or brass bezels optional
Dual-stacked, sealed surface burners, all
with simmer capabilities and automatic
reignition at all settings
15,000 Btu/hr (4.4 kW) burners with 950
Btu/hr (.3 kW) delivered at simmer
9,200 Btu/hr (2.7 kW) burner with 325 Btu/hr
(.1 kW) delivered at simmer and melt feature
Porcelain-coated cast iron continuous top
grates
Ten cooking modes— bake, roast, broil,
convection bake, convection roast, convec-
tion broil, convection, bake stone (accessory
required), dehydrate (accessory required)
and proof
Pivoting hidden touch control panel
Self-cleaning ovens with cobalt blue porce-
lain oven interior
Coaxial temperature-displaying oven selector
knobs
Temperature probe in each oven
Three removable oven racks in each oven,
six-level rack guides and full-extension
bottom rack
Hidden bake element and recessed broil
element in each oven
Triple-pane oven door windows and dual
halogen lighting
Spring/damper door system on oven doors
Adjustable stainless steel legs in front and
adjustable rear casters
CSA certified for US and Canada
Two and five year residential warranty—
exclusions apply; warranty information can
be found on our website, wolfappliance.com
Dimensions in parentheses are in
millimeters unless otherwise specified.
Unit dimensions may vary by ±
1
/ 8 " (3).

Planning Information
60" (1524) Dual Fuel Ranges
MODELS DF606DG, DF606F, DF606CG, DF604CF AND DF604GF
Dimensions in parentheses are in
millimeters unless otherwise specified.
3
MODEL OPTIONS
Six Burners / Double Griddle DF606DG
Six Burners / French Top DF606F
Six Burners / Charbroiler
and Griddle DF606CG
Four Burners / Charbroiler
and French Top DF604CF
Four Burners / Griddle and
French Top DF604GF
Natural gas models listed, for LP gas add
(-LP) to the model number.
VENTILATION OPTIONS
60" (1524) Pro wall hood or liner
66" (1676) Pro wall or island
hood or liner
Also refer to the Pro Ventilation section of
our website, wolfappliance.com.
ACCESSORIES
5" (127) and 10" (254) classic
stainless steel risers
20" (508) classic stainless steel
riser with shelf
Red or black control knobs—
must be ordered with the range
Chrome or brass bezels
One-piece wok grate and single
burner grate
Porcelain-cast two-burner S-grates
Two-piece broiler pan and temper-
ature probe
Set of three oven racks
Hardwood cutting board—griddle
models only
Bake stone accessory
Dehydration accessory
Front leg extension covers and
rear leg caster covers
High altitude conversion kit
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.
SPECIFICATIONS
Overall Range Width 60 1/8" (1527)
Overall Range Height
(to cooking surface) 36 7/8" (937)
Overall Range Depth 291/2" (749)
Dual-Stacked Sealed Surface Burners
15,000 Btu/hr (4.4 kW) burners with 950 Btu/hr
(.3 kW) delivered at simmer
Single 9,200 Btu/hr (2.7 kW) burner with 325 Btu/hr
(.1 kW) delivered at simmer
Infrared Charbroiler 16,000 Btu/hr (4.7 kW)
Infrared Griddle
Natural Gas 15,000 Btu/hr (4.4 kW)
LP Gas 13,000 Btu/hr (3.8 kW)
Double Griddle (two burners)
Natural Gas 15,000 Btu/hr (4.4 kW)
LP Gas 13,000 Btu/hr (3.8 kW)
French Top 15,000 Btu/hr (4.4 kW)
Overall Interior Capacity (per oven) 4.5 cu ft (127 L)
Overall Interior Dimensions 25" W x 161/2" H x 19" D
(per oven) (635 x 419 x 483)
Usable Interior Dimensions 211/2"W x 161/2"H x 163/8"D
(per oven) (546 x 419 x 416)
Opening Width 60 1/4" (1530)
Electrical Supply Requirements 240 / 208 V AC, 60 Hz
50 amp circuit
Electric Rating 10.2 kW at 240 V
8.8 kW at 208 V
Total Amps 42.5
Shipping Weight 875 lbs (397 kg) – 950 lbs (431 kg)
Specifications are subject to change without notice.
IMPORTANT NOTE: A minimum 10" (254) riser is required for all
60" (1524) dual fuel range models installed against a combustible
surface.

Planning Information
60" (1524) Dual Fuel Ranges
MODELS DF606DG, DF606F, DF606CG, DF604CF AND DF604GF
Dimensions in parentheses are in
millimeters unless otherwise specified.
4
13"
(330)
LOCATION OF
ELECTRICAL
36"
(914)
367/8"
(937) TO
COOKING
SURFACE
VENTILATION HOOD
LOCATION OF GAS AND
ELECTRICAL EXTENDS 3" (76)
ON FLOOR FROM BACK WALL
31/4"
(83)
31"
(787)
10" (254)
LOCATION
OF GAS
SUPPLY
601/4" (1530)
FINISHED ROUGH OPENING WIDTH
18"min (457)
TO COUNTERTOP
30"min (762) TO
36"max (914)
TO BOTTOM OF
VENTILATION HOOD
36"min (914)
COUNTERTOP
TO COMBUSTIBLE
MATERIALS
44"min (1118)
FOR CHARBROILER
ISLAND INSTALLATIONS: 12" (305) MINIMUM
CLEARANCE FROM BACK OF RANGE TO
COMBUSTIBLE REAR WALL ABOVE COUNTERTOP–
0" (0) TO NON-COMBUSTIBLE MATERIALS
13" max
(330)
6"min (152)
TO
COMBUSTIBLE
MATERIALS
(BOTH SIDES)
INSTALLATION SPECIFICATIONS
DIMENSIONS
Overall Width of Range 60 1/8" (1527)
Finished Rough Opening Width 60 1/4" (1530)
Location of Gas Supply Within shaded area
Location of Electrical Within shaded area
See Installation Instructions shipped with unit for detailed specifications.

Planning Information
60" (1524) Dual Fuel Ranges
MODELS DF606DG, DF606F, DF606CG, DF604CF AND DF604GF
Dimensions in parentheses are in
millimeters unless otherwise specified.
5
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions, finished rough opening
dimensions and installation specifics.
IMPORTANT NOTE: Caution must be used in
planning the proper installation of the Wolf dual
fuel range to avoid any fires or damage to
adjacent cabinetry or kitchen equipment. Be
sure to follow minimum clearances established
in the finished rough opening dimensions as
shown in the illustration on page 4.
IMPORTANT NOTE: A minimum 10" (254) riser
is required for all 60" (1524) dual fuel range
models installed against a combustible surface.
A Wolf Pro ventilation hood or hood liner is
recommended. When installing a ventilation
hood, refer to the specific requirements of the
hood for the minimum dimension to countertop.
Also refer to the ventilation recommendation
charts in the Pro ventilation section of our
website, wolfappliance.com.
The 60" (1524) dual fuel range requires a
240/208 V AC, 60 Hz, 50 amp fused electrical
supply to operate the electrical portions of the
range. Locate electrical within the shaded area
shown in the illustration on page 4.
Wolf dual fuel ranges are designed with a
terminal block on the rear of the range. The
terminal block allows for a 3-wire or 4-wire
installation. For a 4-wire installation, the ground
strap from the unit to the terminal block must
be cut. Two concentric knockouts on the base
of the unit are provided to allow a certified elec-
trical contractor to wire the range directly to the
electrical supply. The terminal block will also
accept an appliance cord that is sized correctly
for the range’s voltage and amperage.
Wolf dual fuel ranges are designed to operate
on natural gas at 5" (12.5 mb) WC (water
column) pressure or LP gas at 10" (25 mb) WC
pressure. The minimum line pressure for natural
gas is 7" (17.5 mb) WC and 11" (27.4 mb) WC
for LP gas. The maximum gas supply pressure
to the regulator should never exceed 14"
(34.9 mb) WC; .5 psi (3.5 kPa).
Wolf recommends the use of a 1/2" (13) I.D.
commercial type flex hose; this is the minimum
size that may be used. All plumbing to the flex
hose must be 3/4" (19) minimum I.D. pipe.
IMPORTANT NOTE: A separate external gas
shut-off valve must be located near the range in
an accessible location.
You must follow all National Electrical Code
and gas regulations. In addition, be aware of
local codes and ordinances when installing
your services.
Wolf dual fuel ranges using natural gas
function up to an altitude of 8,000' (2438 m)
without any adjustment. Natural gas and LP gas
installations from 8,000' (2438 m) to 11,000'
(3353 m) need the high altitude kit. Contact
your Wolf dealer for details. To obtain local
dealer information, visit the Showroom Locator
section of our website, wolfappliance.com.
Refer to the installation instructions
shipped with each Wolf product for detailed
specifications.
