Wolf DF366 User manual

36" Dual Fuel Ran es
Wolf dual fuel ran es offer a variety
of top confi urations and standard
dual-stacked sealed surface burners.
The optional infrared charbroiler and
infrared riddle ive you the freedom to
customize your ran e. The lar e electric
oven features ten cookin modes and the
Wolf exclusive dual convection system
that delivers even temperature and
airflow throu hout. Dual fuel ran es are
available in natural or LP as.
FEATURES
•Stainless steel exterior finish with island
trim included.
•Red, black or stainless steel control
knobs (specify with range).
•Stainless steel bezels surround all knobs.
•Dual-stacked, sealed burners, all with
simmer capabilities and automatic
reignition at all settings.
•Melt feature on 9,200 Btu burner.
•Ten cooking modes, temperature probe
and self-clean features.
•Porcelain-coated cast iron continuous
top grates.
•Pivoting hidden touch control panel.
•Coaxial temperature displaying oven
selector knob.
•Cobalt blue porcelain oven interior with
halogen lighting.
•Three adjustable oven racks; one full-
extension easy glide, one full-extension
door glide and one standard.
•Hidden bake element and recessed
broil element.
•Spring/damper door hinge system.
Cobalt blue
oven interior.
Rotating
control panel.
Model DF366
Model DF364C
Model DF364G
SURFACE FEATURES
Model DF366 DF364C DF364G
Surface Burners
15,000 Btu high / 950 Btu simmer 533
Surface Burner
9,200 Btu high / 325 Btu simmer 111
Infrared Charbroiler – 16,000 Btu •
Infrared Griddle – 15,000 Btu •
Mode numbers are for natura gas dua fue ranges, add (-LP) to the mode number for LP gas.
ACCESSORIES
•Stainless steel risers in 5" and
10" heights, or 20" riser with shelf.
•Red, black or stainless steel control
knobs.
•Chrome or brass bezels.
•ne piece porcelain-cast wok grate and
single burner grate.
•Porcelain-cast two-burner S-grate.
•Set of three standard oven racks.
•ne full-extension easy glide rack.
•Broiler pan and temperature probe.
•Hardwood cutting board
(griddle model only).
•Bake stone kit.
•Dehydration kit.
•Griddle cleaning kit.
•Front leg extension covers and rear
caster covers.
•High altitude conversion kits.
Accessories are avai ab e through your authorized
Wo f dea er. For oca dea er information, visit the
find a showroom section of our website,
wo fapp iance.com.
Mode DF366 shown.
This appliance is certified by Star-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

357/8" (911)
367/8"
(937)
ISLAND
TRIM
457/8"
(1165)
10"
RISER
557/8"
(1419)
20"
RISER
407/8"
(1035)
5"
RISER
47" (1194)
261/8"(664)
25" (635)
241/8"(613)
271/2"(699)
91/4"
(235)
291/2" (749)
*367/8" (937) MIN TO 39" (991) MAX.
357/8"
(911)
367/8"
(937)
HEIGHT TO
COOKING
SURFACE*
INSTALLATION NOTES
•A riser is required for installations
against a combustible surface.
•A Wolf pro wall, chimney, island ventila-
tion hood or hood liner is recommended.
•High altitude conversion kit for LP gas
installations above 8,600'. For natural
gas above 10,250', contact Wolf
customer service.
Unit dimensions may vary by ± 1/8".
13" (330)
ELECTRICAL
36" (9 14 )
OPENING WIDTH
31/4" (83)
131/2"
(343)
10" (254)
GAS
30" (762) TO 36" (914)
TO BOTTOM OF
VENTILATION HOOD**
*Minimum clearance from rough opening to combustible materials up to 18" (457) above countertop.
**36" (914) minimum clearance, 44" (1118) for charbroiler, from countertop to combustible materials without ventilation hood.
NOTE: For island installations, 12" (305) minimum clearance from back of range to combustible rear wall above countertop.
6" (152) TO
COMBUSTIBLE*
6" (152) TO
COMBUSTIBLE*
18" (457) min
36" (914)
FLOOR TO
COUNTERTOP
367/8"
(937) TO
COOKING
SURFACE
13" (330)
max
21/4"
(57)
LOCATION OF GAS AND
ELECTRICAL EXTENDS
ON FLOOR
SIDE
CABINET
SPECIFICATIONS
Exterior Finish Stainless Steel
verall Width 357/8"
verall Height (to cooking surface) 367/8"
verall Depth 291/2"
ven Interior Capacity 5.4 cu ft
ven Interior
Dimensions 30" W x 161/2" H x 19" D
pening Width 36"
pening Height (to countertop) 36"
pening Depth 24"
Electrical Requirements 240/208 V AC
60 Hz, 30 amp circuit
Electrical Rating 5.2 kW at 240 V AC
4.5 kW at 208 V AC
Total Amps 21.7
Shipping Weight 445–470 lbs
INSTALLATION SPECIFICATIONS
OVERALL DIMENSIONS
36" Dual Fuel Ran es
Dimensions in parentheses are in
mi imeters un ess otherwise specified.
©Wo f App iance, Inc. a rights reserved. Features and specifications are subject to change at any time without notice. 8/13
