Wolf PI363418 User manual

Dimensions in parentheses are in
millimeters unless otherwise specified.
8/07
1
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
Model PI363418
Model PI363418R
Rail Option
AWolf Pro island hood— the final touch to complete
your stage featuring professional cooking equipment.
This premier ventilation system complements your
cooking appliance of choice, guaranteeing you’ll look
the part, no matter what new cooking challenges you
take on.
This 36" (914) wide island hood is 34" (864) deep and
available in the classic stainless steel finish. You also
have the option of decorative rails. While classic stain-
less steel rails are standard on the (R) model, platinum
or brass rails are also available to match the bezels of
our dual fuel ranges and sealed burner rangetops.
The Pro island hoods are recommended for use with
all Wolf cooking appliances.
Wolf Pro island hoods are available in
the classic stainless steel finish. Rail
option hoods (R) come with classic stain-
less steel decorative rails and stand-offs
for both sides of the hood. Optional
platinum or brass rails match dual fuel
range bezels. Pro island hoods are sold as
a shell only; internal, in-line and remote
blower options are available.
Model PI363418R shown with decorative rails.
Classic stainless
steel finish
Stainless steel
baffle filters
Location of
rating plate
Infinite-speed
blower control
Welded seams
and hemmed edges
Halogen lighting
Hand finished
craftsmanship
Recessed easy-
access controls
Decorative rails
(optional)

2
Dimensions in parentheses are in
millimeters unless otherwise specified.
Unit dimensions may vary by ±
1
/ 8 " (3).
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
FEATURES
36" (914) wide island ventilation hood with
classic stainless steel finish
Rail option island hoods (R) come with
classic stainless steel decorative rails and
stand-offs—optional platinum or brass rails
available to match dual fuel range bezels
Internal, in-line and remote blower options
Heavy-duty 16-gauge brushed stainless steel
construction
Stainless steel enclosed liner
Continually welded seams, hemmed edges
and sides and hand finished craftsmanship
Recessed easy-access controls
Infinite-speed blower control
Heat sentry feature automatically turns unit
on when heat is sensed and automatically
adjusts blower speed
Halogen lighting with two settings
Removable, dishwasher-safe, restaurant-
grade stainless steel baffle filters
Transition with backdraft damper included
UL listed to US and Canadian safety
standards
Two and five year residential warranty—
exclusions apply; warranty information can
be found on our website, wolfappliance.com
18" (457)
OVERALL
HEIGHT
36" (914)
OVERALL WIDTH
4"(102)
34" (864)
OVERALL DEPTH
13"
(330)
18"
(457)
36" (914)
OVERALL WIDTH
18"
(457)
18" (457)
OVERALL
HEIGHT
34" (864)
OVERALL DEPTH
13"
(330)
4"(102)
2"
(51)
3/4" (19)
DIAMETER
OF RAIL
2"
(51)
OVERALL DIMENSIONS
Model PI363418
Model PI363418R with Rail

3
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
SPECIFICATIONS
Overall Width of Hood 36" (914)
Overall Height of Hood 18" (457)
Overall Depth of Hood 34" (864)
(including rails) 38" (965)
Internal Blower Option 1200 CFM
In-Line Blower Option 1100 CFM
Remote Blower Options 900, 1200 or 1500 CFM
Discharge Vertical
Duct Size 10" (254) Round
Electrical Supply Requirements 110 / 120 V AC, 60 Hz
15 amp dedicated circuit
Shipping Weight (shell only) 95 lbs (43 kg)
Specifications are subject to change without notice.
BLOWER OPTIONS
1200 CFM Internal Blower 804703
as of Fall 2007 810317
1100 CFM In-Line Blower 808332
900 CFM Remote Blower 801641
1200 CFM Remote Blower 801642
1500 CFM Remote Blower 804701
Refer to Pro Ventilation Recommendations
at the end of this section.
ACCESSORIES
Platinum or brass decorative rails
and stand-offs for both sides of
the hood
6" (152), 12" (305), 18" (457) and
24" (610) classic stainless steel
duct covers
Accessories are available through your
Wolf dealer. To obtain local dealer
information, visit the Showroom Locator
section of our website, wolfappliance.com.

4
18" (457)
HEIGHT
OF HOOD
34" (864)
DEPTH OF HOOD
36" (914)
WIDTH OF HOOD
LOCATION OF ELECTRICAL SUPPLY
CENTERED THROUGH TOP OF HOOD
30" TO 36"
(762–914)
TO COUNTERTOP
30" TO 36"
(762–914)
TO COUNTERTOP
DIMENSIONS
Overall Width of Hood 36" (914)
Overall Height of Hood 18" (457)
Overall Depth of Hood (excluding rail) 34" (864)
Countertop to Bottom of Hood 30" (762) to 36" (914)
Location of Electrical Centered through top of hood
See Installation Instructions shipped with unit for detailed specifications.
INSTALLATION SPECIFICATIONS
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)

5
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions and installation specifics.
Wolf Pro island ventilation hoods are recom-
mended for use with any Wolf cooking appli-
ance. The hood must overlap the cooking
surface by a minimum of 3" (76) on either side.
Installation of all Pro ventilation hoods
should be 30" (762) to 36" (914) from the
bottom of the hood to the countertop. Follow
the dimensions shown in the Installation
illustration on page 4.
Wolf Pro island hoods are shipped without a
blower assembly. Internal, in-line or remote
blower assemblies are available. Blower options
also vary with the volume of air that needs to
be moved and the length of the duct run. Refer
to the charts at the end of this section for Pro
ventilation recommendations and blower
options.
IMPORTANT NOTE: Install this ventilation hood
only with a Wolf blower.
Pro island hoods require a separate,
grounded 110/120 V AC, 60 Hz power supply.
The service should have its own 15 amp circuit
breaker. Placement of the electrical supply is
not critical, as long as you provide enough 120
V AC, 60 Hz power cable to make the electrical
connection. Location of electrical is centered
through the top of the hood as shown in the
Installation illustration on page 4.
You must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
Refer to the installation instructions shipped
with each Wolf product for detailed specifica-
tions. This information can also be found on
our website, wolfappliance.com.

6
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
Ducting for Pro island
hoods.
ROOF CAP OR REMOTE BLOWER
18" (457)
HEIGHT OF HOOD
ISLAND HOOD
DUCTWORK INSTALLATION
THROUGH ROOF
34" (864)
DEPTH OF HOOD
10" ROUND DUCT
VERTICAL
DISCHARGE
VERTICAL DISCHARGE ONLY FOR ISLAND HOODS.
TRANSITION
141/8"W x 9"D TO 10" ROUND
7"H (INCLUDING FLANGES)
SOFFIT, CABINET OR
DUCT COVER
30" TO 36"
(762–914)
COUNTERTOP
TO BOTTOM OF
VENTILATION HOOD
36" (914)
STANDARD
FLOOR TO
COUNTERTOP
HEIGHT
DUCTING CONSIDERATIONS
Wolf Pro island hoods are shipped without the
blower assembly. Internal, in-line and remote
blower assemblies are available.
IMPORTANT NOTE: Install this ventilation hood
only with a Wolf blower.
Pro island hoods have a vertical discharge
location with 10" (254) round duct. A transition
with backdraft damper is included. The hood will
operate most efficiently when ductwork does
not exceed 50' (15 m) in length.
Local building codes may require the use of
make-up air. Consult your local HVAC profes-
sional for specific requirements in your area.
IMPORTANT NOTE: Wolf Pro island hoods
must be vented to the outside. Use only metal
ductwork.
Refer to the illustration below for ducting
considerations for Pro island hoods.

7
Dimensions in parentheses are in
millimeters unless otherwise specified.
Unit dimensions may vary by ±
1
/ 8 " (3).
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
WOLF BLOWER ASSEMBLIES
A ventilation system must include a blower
assembly. Wolf ventilation hoods are shipped
without the blower assembly. An internal, in-line
or remote blower assembly must be selected to
accommodate the cooking appliance, CFM
requirements and homeowner preferences.
Internal, in-line and remote blower assemblies
are available as sales accessories through your
Wolf dealer.
IMPORTANT NOTE: Use only a Wolf blower
with all Wolf ventilation products.
Internal blowers are mounted inside the hood
canopy. In-line blowers are mounted in between
the hood and the exterior of the home. Remote
blowers can be mounted on the roof or in some
cases, on an exterior wall. Refer to the illustra-
tions below for dimensions of Wolf in-line and
remote blowers.
Pro ventilation recommendation charts on the
following page provide minimum CFM recom-
mendations according to the cooking appliance
and ventilation hood used and blower options
for each specific Pro island hood.
241/2"
(622)
151/2"
(394)
281/4"
(718)
203/4"
(527)
243/4"
(629)
14"
(356)
43/4"
(121)
10" (254)
Diameter
143/4"
(375)
291/2"
(749)
291/2"
(749)
18" (457)
22"
(559)
101/8"
(257)
71/4"
(184)
10"
(254)
10" (254)
Diameter
143/4"
(375)
291/2"
(749)
291/2"
(749)
21" (533)
25"
(635)
103/8"
(264)
71/4"
(184)
10"
(254)
10" (254)
Diameter
Remote BLOWER-60REM and
BLOWER-90REM
Remote BLOWER-120REM Remote BLOWER-150REM
18"
(457)
22"
(559)
247/8"
(632)
12"
(305)
18"
(457)
8"
(203)
In-line BLOWER-110IL

8
Dimensions in parentheses are in
millimeters unless otherwise specified.
Planning Information
Pro Island Ventilation Hood
MODEL PI363418(R)
PRO VENTILATION CFM RECOMMENDATIONS
PRO VENTILATION BLOWER OPTIONS
Pro Island Hoods
Blower Description Blower Number Island Hood Models
1200 CFM Internal IBLOWER-120INT (804703 – 810317 as of Fall 2007) All Island Hoods
1100 CFM In-Line BLOWER-110IL (808332) All Island Hoods
900 CFM Remote BLOWER-90REM (801641) PI363418 / PI423418 / PI543418
1200 CFM Remote BLOWER-120REM (801642) All Island Hoods
1500 CFM Remote BLOWER-150REM (804701) All Island Hoods
Pro Island Hoods
Model PI363418 PI423418 PI543418 PI663418
DF304 / R304 / SRT304 600 600
DF366 / R366 / SRT366 / RT366 900
DF364 / R364 / SRT364 / RT364 900
RT362 900
R488 / RT488 1100
DF486 / R486 / SRT486 / RT486 1100
DF484 / R484 / SRT484 / RT484 900
DF606 / R606 1500
DF604 1500
Minimum CFM requirements for Wolf ranges and rangetops. CFM recommendations are based on total Btu/hr output.
Additional CFM may be required for charbroilers, griddles and long duct runs.
