Wonderfire airflame excel mk.3 ac 18xl Instructions for use

5134830/03
AIRFLAME
© Baxi Heating U.K. Limited 2009.
MODEL PRODUCT CODE
AF 16 NV 9500298 (coal)
0505411 (log)
AC 16 NV
9500296 (coal)
0505511 (log)
0503611 (pebble)
AF 18 XL 9500360 (coal)
AC 18 XL 9500361 (coal)
MODEL PRODUCT CODE
AF 16 NV RC 0505601 (coal)
0505611 (log)
AC 16 NV RC 0505701 (coal)
0505711 (log)
AF 18 XL RC 0505301 (coal)
AC 18 XL RC 0505901 (coal)
MODEL PRODUCT CODE
AC 16 NV TC 05036T1 (coal)
0505811 (log)
MODEL PRODUCT CODE
AF 16 NV 5” Leg 9505298 (coal)
We trust that this guide gives
sufficient details to enable this
appliance to be installed, operated
and maintained satisfactorily.
However, if further information is
required, our
Wonderfire Premier Technical
Helpline will be pleased to help.
Telephone [phone]. (National
call rates apply in the United
Kingdom).
In the Republic of Ireland
Telephone [phone].
INSTALLER: Please leave this guide with the owner
INSTALLER AND OWNER GUIDE

© Baxi Heating U.K. Limited 2009.
All rights reserved. No part of this publication may be reproduced in any material form
(including photocopying), stored in any medium by electronic means (including in any
retrieval system or database) or transmitted, in any form or by any means, whether
electronic, mechanical, recording or otherwise, without the prior written permission of
the copyright owner.
Applications for the copyright owner's permission to reproduce any part of this
publication should be made, giving details of the proposed use, to the following
address: The Company Secretary, Baxi Heating UK Limited, The Wyvern Business
Park, Stanier Way, Derby, DE21 6BF.
Warning: Any person who does any unauthorised act in relation to a copyright work
may be liable to criminal prosecution and civil claims for damages.
Wonderfire Premier, Wood Lane, Erdington, Birmingham B24 9QP
www.wonderfire.co.uk
Because our policy is one of constant development and improvement, details may vary slightly from
those given in this publication
Page 2
© Baxi Heating U.K. Limited 2009.
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20).
WHEN CONVERTED USING CONVERSION KITS AS SHOWN IN SECTION 2 OF
THE INSTALLER GUIDE THE SPECIFIED APPLIANCES ARE FOR USE WITH
PROPANE GAS (G31).
THIS APPLIANCE IS SUITABLE ONLY FOR INSTALLATION IN THE UNITED
KINGDOM (GB) AND THE REPUBLIC OF IRELAND (IE).
INSTALLER GUIDE

Safety First.
Wonderfire Premier fires are CE Approved and designed to meet the appropriate
British Standards and Safety Marks.
Quality and Excellence.
Wonderfire Premier fires are manufactured to the highest standards of quality and
excellence and are manufactured under a BS EN ISO 9001 quality system accepted
by the British Standards Institute.
The Highest Standards
Wonderfire Premier is a member of SBGI and HHIC (Heating and Hot water Industry
Council) which works to ensure high standards of safety, quality and performance.
Careful Installation
This gas fires must be installed by a competent GAS SAFE REGISTER engineer
(GAS SAFE REGISTER or CORGI engineer outside of UK) in accordance with our
installer guide and should not be fitted directly on to a carpet or floor of combustible
material.
Page 3
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

Page 4
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
FOR OWNER GUIDE SEE PAGES 40 TO 59
INSTALLER GUIDE

CONTENTS
Section Page
INSTALLER GUIDE 4 - 39
OWNER GUIDE 40 - 59
1. SAFETY 7
2. LPG CONVERSION 8
3. APPLIANCE DATA AND EFFICIENCY 9
3.1 General information. 9
3.2 Efficiency. 10
4. GENERAL INSTALLATION REQUIREMENTS 11
4.1 Regulations, Standards and Law. 11
4.2 Ventilation requirements. 12
4.3 The Atmosphere sensing device (ASD). 12
4.4 Fireguard requirements. 13
4.5 Room considerations. 13
4.6 Chimney preparation. 13
4.7 Fireplace preparation. 13
4.8 Fireplace clearances. 14
4.9 The hearth. 14
4.10 Installation options. 16
4.10.1. ‘Hole-in-the-wall’ / elevated installations 16
4.11 Flues. 17
4.12 Propane appliances. 17
5. UNPACKING THE APPLIANCE 18
6. SIZES AND INSTALLATION OF STANDARD
/ LARGE CONVECTION BOXES 19
6.1 General convection box information. 19
6.2 Additional flue information for NV models fitted to convection boxes. 19
6.3 Convection box sizes. 19
6.4 Fireplace requirements. 21
6.4.1 Fireplace opening and hearth dimensions. 21
6.4.2 Fireplace size. 21
6.4.3 Fireplace general condition. 22
6.4.4 Soundness for appliance attachment. 22
6.4.5 Fireplace flue pull. 22
6.5 Gas supply connection. 23
6.6 Preparing for installation. 23
6.7 Convection box installation. 24
6.8 Sealing floor front - all installations. 26
Page 5
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
Continued on next page

7. BURNER AND SUPPLY PIPE INSTALLATION 26
8. FITTING THE CERAMIC FUEL EFFECT 27
9. FULL OPERATIONAL CHECKS 27
9.1 General information. 27
9.2 Checking the operation of the MANUAL CONTROL burner. 27
9.2.1 To light the pilot. 27
9.2.2 Lighting the main burner. 27
9.2.3 Controlling the heat setting. 28
9.2.4 To turn the fire back to pilot setting. 28
9.3 Checking the operation of the REMOTE CONTROL (RC) burner. 28
9.3.1 Fitting batteries to the remote control handset. 28
9.3.2 Fitting batteries to the receiver box. 28
9.3.3 Setting the handset and receiver relationship. 28
9.3.4 Lighting the fire. 29
9.3.5 Adjusting flame height. 29
9.3.6 Adjusting to pilot only setting. 29
9.3.7 Turning off. 29
9.4 Checking the operation of the TOP CONTROL (TC) burner. 30
9.4.1 Preliminaries. 30
9.4.2 Lighting the pilot. 30
9.4.3 Checking the heat settings. 31
9.4.4 To turn the fire back to pilot setting. 31
9.4.5 To turn the fire off. 31
9.4.6 Using the Top Control. 31
9.5 Inlet pressure check. 31
9.6. Aeration setting for fires fitted with aeration control. 32
10. SPILLAGE AND FLAME SUPERVISION CHECKS 32
10.1 Spillage check. 32
10.2 Flame supervision & spillage monitoring system. 34
11. DECORATIVE FIREFRONTS 35
12. FINAL REVIEW 36
13. SERVICING & PARTS REPLACEMENT 37
13.1 Annual maintenance. 37
13.2 To remove the injector. 38
13.3 To remove the thermocouple & pilot unit. 38
13.4 To remove the gas valve unit. 38
13.5 To remove the convection box from the
fireplace (For models fitted into a convection box). 39
Page 6
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
CONTENTS (Continued)
Section Heading Page

1. SAFETY
This product uses fuel effect pieces and burner (AC models also include a
burner compartment rear wall) containing Refractory Ceramic Fibres (RCF),
which are man-made vitreous silicate fibres. Excessive exposure to these
materials may cause irritation to eyes, skin and respiratory tract. Consequently,
it is important to take care when handling these articles to ensure that the
release of dust is kept to a minimum. To ensure that the release of fibres from
these RCF articles is kept to a minimum, during installation and servicing we
recommend that you use a HEPA filtered vacuum to remove any dust and soot
accumulated in and around the fire before and after working on the fire. When
replacing these articles we recommend that the replaced items are not broken
up, but are sealed within a heavy duty polythene bag, clearly labelled as RCF
waste. RCF waste is classed as a stable, non-reactive hazardous waste and
may be disposed at a landfill licensed to accept such waste. Protective clothing
is not required when handling these articles, but we recommend you follow the
normal hygiene rules of not smoking, eating or drinking in the work area and
always wash your hands before eating or drinking. This appliance does not
contain any component manufactured from asbestos or asbestos related
products.
Installer: Before continuing any further with the installation of this appliance please
read the following guide to manual handling.
The approximate lifting weight of this appliance is as below:
Model Heat Engine (kg) Convection box (kg)
AF 16 NV 1.8 Not supplied
AC 16 NV 1.8 9.45
AF 18 XL 2.0 Not supplied
AC 18 XL 2.0 18.7
AF 16 NV RC 3.4 Not supplied
AC 16 NV RC 3.4 9.45
AF 18 XL RC 2.0 Not supplied
AC 18 XL RC 2.0 18.7
AF 16 NV 5” Leg 2.0 Not supplied
AC 16 NV TC 3.0 11.33
One person should be sufficient to lift the fire. If for any reason this weight is
considered too heavy then obtain assistance.
When lifting always keep your back straight. Bend your legs and not your back.
Avoid twisting at the waist. It is better to reposition your feet.
Avoid upper body/top heavy bending. Do not lean forward or sideways whilst
handling the fire.
Page 7
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

Always grip with the palm of the hand. Do not use the tips of fingers for support.
Always keep the fire as close to the body as possible. This will minimise the
cantilever action.
Use gloves to provide additional grip.
Always use assistance if required.
2. LPG CONVERSION
The following conversion kits are available to convert from natural gas (G20) to
propane gas (G31).
* Important: The AC16NV Model supplied / fitted with a ceramic PEBBLE fuel
effect shall not be converted to LPG.
Page 8
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
MODEL CONVERSION KIT PART NUMBER
AF16NVP / AC16NVP* / AC16NVPTC 9500365
AF16NVP RC / AC16NVP RC 9500376
AF18XLP / AC18XLP 9500362
AF18XLP RC / AC18XLP RC 9500377

3. APPLIANCE DATA AND EFFICIENCY
3.1 General information.
Page 9
© Baxi Heating U.K. Limited 2009.
MODEL
GROSS HEAT
INPUT (kW) INLET PRESSURE
(TO BE TAKEN ON MAX. SETTING
WITH THE FIRE COLD).
INJECTOR
SIZE
MIN.MAX.
AF16NV (Coal or Log)
AC16NV (Coal or Log)
AC16NV TC (Coal or Log)
AF16NV 5” LEG (Coal)
4.8 6.95 20.0mbar ± 1.0mbar
(8.0 ± 0.4in w.g.) 82 - 442
AF16NV RC (Coal or Log)
AC16NV RC (Coal or Log) 3.2 6.95 20.0mbar ± 1.0mbar (8.0 ± 0.4in w.g.) 82 - 442
AC16NV (Pebble) 4.8 6.3 20.0mbar ± 1.0mbar
(8.0 ± 0.4in w.g.) 82 - 069
AF16NVP AC16NVP 5.8 6.2 37.0 ± 1.0 mbar
(14.85 ± 0.4in w.g.) 92 - 200
AF16NVP RC
AC16NVP RC 4.3 6.2 37.0 ± 1.0 mbar (14.85 ± 0.4in w.g.) 92 - 200
AF18XL AC18XL 5.8 10.5 20.0mbar ± 1.0mbar
(8.0 ± 0.4in w.g.) 82 - 722
AF18XL RC AC18XL RC 5.8 10.5 20.0mbar ± 1.0mbar
(8.0 ± 0.4in w.g.) 82 - 722
AF18XLP AC18XLP 7.6 9.0 37.0 ± 1.0 mbar
(14.85 ± 0.4in w.g.) 92 - 260
AF18XLP RC AC18XLP RC 7.6 9.0 37.0 ± 1.0 mbar
(14.85 ± 0.4in w.g.) 92 - 260
INSTALLER GUIDE

3.2 Efficiency.
The efficiency of this appliance has been measured as specified in BS 7977 - 1 and
the result is as below:
Model Efficiency %(Gross) Model Efficiency %(Gross)
AC 16 NV RC 53 AC 16 NV 53
AC 18 XL RC 55 AC 18 XL 55
AC 16 NV TC 53
AF models are not included above as they have a default value included in the SAP
calculation.
The gross calorific value of the fuel has been used for this efficiency calculation. The
test data from which it has been calculated has been certified by Advantica
Certification services (0087). The efficiency value may be used in the UK
Government's Standard Assessment Procedure (SAP) for energy rating of dwellings.
The conversion of net efficiency to gross was achieved by multiplying the net
efficiency by the following conversion factor from Table E3 of SAP 2005, rounding
down to the nearest whole number.
Page 10
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
MODEL
BURNER TRAY DIMENSIONS
WIDTH DEPTH
HEIGHT
(INCLUDING
FUEL
EFFECT)
AF16NV AC16NV
AF16NV RC AC16NV RC AF16NV TC 380mm (15”)
at front tapering
to 280mm (11”) at
the rear
225mm
(9”) 305mm (12”)
AF16NVP AC16NVP
AF16NVP RC AC16NVP RC
AF16NV 5” LEG As Above As
Above
345mm
(13½”)
AF18XL AC18XL
AF18XL RC AC18XL RC 430mm (17”) at
the front tapering
to 300mm (11¾”)
at the rear
225mm
(9”) 305mm (12”)
AF18XLP AC18XLP
AF18XLP RC AC18XLP RC
Gas Conversion factor from net to gross efficiency
Natural Gas 0.901
LPG 0.921

4. GENERAL INSTALLATION REQUIREMENTS
4.1 Regulations, Standards and Law.
The installation must be in accordance with these instructions.
For the user’s protection, in the United Kingdom it is the law that all gas appliances
are installed by competent persons in accordance with the current edition of the Gas
Safety (Installation and Use) Regulations. Failure to install the appliance correctly
could lead to prosecution. GAS SAFE REGISTER and CORGI require their members
to work to recognised standards.
In the United Kingdom the installation must also be in accordance with:
All the relevant parts of local regulations.
All relevant codes of practice.
The relevant parts of the current editions of the following British Standards:-
BS 1251 - Fireplace components.
BS EN 1856 Part 1 - Chimneys - Requirements for metal chimneys.
BS 5440 Part 1 - Installation of flues.
BS 5440 Part 2 - Installation and maintenance of flues and ventilation for gas
appliances of rated input not exceeding 70 kW net (1st, 2nd
and 3rd family gases).
BS 5871 Part 2 - Installation - Inset LFE gas fires.
BS 5871 Part 3 - Installation – DFE gas fires.
BS 6461 Part 1 - Masonry chimney & flues - Installation.
BS 6891 - Installation of low pressure gas pipework of up to 35mm
(R1 ¼) in domestic premises (2nd family gas) - specification.
BS 8303 Part 1- Solid fuel appliances – Design of installations.
BS 8303 Part 2- Solid fuel appliances – Installing & commissioning on site.
BS 8303 Part 3- Solid fuel appliances – Design & on-site installation
recommendations.
In England and Wales, the current edition of the Building Regulations issued by the
Department of the Environment and the Welsh Office.
In Scotland, the current edition of the Building Standards (Scotland) Regulations
issued by the Scottish Executive.
In Northern Ireland, the current edition of the Building regulations (Northern
Ireland) issued by the Department of the Environment for Northern Ireland.
In the republic of Ireland the installation must be carried out by a competent person
and also conform to the relevant current editions of:
a) The current edition of IS 813 “Domestic Gas Installations”.
b) ICP3
c) IS327
d) All relevant national and local rules in force.
Where no specific instructions are given, reference should be made to the relevant
British Standard Code of Practice.
Page 11
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

Improper installation of this gas fire could be hazardous to health. This gas fire is to
be used only in a properly flued, incombustible, masonry fireplace with the chimney or
flue free from obstruction.
4.2 Ventilation requirements.
IE only: This appliance must be installed in accordance with the current edition of
IS 813 “Domestic Gas Installations” which makes clear the conditions that must be
met to demonstrate that sufficient ventilation is available.
GB only: See the table below for purpose made ventilation requirements. In GB
reference should be made to BS 5871 Part 2.
* When converted to propane using the kits from section 2 of this guide.
**AF16NV / AF16NVP - see below.
GB only: Normal adventitious ventilation is usually sufficient to satisfy the ventilation
requirements of this appliance, however on larger fireplace openings with a height
greater than 24” and a width greater than 18” we do recommend that a purpose made
ventilation grille with a minimum opening size of 100cm² is fitted. In all cases a
clearance of products (spillage test) must be carried out.
IE only: This appliance must be installed in accordance with the current edition of
IS 813 “Domestic Gas Installations” which makes clear the conditions that must be
met to demonstrate that sufficient ventilation is available. In all cases a clearance of
products (spillage test) must be carried out.
4.3 The Atmosphere sensing device (ASD).
The appliance is fitted with an A.S.D (Atmosphere sensing device). If the appliance
closes down after a period of operation for no apparent reason, the consumer should
be informed to stop using the appliance until the installation and appliance have been
thoroughly checked. The A.S.D will shut the appliance down if an unacceptable
amount of harmful products of combustion accumulate. Under no circumstances
Page 12
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
MODEL HEAT INPUT
( kw GROSS)
PURPOSE MADE
VENTILATION SIZE (cm²)
AF16NV / AF16NV RC /
AF16NV 5” LEG 6.95 (Coal or Log) NONE**
AC16NV / AC16NV RC
AC16NV TC
6.95 (Coal or Log) /
6.3 (Pebble on
AC16NV only)
NONE**
AF18XL / AF18XL RC 10.5 100
AC18XL / AC18XL RC 10.5 15.75
AF16NVP* / AF16NVP RC* 6.2 NONE**
AC16NVP* / AC16NVP RC* 6.2 NONE**
AF18XLP* / AF18XLP RC* 10.5 100
AC18XLP* / AC18XLP RC* 9.0 11.25

should the A.S.D be altered or bypassed in any way. Only a genuine manufacturer’s
replacement part should be fitted. The individual A.S.D components are not
replaceable.
4.4 Fireguard requirements.
A fireguard complying with BS 8423 should be fitted for the protection of young
children, the elderly, the infirm or pet animals.
4.5 Room considerations.
4.5.1 This appliance must not be installed in any room that contains a bath or shower
or where steam is regularly present.
4.5.2 An extractor fan may only be used in the same room as this appliance, or in
any area from which ventilation for the appliance is taken, if it does not affect the safe
performance of the appliance. Note the spillage test requirements detailed further on
in this manual. If the fan is likely to affect the appliance, the appliance must not be
installed unless the fan is permanently disconnected.
4.5.3 Note that soft wall coverings (e.g. embossed vinyl, etc.) are easily affected by
heat. They may scorch or become discoloured when close to a heating appliance.
Please bear this in mind when installing.
4.6 Chimney preparation.
4.6.1 If the appliance is intended to be installed to a chimney that was previously
used for solid fuel, the flue must be swept clean prior to installation. All flues should
be inspected for soundness and freedom from blockages.
4.6.2 Any chimney damper or restrictor should be removed. If removal is not possible,
they must be secured in the open position.
If the appliance is intended to be installed to a chimney that was previously used for
solid fuel, the flue must be swept clean prior to installation.
All flues should be inspected for soundness and freedom from blockages.
4.7 Fireplace preparation.
4.7.1 If the fireplace opening is an underfloor draught type, it must be sealed to stop
any draughts.
4.7.2 The fireplace floor should be reasonably flat.
4.7.3 On models with a convector box the front face of the fireplace should be
reasonably flat over the area covered by the convector box top and side flange seals
to ensure good sealing. These faces should be made good if necessary.
4.7.4 If the fireplace opening is greater than the opening in the intended surround
back, do not use the back of a fire surround or marble to reduce the opening. This
may cause cracking of the surround back or marble.
Page 13
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

4.7.5 The appliance must not stand on combustible materials or carpets.
4.8 Fireplace clearances.
The minimum height from the base of the fireplace opening to the underside of any
shelf made from wood or other combustible materials is as follows: -
•For a shelf up to 150mm deep
Minimum height = 818mm.
•For a shelf deeper than 150mm
818mm + 12.5mm for every 25mm depth over 150mm
(See Figure 1).
4.9 The hearth.
The appliance must be mounted behind a non-combustible hearth unless the
conditions of section 4.10.1 are met (N.B. conglomerate marble hearths are
considered as non-combustible). The appliance can be fitted to a minimum class “O”
– 150°C surround. The hearth material must be at least 12mm thick. The periphery of
the hearth (or fender) should be at least 50mm above floor level to discourage the
placing of carpets or rugs over it (See figure 2). On none elevated installations the
surface of the hearth must be sufficiently flat to enable the bottom of the fascia and
the bottom front cover to be aligned horizontally. Any excessive unevenness (uneven
tiles, Cotswold stone, etc.) should be rectified. The base of the fireplace opening must
be level with the top surface of the hearth. There should be no gaps between the
hearth and the fireplace opening.
Page 14
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
Figure 1. Combustible shelf clearances

Page 15
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
Figure 2. Hearth sizes.

4.10 Installation options.
In the United Kingdom, as supplied, the appliance can be installed in to a
fireplace complete with a hearth complying with BS1251. The required hearth and
clearance dimensions are shown in figure 2. (Remove any existing heating appliance
- when using a convection box it may be necessary to remove the firebrick back).
When installing using a convection box see section 6.
4.10.1. ‘Hole-in-the-wall’ / elevated installations -
It is recommended that a hearth should be installed as in section 4.9.
For models fitted with the Essence fascia - The fascia has been specifically
designed for ‘hole in the wall’ installations. It is recommended that a hearth should
be installed as in figure 2. If a hearth is not fitted, the fire must be installed so that
the distance from the base of the fireplace opening in the wall to the finished floor
level is at least 115mm (This will give a distance under the fascia of 56mm to the
finished floor level). Where there is no floor covering or carpet and the floor is of a
type that is likely to be covered in such a way then the distance from the base of
the fireplace opening in the wall to the finished floor level should be increased to at
least 190mm.
For models NOT fitted with 5” legs (excluding the Essence model) - If a
reduced depth hearth is fitted, the fire must be installed so that the distance from
the base of the fireplace opening in the wall to the finished floor level is 115mm
minimum. Where there is no floor covering or carpet and the floor is of a type that is
likely to be covered in such a way in the future then the distance from the base of
the fireplace opening in the wall to the floor level should be increased to at least
190mm.
It is recommended that the reduced hearth has a depth from the fixing plane of
the fire of 100mm minimum. This is necessary to support the lower front casting /
firefront.
For models fitted with 5” legs - If a reduced depth hearth is fitted, the fire must be
installed so that the distance from the base of the fireplace opening in the wall to
the finished floor level is 75mm minimum. Where there is no floor covering or carpet
and the floor is of a type that is likely to be covered in such a way in the future then
the distance from the base of the fireplace opening in the wall to the floor level
should be increased to at least 150mm.
It is recommended that the reduced hearth has a depth from the fixing plane of
the fire of 100mm minimum. This is necessary to support the lower front casting /
firefront.
All models
To protect from the risk of burns and ignition of clothing a tactile separator shall
be used. The hearth detailed in section 4.9 meets the requirements for a tactile
Page 16
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

separator.
For 16” fires - If this is not used then a 700mm long fender, kerb, horizontal bar, or
other barrier, being fixed not less than 50mm above floor level and positioned
300mm in front of the fixing plane of the fire will meet the requirement.
For 18” fires - If this is not used then a 760mm long fender, kerb, horizontal bar, or
other barrier, being fixed not less than 50mm above floor level and positioned
300mm in front of the fixing plane of the fire will meet the requirement.
4.11 Flues.
1. Suitable flues and minimum flue sizes are as follows: -
a) 225mm x 225mm conventional brick flue.
b) 175mm diameter lined brick or stone flue.
c) 200mm diameter factory made insulated flue manufactured to BS EN 1856 Part 1.
d) 175mm diameter flue pipe. See BS6461 Part 1 for suitable materials.
2. Additional flue information for NV models fitted to convection boxes.
In addition to the flues specified above NV MODELS can be used on the following
flue:
A correctly installed metal flue with a minimum diameter of 125mm (5”) is acceptable
for NV models only, providing both inner and outer convection box restrictor plates
are removed (See section 6.6 - point 3).
Larger fireplace openings may require a correspondingly larger chimney diameter, a
faulty flue or chimney may result in products of combustion spilling into the room with
consequent possible damage to furniture and decor. Conduct a smoke test before
proceeding with installation. Refer to the section 6.4.5 “Fireplace flue pull”.
The minimum effective height of the flue must be 3m.
The flue must not be used for any other appliance or application.
4.12 Propane appliances.
Propane gas appliances must not be installed in a room that is built entirely below
ground level (See BS 5871 Part 3).
Important: The AC16NV Model supplied / fitted with a ceramic PEBBLE fuel
effect shall not be converted to LPG.
Page 17
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

5. UNPACKING THE APPLIANCE
Carefully remove the contents. Check that all the listed parts are present and in good
condition.
Contents:
1 Burner assembly.
1 Ceramic fuel effect.
1 Guarantee card.
1 Smoke match tube.
AF MODELS ONLY
1 Loose parts pack (1 x fixing screw and fibre wall plug).
AC MODELS ONLY
1 Loose parts pack (2 tension wires, 2 cable retainer assemblies and foam seal).
1 Convection box.
REMOTE CONTROL (RC) MODELS ONLY
1 Remote control handset.
1 PP3 battery.
4 AA batteries.
Page 18
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
(TC) MODELS ONLY
4 AA batteries.
1 Convection box.

6. SIZES AND INSTALLATION OF STANDARD /
LARGE CONVECTION BOXES.
6.1 General convection box information.
The Standard Wonderfire Premier Convection box is designed to fit into fireplace
openings between 16" and 18" and constructed in accordance with the requirements
of BS1251. Any chairbrick / fireback will require removal.
The large Wonderfire Premier Convection box is designed to fit into fireplace
openings between 19" and 22" and constructed in accordance with the requirements
of BS1251. Any chairbrick / fireback will require removal.
There are three grommets supplied with the convection box. The large grommet is to
be fitted to the rear hole in the convection box. The two smaller grommets are to be
fitted into the holes in the sides of the convection box. The grommets must be fitted
before continuing with the installation. On (TC) models the grommet on the right hand
side will have to be cut to accommodate the wiring harness.
The installation of any fire other than the listed Wonderfire Premier products will
invalidate the approval status and guarantee.
This fireplace insert / Convection box is unsuitable for use with solid fuel.
Note: This appliance is fitted with a restrictor plate. If, after conducting a spillage test
(See section 10.1) smoke is not positively drawn into the chimney, this plate must be
removed and the spillage test repeated. Also, see section 6.2 below.
If there is a possibility of birds nesting in the area an approved cowl suitable for solid
fuel should be fitted.
6.2 Additional flue information for NV models fitted to convection boxes.
In addition to the flues specified in section 4.11 NV MODELS can be used on the
following flue:
A correctly installed metal flue with a minimum diameter of 125mm (5”) is acceptable
for NV models only, providing both inner and outer convection box restrictor plates
are removed (See section 6.6 - point 3).
6.3 Convection box sizes.
The convection box sizes are shown in figure 3.
Page 19
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE

Page 20
© Baxi Heating U.K. Limited 2009.
INSTALLER GUIDE
Figure 3. Convection box dimensions (The convection box may differ in design
from that shown)
KEY STANDARD LARGE
A 530mm 590mm
B 605mm 605mm
C 410mm 470mm
D 545mm 545mm
E 405mm 475mm
F 350mm 415mm
G 255mm 225mm
H 550mm 550mm
J 395mm 395mm
K 295mm 295mm
L 10mm 10mm
L (TC) models 35mm N/A
