woodmizer EG800EH40S User manual

Wood-Mizer®
Edger
Safety, Operation,
Maintenance and Replacement Parts
EG800EH40S rev. A2.00
Safety is our #1 concern! Read and understand
all safety information and instructions before
operating, setting up and/or maintaining this
machine.
Form #810
!
This is the original language
for the manual.

4 SW-07doc031120Table of Contents
Table of Contents Section-Page
SECTION 1 SERVICING THE EDGER 1-1
1.1 Safety & General Information ................................................................1-1
1.2 If You Need To Order Parts ...................................................................1-1
1.3 Customer and Edger Identification.........................................................1-1
1.4 If You Need Service ...............................................................................1-2
1.5 EG800 Edger Components.....................................................................1-3
SECTION 2 SAFETY 2-1
2.1 Safety Symbols.......................................................................................2-1
2.2 Safety Instructions..................................................................................2-1
SECTION 3 3-1
3.1 Operation ................................................................................................3-2
3.2 Pre-Operation Check ..............................................................................3-2
3.3 Control Overview ...................................................................................3-5
3.4 Edger Setup ............................................................................................3-6
3.5 Machine start ..........................................................................................3-8
3.6 Board entry cover installation ..............................................................3-10
SECTION 4 MAINTENANCE AND ALIGNMENT 4-1
4.1. Rollers and Blades Cover .......................................................................4-1
4.2 Replacing and Aligning the Blades .......................................................4-2
4.3 Tensioning the Chains and Belts ............................................................4-4
4.4 Adjusting Height of the Hold-Down Rollers..........................................4-9
4.5 Lubrication and cleaning ......................................................................4-12
4.6 Maintaining the Anti-Kickback Fingers...............................................4-13
4.7 Blade Sharpening..................................................................................4-14
4.8 Using the Blades...................................................................................4-14
4.9 Safety Devices Inspection (Only CE Version).....................................4-15
SECTION 5 SPECIFICATIONS 5-1
5.1 Overall Dimensions ................................................................................5-1
5.2 EG800 Edger Specifications...................................................................5-2
5.3 Sawdust Extractor Specifications...........................................................5-3
SECTION 6 LASER INFORMATION 6-1
