woodmizer SBEG10 Guide

Single Blade Edger
Safety, Operation, Maintenance & Parts Manual
EG50G10 rev. A2.02
Safety is our #1 concern! Read and understand all safety
information and instructions before operating, setting up or
maintaining this machine.
Form #1621

Table of Contents Section-Page
ii SBEdoc072519 Table of Contents
SECTION 1 INTRODUCTION 1-1
1.1 About This Manual.................................................................................................... 1-1
1.2 Getting Service .......................................................................................................... 1-2
1.3 Specifications ............................................................................................................ 1-4
1.4 Customer and Equipment Identification.................................................................... 1-5
SECTION 2 SAFETY 2-1
2.1 Safety Symbols.......................................................................................................... 2-1
2.2 Safety Instructions..................................................................................................... 2-2
SECTION 3 SETUP & OPERATION 3-1
3.1 Setup .......................................................................................................................... 3-1
3.2 Alignment .................................................................................................................. 3-5
3.3 Operation ...................................................................................................................3-8
3.4 Transporting The Edger........................................................................................... 3-10
SECTION 4 MAINTENANCE 4-1
4.1 Drive System ............................................................................................................. 4-1
4.2 Feed Table Rollers..................................................................................................... 4-2
4.3 Blade System............................................................................................................. 4-3
SECTION 5 REPLACEMENT PARTS 5-1
5.1 Edger.......................................................................................................................... 5-1
5.2 Frame Assembly........................................................................................................ 5-2
5.3 Guide Fence Assembly.............................................................................................. 5-4
5.4 Rear Leg Assembly ................................................................................................... 5-6
5.5 Blade Assembly......................................................................................................... 5-7
5.6 Blade Cover Assembly .............................................................................................. 5-9
5.7 Engine Assembly..................................................................................................... 5-10
INDEX I

Introduction
About This Manual
Introduction SBEdoc072519 1-1
1
SECTION 1 INTRODUCTION
1.1 About This Manual
This manual is to replace or to be used with all previous information received on the
Wood-Mizer® * Single Blade Edger. All future mailings will be an addition to or a revision of
individual sections of this manual as we obtain new information.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
Important components of the edger are identified below.
*Wood-Mizer® is a registered trademark of Wood-Mizer Products, Inc.
Top Blade Guard
Engine
Assembly
Front
Fence
Rear
Fence
Clutch Lever
Rear Leg
Lock Bracket
U-Brackets &
Lock Pins
SB0001

Introduction
Getting Service
1
1-2 SBEdoc072519 Introduction
1.2 Getting Service
Wood-Mizer is committed to providing you with the latest technology, best quality and
strongest customer service available on the market today. We continually evaluate our
customers’ needs to ensure we’re meeting current wood-processing demands. Your com-
ments and suggestions are welcome.
General Contact Information
Toll free phone numbers are listed below for the continental U.S. and Canada. See the
next page for contact information for specific Wood-Mizer locations.
Office Hours: All times are Eastern Standard Time.
Please have your vehicle identification number and your customer number ready when
you call.
Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Discover
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If your sawmill was purchased outside the United States or Canada, contact the distribu-
tor for service.
United States Canada
Sales 1-800-553-0182 1-877-866-0667
Service 1-800-525-8100 1-877-866-0667
Website www.woodmizer.com www.woodmizer.ca
E-mail [e-mail] [e-mail]
Monday - Friday Saturday
(Indianapolis Office Only)
Sunday
8 a.m. to 5 p.m. 8 a.m. to 12 p.m. Closed

Introduction
Wood-Mizer Locations
Introduction SBEdoc072519 1-3
1
Wood-Mizer Locations
USA World Headquarters Canadian Headquarters
Serving North & South America, Oceania, East Asia
Wood-Mizer LLC
8180 West 10th Street
Indianapolis, IN 46214
Phone: [phone] or 800.553.0182
Customer Service: 800.525.8100
Fax: [phone]
Email: [e-mail]
Serving Canada
Wood-Mizer Canada
396 County Road 36, Unit B
Lindsay, ON K9V 4R3
Phone: [phone] or 877.357.3373
Fax: [phone]
Email: [e-mail]
Brazil Headquarters Europe Headquarters
Serving Brazil
Wood-Mizer do Brasil
Rua Dom Pedro 1, No: 205 Bairro: Sao Jose
Ivoti/RS CEP:93.900-000
Tel: [phone]/ +55 51
3563-4784
Email: [e-mail]
Serving Europe, Africa, West Asia
Wood-Mizer Industries Sp z o.o.
Nagorna 114
62-600 Kolo, Poland
Phone: [phone]
Fax: [phone]
Branches & Authorized Sales Centers
For a complete list of dealers, visit www.woodmizer.com

Introduction
Specifications
1
1-4 SBEdoc072519 Introduction
1.3 Specifications
Model: SBEG10/EG50G10 Rev. A1.01+
Dimensions
Length: 96"
Width: 35 3/4"
Height: 40"
Table Height: 32 5/8"
Weight: 373 lbs (480 lbs w/shipping crate)
Capacity:
Min. Output Width (Fence to Blade): 2"
Max. Output Width (Fence to Blade): 12"
Min. Material Thickness: 1/4"
Max. Material Thickness: 2 1/4"
Misc Specifications
Blade Diameter: 10"
Blade Bore:5/8"
Blade Kerf (24 Tooth):."
Engine/Motor:
Fuel/Energy: Gas
Make: Briggs
HP Rating: 10.4
Weight: 52.8 lbs
RPM-Idle: 1750 RPM
RPM-High (No load): 3750 RPM
Noise Level (Operator; not cutting/cutting; dBA):
Noise Level (Puller; not cutting/cutting; dBA):
Blade Speed (No load) RPM: 3750
Fuel Consumption (Gallon/Clock Hr.):
Cooling: Air
Engine Drive Shaft O.D. (inches): 1"
Engine Drive Pulley: 3.65"
Main Driven Pulley: 3.65"
Drive Belt: 2/3VX600
Oil Capacity w/Filter (qts.): .875 qts. (.8 liters)
SB0001-1

Introduction
Customer and Equipment Identification
Introduction SBEdoc072519 1-5
1
1.4 Customer and Equipment Identification
An identification plate is located on unit. The plate contains the model and revision infor-
mation for your unit. You will also receive a customer number when you purchase your
unit.
These numbers will help expedite our service to you. Please locate them now and write
them below so you have quick, easy access to them.
Identification Information (To be filled in by purchaser)
Model No.
Revision No.
Customer No.
IDENTIFICATION PLATE
SB0002
Model No.:
Serial No.: Rev.:
SBEG10
08090001 A1.00
WOOD-MIZER PRODUCTS, INC. 8180 W. 10th St. Indianapolis, IN
46214-2400 U.S.A. 317/ 271-1542 Or 800/ 553-0182
M FG BY/ FABRIQUÉ PAR:

Safety
Safety Symbols
2
2-1 SBEdoc072519 Safety
SECTION 2 SAFETY
2.1 Safety Symbols
The following symbols and signal words call your attention to instructions concerning your
personal safety. Be sure to observe and follow these instructions.
DANGER! indicates an imminently hazardous situation
which, if not avoided, will result in death or serious injury.
WARNING! suggests a potentially hazardous situation
which, if not avoided, could result in death or serious injury.
CAUTION! refers to potentially hazardous situations which,
if not avoided, may result in minor or moderate injury or
damage to equipment.
IMPORTANT! indicates vital information.
NOTE: gives helpful information.
Warning stripes are placed on areas where a single decal
would be insufficient. To avoid serious injury, keep out of
the path of any equipment marked with warning stripes.

Safety
Safety Instructions
Safety SBEdoc072519 2-2
2
2.2 Safety Instructions
Read and observe all safety instructions before operating this equipment! Also read any
additional manufacturer’s manuals and observe any applicable safety instructions includ-
ing dangers, warnings, and cautions.
Always be sure that all safety decals are clean and readable. Replace all damaged safety
decals to prevent personal injury or damage to the equipment. Contact your local distribu-
tor, or call your Customer Service Representative to order more decals.
IMPORTANT! It is always the owner's responsibility to com-
ply with all applicable federal, state and local laws, rules
and regulations regarding the ownership and operation of
your Wood-Mizer Edger. All Wood-Mizer Edger owners are
encouraged to become thoroughly familiar with these appli-
cable laws and comply with them fully while using the
equipment.
Always properly dispose of all sawing by-products, includ-
ing sawdust and other debris, coolant, oil, fuel, oil filters and
fuel filters.
DISPOSE OF SAWING BY-PRODUCTS PROPERLY
WARNING! Clean sawdust from all guards, vents, con-
trol boxes, or any area where sawdust may gather after
every shift. Failure to do so may result in fire, causing
death or serious injury.
IMPORTANT! Always properly dispose of all sawing by-products,
including sawdust and other debris, coolant, oil, fuel, oil filters and
fuel filters.
Edger Setup and Transportation Safety
WARNING! When setting up or transporting the Edger,
avoid areas marked as pinch points. These are located
near the rear folding leg and the engine pulley. Keep your
hands away from these areas to prevent injury.
WARNING! Always wear gloves and eye protection when
handling blades. Failure to do so may result in serious
injury.
CAUTION! Before operating the Edger, be sure to remove

Safety
Safety Instructions
2
2-3 SBEdoc072519 Safety
the shipping block from under the blade cover. Failure to do
so will cause damage to the machine.

Safety
Safety Instructions
Safety SBEdoc072519 2-4
2
Edger Operation Safety
DANGER! Make sure all guards and covers are in place
and secured before operating or transporting the Edger.
Failure to do so may result in serious injury.
DANGER! Always keep hands away from moving blade.
Blade may still be moving even when the clutch lever is dis-
engaged. Failure to do so will result in serious injury.
DANGER! Keep all persons out of the path of moving
equipment and boards when operating the Edger or loading
boards. Failure to do so will result in serious injury.
DANGER! Maintain a clean and clear path for all necessary
movement around the Edger and lumber stacking areas.
Failure to do so will result in serious injury.
DANGER! Always be sure the blade is disengaged and all
persons are out of the path of the blade before starting the
engine or motor. Failure to do so will result in serious injury.
DANGER! Always shut off the engine and allow all moving
parts to come to a complete stop before removing any
guards or covers. Failure to do so will result in serious
injury.
WARNING! Always shut off the engine to stop the blade
whenever the Edger is not in use. Failure to do so may
result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot pro-
tection when operating the Edger. Failure to do so may
result in serious injury.
WARNING! Secure all loose clothing and jewelry before
operating the Edger. Failure to do so may result in serious
injury or death.
WARNING! Kickback Hazard. Stay clear of area during
operation. Follow all anti-kickback service and safety rules.
Failure to do so may result in serious injury.
CAUTION! Avoid resting boards or other objects on the
blade guard. Damage to the guard may result.

Safety
Safety Instructions
2
2-5 SBEdoc072519 Safety
Refueling and Engine Operation Safety
DANGER! Always be sure the blade is disengaged and all
persons are out of the path of the blade before starting the
engine or motor. Failure to do so will result in serious injury.
WARNING! Store gasoline away from sawdust and other
flammable materials. Also remove sawdust from above the
engine tank before refueling. Failure to do so may result in
serious injury.
WARNING! Use an appropriate funnel to refuel tank.
Remove any spilled fuel from area before starting engine.
Failure to do so may result in serious injury.
WARNING! Do not for any reason adjust the engine drive
belts or belt support bracket with the engine running. Doing
so may result in serious injury.
WARNING! Always wear proper and necessary safety
equipment when performing service functions. Proper
safety equipment includes eye protection, breathing protec-
tion, hand protection and foot protection.
WARNING! The engine exhaust from this product contains
chemicals known to the State of California to cause cancer,
birth defects or other reproductive harm.
CAUTION! Do not lift the engine by the carburetor when
replacing the drive belt. Damage to the engine may result.

Setup & Operation
Setup
Setup & Operation SBEdoc072519 3-1
3
SECTION 3 SETUP & OPERATION
3.1 Setup
CAUTION! Before operating the Edger, be sure to remove
the shipping block from under the blade cover. Failure to do
so will cause damage to the machine.
1. A shipping block supports the blade guard during factory shipment. Remove this block
before operating the Edger. To remove:
Loosen the two mount knobs on the right side of the blade guard. Lift the guard from
the machine and remove the shipping block.
Replace the blade guard. Retighten the mount knobs.
2. Unfold the rear leg. Swing the leg all the way down until they lock in position. Be sure the
pivot bolts seat in the brace notches.
WARNING! When setting up or transporting the Edger,
avoid areas marked as pinch points. These are located
near the rear folding leg and the engine pulley. Keep your
hands away from these areas to prevent injury.
See Figure 3-1.
FIG. 3-1
Loosen
Mount Knobs
Lift blade guard
& remove
shipping block
Swing rear leg
down until locked
in position
(See Detail)
DETAIL
SB0001-10B

Setup & Operation
Setup
3
3-2 SBEdoc072519 Setup & Operation
3. Install the engine. To install:
See Figure 3-2.
Position the engine beneath the Edger.
Remove the U-bracket lock pins and clutch retaining pin. Raise the clutch handle.
FIG. 3-2
Remove clutch
retaining pin
Raise clutch
handle
Remove U-bracket
lock pins
SB0001-11

Setup & Operation
Setup
Setup & Operation SBEdoc072519 3-3
3
See Figure 3-3.
Place the ends of the engine mounting bar in the U-brackets and reinstall the
U-bracket lock pins.
Position the drive belt around the engine pulley.
WARNING! When setting up or transporting the Edger,
avoid areas marked as pinch points. These are located
near the rear folding leg and the engine pulley. Keep your
hands away from these areas to prevent injury.
Connect the clutch linkage to the motor mount plate pin and replace the retaining
pin.
4. If necessary, level the Edger by shimming under the leg foot pads. NOTE: Adjust the rear
of the edger slightly lower than the front to allow gravity to assist in feeding boards.
FIG. 3-3
Place mounting bar
in U-brackets &
replace lock pins
Position belt around engine
pulley. Connect clutch linkage
to mount pin and replace
retaining pin
SB0001-12

Setup & Operation
Setup
3
3-4 SBEdoc072519 Setup & Operation
5. Adjust the front guide fence:
See Figure 3-4.
The guide scale shows how many inches the front fence is from the blade. This
helps you to determine the width of lumber you will be sawing.
For example, if you wish to cut 2" lumber, you will need to adjust the front fence 2"
from the blade, or to the 2" mark on the guide scale. The front fence can be adjusted
as often as necessary.
The front fence can be adjusted from 0 to 12". To adjust the front fence, pull the
fence lock handle and slide the fence to the desired position. Release the fence lock
handle to lock the fence into place.
FIG. 3-4
Pull fence lock handle
back and move fence
to desired board width
1
5
2
6
S12876
SB0001-13

Setup & Operation
Alignment
Setup & Operation SBEdoc072519 3-5
3
3.2 Alignment
Proper machine alignment is important for optimum cutting performance. Check machine
alignment often and adjust as necessary. To check:
1. Adjust the front fence to the 5" position. Be sure the blade clutch handle is disengaged.
2. Loosen the mount knobs and remove the blade guard. Unscrew and remove the blade
bearing cover plate.
See Figure 3-5.
3. Tie one end of a string (string must be approximately 11’ or longer in length) to the front
fence tab. Route the string around the front end of the fence. Pulling the string tight, align
it with the face of the front fence along the entire length of fence.
FIG. 3-5
Remove top blade
guard & bearing
cover plate
Tie string around fence
tab and route
around front face of fence
Clamp string to
rear cross tube
SB0001-14B

Setup & Operation
Alignment
3
3-6 SBEdoc072519 Setup & Operation
4. Use a C-clamp to secure the string to the rear frame cross tube, maintaining the string
alignment to the front fence.
5. Measure the distance between the face of the blade and the string at each end of the
blade. The measurements should be the same as the front fence setting (5 inches) at
both ends.
See Figure 3-6.
6. If necessary, loosen the blade shaft bearing mount bolts and adjust the position of the
blade. Retighten the bearing mount bolts. After adjusting the blade, loosen the blade filler
plate thumb screws and adjust the plate close to, but not touching the blade. Retighten
the thumb screws.
FIG. 3-6
SB0001-16
With string flat against front
fence, measure the distance
from the string to the blade
tube at both ends
Loosen blade shaft
bearing mount bolts
to adjust position
of blade
After blade is adjusted, loosen
thumb screws and adjust blade
filler plate close to, but not
touching the blade

Setup & Operation
Alignment
Setup & Operation SBEdoc072519 3-7
3
7. Measure the distance between the face of the rear fence and the string at each end of the
rear fence. The measurements should be the same as the front fence setting (5 inches).
See Figure 3-7. If necessary, loosen the locking nuts and move the rear fence rail as nec-
essary. Retighten the nuts.
FIG. 3-7
With string flat against front
fence, measure the distance
from the string to rear fence
at both ends
SB0001-17 Loosen rear fence mount
bolts to adjust fence

Setup & Operation
Operation
3
3-8 SBEdoc072519 Setup & Operation
3.3 Operation
1. Make sure the Edger has been properly set up and the blade guard and fences have
been properly adjusted to cut your size boards. See Section 3.1.
2. Check the alignment. See Section 3.2.
3. Start the engine:
DANGER! Always be sure the blade is disengaged and all
persons are out of the path of the blade before starting the
engine or motor. Failure to do so will result in serious injury.
DANGER! Make sure all guards and covers are in place
and secured before operating or transporting the Edger.
Failure to do so may result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot pro-
tection when operating the Edger. Failure to do so may
result in serious injury.
WARNING! Secure all loose clothing and jewelry before
operating the Edger. Failure to do so may result in serious
injury or death.
Making sure the clutch lever is disengaged (in the raised position), turn the engine
switch located on top of the engine to the ON position.
Move the choke to the START position.
Pull the engine cord slowly until you feel resistance, then pull the cord quickly to
start the engine. Repeat with the choke opened slightly if necessary.
When the engine starts, slowly open the choke all the way by moving the choke
lever to the OFF position.
4. Begin edging:
Lower the clutch lever to engage the blade. Push the lever down until the clutch link-
age locks into the engaged position.
DANGER! Always keep hands away from moving blade.
Blade may still be moving even when the clutch lever is dis-
engaged. Failure to do so will result in serious injury.
DANGER! Keep all persons out of the path of moving
equipment and boards when operating the Edger or loading
boards. Failure to do so will result in serious injury.
