woodmizer LT40 B1 Series User manual

Wood-Mizer
®
Sawmill
Safety, Setup, Operation
& Maintenance Manual
LT40 B1-4 Series rev. A2.02
LT40 B1-4 Wide rev. A2.02
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
Form #635
!
This is the original language
for the manual.

4 HDSdoc092820
This manual is to replace or to be used with all previous information received on the
Wood-Mizer
®
* sawmill. All future mailings will be an addition to or a revision of individual
sections of this manual as we obtain new information.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
If You Need To Order Parts...
From Europe call our European Headquarters and Manufacturing Facility in Kolo, Poland
at [phone]. Please have the vehicle identification number and your customer
number ready when you call. Wood-Mizer will accept these methods of payment:
 Visa, Mastercard, or Select Purchase
 COD
 Prepayment
 Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If You Need Service...
From Europe call our European Headquarters and Manufacturing Facility in Kolo, Poland
at [phone]. Ask to speak with a Customer Service Representative. Please have
your vehicle identification number and your customer number ready when you call. The
Service Representative can help you with questions about alignment of your mill, blade
sharpening, or cutting a particular species of wood. He also can schedule you for a ser-
vice call.
Office Hours: All times are Eastern Standard Time. Please remember that Indiana does
not go on Daylight Savings Time in the summer.
IMPORTANT! Read the entire Operator's Manual before
operating the sawmill. Take notice of all safety warnings
throughout this manual and those posted on the machine.
Keep this manual with this machine at all times, regardless
of ownership.
*Wood-Mizer
®
is a registered trademark of Wood-Mizer Products, Inc.
Country Monday - Friday Saturday Sunday
U.S., Indiana 8 a.m. to 5 p.m. Closed Closed
Poland 7 a.m. to 3:00 p.m. Closed Closed

HDSdoc092820 5
Sawmill and Customer Identification
Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). See the fig-
ure below for VIN locations. See the chart for VIN description.
V.I.N. LOCATIONS.
456 A 4 24 1 X H P A F9 017 F9 .01
V.I.N. DESCRIPTION
1.
2.
Company Identification Number
456=Wood-Mizer Indiana
Weight Class; A=Under 1300 kg, B=1301-1800 kg,
C=1801-2200 kg, D=2201-3000kg, X- Stationary.
Product No.; 1=LT10/15, 2=LT20 Series,
4=LT40 Series, 7=LT70 Series
Length of the Trailer;
20= 20’ (6 m), 24=24’ (7 m), 35=35’ (11 m)
Number of axles on the trailer
Year of Manufacture;
N=2015, P=2016, R=2017, S=2018, T=2019
State of Manufacture
N=Indiana, P=Poland
Month of Manufacture
A=January, B=February, C=March, etc...
Revision Level
Sequence Number
Ranging from 000-999
End of 17-Digit VIN
Revision Level (Repeated)
Two-Digit Minor Revision Level
Check Digit
Add all the number and divide by 11

6 HDSdoc092820
Each sawmill is also identified with a model number which includes the base model and
the engine/motor configuration. See the figure for a description of the model number.
When you pick up your mill, you will receive a customer number. Both the VIN and your
customer number expedite our service to you. Please write these numbers below so you
have quick, easy access to them.
MODEL NUMBER DESCRIPTION.
Customer No. Model No. V.I.N. Revision
LT40
Basic Sawmill I.D.
E25
Configuration
Engine/Motor

Getting Service
Wood-Mizer is committed to providing you with the latest technology, best quality and strongest
customer service available on the market today. We continually evaluate our customers’ needs to
ensure we’re meeting current wood-processing demands. Your comments and suggestions are
welcome.
General Contact Information
From Europe call your local distributor or our European Headquarters and Manufacturing Facility in
Koło, Nagórna 114 St, Poland at [phone]. From the continental U.S., call our U.S.
Headquarter 8180 West 10th St.Indianapolis, IN 46214, toll-free at 1-800-525-8100. Ask to speak
with a Customer Service Representative. Please have your machine identification number and your
customer number ready when you call. The Service Representative can help you with questions
about the operation and maintenance of your machine. He also can schedule you for a service call.
Office Hours:
Please have your vehicle identification number and your customer number ready when you call.
Wood-Mizer will accept these methods of payment:
 Visa, Mastercard, or Discover
 COD
 Prepayment
 Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on size and
quantity of order.
Technical data are subject to change without prior notice.
Actual product may differ from product images. Some illustrations show machines with optional
equipment.
Country Monday - Friday Saturday Sunday
Poland 7 a.m.- 3 p.m. Closed Closed
US 8 a.m.- 5 p.m. 8 a.m.- 12 p.m Closed

Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
EUROPE UNITED STATES
European Headquarters
Wood-Mizer Industries Sp. z o.o.
Nagórna 114, 62-600 Koło, Poland
Tel.: [phone]
Fax: [phone]
www.woodmizer.eu
World Headquarters
Wood-Mizer LLC
8180 West 10th Street
Indianapolis,Indiana 46214-2400,
USA
Tel.: [phone]
Fax: [phone]
www.woodmizer.com
BELARUS
MOST-GRUPP
Siemashko 15, k.3
Minsk 2200116
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
SWITZERLAND Stefan Wespi
Maschinen u. Geräte
Spezialarbeiten GmbH
Eichistraße 4
6353 Weggis
Tel.: [phone]
GSM: [phone]
[email protected]
www.woodmizer.ch
RUSSIA Dariusz Mikołajewski
OOO WOOD-MIZER INDUSTRIES
141031, Moscow
Reg., Mytishenski raj., pos. Veshki,
Zavodskaja str., 3B
Tel.Fax: [phone]
Tel.Fax: [phone]
e-mail: [email protected]
BULGARIA Kalin Simeonov
Ecotechproduct
38 Star Lozenski pat str.
Sofia 1186
Tel.: [phone]
Tel.: [phone]
Tel:/Fax
: [phone]
Kalin Simeonov
GSM: [phone]
e-mail: [email protected]
HUNGARY Wiktor Turoczy
Wood-Mizer Hungary K.F.T.
Szonyi Ut 67., 2921 Komárom
Tel.:/Fax: [phone]
e-mail: [email protected]
RUSSIA Far East Wladimir Głazaczew
“WM Service”
Krasnoretchenskaya Str.111
680006 Khabarovsk
Tel.:/Fax: [phone]
e-mail: [email protected]

CROATIA Krešimir Pregernik
Pregimex d.o.o.
S. Batušiæa 31, 10090 Zagreb
Tel.:/Fax: [phone]
Krešimir Pregernik
GSM: [phone]
e-mail: [email protected]
ITALY Pasquale Felice
Wood-Mizer Italia Srl
Cda. Capoiaccio SN
86012 Cercemaggiore
Campobasso
Tel.:/Fax: [phone]
GSM: [phone]
e-mail: [email protected]
SERBIA Dragan Markov
Wood-Mizer Balkan d.o.o.
Svetosavska GA 3/3; P. Fah 25
23 300 Kikinda
Tel.:/Fax: [phone]
Tel.:/Fax: [phone]
GSM: [phone]
e-mail: [email protected]
CZECH REPUBLIC Miroslaw Greill
Wood-Mizer CZ s.r.o.
Osvaldova 91
339 01 Klatovy-Luby
Tel.:/Fax: [phone]
Fax: [phone]
Miroslaw Greill
GSM: [phone]
e-mail: [email protected]
SLOVAKIA Wiktor Turoczy
Wood-Mizer Danubia s.r.o.
Hadovce 5, 94501 Komárno
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
CZECH REPUBLIC Lubomir Kudlik
Wood-Mizer Moravia
Sovadinova 6
69002 Breclav
Tel.:/Fax: [phone]
Lubomir Kudlik
GSM: [phone]
e-mail: [email protected]
LATVIA Vilmars Jansons
OBERTS Ltd
Gaujas str. 32/2
LV-2167 Marupe, Rigas Raj.
Tel.: [phone]
Fax: [phone]
Vilmars Jansons
GSM: [phone]
Andris Orols
GSM: [phone]
e-mail: [email protected]
TURKEY
Er-Ka Ahsap Profil Kerestecilik San.
ve Tic. Ltd. Sti.
Adana Keresteciler Sitesi 191 sk No.41
ADANA
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
FINLAND Howard Blackbourn
Oy Falkberg Jordbruk Ab
Falkintie 220
25610 Ylonkyla
Tel.: [phone]
Fax: [phone]
Howard Blackbourn
GSM: [phone]
e-mail: [email protected]
LITHUANIA Andrius Zuzevicius
UAB Singlis
Savanoriu pr. 187, 2053 Vilnius
Tel.: [phone]
Fax: [phone]
GSM: [phone]
e-mail: [email protected]
Dmitrij Gaiduk
GSM: [phone]
e-mail: [email protected]
UKRAINE Ivan Vinnicki
MOST UKRAINA
bul. Myru 3, Bajkivtsi Ternoplskyj r-j
Ternopolska oblast
47711 Ukraine
Tel/Fax: [phone]
GSM: [phone]
GSM: [phone]
E-mail: [email protected]
FRANCE Tizoc Chavez
Wood-Mizer France
556 chemin des Embouffus,
ZAC des Basses Echarrieres
38440 SAINT JEAN DE BOURNAY
Tel: [phone]
GSM: [phone]
Mail: [email protected]
NORWAY Tor Bakken Flaathe
Bakken Flaathe A/S
Løkenvegen 5, 2034 Holter
Tel: + 47-638 74 989
Sales: + 47- 412 80 076
Service: [phone]
[e-mail]
www.woodmizer.no
UNITED KINGDOM & IRELAND
Wood-Mizer UK
Hopfield Barn
Kenward Road, Yalding
Kent ME18 6JP, UK
Tel.: [phone]
Fax: [phone]
e-mail: [e-mail]
SLOVENIA Jan Fale
FAMTEH d.o.o.
Gacnikova pot 2,
2390 Ravne na Koroskem
Tel.: [phone]
Fax: [phone]
Jan Fale
GSM: [phone]
e-mail: [email protected]
Matjaz Kolar
Tel.: [phone]
GSM: [phone]
e-mail: [email protected]

GERMANY\AUSTRIA Klaus Longmuss
Wood-Mizer GmbH
Dorfstraße 5, 29485 Schletau
Büro
Tel: [phone]
Werkstatt
Tel: [phone]
Ersatzteilservice
Tel: +49 58 83 - 98 80 250
Schärfservice
Tel: +49-58 83 - 98 80 270
E-mail:
[email protected]
www.woodmizer.de
Klaus Longmuss
Tel.: [phone]
GSM: [phone]
e-mail: [email protected]
Subagent:
SWEDEN Kjell Larsson
Mekwood AB
Slingan 14, 812 41 Gästrike-Hammarby
Tel.: [phone]
Kjell Larsson
GSM: [phone]
e-mail: [email protected]
IRELAND
Wood-Mizer Ireland
Stephen Brennan
Cum Lahardane Ballina County Mayo
Tel:[phone]
E-mail: [email protected]
Subagents:
DENMARK Kevin Christiansen
Kevin Christiansen's
savværker PMV
Arnborgvej 40, 7330 Brande- Fasterholt
Mobile: [phone]
Mobile: [phone]
[email protected]
www.woodmizer.dk
ROMANIA Adrian Echert
SC WOOD-MIZER RO SRL
TRANSILVANIEI Nr. 5
Sibiu, Cisnadie 555300
Tel.:/Fax: : [phone]
GSM: [phone]
e-mail: [email protected]
Regional Manager - Asia
Robert Moxham
Regional Direction - Asia
Wood-Mizer Asia Manufacturing Co., Ltd.
No.2, Gongyequ 40th Rd. Xitun District,
Taichung City, 40768, Taiwan, R.O.C.
TEL: [phone]
FAX: [phone]
CELL: [phone]
EMAIL: [email protected]
www.woodmizerasia.com
Skype: r.g.moxham
NETHERLANDS Gerlo Breukers
Breukers Houtzagerij en Bosbouwmachines
Hazenweg 5, 7481 PC Haaksbergen
Tel: [phone]
Mobile: [phone]
[email protected]
www.woodmizer.nl
Subagent:
ROMANIA M. Echert
S.C. Echert Comprod s.r.l
Str. Schitului Nr. 6, Apt.7 etajul-1
725 70 Vatra Dornei, Romania
Tel.:/Fax: [phone]
Tel. : [phone]
Regional Manager - Africa
Gavin Prowse
Regional Sales Director - Africa
Wood-Mizer Africa (Pty) Ltd.
Unit 1,Leader Park
20 Chariot Street
Stormill Ext.5
Maraisburg, Johannesburg
South Africa
TEL: [phone]
FAX: [phone]
CELL: [phone]
EMAIL: [e-mail]
www.woodmizerafrica.com
Skype: gavin.prowse
USA World Headquarters Canadian Headquarters
Serving North & South America, Oceania, East Asia
Wood-Mizer LLC
8180 West 10th Street
Indianapolis, IN 46214
Phone: [phone] or 800.553.0182
Customer Service: 800.525.8100
Fax: [phone]
Email: [e-mail]
Serving Canada
Wood-Mizer Canada
396 County Road 36, Unit B
Lindsay, ON K9V 4R3
Phone: [phone] or 877.357.3373
Fax: [phone]
Email: [e-mail]
Brazil Headquarters Europe Headquarters

Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
doc122921 -11
Serving Brazil
Wood-Mizer do Brasil
Rua Dom Pedro 1, No: 205 Bairro: Sao Jose
Ivoti/RS CEP:93.900-000
Tel: [phone]
Email: [e-mail]
Serving Europe, Africa, West Asia
Wood-Mizer Industries Sp z o.o.
Nagorna 114
62-600 Kolo, Poland
Phone: [phone]
Fax: [phone]
Branches & Authorized Sales Centers
For a complete list of dealers, visit www.woodmizer.com

1 SW-07doc092820Table of Contents
Table of Contents Section-Page
General Contact Information
Branches & Authorized Sales CentersWood-Mizer Locations (North and South America)
SECTION 1 SAFETY & GENERAL INFORMATION 1-1
1.1 Blade Handling.......................................................................................1-1
1.2 Sawmill Setup.........................................................................................1-2
1.3 Sawmill Operation..................................................................................1-2
1.4 Sawmill Maintenance .............................................................................1-5
1.5 Belt Sizes..............................................................................................1-10
1.6 Blade Sizes ...........................................................................................1-10
1.7 Cutting Capacity...................................................................................1-11
1.8 Engine/Motor Specifications ................................................................1-12
1.9 Noise Level...........................................................................................1-14
1.10 Overall Dimensions ..............................................................................1-15
1.11 Chains ...................................................................................................1-15
1.12 Hydraulic System .................................................................................1-15
1.13 Dust Extractor Specifications...............................................................1-16
1.14 Components..........................................................................................1-17
SECTION 2 SAWMILL ASSEMBLY 2-1
2.1 Mounting Parts of LT40 Sawmills .........................................................2-1
Specifications of Parts
Specifications of Fasteners
Tools Necessary for Assembling the Sawmill
2.2 Unpacking the Sawmill ..........................................................................2-6
Standard Version of the Sawmill
Sawmill with Remote Equipment
2.3 Bed Frame Assembly .............................................................................2-9
SECTION 3 SETUP & OPERATION 3-1
3.1 Sawmill Setup.........................................................................................3-1
Setting up sawmills equipped with non-adjustable legs
Setting up sawmills equipped with outrigger legs
3.2 Sawmills with cable guide......................................................................3-6
3.3 Middle Track Cover .............................................................................3-11
3.4 Replacing The Blade ............................................................................3-13
3.5 Tensioning The Blade...........................................................................3-14
3.6 Tracking The Blade ..............................................................................3-15
3.7 Starting The Motor (LT40 B1-4 AC) ...................................................3-17
3.8 Starting The Engine (LT40 B1-4 DC)..................................................3-18
3.9 Loading, Turning, And Clamping Logs ...............................................3-20
3.10 Up/Down Operation .............................................................................3-22
3.11 Blade Guide Arm Operation.................................................................3-23

Table of Contents Section-Page
Table of Contents SW-07doc0928202
3.12 Clutch/Brake Operation........................................................................3-24
3.13 Power Feed Operation ..........................................................................3-26
3.14 Blade Height Scale ...............................................................................3-27
3.15 Water Lube Operation ..........................................................................3-30
SECTION 4 MAINTENANCE 4-1
4.1 Wear Life................................................................................................4-1
4.2 Blade Guides ..........................................................................................4-2
Steel Blade Guide Blocks
4.3 Sawdust Removal ...................................................................................4-3
4.4 Carriage Track, Wiper & Scrapers .........................................................4-4
4.5 Vertical Mast Rails.................................................................................4-5
4.6 Drum Switches .......................................................................................4-5
4.7 Miscellaneous .........................................................................................4-6
4.8 Blade Tensioner......................................................................................4-7
4.9 Brake Strap Adjustment .........................................................................4-9
4.10 Blade Wheel Belts ..................................................................................4-9
4.11 Drive Belt Adjustment..........................................................................4-10
4.12 Clutch Handle Adjustment ...................................................................4-13
4.13 Autoclutch Option Adjustment.............................................................4-14
4.14 Drive Bearing .......................................................................................4-15
4.15 Up/Down System..................................................................................4-16
4.16 Power Feed ...........................................................................................4-18
4.17 Safety Devices Inspection ....................................................................4-20
SECTION 5 TROUBLESHOOTING GUIDE 5-1
5.1 Sawing Problems....................................................................................5-1
5.2 Electrical Problems.................................................................................5-3
5.3 Power Feed Problems .............................................................................5-5
5.4 Motor and Drive Pulleys Alignment ......................................................5-7
5.5 Power Feed Variable Speed Switch Test................................................5-8
5.6 Power Feed Preliminary Test .................................................................5-8
5.7 Power Feed Mechanical Test..................................................................5-8
SECTION 6 SAWMILL ALIGNMENT 6-1
6.1 Pre-Alignment Procedures......................................................................6-1
6.2 Frame Setup............................................................................................6-2
6.3 Blade Installation And Alignment..........................................................6-2
6.4 Saw Head Slide Pad Adjustment............................................................6-6
6.5 Adjusting The Lower Track Rollers.......................................................6-9
6.6 Adjusting Bed Rails To The Blade.......................................................6-13
6.7 Blade Guide Arm Alignment................................................................6-14
6.8 Blade Deflection...................................................................................6-20

3 SW-07doc092820Table of Contents
Table of Contents Section-Page
6.9 Blade Guide Vertical Tilt Adjustment..................................................6-22
6.10 Blade Guide Spacing ............................................................................6-25
6.11 Horizontal Tilt Adjustment...................................................................6-27
6.12 Blade Guide Disc Adjustment..............................................................6-29
6.13 Horizontal Adjustment of Side Supports..............................................6-32
6.14 Vertical Adjustment of Side Supports..................................................6-34
6.15 Saw Head Tilt .......................................................................................6-35
6.16 Blade Height Scale Adjustment............................................................6-38

Safety & General Information
Blade Handling
Safety & General Information doc092820 1-1
1
SECTION 1 SAFETY & GENERAL INFORMATION
This symbol calls your attention to instructions concerning your personal safety. Be sure to observe
and follow these instructions. This symbol accompanies a signal word. The word DANGER indicates
an imminently hazardous situation which, if not avoided, will result in death or serious injury. WARN-
ING suggests a potentially hazardous situation which, if not avoided, could result in death or serious
injury. CAUTION refers to potentially hazardous situations which, if not avoided, may result in minor
or moderate injury to persons or equipment. Read all safety instructions before operating this equip-
ment and observe all safety warnings!
Warning stripes are placed on areas where a single decal would be insufficient. To avoid serious
injury, keep out of the path of any equipment marked with warning stripes.
Read and observe all safety instructions before operating this equipment! Also read any additional
manufacturer’s manuals and observe any applicable safety instructions including dangers, warnings,
and cautions.
Always be sure that all safety decals are clean and readable. Replace all damaged safety decals to
prevent personal injury or damage to the equipment. Contact your local distributor, or call your Cus-
tomer Service Representative to order more decals.
IMPORTANT! It is always the owner's responsibility to comply with all applicable federal, state and
local laws, rules and regulations regarding the ownership, operation and towing of your Wood-Mizer
sawmill. All Wood-Mizer mill owners are encouraged to become thoroughly familiar with these appli-
cable laws and comply with them fully while using or towing the mill.
Always properly dispose of all sawing by-products, including sawdust and other debris, coolant, oil,
fuel, oil filters and fuel filters.
Safety instructions are listed in this section by the following operations:
 Blade Handling
 Sawmill Setup
 Sawmill Operation
 Sawmill Maintenance
1.1 Blade Handling
DANGER! Shut off the sawmill motor before changing the blade. Fail-
ure to do so will result in serious injury.
WARNING! Always wear gloves and eye protection when handling
bandsaw blades. Changing blades is safest when done by one person!
Keep all other persons away from area when coiling, carrying or
changing a blade. Failure to do so may result in serious injury.

Safety & General Information
Sawmill Setup
1
1-2 doc092820 Safety & General Information
WARNING! Do not spin the blade wheels by hand. Spinning the blade
wheels by hand may result in serious injury.
1.2 Sawmill Setup
WARNING! Securely fasten the feet of a stationary sawmill to the floor
before operating the sawmill. Failure to do so may result in serious
injury or death.
WARNING! Do not set up the mill on ground with more than a 10
degree incline. If setup on an incline is necessary, put blocks under
one side of the mill or dig out areas for outrigger legs to keep mill level.
Setting up the mill on an incline could cause it to tip over, resulting in
serious personal injury.
CAUTION! Changes in temperature could cause increased pressure
in the blade tensioner and loss of fluid from the gauge. Release the
blade tension when the mill is not in use to avoid damage to the
tensioner.
1.3 Sawmill Operation
IMPORTANT! The sawmill is intended for sawing wood only. See
Section 1.7 for log size capacities of the machine.
IMPORTANT! The operator of the sawmill should get adequate train-
ing in the operation and adjustment of the machine.
DANGER! Make sure all guards and covers are in place and secured
before operating or towing the sawmill. Failure to do so may result in
serious injury.
Be sure the blade housing and pulley covers are in place and secure.
Use the safety retainer pin and cable to fasten blade housing covers.
DANGER! Always keep hands away from moving bandsaw blade.
Failure to do so will result in serious injury.
DANGER! Stay clear of the area between the trailer axle and saw car-
riage. Failure to do so will result in serious injury.
DANGER! Keep all persons out of the path of moving equipment and
logs when operating sawmill or loading and turning logs. Failure to do
so will result in serious injury.
DANGER! Maintain a clean and clear path for all necessary movement
around the mill and lumber stacking areas. Failure to do so will result in
serious injury.
!

Safety & General Information
Sawmill Operation
Safety & General Information doc092820 1-3
1
DANGER! Always be sure the blade is disengaged and all persons are
out of the path of the blade before starting the engine or motor. Failure
to do so will result in serious injury.
DANGER! Keep all persons out of the path of returning boards. Failure
to do so will result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot protection
when operating the sawmill. Failure to do so may result in serious
injury.
WARNING! Be sure the power feed switch is in the neutral position
before turning the key switch to the (#1) or (#2) position. This prevents
accidental carriage movement which may cause serious injury or
death.
WARNING! Secure all loose clothing and jewelry before operating the
sawmill. Failure to do so may result in serious injury or death.
WARNING! Always make sure log is clamped securely before sawing.
Failure to do so may result in serious injury or death.
WARNING! Use ONLY water with the water lube accessory. Never use
flammable fuels or liquids. If these types of liquids are necessary to
clean the blade, remove it and clean with a rag. Failure to do so may
result in serious injury or death.
CAUTION! Be sure the pivot rails, turning arm, clamp, and toe boards
are below bed level before loading a log onto the bed. Failure to do so
may result in machine damage or cause misalignment.
CAUTION! Before loading a log, be sure the cutting head is moved far
enough forward so the log does not hit it. Failure to do so may result in
machine damage.
CAUTION! Do not try to force the saw head beyond its upper and
lower travel limits. Damage to the up/down system may result.
CAUTION! Always make sure the up/down switch moves to the neutral
or off position when released to ensure that the saw head stops mov-
ing. Failure to do so may result in machine damage.
CAUTION! Be sure to stop the blade when returning the carriage. This
will not only prevent the blade from being pulled off and ruined by a
wood sliver, but also will increase the life of the blade.
DANGER! Any arbitrary repairs of the electric installation could result
in serious injury or death.
DANGER! Any damaged electric parts, especially the wires supplying

Safety & General Information
Sawmill Operation
1
1-4 doc092820 Safety & General Information
the power feed motors must be repaired by a qualified electrician.
DANGER! Any repairs done to the electric installation may be done by
a qualified electrician with the power off.
DANGER! The electric connector must be equipped with a safety
device to protect against shock.
DANGER! The electric connector must be installed by a qualified elec-
trician.
DANGER! Do not operate the sawmill with an open electric box.
DANGER! In the event that water appears in the electric box further
work on the sawmill may result in electric shock as well as damage to
the power feed motor.
DANGER! The electric box door must always be closed, even when
the sawmill is not in use.
DANGER! Always disconnect the power when the sawmill has been
not in use for a long period.
DANGER! Any maintenance or repair must be done with the power off
(the plug must be taken out of the outlet).
DANGER! Maintain a clean and clear path for all necessary movement
around the mill and lumber stacking areas. Failure to do so will result in
serious injury.
CAUTION! Be sure all safety plates are clean and readable. For new
safety plates please contact your local distributor.
CAUTION! The saw head will hit the spring-loaded ramp stops when
adjusted for low cuts. Remove the loading ramps before sawing to
prevent damage to the saw head and/or blade guide arm.
CAUTION! Never clean the blade or the blade wheels with a brush or
a scraper during sawmill operation.
CAUTION! Before installation of the blade, inspect it for damage and
cracks. Use only properly sharpened blades. Always handle the blade
with extreme caution. Use suitable carrier equipment for transporting
the blades.
CAUTION! Always wear gloves when handling the blade. Never grab
the blade with bare hands!
CAUTION! If the blade breaks during sawmill operation, push the
EMERGENCY STOP button to stop the blade motor and wait 10 sec-

Safety & General Information
Sawmill Maintenance
Safety & General Information doc092820 1-5
1
onds before you open the blade housing cover.
CAUTION! The sawmill’s work-stand should be equipped with a 4 kg
or bigger dry powder extinguisher.
1.4 Sawmill Maintenance
WARNING! Always secure the cutting head with a chain or a brace
before adjusting the up/down chain. The cutting head may fall, causing
severe injury or death.
WARNING! Always secure the cutting head with a chain or a brace
before adjusting the mast pads. The cutting head may fall, causing
severe injury or death.
WARNING! Always secure the cutting head with a chain or a brace
before removing the up/down motor belt. The cutting head may fall,
causing severe injury or death.
WARNING! Drum switch grease contains Petroleum Hydrocarbon
Lubricant. Eye and skin irritant. If introduced into eyes, flush with water
for at least 15 minutes. If film or irritation persists, seek medical atten-
tion. Wash skin with soap and water. If ingested, do not induce vomit-
ing - contact a physician. KEEP OUT OF THE REACH OF CHILDREN.
CAUTION! Reinstall the track wiper so that it lightly touches the track
rail. If the wiper presses too firmly against the rail, it can cause the
power feed to bind.
CAUTION! Never use grease on the mast rails as it will collect saw-
dust.
CAUTION! Do not use chain lube. It causes sawdust buildup in chain
links.
CAUTION! Do not over-tension the up/down chain. Over-tensioning
may lead to early failure of the gear reducer.
CAUTION! Do not overtighten the feed chain. Damage to the power
feed motor may result.
CAUTION! Due to variations in the vertical mast, the pad spacing may
vary throughout the travel of the saw head. Check the pad spacing at
the top and bottom ends of the mast only. Pads adjusted too tight will
cause premature up/down motor failure.
CAUTION! It is important that the lower stop bolts are properly
adjusted to secure the carriage on the track rail. Failure to properly

Safety & General Information
Sawmill Maintenance
1
1-6 doc092820 Safety & General Information
adjust the stop bolts can cause saw head damage, especially during
mill transportation.
CAUTION! Failure to remove sawdust buildup from the battery box lid
and/or track rail cover could result in damage to these parts when the
saw head is lowered to its lowest position.
See Table 1-1. Pictogram decals used to warn and inform the user about danger in the LT40.
TABLE 1-1
Decal View W-M No. Description
096317 CAUTION! Read thoroughly the manual
before operating the machine. Observe all
safety instructions and rules when
operating the sawmill.
099220 CAUTION! Close all guards and covers
before starting the machine.
099219 Blade tension. Turning the bolt clockwise
will increase the blade tension and turning
the bolt counterclockwise will decrease the
tension.
099220
099219
+
