woodmizer LX450 Series Guide

WARNING! Read and understand this
manual before using this machine.
!
WM doc Bed Extension
Safety, Operation,
Maintenance, & Parts Manual
LX450 Bed Extension rev. A1.00
Safety is our #1 concern!
Form #2413

©2019
Printed in the United States of America, all rights reserved. No part of this manual may be
reproduced in any form by any photographic, electronic, mechanical or other means or used in
any information storage and retrieval system without written permission from
Wood-Mizer
8180 West 10th Street
Indianapolis, Indiana 46214
&DOLIRUQLD
3URSRVLWLRQ:DUQLQJ
:$51,1*%UHDWKLQJJDVGLHVHOHQJLQHH[KDXVWH[SRVHV\RXWRFKHPLFDOVNQRZQWR
WKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHUDQGELUWKGHIHFWVRURWKHUUHSURGXFWLYHKDUP
$OZD\VVWDUWDQGRSHUDWHWKHHQJLQHLQDZHOOYHQWLODWHGDUHD
,ILQDQHQFORVHGDUHDYHQWWKHH[KDXVWWRWKHRXWVLGH
'RQRWPRGLI\RUWDPSHUZLWKWKHH[KDXVWV\VWHP
'RQRWLGOHWKHHQJLQHH[FHSWDVQHFHVVDU\
)RUPRUHLQIRUPDWLRQJRWRZZZ3ZDUQLQJVFDJRY
:$51,1*'ULOOLQJVDZLQJVDQGLQJRUPDFKLQLQJZRRGSURGXFWVFDQH[SRVH\RXWR
ZRRGGXVWDVXEVWDQFHNQRZQWRWKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHU$YRLGLQKDOLQJ
ZRRGGXVWRUXVHDGXVWPDVNRURWKHUVDIHJXDUGVIRUSHUVRQDOSURWHFWLRQ
)RUPRUHLQIRUPDWLRQJRWRZZZ3:DUQLQJVFDJRYZRRG

Table of Contents Section-Page
Table of Contents WM doc 3/3/20 3
SECTION 1 INSTALLATION 1-1
1.1 Options ...................................................................................................1-1
1.2 Sawmill Preparation ...............................................................................1-1
1.3 Extension Frame Attachment .................................................................1-3
SECTION 2 BED EXTENSION ALIGNMENT 2-1
SECTION 3 LOG CLAMP OPERATION 3-1
SECTION 4 STORAGE PROTECTION 4-1
SECTION 5 BED EXTENSION PARTS 5-1
5.1 Assembly, Bed Extension.......................................................................5-1
5.2 Support Assembly, Side, Manual ...........................................................5-2
5.3 Leg Assembly, Loading Side Adjustable ...............................................5-3
5.4 Assembly, Bed Tube ..............................................................................5-5

Installation
Options
1-1 3/3/20 Installation
1
SECTION 1 INSTALLATION
1.1 Options
The bed extension option includes a frame and the necessary hardware to attach it to the
LX450 sawmill. Mount the extension to a firm, level footing.
1.2 Sawmill Preparation
CAUTION! Disconnect the negative battery lead. This will
ensure the chain does not short the system if it contacts the
power supply.
1. Remove the trailer hitch from the frame of the sawmill.
2. Remove the feed chains from the feed stop brackets. Break apart the master link to dis-
connect the chain from the bracket.
3. Remove the flat washers, split washers, and bolts holding the feed stop bracket to the
sawmill frame.
4. Remove both of the entire assemblies from the sawmill frame retaining the same bolts
and hardware to remount the feed stop bracket assemblies to the end of the extension

Installation
Sawmill Preparation
Installation 3/3/20 1-2
1
frame as shown in Fig. 1-1.
5. Remove the cap from the end of the main tube that faces the bed extension by removing
the bolt and washer underneath the tube.
6. If attached, remove the plates, bolts, nuts and washers from the end of the bed extension
that faces the sawmill.
FIG. 1-1
BX45005-2
Feed Stop Bracket Assembly
Bolt
Split Washer
Flat Washer

Installation
Extension Frame Attachment
1-3 3/3/20 Installation
1
1.3 Extension Frame Attachment
1. Position the extension frame at the end of the sawmill frame.
2. Sight down the length of the frames to see that the rods and pins are lined up as close as
possible.
3. Slide the extension frame against the sawmill frame, allowing the pin to insert into the end
of both rods.
4. Secure the frames together with the plates, bolts, flat washers, and nuts as shown in Fig.
1-2
FIG. 1-2
BX45005-3
Nuts Washers
Plate
Bolts

Installation
Extension Frame Attachment
Installation 3/3/20 1-4
1
5. Install the FAO extension, part 110617, in between the leg assembly and the sawmill
frame to provide clearance for the cable carrier as shown in Fig. 1-3.
NOTE: Install the FAO extension on the sawmill, not the bed exten-
sion.
FIG. 1-3
BX45005-4

Bed Extension Alignment
2-1 3/3/20 Bed Extension Alignment
2
SECTION 2 BED EXTENSION ALIGNMENT
1. Align the extension to the sawmill using the pins.
2. Adjust the height using the legs to align the tracks on the sawmill to the tracks on the
extension.
NOTE: You should not be able to detect any variance where one track
ends and the other starts.
NOTE: Reference the instructions in the Operation & Maintenance
Manual for the sawmill to adjust the height of the sawmill using the out-
riggers.
WARNING! Hold the adjustable leg with one hand to prevent a
sudden release and pull out the locking pin. Failure to follow this
may result in serious injury.
3. Unclip the retainer on each locking pin on the adjustable outriggers, and use the adjust-
ment handle to set the height of the extension as shown in Fig. 2-1.
FIG. 2-1. OUTRIGGER ADJUSTMENT.
LX0006
LX0006-19
Locking Pin
Adjustment nut
Locking Bracket
Locking Pin Retainer

Bed Extension Alignment
Bed Extension Alignment 3/3/20 2-2
2
4. Lower the adjustable leg to align the locking pin holes so that the foot is as close to the
ground as possible.
5. Reinstall the locking pin and secure with the retainer.
6. Use the provided crank handle to turn the outrigger adjustment nut counterclockwise to
push the foot pad down to support the weight of the sawmill frame.
7. Install the locking brackets over the adjustment nut to prevent downward creep from
vibration.
8. Move the cutting head across the area where the sawmill frame and extension meet.
NOTE: If the tracks are properly aligned, you should not be able to tell
when the track bearings cross from the sawmill to the extension. Any
variance will cause inaccurately sawn boards!
9. Fine tune the height of the bed extension until the sawmill and extension tracks are per-
fectly matched.

Log Clamp Operation
3-1 3/3/20 Log Clamp Operation
3
SECTION 3 LOG CLAMP OPERATION
A manual log clamp is supplied with the bed extension to help clamp long logs against the
side supports.
1. Insert the log clamp post in a hole close to the log on the slotted channel between the
middle bed rails of the extension.
2. Pull the clamp handle to spin the cam against the log and clamp the log firmly against the
side supports.
3. Lock the clamp in place stretching the chain up to the clamp.
4. Slip the chain through the slot on the clamp handle using a link in the chain that holds the
clamp firmly against the log.

Storage Protection
Storage Protection 3/3/20 4-1
4
SECTION 4 STORAGE PROTECTION
1. Coat the top and bottom bed extension rails with a rust inhibitor such as Sherwin-Williams
P.D.R.P. #710.
2. Coat the power feed chain with a light film of a light-weight lubricant such as Dexron III
ATF.
3. Ensure the connecting link is attached to the chain to prevent chain loss.
4. Coat the threads of the bed rail leveling bolts with a dry lube such as Gunk L-508.
Preparation For Use
Before using a bed extension that has been stored in the above manner, remove the rust
inhibitor protection coat from the bed extension rails. Use a clean, dry cloth and a light
lubricant such as WD-40 to remove the protection coat.

Bed Extension Parts
Assembly, Bed Extension
5-1 3/3/20 Bed Extension Parts
5
SECTION 5 BED EXTENSION PARTS
5.1 Assembly, Bed Extension
REF DESCRIPTION (♦Indicates Parts Available in Assemblies Only) PART # QTY.
FRAME ASSY, 7.5" BED EXTENSION BX7-LX450 1
1Leg Assy, Loading Side Adjustable 056781 4
2Frame Weldment, LX450BX7.5 N / A 1 
3Assy, Bed Tube Front And Rear N / A 3 
4Support Assy, Side, Manual 034554 2
5Clamp Weldment, Manual Log Painted W09412 1
6Stop Weldment, Clamp Ptd W09404 1
7Extension Weldment, FAO Mount 110617 1
BX45004-1
1 2 34
5
6
7

Bed Extension Parts
Support Assembly, Side, Manual
Bed Extension Parts 3/3/20 5-2
5
5.2 Support Assembly, Side, Manual
REF DESCRIPTION (♦Indicates Parts Available in Assemblies Only) PART # QTY.
SUPPORT ASSY, SIDE, MANUAL 034554 2
1Shaft Weldment, Side Support Pivot 016544 1
2Plate, Side Support Mount Ptd 016555 1
3Support Weldment, Manual Side Ptd 015235 1
4Washer, 1/4 SAE Flat F05011-11 2
5Nut, 1/4-20 Nylock F05010-69 1
6Nut, 1/2-13 Nyl Hex Lock F05010-8 3
7Screw, 1/4-20x1 3/4 HHC F05005-4 1
8Washer, 1/2 SAE Flat F05011-2 5
9Plate, Side Support Clamp Ptd 016558 1
10 Fitting, 3/16x3/16 Straight Grease P04107 2
11 Washer, .52x1.69 014632 1
12 Bolt, 1/2-13x1 1/2 HH Gr5 F05008-33 1
13 Bolt, 1/2-13x3 1/2 HH Gr5 F05008-61 2
BX45002-1
1 2 3
4
5
6
7
8
9
10
11
12
13

Bed Extension Parts
Leg Assembly, Loading Side Adjustable
5-3 3/3/20 Bed Extension Parts
5
5.3 Leg Assembly, Loading Side Adjustable
REF DESCRIPTION (♦Indicates Parts Available in Assemblies Only) PART # QTY.
LEG ASSY, LOADING SIDE ADJUSTABLE 056781 4
1Pin, 1/8x2-13/16L Locking Wire F05012-162 1
2Bracket, Adjustable Outrigger Lock 059577 1
3Nut, Adjustable Outrigger Hex 056774 1
4Pin, 5/16x1 1/4 Roll F05012-127 1
5Washer, 3/4 SAE Flat F05011-62 1
6Seal, Outrigger Acme Screw 039641 1
7Weldment, Loading Side Adj Outrigger Mnt 056780 1
8Assy, Adj. Outrigger Thrust Bearing 039639 1
9Sleeve, Outrigger Screw 039645 1
10 Screw, 1-5 ACME Adj. Outrigger Long 039642 1
11 Tube, Front Adj Outrigger Slide 003981 1
12 Nut, Adj. Outrigger Long Acme 039636 1
BX45001-1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16

Bed Extension Parts
Leg Assembly, Loading Side Adjustable
Bed Extension Parts 3/3/20 5-4
5
13 Pin, Adj Outrigger Locking 056817 1
14 Weldment, Adjustable Outrigger Base 056783 1
15 Fitting, 1/4-28 Grease P05060 1
16 Nut, Loading Side Adj Outrigger Mnt 056826 4
Inst Sht, Field Installed Adj Outrigger FAO-1524 1
REF DESCRIPTION (♦Indicates Parts Available in Assemblies Only) PART # QTY.

Bed Extension Parts
Assembly, Bed Tube
5-5 3/3/20 Bed Extension Parts
5
5.4 Assembly, Bed Tube
REF DESCRIPTION (♦Indicates Parts Available in Assemblies Only) PART # QTY.
ASSY, BED TUBE FRONT AND REAR 075703 3
1Tube Weldment, Bed Rail 075702 1
2Cover, 33-13/16 Rail SS 106551 1
3Nut, 5/16-18 Swaged Hex F05010-6 3
4Washer, 1/2 SAE Flat F05011-2 4
5Bolt, 1/2-13x4 HH Gr5 F05008-78 2
6Nut, 1/2-13 Nyl Hex Lock F05010-8 2
7Bolt, 5/16-18x2 1/2 HH F05006-10 3
8Nut, 5/8-11 Hex F05010-5 3
9Bolt, Bed Rail Adj S13006 3
BX45003-1
1 2 345
6
7
8
9
