WARNING! Read and understand this
manual before using this machine.
!
LX25 Sawmill
Safety, Operation,
Maintenance, & Parts Manual
LX25G9 rev. A1.00
LX25G7 rev. A1.00
Safety is our #1 concern!
May 2020
Form #2427

Active Patents assigned to Wood-Mizer, LLC
Wood-Mizer, LLC has received patents that protect our inventions which are a result of a dedication to
research, innovation, development, and design. Learn more at: woodmizer.com/patents
©2021 Wood-Mizer LLC
Printed in the United States of America, all rights reserved. No part of this manual may be reproduced in any form by
any photographic, electronic, mechanical or other means or used in any information storage and retrieval system with-
out written permission from
Wood-Mizer, LLC
8180 West 10th Street
Indianapolis, Indiana 46214
&DOLIRUQLD
3URSRVLWLRQ:DUQLQJ
:$51,1*%UHDWKLQJJDVGLHVHOHQJLQHH[KDXVWH[SRVHV\RXWRFKHPLFDOVNQRZQWR
WKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHUDQGELUWKGHIHFWVRURWKHUUHSURGXFWLYHKDUP
$OZD\VVWDUWDQGRSHUDWHWKHHQJLQHLQDZHOOYHQWLODWHGDUHD
,ILQDQHQFORVHGDUHDYHQWWKHH[KDXVWWRWKHRXWVLGH
'RQRWPRGLI\RUWDPSHUZLWKWKHH[KDXVWV\VWHP
'RQRWLGOHWKHHQJLQHH[FHSWDVQHFHVVDU\
)RUPRUHLQIRUPDWLRQJRWRZZZ3ZDUQLQJVFDJRY
:$51,1*'ULOOLQJVDZLQJVDQGLQJRUPDFKLQLQJZRRGSURGXFWVFDQH[SRVH\RXWR
ZRRGGXVWDVXEVWDQFHNQRZQWRWKH6WDWHRI&DOLIRUQLDWRFDXVHFDQFHU$YRLGLQKDOLQJ
ZRRGGXVWRUXVHDGXVWPDVNRURWKHUVDIHJXDUGVIRUSHUVRQDOSURWHFWLRQ
)RUPRUHLQIRUPDWLRQJRWRZZZ3:DUQLQJVFDJRYZRRG

Table of Contents Section-Page
Table of Contents LX25 4/8/21 3
INTRODUCTION
1.1 About This Manual.................................................................................1-6
1.2 Getting Service .......................................................................................1-6
1.3 Specifications .........................................................................................1-6
1.4 Major Components .................................................................................1-7
1.5 Specifications .........................................................................................1-8
SAFETY
2.1 Safety Symbols.......................................................................................2-1
2.2 Safety Instructions..................................................................................2-1
Observe ALL Safety Instructions...........................................2-1
Wear Safety Clothing (Personal Protection Equipment)......2-2
Keep Work Area Clean .........................................................2-3
Fuel/Flammable Liquid Handling Safety..............................2-3
Battery Safety ........................................................................2-4
Sawmill Setup Safety .............................................................2-5
2.3 Safety Decals..........................................................................................2-7
SETUP
3.1 Assemble the bed sections....................................................................3-10
3.2 Level the bed ........................................................................................3-13
3.3 Install the mast......................................................................................3-16
Prepare the mast carriages.................................................3-16
Prepare mast .......................................................................3-17
Install the sawhead..............................................................3-18
3.4 Install the sweepers and sawhead stops................................................3-21
3.5 Install the operator’s handle .................................................................3-22
3.6 Install the clutch cable..........................................................................3-24
3.7 Assemble the up/down crank................................................................3-26
3.8 Install sawhead cover latch and scale...................................................3-29
3.9 Install the lube water tank.....................................................................3-32
3.10 Install the dust chute.............................................................................3-32
3.11 Install the Blade....................................................................................3-33

Table of Contents Section-Page
4 LX25 4/8/21 Table of Contents
SAWMILL OPERATION
4.1 Sawmill adjustments.............................................................................4-36
Tension the blade ................................................................4-36
Blade tracking .....................................................................4-37
Blade guides .......................................................................4-39
Drive belt adjustment ..........................................................4-40
Changing blades .................................................................4-41
Blade straightness ...............................................................4-42
Blade height scale ...............................................................4-43
4.2 Starting the Engine/Motor ....................................................................4-43
4.3 Loading, Turning, and Clamping Logs ................................................4-43
4.4 Level a Log...........................................................................................4-45
4.5 Lift Operation .......................................................................................4-46
4.6 Engine Operation..................................................................................4-46
4.7 Feed Operation .....................................................................................4-48
4.8 Cutting The Log ...................................................................................4-48
4.9 Edging...................................................................................................4-49
4.10 Blade Height Scale ...............................................................................4-50
4.11 Water Lube Operation ..........................................................................4-52
4.12 Transporting the Sawmill .....................................................................4-53
MAINTENANCE
5.1 Continuous maintenance ......................................................................5-54
Rails, rollers, and sweepers ................................................5-54
5.2 General maintenance ............................................................................5-55
Daily (8 hours of operation) ...............................................5-55
Weekly (40 hours of operation)...........................................5-55
Monthly (160 hours of operation).......................................5-56
5.3 Engine maintenance..............................................................................5-56
SAWHEAD PARTS
6.1 Sliding Blade Guide Arm Assembly ....................................................6-57
6.2 Blade Guide Assembly.........................................................................6-58
6.3 Clutch Assembly .................................................................................6-60
6.4 Scale and Sawdust Chute......................................................................6-61
6.5 Cover Hold-up Latch...........................................................................6-62
6.6 Water Tank ...........................................................................................6-63
6.7 Up/down Slides ....................................................................................6-64
6.8 Winch ..................................................................................................6-65
6.9 Throttle Lever .....................................................................................6-67
6.10 Blade Tension Assembly......................................................................6-69
6.11 Band Wheel Assembly .........................................................................6-70
6.12 Sawhead Cover ...................................................................................6-71

Table of Contents Section-Page
Table of Contents LX25 4/8/21 5
6.13 Decals ...................................................................................................6-73
ENGINE PARTS
7.1 Kohler 9hp Gas Engine .......................................................................7-75
7.2 Kohler 7hp Gas Engine ........................................................................7-76
BED AND CARRIAGE ASSEMBLY
8.1 Bed........................................................................................................8-77
8.2 Log Clamp ...........................................................................................8-78
8.3 Carriage ...............................................................................................8-79
8.4 Log Rest................................................................................................8-81
8.5 Optional Log Ramps.............................................................................8-82
8.6 Optional Adjustable Feet......................................................................8-83

Introduction
About This Manual
1-6 LX25 4/8/21 Introduction
1
SECTION 1 INTRODUCTION
1.1 About This Manual
This manual replaces any previous information received on your Wood-Mizer® equip-
ment.
The information and instructions in this manual do not amend or extend the limited war-
ranties for the equipment given at the time of purchase.
1.2 Getting Service
For contact information, sales, service, parts, and additional manuals, sign into your
account on https://woodmizer.com, or call inside the USA: 1-800-553-0182 or from out-
side the USA: 317-271-1542
1.3 Specifications
Equipment specification are included in the Online Manuals, which are found at
https://apps.woodmizer.com/Manuals/Manuals.aspx?parent=0.

Introduction
Major Components
Introduction LX25 4/8/21 1-7
1
1.4 Major Components
Major components of the basic LX25 sawmill are shown in MAJOR COMPONENTS.
Other components are model-specific. These terms will be used throughout this manual.
100B-001
Sawhead
Mast
Log rest posts
Log clamp
Rails
Bed
Blade guides
Sawdust
chute
Scale
Water (lube)
tank
Up/down
crank
FIG. 1-1 MAJOR COMPONENTS

Introduction
Specifications
1-8 LX25 4/8/21 Introduction
1
1.5 Specifications
TDL-LX25

Safety
Safety Symbols
Safety LX25 4/8/21 2-1
2
SECTION 2 SAFETY
2.1 Safety Symbols
The following symbols and signal words call your attention to instructions concerning your
personal safety. Be sure to observe and follow these instructions.
indicates an imminently hazardous situation which, if not avoided,
will result in serious injury or death.
suggests a potentially hazardous situation which, if not avoided,
could result in serious injury or death.
refers to potentially hazardous situations which, if not avoided, may
result in minor or moderate injury or damage to equipment.
NOTICE indicates vital information pertaining to equipment.
NOTE: contains useful information.
2.2 Safety Instructions
OWNER/OPERATOR'S RESPONSIBILITY
The procedures listed in this manual may not include all ANSI, OSHA, or locally required
safety procedures. It is the owner/operator’s responsibility and not Wood-Mizer LLC
to ensure all operators are properly trained and informed of all safety protocols.
Owner/Operators are responsible for following all safety procedures when operating and
performing maintenance to the equipment.
Observe ALL Safety Instructions
NOTICE Read the entire Operator's Manual before operating
this equipment.
Note all safety warnings throughout this manual and those posted
on the machine.
Be able to access this manual at all times while operating this
equipment.
DANGER!
WARNING!
CAUTION!

Safety
Safety Instructions
2-2 LX25 4/8/21 Safety
2
Read additional manufacturer’s manuals and observe their appli-
cable safety instructions.
Only persons who have read and understood the entire operator's
manual should operate this equipment.
This equipment is not intended for use by or around children.
It is the owner/operator's responsibility to
comply with all applicable federal, state, and
local laws, rules, and regulations regarding
the ownership, operation, and transporting
your equipment.
Operators should become thoroughly familiar with
and comply with these applicable laws for operat-
ing and transporting equipment.
Clean sawdust from all guards, vents, control boxes,
or any area where sawdust may gather after every
shift. Failure to do so may result in fire, causing
death or serious injury.
Wear Safety Clothing (Personal Protection Equipment)
Always wear eye, ear, and foot protection
when operating or servicing the sawmill.
Secure all loose clothing, hair, and jew-
elry before operating the sawmill.
Wear gloves and eye protection when
handling bandsaw blades. Changing
blades is safest when done by one per-
son. Keep all other persons away from
area when coiling, carrying, or changing a
blade.
Some woods require respiration protec-
tion when operating the sawmill. It is the
sawyer’s responsibility to know which
woods require respiration protection.
WARNING!
WARNING!

Safety
Safety Instructions
Safety LX25 4/8/21 2-3
2
Keep Work Area Clean
Clean sawdust from all guards, vents, control boxes, or any area
where sawdust may gather after every shift. Failure to do so may
result in fire, causing death or serious injury
Maintain a clean and clear path for all necessary movement
around the equipment and lumber stacks.
NOTICE Always properly dispose of all sawing by-products,
including sawdust and wood debris, coolant, oil, fuel, oil filters, and
fuel filters.
If replacing a component which has a safety decal affixed to it,
make sure the new component also has the safety decal affixed.
Inspect all safety decals to ensure they are clean and readable.
Replace all damaged safety decals to prevent personal injury or
damage to the equipment. Contact your local distributor, or call
your Customer Service Representative to order more decals.
Fuel/Flammable Liquid Handling Safety
Do not smoke, weld, grind, or otherwise create sparks near your
engine or storage tanks, especially during times of fueling.
Do not allow fuel/flammable liquid to spill on a heat source, such as
a hot engine.
Store gasoline away from sawdust and other
flammable materials.
Do not use flammable liquids (diesel fuel or kero-
sene) in the water lube accessories.
Clean fuel/flammable liquid spills immediately.
WARNING!
DANGER!
WARNING!

Safety
Safety Instructions
2-4 LX25 4/8/21 Safety
2
NOTICE Remove blades from equipment before cleaning
them with fuel/flammable liquid.
Dispose of fuel/flammable liquids per local ordinances.
Battery Safety
Batteries expel explosive gases; keep sparks, flames, burning cig-
arettes, or other ignition sources away at all times.
Wear safety goggles and a face shield when working near batter-
ies.
Wash hands after handling batteries to remove possible lead, acid,
or other contaminants.
Charge the battery in a well ventilated area.
Do not attempt to charge a frozen battery.
NOTICE When working with batteries, do not spill or splash
electrolyte (dilute sulfuric acid) as it is a strong corrosive.
Overcharging may reduce the overall service life of the battery.
WARNING!

Safety
Safety Instructions
Safety LX25 4/8/21 2-5
2
Ensure the battery is fully charged before transporting the sawmill.
If the battery is not fully charged, excessive vibration could reduce
the overall service life of the battery.
Sawmill Setup Safety
Do not set up the mill on ground with more than
a 10 degree incline. Setting up the mill on an
incline could cause it to tip over.
If setup on an incline is necessary, put blocks
under one side of the mill or dig out areas for
the legs to keep mill level.
Use a lifting device (fork lift, crane, etc.) for parts
over 100 lbs.
Use two persons for lifting parts over 50lbs.1
1.For more information on lifting safety see NOISH Lifting Equation at
https://www.cdc.gov/niosh/docs/94-110/
EMERGENCY TREATMENT FOR CONTACT WITH BATTERY COMPONENTS (LEAD/SUL-
FURIC ACID) per SDS (Safety Data Sheet):
EYE CONTACT Sulfuric Acid and Lead: Flush eyes immediately with large amounts
of water for at least 15 minutes while lifting lids. Seek immediate med-
ical attention if eyes have been exposed directly to acid.
SKIN CONTACT Sulfuric Acid: Flush affected area(s) with large amounts of water
using deluge emergency shower, if available, shower for at least 15
minutes. Remove contaminated clothing, including shoes. If symp-
toms persist, seek medical attention. Wash contaminated clothing
before reuse. Discard contaminated shoes.
Lead: Wash immediately with soap and water.
INGESTION Sulfuric Acid: Administer large amounts of water. Do NOT induce
vomiting or aspiration into the lungs may occur and can cause perma-
nent injury or death; consult physician.
INHALATION Sulfuric Acid: Remove to fresh air immediately. If not breathing, give
artificial respiration. If breathing is difficult, give oxygen. Consult a
physician.
Lead: Remove from exposure, gargle, wash nose and lips; consult
physician.
WARNING!

Safety
Safety Instructions
2-6 LX25 4/8/21 Safety
2
Keep all non-essential personnel out of the area while setting up
the sawmill.

Safety
Safety Decals
Safety LX25 4/8/21 2-7
2
2.3 Safety Decals
096317 Read Operator’s Manual
CAUTION! Thoroughly read the
manual before operating the
machine. Observe all safety instruc-
tions and rules when operating the
mill.
096319 Disconnect Power Supply Before
Opening
(Electric version only)
096321 Blade Movement Direction
099220 Sawmill Covers Caution
CAUTION! Close all guards and cov-
ers before starting the machine.

Safety
Safety Decals
2-8 LX25 4/8/21 Safety
2
099222 Warning Projectile Hazard
Wear safety goggles.
099221 Keep Away Danger
CAUTION! Keep all persons a safe
distance away from work area when
operating the machine.
527864 Blade Tension
Align the disc in the notch for proper
blade tension.
501465 Use Safety Boots
Wear protective boots at all times
when operating the mill!
S12004g Use Eye Protection
Wear safety goggles at all times
when operating the mill!
099221B

Safety
Safety Decals
Safety LX25 4/8/21 2-9
2
S12005g Use Ear Protection
Wear ear protection at all times when
operating the mill!

Setup
Assemble the bed sections
3-10 LX25 4/8/21 Setup
3
SECTION 3 SETUP
3.1 Assemble the bed sections
The tools needed are:
Socket, 17mm
Ratchet handle
Ratchet extension bar (optional)
Combination wrench, 17mm
Assemble the bed on firm, level ground. Failure to do so may
cause the sawhead to tip, causing serious injury or death.
1. Assemble all of the bed sections using track rails and cross rails, and one cross member
where each bed section joins together.(See FIG. 3-1 .)
a. Attach two cross rails per bed section. Make sure to place the cross rails closer
together, leaving room for the sawhead assembly, as shown.
b. Attach the track rails to the cross rail. Make sure all of the cross rails face the
same direction. (See FIG. 3-2 .)
NOTE: Do not attach the catch rails at this time!
FIG. 3-1
WARNING!
TDLX2503-03
Track Rails
Cross Rails
Cross Member
Bolt, M10-1.5x30 HH
Class 8
Nut, M10-1.5 Flanged
Nylon Lock
Washer, M10 Flat

Setup
Assemble the bed sections
Setup LX25 4/8/21 3-11
3
2. Assemble the remaining track rails and cross rail in a similar fashion. (See FIG. 3-2 .)
3. Connect the bed sections using a connecting plate, a clamp, and hardware.
a. Attach the connecting plate (X100-934) to each bed section, joining them together.
b. Tighten the side of the plate that has the fixed holes. Do not fully tighten the bolts
(M10-1.5x30) on the side of the plate that has slotted holes.
c. Set the clamp in place by inserting the larger notch first (on bottom) and then tilting
the clamp in and upward to catch the smaller notch (on top). (See FIG. 3-3 .)
d. Tighten the bolts on the clamp (M10-1.5x85) to draw bed sections together.
FIG. 3-2
FIG. 3-3
TDLX2503-02
Direction of cut
T100001-3
Smaller Notch
Larger Notch
Fixed Holes
Slotted Holes
Plate Bolts
Connecting Plate
Clamp
Bolt, M10-1.5x85, HH,
Class 8
Washer, M10 Flat
Bolt, M10-1.5x85
Nut, M10-1.5 Flanged
Nylon Lock
Washer, M10 Flat Nut, M10-1.5
Flanged Nylon Lock

Setup
Assemble the bed sections
3-12 LX25 4/8/21 Setup
3
NOTE: Be sure the track rails of each bed section are aligned before
tightening the plate bolts.
e. Fully tighten the plate bolts in the slotted holes on connecting plate.
NOTE: Be sure the slotted holes on the connecting plate are con-
nected to the same bed section on both sides of the bed frame.
f. Repeat for the remaining 3 connections.
g. Attach the cross member between the bed sections.
NOTE: Optional bed extension sections may be added at this time, in
the same manner as the standard bed sections.
4. Attach the log clamp in the middle of the bed. (See FIG. 3-4 .)
FIG. 3-4
T100001-4
Washer, 3/8 Flat SAE
Log Clamp
Spacer
Bolt, M10-1.5x140 Washer, 3/8 Flat SAE
Nut, M10-1.50 Hex Nyl
Lock
