woodmizer LT40DC Series User manual

Wood-Mizer® Sawmill
Safety, Setup, Operation
& Maintenence Manual
LT40DC Series MH rev. E2.00
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
February 1998
Form #533
!

4 30Sdoc120507
This manual is to replace or to be used with all previous information received on the
Wood-Mizer®* sawmill. All future mailings will be an addition to or a revision of individual
sections of this manual as we obtain new information.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
If You Need To Order Parts...
From Europe call our European Headquarters and Manufacturing Facility in Kolo, Poland
at [phone] or [phone]. From the continental U.S., call our toll-free Parts
hotline at 1-800-448-7881. Please have the vehicle identification number and your cus-
tomer number ready when you call. Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Select Purchase
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If You Need Service...
From Europe call our European Headquarters and Manufacturing Facility in Kolo, Poland
at [phone] or [phone]. From the continental U.S., call us toll-free at
1-800-525-8100. Ask to speak with a Customer Service Representative. Please have
your vehicle identification number and your customer number ready when you call. The
Service Representative can help you with questions about alignment of your mill, blade
sharpening, or cutting a particular species of wood. He also can schedule you for a ser-
vice call.
Office Hours: All times are Eastern Standard Time. Please remember that Indiana does
not go on Daylight Savings Time in the summer.
IMPORTANT! Read the entire Operator's Manual before
operating the sawmill. Take notice of all safety warnings
throughout this manual and those posted on the machine.
Keep this manual with this machine at all times, regardless
of ownership.
*Wood-Mizer®is a registered trademark of Wood-Mizer Products, Inc.
Country Monday - Friday Saturday Sunday
U.S., Indiana 8 a.m. to 5 p.m. 8 a.m. to 4 p.m. Closed
Poland 8 a.m. to 4:30 p.m. 8 a.m. to 1 p.m. Closed

30Sdoc120507 5
Sawmill and Customer Identification
Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). See the fig-
ure below for VIN locations. See the chart for VIN description.
V.I.N. LOCATIONS.
456 A 4 24 1 X S N A F9 017 F9 .01
V.I.N. DESCRIPTION
2
1
3
300
11
9
Company Identification Number
456=Wood-Mizer Indiana
Weight Class; A=Under 3,000 lbs B=3,001-4,000 lbs
C=4,001-5000 lbs
Product No.; 1=LT15, 2=LT20, 4=LT40 Series,
7=LT70 Series
Length of the Trailer;
20=20 Ft., 24=24’, 35=35’
Number of axles on the trailer
Year of Manufacture;
Y=2001, Z=2002, A=2003, B=2004, C=2005, D=2006
State of Manufacture
N=Indiana, P=Poland
Month of Manufacture
A=January, B=February, C=March, etc...
Revision Level
Sequence Number
Ranging from 000-999
End of 17-Digit VIN
Revision Level (Repeated)
Two-Digit Minor Revision Level
Check Digit
Add all the number and divide by 11

6 30Sdoc120507
Each sawmill is also identified with a model number which includes the base model and
the engine/motor configuration. See the figure for a description of the model number.
When you pick up your mill, you will receive a customer number. Both the VIN and your
customer number expedite our service to you. Please write these numbers below so you
have quick, easy access to them.
MODEL NUMBER DESCRIPTION.
Customer No. Model No. V.I.N. Revision
LT40
Basic Sawmill I.D.
D42
Configuration
Engine/Motor

Table of Contents Section-Page
Table of Contents Sdoc120507 i
SECTION 1 SAFETY & GENERAL INFORMATION 1-1
1.1 Blade Handling.......................................................................................................... 1-2
1.2 Sawmill Setup............................................................................................................ 1-3
1.3 Sawmill Operation..................................................................................................... 1-4
1.4 Sawmill Maintenance ................................................................................................ 1-7
1.5 Belt Sizes ................................................................................................................. 1-13
1.6 Blade Sizes .............................................................................................................. 1-14
1.7 Cutting Capacity...................................................................................................... 1-15
1.8 Engine/Motor Specifications ................................................................................... 1-16
1.9 Dust Extractor Specifications .................................................................................. 1-16
1.10 Overall Dimensions ................................................................................................. 1-17
1.11 Chains ......................................................................................................................1-17
1.12 Components............................................................................................................. 1-18
SECTION 2 SETUP & OPERATION 2-1
2.1 Stationary Sawmill Setup .......................................................................................... 2-1
2.2 Portable Sawmill Setup ............................................................................................. 2-3
2.3 Middle Track Cover .................................................................................................. 2-5
2.4 Replacing The Blade ................................................................................................. 2-6
2.5 Tensioning The Blade................................................................................................ 2-7
2.6 Tracking The Blade ................................................................................................... 2-8
2.7 Starting The Engine (or Motor)............................................................................... 2-10
2.8 Board Return ........................................................................................................... 2-11
2.9 Loading, Turning, and Clamping Logs ................................................................... 2-14
2.10 Up/Down Operation ................................................................................................ 2-17
2.11 Blade Guide Arm Operation.................................................................................... 2-18
2.12 Clutch/Brake Operation........................................................................................... 2-19
2.13 Power Feed Operation ............................................................................................. 2-21
2.14 Cutting The Log ...................................................................................................... 2-23
2.15 Edging......................................................................................................................2-25
2.16 Optional Cutting Procedure for Super Series Mills................................................. 2-26
2.17 Blade Height Scale .................................................................................................. 2-27
2.18 Water Lube Operation ............................................................................................. 2-30
2.19 Preparing The Sawmill For Towing ........................................................................ 2-32
2.20 Manual Toe Board................................................................................................... 2-35

Table of Contents Section-Page
Table of Contents Sdoc120507 ii
SECTION 3 MAINTENANCE 3-1
3.1 Wear Life................................................................................................................... 3-1
3.2 Blade Guides ............................................................................................................. 3-2
3.3 Sawdust Removal ...................................................................................................... 3-4
3.4 Carriage Track, Wiper & Scrapers ............................................................................ 3-5
3.5 Vertical Mast Rails .................................................................................................... 3-6
3.6 Drum Switches .......................................................................................................... 3-6
3.7 Miscellaneous ............................................................................................................ 3-7
3.8 Blade Tensioner......................................................................................................... 3-8
3.9 Blade Wheel Belts ................................................................................................... 3-10
3.10 Brake Strap Adjustment .......................................................................................... 3-10
3.11 Drive Belt Adjustment............................................................................................. 3-11
3.12 Clutch Handle Adjustment ...................................................................................... 3-14
3.13 Autoclutch Option Adjustment................................................................................ 3-15
3.14 Drive Bearing .......................................................................................................... 3-16
3.15 Up/Down System..................................................................................................... 3-17
3.16 Power Feed .............................................................................................................. 3-19
SECTION 4 TROUBLESHOOTING GUIDE 2-1
4.1 Sawing Problems ....................................................................................................... 2-1
4.2 Electrical Problems.................................................................................................... 2-3
4.3 Power Feed Problems ................................................................................................ 2-5
4.4 Power Feed Circuit Troubleshooting......................................................................... 2-7
4.5 Engine/Motor and Drive Pulleys Alignment............................................................. 2-9
4.6 Power Feed Preliminary Test .................................................................................... 2-9
4.7 Power Feed Mechanical Test..................................................................................... 2-9
4.8 Fuse Terminal Extension Stud................................................................................. 2-11
4.9 Circuit Breaker Operation ....................................................................................... 2-13

Table of Contents Section-Page
Table of Contents Sdoc120507 iii
SECTION 5 SAWMILL ALIGNMENT 3-1
5.1 Pre-Alignment Procedures......................................................................................... 3-1
5.2 Frame Setup............................................................................................................... 3-2
5.3 Blade Installation And Alignment............................................................................. 3-3
5.4 Saw Head Slide Pad Adjustment............................................................................... 3-6
5.5 Adjusting The Lower Track Rollers.......................................................................... 3-8
5.6 Adjusting Bed Rails To The Blade.......................................................................... 3-11
5.7 Blade Guide Arm Vertical Adjustment ................................................................... 3-14
5.8 Blade Guide Arm Horizontal Adjustment............................................................... 3-16
5.9 Aligning the Blade Guides ...................................................................................... 3-18
5.10 Blade Deflection...................................................................................................... 3-19
5.11 Blade Guide Vertical Tilt Adjustment..................................................................... 3-20
5.12 Blade Guide Spacing ............................................................................................... 3-22
5.13 Horizontal Tilt Adjustment...................................................................................... 3-23
5.14 Blade Guide Block Adjustment............................................................................... 3-24
5.15 Horizontal Adjustment of Side Supports................................................................. 3-25
5.16 Vertical Adjustment of Side Supports..................................................................... 3-26
5.17 Clamp Stop/Stop Bolt Adjustment .......................................................................... 3-27
5.18 Saw Head Tilt .......................................................................................................... 3-28
5.19 Blade Height Scale Adjustment............................................................................... 3-29
5.20 Board Return Bracket .............................................................................................. 3-30

Safety & General Information
1
1-1 30Sdoc120507 Safety & General Information
SECTION 1 SAFETY & GENERAL INFORMATION
This symbol calls your attention to instructions concerning your personal safety. Be sure
to observe and follow these instructions. This symbol accompanies a signal word. The
word DANGER indicates an imminently hazardous situation which, if not avoided, will
result in death or serious injury. WARNING suggests a potentially hazardous situation
which, if not avoided, could result in death or serious injury. CAUTION refers to potentially
hazardous situations which, if not avoided, may result in minor or moderate injury to per-
sons or equipment. Read all safety instructions before operating this equipment and
observe all safety warnings!
Warning stripes are placed on areas where a single decal would be insufficient. To avoid
serious injury, keep out of the path of any equipment marked with warning stripes.
Read and observe all safety instructions before operating this equipment! Also read any
additional manufacturer’s manuals and observe any applicable safety instructions includ-
ing dangers, warnings, and cautions.
Always be sure that all safety decals are clean and readable. Replace all damaged safety
decals to prevent personal injury or damage to the equipment. Contact your local distribu-
tor, or call your Customer Service Representative to order more decals.
IMPORTANT! It is always the owner's responsibility to comply with all applicable federal,
state and local laws, rules and regulations regarding the ownership, operation and towing
of your Wood-Mizer sawmill. All Wood-Mizer mill owners are encouraged to become thor-
oughly familiar with these applicable laws and comply with them fully while using or tow-
ing the mill.
Always properly dispose of all sawing by-products, including sawdust and other debris,
coolant, oil, fuel, oil filters and fuel filters.
Safety instructions are listed in this section by the following operations:
Blade Handling
Sawmill Setup
Sawmill Operation
Sawmill Maintenance

Safety & General Information
Blade Handling
Safety & General Information 30Sdoc120507 1-2
1
1.1 Blade Handling
DANGER! Always disengage the blade and shut off the
sawmill engine before changing the blade. Failure to do so
will result in serious injury.
WARNING! Always wear gloves and eye protection when
handling bandsaw blades. Changing blades is safest when
done by one person! Keep all other persons away from
area when coiling, carrying or changing a blade. Failure to
do so may result in serious injury.
WARNING! Do not spin the blade wheels by hand.
Spinning the blade wheels by hand may result in serious
injury.

Safety & General Information
Sawmill Setup
1
1-3 30Sdoc120507 Safety & General Information
1.2 Sawmill Setup
WARNING! Chock the trailer wheels to prevent movement
before unhitching it from the towing vehicle. Failure to do so
may result in serious injury or death.
WARNING! Failure to put front outrigger down before mov-
ing cutting head from the rest position may result in serious
injury.
WARNING! Securely fasten the feet of a stationary sawmill
to the floor before operating the sawmill. Failure to do so
may result in serious injury or death.
WARNING! Always make sure the trailer is supporting the
sawmill frame when operating a sawmill with adjustable
outriggers. Failure to do so may result in serious injury or
death. The adjustable outriggers are intended to support
the saw frame with assistance from the trailer.
WARNING! Do not set up the mill on ground with more than
a 10 degree incline. If setup on an incline is necessary, put
blocks under one side of the mill or dig out areas for outrig-
ger legs to keep mill level. Setting up the mill on an incline
could cause it to tip over, resulting in serious personal
injury.
CAUTION! Changes in temperature could cause increased
pressure in the blade tensioner and loss of fluid from the
gauge. Release the blade tension when the mill is not in
use to avoid damage to the tensioner.

Safety & General Information
Sawmill Operation
Safety & General Information 30Sdoc120507 1-4
1
1.3 Sawmill Operation
DANGER! Make sure all guards and covers are in place
and secured before operating or towing the sawmill. Failure
to do so may result in serious injury.
Be sure the blade housing and pulley covers are in place
and secure. Use the safety retainer pin and cable to fasten
blade housing covers.
DANGER! Always keep hands away from moving bandsaw
blade. Failure to do so will result in serious injury.
DANGER! Stay clear of the area between the trailer axle
and saw carriage. Failure to do so will result in serious
injury.
DANGER! Keep all persons out of the path of moving
equipment and logs when operating sawmill or loading and
turning logs. Failure to do so will result in serious injury.
DANGER! Maintain a clean and clear path for all necessary
movement around the mill and lumber stacking areas. Fail-
ure to do so will result in serious injury.
DANGER! Always be sure the blade is disengaged and all
persons are out of the path of the blade before starting the
engine or motor. Failure to do so will result in serious injury.
DANGER! Keep all persons out of the path of returning
boards. Failure to do so will result in serious injury.
WARNING! Always disengage the clutch/brake mechanism
whenever the sawmill is not cutting. Failure to do so may
result in serious injury.
WARNING! Always wear eye, ear, respiration, and foot pro-
tection when operating the sawmill. Failure to do so may
result in serious injury.
WARNING! Be sure the power feed switch is in the neutral
position before turning the key switch to the on (#1) or
accessory (#3) position. This prevents accidental carriage
movement which may cause serious injury or death.

Safety & General Information
Sawmill Operation
1
1-5 30Sdoc120507 Safety & General Information
WARNING! Secure all loose clothing and jewelry before
operating the sawmill. Failure to do so may result in serious
injury or death.
WARNING! Always make sure log is clamped securely
before sawing. Failure to do so may result in serious injury
or death.
WARNING! The automatic board return is intended to
assist a second operator in removing boards quickly. Do not
use the board return when operating the sawmill alone.
Serious injury, death or damage to the equipment may
result.
WARNING! Never use the board return table as a platform
to stand on. This table is designed and intended to assist in
the removal of boards only. Standing on the table may
result in serious injury.
WARNING! Use ONLY water with the water lube acces-
sory. Never use flammable fuels or liquids. If these types of
liquids are necessary to clean the blade, remove it and
clean with a rag. Failure to do so may result in serious
injury or death.
CAUTION! Be sure the pivot rails, turning arm, clamp, and
toe boards are below bed level before loading a log onto
the bed. Failure to do so may result in machine damage or
cause misalignment.
CAUTION! Before loading a log, be sure the cutting head is
moved far enough forward so the log does not hit it. Failure
to do so may result in machine damage.
CAUTION! Do not try to force the saw head beyond its
upper and lower travel limits. Damage to the up/down sys-
tem may result.
CAUTION! Always make sure the up/down switch moves to
the neutral or off position when released to ensure that the
saw head stops moving. Failure to do so may result in
machine damage.
CAUTION! If the weight of the sawmill exceeds 3,000 lbs
(1361 Kg) for any reason, an auxiliary braking system (such
as electric brakes) must be used. Failure to do so may

Safety & General Information
Sawmill Operation
Safety & General Information 30Sdoc120507 1-6
1
result in severe machine damage.
CAUTION! Be sure to stop the blade when returning the
carriage. This will not only prevent the blade from being
pulled off and ruined by a wood sliver, but also will increase
the life of the blade.

Safety & General Information
Sawmill Maintenance
1
1-7 30Sdoc120507 Safety & General Information
1.4 Sawmill Maintenance
WARNING! Always secure the cutting head with a chain or
a brace before adjusting the up/down chain. The cutting
head may fall, causing severe injury or death.
WARNING! Always secure the cutting head with a chain or
a brace before adjusting the mast pads. The cutting head
may fall, causing severe injury or death.
WARNING! Always secure the cutting head with a chain or
a brace before removing the up/down motor belt. The cut-
ting head may fall, causing severe injury or death.
WARNING! Drum switch grease contains Petroleum Hydro-
carbon Lubricant. Eye and skin irritant. If introduced into
eyes, flush with water for at least 15 minutes. If film or irrita-
tion persists, seek medical attention. Wash skin with soap
and water. If ingested, do not induce vomiting - contact a
physician. KEEP OUT OF THE REACH OF CHILDREN.
CAUTION! Do not over-grease the blade guide bearings.
Over-greasing will push the seals out of the bearings caus-
ing premature failure.
CAUTION! Reinstall the track wiper so that it lightly touches
the track rail. If the wiper presses too firmly against the rail,
it can cause the power feed to bind.
CAUTION! Never use grease on the mast rails as it will col-
lect sawdust.
CAUTION! Do not use chain lube. It causes sawdust
buildup in chain links.
CAUTION! Do not over-tension the up/down chain.
Over-tensioning may lead to early failure of the gear
reducer.
CAUTION! Do not overtighten the feed chain. Damage to
the power feed motor may result.

Safety & General Information
Sawmill Maintenance
Safety & General Information 30Sdoc120507 1-8
1
CAUTION! Due to variations in the vertical mast, the pad
spacing may vary throughout the travel of the saw head.
Check the pad spacing at the top and bottom ends of the
mast only. Pads adjusted too tight will cause premature
up/down motor failure.
CAUTION! It is important that the lower stop bolts are prop-
erly adjusted to secure the carriage on the track rail. Failure
to properly adjust the stop bolts can cause saw head dam-
age, especially during mill transportation.
CAUTION! Failure to remove sawdust buildup from the bat-
tery box lid and/or track rail cover could result in damage to
these parts when the saw head is lowered to its lowest
position.

Safety & General Information
Sawmill Maintenance
1
1-9 30Sdoc120507 Safety & General Information
See Table 1-1. Pictogram decals used to warn and inform the user about danger in the
LT40.
TABLE 1-1
Decal View W-M No. Description
096317 CAUTION! Read thoroughly the manual
before operating the machine. Observe all
safety instructions and rules when
operating the sawmill.
099220 CAUTION! Close all guards and covers
before starting the machine.
099219 Blade tension. Turning the bolt clockwise
will increase the blade tension and turning
the bolt counterclockwise will decrease the
tension.
099220
099219
+

Safety & General Information
Sawmill Maintenance
Safety & General Information 30Sdoc120507 1-10
1
099223 Blade tension - See manual.
099221 CAUTION! Keep all persons a safe
distance away from work area when
operating the machine.
098176 CAUTION! Keep away from debarker
blade!
099222 CAUTION! Sawdust outlet. Protect eyes!
TABLE 1-1
099223
099221
098176

Safety & General Information
Sawmill Maintenance
1
1-11 30Sdoc120507 Safety & General Information
099542 CAUTION! Trailer.
086099 CAUTION! Keep away - hot parts!
096321 Blade movement direction
S12004G CAUTION! Always wear safety goggles
when operating the sawmill!
TABLE 1-1
099542
086099
