Wood-Mizer® Sawmill
Safety, Setup, Operation
& Maintenance Manual
LT30HD rev. F8 - F9.01
LT30HD Super rev. F8 - F9.01
LT40HD rev. F8 - F9.01
LT40HD Super rev. F8 - F9.01
Safety is our #1 concern! Read and understand
all safety information and instructions before oper-
ating, setting up or maintaining this machine.
October 2004 Form #688

ii HD96doc041910
This manual is to replace or to be used with all previous information received on the
Wood-Mizer®* sawmill. All future mailings will be an addition to or a revision of individual
sections of this manual as we obtain new information.
The information and instructions given in this manual do not amend or extend the limited
warranties for the equipment given at the time of purchase.
If You Need To Order Parts...
From the continental U.S., call our toll-free Parts hotline at 1-800-525-8100. Please have
the vehicle identification number and your customer number ready when you call.
Wood-Mizer will accept these methods of payment:
Visa, Mastercard, or Select Purchase
COD
Prepayment
Net 15 (with approved credit)
Be aware that shipping and handling charges may apply. Handling charges are based on
size and quantity of order. In most cases, items will ship on the day they are ordered.
Second Day and Next Day shipping are available at additional cost.
If your sawmill was purchased outside of the United States, contact your distributor for
replacement parts.

HD96doc041910 iii
If You Need Service...
From the continental U.S., call us toll-free at 1-800-525-8100. Ask to speak with a Cus-
tomer Service Representative. Please have your vehicle identification number and your
customer number ready when you call. The Service Representative can help you with
questions about alignment of your mill, blade sharpening, or cutting a particular species
of wood. He also can schedule you for a service call.
All times are Eastern Standard Time. Please remember that Indiana does not go on Day-
light Savings Time in the summer.
Monday - Friday 8 a.m. to 5 p.m.
Saturday 8 a.m. to 12 p.m.
If your sawmill was purchased outside the United States, contact the distributor for ser-
vice.
IMPORTANT! Read the entire Operator's Manual before
operating the sawmill. Take notice of all safety warnings
throughout this manual and those posted on the machine.
Keep this manual with this machine at all times, regardless
of ownership.
*Wood-Mizer®is a registered trademark of Wood-Mizer Products, Inc.

iv HD96doc041910
Your Vehicle Identification Number And Customer Number
Each Wood-Mizer sawmill has a 17-digit Vehicle Identification Number (VIN). see the fig-
ure below for VIN locations. See the chart for VIN description.
Each sawmill is also identified with a model number which includes the base model and
the engine/motor configuration. An ’s’ after the model number indicates the model is
approved for sale in countries that have adopted German "Gerprüfte Sicherheit: (G.S.)
safety standards. The model number is located on the middle blade housing cover. See
the figure for a description of the model number.
When you pick up your mill, you will receive a customer number. Both the VIN and your
customer number expedite our service to you. Please write these numbers below so you
have quick, easy access to them.
VIN: ___________________________
Customer No: ___________________
Model No: ___________________________
V.I.N. DESCRIPTION.

HD96doc041910 v
The vehicle identification number locations for mills LT30HD rev. F8534, LT30HD Super
rev. F8008, LT40HD rev. F8695, and LT40HD Super rev. F8129 and later are shown in
the following figure.
The vehicle identification number locations for mills prior to LT30HD rev. F8534, LT30HD
Super rev. F8008, LT40HD rev. F8695, and LT40HD Super rev. F8129 are shown in the
following figure.
NOTE: Sawmills manufactured before January, 1997 do not have the repeated revision
level or the minor revision level.
V.I.N. LOCATIONS FOR LATER MODEL MILLS.
V.I.N. LOCATIONS FOR EARLIER MODEL MILLS.
MODEL NUMBER DESCRIPTION.

Table of Contents Section-Page
Table of Contents HD96doc041910 i
SECTION 1 SAFETY & GENERAL INFORMATION 1-1
1.1 Blade Handling..........................................................................................................1-1
1.2 Sawmill Setup............................................................................................................1-2
1.3 Sawmill Operation.....................................................................................................1-3
1.4 Electric Sawmill ........................................................................................................1-5
1.5 Belt Sizes...................................................................................................................1-9
1.6 Blade Sizes ..............................................................................................................1-10
1.7 Cutting Capacity......................................................................................................1-11
1.8 Engine/Motor Specifications...................................................................................1-12
1.9 Overall Dimensions.................................................................................................1-13
1.10 Components.............................................................................................................1-14
1.11 Hydraulic Schematic ...............................................................................................1-15
1.12 Hydraulic Components............................................................................................1-16
1.13 Hydraulic Hoses ......................................................................................................1-17
SECTION 2 SETUP & OPERATION 2-1
2.1 Stationary Sawmill Setup..........................................................................................2-1
2.2 Portable Sawmill Setup .............................................................................................2-3
2.3 Replacing The Blade .................................................................................................2-7
2.4 Tensioning The Blade................................................................................................2-8
2.5 Tracking The Blade...................................................................................................2-9
2.6 Starting The Engine (or Motor)...............................................................................2-10
2.7 Hydraulic Control Operation...................................................................................2-11
2.8 Loading, Turning, And Clamping Logs..................................................................2-14
2.9 Clamp Extension ....................................................................................................2-16
2.10 Up/Down Operation ................................................................................................2-17
2.11 Blade Guide Arm Operation....................................................................................2-18
2.12 Clutch/Brake Operation...........................................................................................2-19
2.13 Power Feed Operation.............................................................................................2-20
2.14 Cutting The Log ......................................................................................................2-22
2.15 Edging......................................................................................................................2-23
2.16 Blade Height Sight Gauge.......................................................................................2-24
2.17 Blade Height Scale..................................................................................................2-25
2.18 Water Lube Operation.............................................................................................2-27
2.19 Preparing The Sawmill For Towing........................................................................2-28
TOC

Table of Contents Section-Page
ii HD96vdoc041910 Table of Contents
SECTION 3 MAINTENANCE 3-1
3.1 Wear Life...................................................................................................................3-1
3.2 Blade Guides .............................................................................................................3-2
3.3 Hydraulic Log Loader ...............................................................................................3-3
3.4 Blade Housing...........................................................................................................3-4
3.5 Carriage Track, Wiper & Scrapers............................................................................3-5
3.6 Vertical Mast Rails....................................................................................................3-6
3.7 Drum Switches ..........................................................................................................3-7
3.8 Miscellaneous Lubrication ........................................................................................3-8
3.9 Blade Tensioner.........................................................................................................3-9
3.10 Blade Wheel Belts...................................................................................................3-10
3.11 Brake Strap Adjustment ..........................................................................................3-11
3.12 Hydraulic System ....................................................................................................3-13
3.13 Drive Bearing ..........................................................................................................3-14
3.14 Up/Down System.....................................................................................................3-15
3.15 Power Feed..............................................................................................................3-18
3.16 Miscellaneous Maintenance ....................................................................................3-19
SECTION 4 TROUBLESHOOTING GUIDE 4-1
4.1 Sawing Problems.......................................................................................................4-1
4.2 Electrical Problems....................................................................................................4-3
4.3 Power Feed Problems................................................................................................ 4-5
4.4 Power Feed Circuit Troubleshooting.........................................................................4-7
4.5 Hydraulic Problems...................................................................................................4-9
4.6 Engine/Motor and Drive Pulleys Alignment...........................................................4-12
4.7 Power Feed Variable Speed Switch Test.................................................................4-13
4.8 Power Feed Preliminary Test ..................................................................................4-14
4.9 Power Feed Mechanical Test...................................................................................4-15
4.10 Hydraulic Pressure Test...........................................................................................4-16

Table of Contents Section-Page
Table of Contents HD96doc041910 iii
SECTION 5 SAWMILL ALIGNMENT 5-1
5.1 Pre-Alignment Procedures.........................................................................................5-1
5.2 Frame Setup...............................................................................................................5-2
5.3 Blade Installation And Alignment.............................................................................5-3
5.4 Saw Head Slide Pad Adjustment...............................................................................5-5
5.5 Adjusting The Lower Track Rollers.......................................................................... 5-7
5.6 Adjusting Bed Rails To The Blade............................................................................ 5-9
5.7 Blade Guide Arm Vertical Adjustment...................................................................5-12
5.8 Blade Guide Arm Horizontal Adjustment...............................................................5-13
5.9 Aligning The Blade Guides.....................................................................................5-15
5.10 Blade Deflection......................................................................................................5-16
5.11 Blade Guide Vertical Tilt Adjustment.....................................................................5-17
5.12 Blade Guide Spacing...............................................................................................5-19
5.13 Horizontal Tilt Adjustment......................................................................................5-20
5.14 Horizontal Adjustment Of Side Supports................................................................5-21
5.15 Vertical Adjustment Of Side Supports....................................................................5-22
5.16 Clamp Stop Adjustment ..........................................................................................5-23
5.17 Sight Gauge Adjustment..........................................................................................5-24
5.18 Saw Head Tilt..........................................................................................................5-25
5.19 Blade Height Scale Adjustment...............................................................................5-26

Safety & General Information
Blade Handling
Safety & General Information HD96doc041910 1-1
1
SECTION 1 SAFETY & GENERAL INFORMATION
This symbol calls your attention to instructions concerning your personal safety. Be sure
to observe and follow these instructions. This symbol accompanies a signal word. The
word DANGER refers to hazards that can cause death or serious, irreversible personal
injury. The word WARNING suggests a safety hazard that can cause personal injury.
CAUTION refers to hazards that can cause damage to the equipment or property only.
Read all safety instructions before operating this equipment and observe all safety warn-
ings!
Safety instructions are listed in this section by the following operations:
Blade Handling
Sawmill Setup
Sawmill Operation
Electric Sawmill
1.1 Blade Handling
WARNING! Always wear gloves and eye protection when
handling bandsaw blades. Keep all persons away from
area when coiling or carrying a blade.

Safety & General Information
Sawmill Setup
1
1-2 HD96doc041910 Safety & General Information
1.2 Sawmill Setup
WARNING! Put front outrigger down before moving cutting
head from the rest position. Failure to do so may result in
serious injury.
WARNING! Do not set up the mill on ground with more than
a 10 degree incline. If setup on an incline is necessary, put
blocks under one side of the mill or dig out areas for outrig-
ger legs to keep mill level. Setting up the mill on an incline
could cause it to tip over, resulting in serious personal
injury.
WARNING! Chock the trailer wheels to prevent movement
before unhitching it from the towing vehicle. Failure to do so
may result in serious injury or death.
WARNING! Always make sure the trailer is supporting the
sawmill frame when operating a sawmill with adjustable
outriggers. Failure to do so may result in serious injury or
death. The adjustable outriggers are intended to support
the saw frame with assistance from the trailer.
WARNING! The adjustable outriggers supplied with porta-
ble sawmills are not intended for setup on concrete or other
hard surfaces. Long-term use of the adjustable outriggers
on hard surfaces may cause the outriggers to fail, causing
the sawmill to drop. This could result in possible serious
injury or death.
If setting the sawmill up on concrete or other hard surface,
replace the adjustable outrgger legs with stationary legs.

Safety & General Information
Sawmill Operation
Safety & General Information HD96doc041910 1-3
1
1.3 Sawmill Operation
DANGER! Never operate or tow the sawmill without all
guards and covers in place and secured.
Be sure the blade housing and pulley covers are in place
and secure. Use the safety retainer pin and cable to fasten
blade housing covers.
DANGER! Always disengage the clutch/brake mechanism
whenever the sawmill is not cutting.
DANGER! Always keep hands away from moving bandsaw
blade.
DANGER! Keep all persons a safe distance away from
work area when operating sawmill or loading and turning
logs.
DANGER! Be sure the power feed switch is in the neutral
position before turning the key switch to the ON or ACC
position. This prevents unwanted carriage movement.
DANGER! Check to be sure the saw head is resting firmly
on the rest pin and mast rail stops and that the safety chain
is secured before towing the sawmill.
WARNING! Always wear eye, ear, respiration, and foot pro-
tection when operating the sawmill.
WARNING! Secure all loose clothing and jewelry before
operating the sawmill.
WARNING! Always make sure log is clamped securely
before sawing.
CAUTION! Always be sure that all safety warning decals
are clean and readable. Replace all damaged warning
decals. Contact your local distributor, or call your Customer
Service Representative to order more decals.
CAUTION! Be sure the pivot rails, turning arm, clamp, and
toe boards are out of the way before loading a log onto the
bed. Also, be sure the cutting head is moved far enough
forward so the log does not hit it.

Safety & General Information
Sawmill Operation
1
1-4 HD96doc041910 Safety & General Information
CAUTION! Failure to fully extend the log clamp before tow-
ing can result in damage to the clamping assembly during
towing.
CAUTION! It is important that the lower stop bolts are prop-
erly adjusted to secure the carriage on the track rail. Failure
to properly adjust the stop bolts can cause saw head dam-
age, especially during mill transportation.
IMPORTANT! It is always the owner's responsibility to com-
ply with all applicable federal, state and local laws, rules
and regulations regarding the ownership, operation and
towing of your Wood-Mizer sawmill. All Wood-Mizer mill
owners are encouraged to become thoroughly familiar with
these applicable laws and comply with them fully while
using or towing the mill.
Always properly dispose of all sawing byproducts, including
sawdust and other debris.

Safety & General Information
Electric Sawmill
Safety & General Information HD96doc041910 1-5
1
1.4 Electric Sawmill
USE PROPER PROCEDURE WHEN CONDUCTING ELECTRICAL SAFETY CHECKS
AND MAINTENANCE
DANGER! Make sure all electrical installation, service and/or
maintenance work is performed by a qualified electrician and is in
accordance with applicable electrical codes.
DANGER! Hazardous voltage inside the electric sawmill discon-
nect box, starter box, and at the motor can cause shock, burns, or
death. Disconnect and lock out power supply before servicing!
Keep all electrical component covers closed and securely fastened
during mill operation.
WARNING! Consider all electrical circuits energized and danger-
ous.
WARNING! Never assume or take the word of another person that
the power is off; check it out and lock it out.
WARNING! Do not wear rings, watches, or other jewelry while
working around an open electrical circuit.
WARNING! Before performing service near moving parts such as
blades, pulleys, motors, belts and chains, first turn the key switch
to the OFF (#0) position and remove the key. If the key is turned on
and moving parts activated, serious injury may result.
WARNING! Remove the blade before performing any service to
the engine or sawmill. Failure to do so may result in serious injury.

Safety & General Information
Electric Sawmill
1
1-6 HD96doc041910 Safety & General Information
DANGER! Lockout procedures must be used during:
Changing or adjusting blades
Unjamming operations
Cleaning
Mechanical repair
Electrical maintenance
Retrieval of tools/parts from work area
Activities where guards or electrical panel guard is open or
removed
Maintenance hazards include:
Blade contact
Pinch points
Kickbacks
Missiles (thrown blades/wood chips)
Electrical
Failure to lockout may result in:
Cut
Crush
Blindness
Puncture
Serious injury and death
Amputation
Burn
Shock
Electrocution
To control maintenance dangers:
Lockout procedures must be followed (see ANSI Standard
Z244.1-1982 and OSHA regulation 1910.147).
Never rely on machine stop control for maintenance safety (emer-
gency stops, on/off buttons, interlocks).
Do not reach into moving blades or feed systems. Allow all coast-
ing parts to come to a complete stop.
Electrical power supply and air supply must both be locked out.
Where established lockout procedures cannot be used (electrical
troubleshooting or mechanical dynamic troubleshooting), alterna-
tive effective protective techniques shall be employed which may
require special skills and planning.
Always follow safe operations practices in the workplace.

Safety & General Information
Electric Sawmill
Safety & General Information HD96doc041910 1-7
1
SAWMILL LOCKOUT PROCEDURE
Lockout procedures must be followed (see ANSI Standard Z244.1-1982 and OSHA regu-
lation 1910.147).
Purpose:
This procedure establishes the minimum requirements for lockout of energy sources that
could cause injury.
Responsibility:
The responsibility for seeing that this procedure is followed is binding upon all workers. All
workers shall be instructed in the safety significance of the lockout procedure. It is your
responsibility to ensure safe operation of the machine.
Preparation For Lockout:
Sawmillmust be locked out both electrically and pneumatically (lockout air valve).
Sequence of Lockout Procedure:
1. Notify all persons that a lockout is required and the reason therefore.
2. If the Sawmill is operating, shut it down by the normal stopping procedure.
3. Operate the switch and valve so that the energy sources are disconnected or isolated
from the Sawmill. Stored energy such as moving blades, feed system and air pressure
shall be dissipated.
4. Lockout the energy isolating devices with assigned individual locks.
5. After ensuring that no persons are exposed and as a check on having disconnected the
energy sources, operate the push button or other normal operating controls to make cer-
tain the Sawmill will not operate. Caution: Return operating controls to neutral position
after the test.
6. The Sawmill is now locked out.

Safety & General Information
Electric Sawmill
1
1-8 HD96doc041910 Safety & General Information
Restoring Equipment to Service
1. When the job is complete and the Sawmill is ready for testing or normal service, check
the Sawmill area to see that no one is exposed.
2. When the Sawmill is all clear, remove all locks. The energy isolating devices may be
operated to restore energy to the Sawmill.
Procedure Involving More Than One Person
In the preceding steps, if more than one individual is required to lock out the Sawmill,
each shall place his own personal lock on the energy isolating devices.
Rules for Using Lockout Procedure
The Sawmill shall be locked out to protect against accidental or inadvertent operation
when such operation could cause injury to personnel. Do not attempt to operate any
switch or valve bearing a lock.
Owner’s Responsibility
The procedures listed in this manual may not include all ANSI, OSHA, or locally required
safety procedures. It is the owner/operator’s responsibility and not Wood-Mizer Products
to ensure all operators are properly trained and informed of all safety protocols.
Owner/Operators are responsible for following all safety procedures when operating and
performing maintenance to the Sawmill.

Safety & General Information
Belt Sizes
Safety & General Information HD96doc041910 1-9
1
1.5 Belt Sizes
See Table 1-1. Belt sizes for the LT30HD/40HD and LT30HD/40HD Super are shown.
Description Belt Size Wood-Mizer Part #
15hp Electric Motor Drive Belt 2BX74 P10277-2
24hp Gas Engine Drive Belt 2BX74 P10277-2
20hp Electric Motor Drive Belt 3BX72 014085
25hp 60Hz Elec. Motor Drive Belt 3BX72 014085
25hp 50Hz Elec. Motor Drive Belt 3BX74 014249
35hp Gas Engine Drive Belt 3BX74 014249
40hp Diesel Engine Drive Belt 3BX72 014085
Alternator Belt (G24) A36 014514 1
1 For LT30HD and LT40HD Rev. F9+.
Alternator Belt (G24) A33 P11542 2
2 For LT30HD and LT40HD Rev. F8.
Alternator Belt (G35) A27 014250 3
3 A27 Belt replaces AX28 belt used prior to 7/96. Shorter belt allows for more ad-
justment.
Alternator Belt (E15/E20) A30 P11628
Alternator Belt (E25 60Hz) A25 4
4 014643 A25 Belt replaces P04031 4L280 belt originally supplied until Rev.
F9.01. Shorter belt allows for more adjustment.
014643
Alternator Belt (E25 50Hz) A27 014250
Blade Pulley Belts B57 5
5 To insure proper blade tracking, use Goodyear, Dayco Super II, or Browning
belts only.
P04185
Power Feed Drive Belt 4L280 P04031
Up/Down Drive Belt 4L280 P04031 1
Up/Down Drive Belt 3L290 P04349 2
TABLE 1-1

Safety & General Information
Blade Sizes
1
1-10 HD96doc041910 Safety & General Information
1.6 Blade Sizes
See Table 1-2. Wood-Mizer offers three types of blades to provide efficient sawing for all
models of sawmills. The engine/motor size of your sawmill and the type of wood you saw
should determine which blade you choose for optimum performance.
See The Wood-Mizer Blade Handbook for blade hook angle, tooth height, and tooth set
specifications.
Gas/Diesel
Engine Size Recommended Blade For Sawing:
Softwood Hardwood
5 hp - 14hp .042 x 7/8 x 1 1/4” .035 x 7/8 x 1 1/4”
16hp or more .045 x 7/8 x 1 1/2” .042 x 7/8 x 1 1/4”
.045 x 7/8 x 1 1/2” 1
1 Customer may choose preferred blade.
Electric Motor .045 x 7/8 x 1 1/2” .042 x 7/8 x 1 1/4”
.045 x 7/8 x 1 1/2” 1
TABLE 1-2
