Woodson Urn Models:
W.URN.10
W.URN.20
W.URN.30
Manufactured by:
Tom Stoddart Pty Ltd
39 Forest Way, Karawatha, QLD, 4117
Ph: 07 3440 7600 (int [phone])
Fax: [phone] (int [phone])

INSTALLATION,OPERATION & MAINTENANCE
Woodson Urns
–
W.U
RN
.xxx
Tel: [phone] Web: www.stoddart.com.au mail: [e-mail]
Due to continuous product research and development, the information contained herein is subject to change without notice
Page 1
Ta le of Contents
General Recommendations ............................................................................ 2
General Safety .............................................................................................. 2
Service ..................................................................................................... 2
Sharp dges ............................................................................................. 2
Power Cables ............................................................................................ 2
Introduction ................................................................................................. 3
General Precautions .................................................................................. 6
Setting Up ................................................................................................ 7
lectrical Connection ................................................................................. 8
Operation ..................................................................................................... 9
General Recommendations ........................................................................ 9
Operating Instructions ............................................................................. 10
After Hours ............................................................................................. 10
Over temperature cut-out ........................................................................ 10
Cleaning Procedure ................................................................................. 11
Maintenance ............................................................................................... 12
Routines ................................................................................................. 12
Stainless Steel Protection ......................................................................... 13
Water Damage ....................................................................................... 14
Replacements ......................................................................................... 15
Servicing and Replacement Information Line ............................................ 15
Troubleshooting .......................................................................................... 16
lectrical Diagrams ...................................................................................... 17
Warranty .................................................................................................... 18
Appendix 1 – Australian Warranty and Importer/Distributor Contact Details 18
Australian Warranty Policy & Procedure .................................................... 18
Warranty Request Form .......................................................................... 23

INSTALLATION,OPERATION & MAINTENANCE
Woodson Urns
–
W.U
RN
.xxx
Tel: [phone] Web: www.stoddart.com.au mail: [e-mail]
Due to continuous product research and development, the information contained herein is subject to change without notice
Page 2
Disclaimer:
The manufacturer cannot e held responsi le or lia le for any injuries or damages
of any kind occurred to persons, appliances or others, due to lack of conformity
with the instructions indicated in this documentation.
The manufacturer also cannot e held responsi le or lia le for a use, misuse and
lack of conformity with the instructions indicated in this documentation in regards
to installation, un-installation, operation, servicing or maintenance.
All appliances made y the manufacturer are delivered assem led and ready to
install. Any installation, un-installation, servicing, maintenance and access or
removal of any parts, panels or safety arriers that is not permitted, does not
comply in accordance to this documentation, or not performed y a TRAINED AND
AUTHORISED SPECIALISTS will result in the IMMEDIATE LOSS OF THE
WARRANTY.
The manufacturer cannot e held responsi le or lia le for any unauthorized
modifications. All modifications must e approved y the manufacturer in writing
efore initiating. All modifications or works performed to this appliance must e
performed at all times y a TRAINED AND AUTHORISED SPECIALIST.
General Recommendations
ATTENTION
Carefully read this instruction booklet, as it contains important advice for safe installation, operation and
maintenance. Keep this booklet on hand in a safe place for future reference by other operators or service
technicians.
Do not store or use gasoline or other flammable vapours or liquids in the vicinity of this or any other appliance.
Only qualified personnel, specifically trained in the following instructions, can perform installation and service of
the appliance:
General Safety
Service
Stoddart, one of our agents, or a similarly qualified person(s) should carry out any and all repairs, maintenance
and services. Any repair person(s) should be instructed to read the safety warnings within this manual before
commencing work on these units.
Do NOT remove any cover panels that may be on the appliance.
Sharp Edges
Steel cutting processes such as those used in the construction of this appliance result in sharp edges. Whilst any
such edges are removed to the best of our ability it is always wise to take care when contacting any edge.
Particular care should be taken to avoid contact with any steel edge, and warnings should be given in regards to
the danger of such contact to any repair or maintenance person(s) prior to commencement of any servicing.
Power Ca les
nsure that any damaged power cord is replaced before further use.

INSTALLATION,OPERATION & MAINTENANCE
Woodson Urns
–
W.U
RN
.xxx
Tel: [phone] Web: www.stoddart.com.au mail: [e-mail]
Due to continuous product research and development, the information contained herein is subject to change without notice
Page 3
Sight glass with
graduations indicating cup
capacity
ON / OFF switch
Over Temp Cut-out
Located under ase of unit
Filler tap
Carry handles
Twist lock lid
with steam vent
Heating &
Ready lights
Thermostat knob
Introduction
Woodson Urns has been specifically designed to meet the rigorous demands of a busy food service operation, but
is not meant to be used for continuous mass production of food.
ach Woodson Urn has been assembled and tested according to Stoddart’s strict quality standards.
Product Overview
Configuration may vary according to model.

INSTALLATION,OPERATION & MAINTENANCE
Woodson Urns
–
W.U
RN
.xxx
Tel: [phone] Web: www.stoddart.com.au mail: [e-mail]
Due to continuous product research and development, the information contained herein is subject to change without notice
Page 4
Specifications
Technical Specifications
SPECIFICATIONS
Model W.URN.10D W.URN.20D W.URN.30D
Height
48
8
mm
484
mm
613
mm
Diameter
300
mm
388mm 390mm
Voltage
220
-
240V, 50Hz
220
-
240V, 50Hz
220
-
240V, 50Hz
Power
2200W
2200W
2200W
Connection
10A Plug and L
ead
10A Plug and Lead
10A Plug and Lead
Amps
9.2
9.2
9.2
Capacity
10 Litres
20 Litres 30 Litres
35 cups (280ml)
70 cups (280ml) 105 cups (280ml)
