WOODWARD-FAB WFBR24P User manual

BEAD ROLLER MACHINE
MODEL: WFBR24P / WFBR36P / WFBR43
INSTRUCTION MANUAL
WOODWARD FAB
P.O BOX 425
HARTLAND, MI 48353
PHONE: [phone]
FAX: [phone]
EMAIL: [email protected]M
WEBSITE: WWW.WOODWARDFAB.COM

Save This Manual
You will need the manual for safety warnings and precautions, assembly instructions, operating and maintenance
procedures, parts list and diagram. Keep your invoice with this manual. Write the invoice number on the inside of
the front cover. Keep the manual and invoice in a safe and dry place for future reference.
SAFETY WARNINGS AND PRECAUTIONS
WARNING: When using tool, basic safety precautions should always be followed to reduce the risk of personal
injury and damage to the equipment. Read all instructions prior to use!
1. Keep work area clean. Cluttered areas invite injuries.
2. Observe work area conditions. Do not use machines in damp or wet locations. Do not expose to rain.
Keep work area well lighted.
3. Keep children away.
4. Store Idle Equipment. When not in use, tools must be stored in a dry location to inhibit rust and
corrosion. Always lock up tools and keep out of reach of children.
5. Use the right tool for the job. Do not attempt to force a small tool or attachment to do the work of a
larger industrial tool. There are certain applications for which this tool was designed. Do not modify
this tool and do not use this tool for a purpose for which it was not intended.
6. Dress Properly. Do not wear loose clothing or jewelry as they can be caught in moving parts.
Protective, electrically non-conductive clothing and non-skid footwear are recommended when
working. Wear restrictive hair covering to contain long hair. Wear proper hand protection when
handling sheet metal.
7. Use eye and ear protection. Always wear ANSI approved impact safety goggles. Wear a full face
shield if you are producing metal filings. Wear an ANSI approved dust mask or respirator when
working around metal, wood, and chemical dusts and mists.
8. Do not overreach. Keep proper footing and balance at all times.
9. Maintain tools with care. Keep tools sharp and clean for optimum safety and performance. Follow
instructions for lubricating and changing accessories.
10. Remove adjusting keys and wrenches. Check that all keys and wrenches are removed from tool or
machine work surface before operating.
11. Stay alert. Be aware of surroundings.
12. Check for damaged parts. Before using any tool, inspect all parts and equipment. Any part that
appears damaged or shows signs of wear should be taken out of service or replaced before use.
Check for alignment and binding of moving parts.
13. Replacement parts and accessories. When servicing, use only identical replacement parts. Use of any
other parts will void warranty. Use only accessories intended for use with this tool. Approved
accessories are available.
14. Do not operate the tool if under the influence of alcohol or drugs. Follow and observe warning
labels if taking prescription medicine.
15. Work piece may be sharp. After bending or cutting work pieces use caution. Be aware of sharp
edges, and use proper hand protection when handling the work piece.
WARNING: These warnings, cautions, and instructions outlined above and within this manual do not constitute all
of the possible conditions and situations that may occur. It must be understood that the operator of this tool be a
competent person, capable of using this tool in a proper and safe manner for which it is intended.

Machine Setup
1. Remove machine from packaging.
2. Assemble stand by bolting through the bottom of stand with the M12X60 allen bolt.
3. Then secure gusset from the top with (2) M8X16 bolts.
4. Place machine on top of the bead roller stand and secure using (2) M10X25 allen bolts.
5. Remove the shoulder bolt holding the aluminum handle to the bottom of the bead depth
adjuster.
6. Place the aluminum handle on top of the bead depth adjuster and secure using the shoulder bolt.
7. Remove the (2) M10X25 allen bolts and washers from the ends of the shafts.
8. Turn the bead depth adjuster counter-clockwise a few turns to allow room for the rolls to slide
onto the shafts.
9. Place the bead rolls on the shafts toward the machine. Either roll can be put either shaft, but we
usually recommend that the male type roll go on the top.
10. Secure the rolls to the shafts with the bolts removed in step #7 and snug them down.
11. Unwrap power cord and variable speed foot pedal.
12. Plug in the 110v volt power.
13. Machine is now ready for use.
Operation
1. Step down on the foot pedal to determine if the rolls are turning in the direction you are going to
feed the metal from.
2. Release the foot pedal.
3. If the rolls are not turning in the proper direction, flip the forward / reverse switch.
4. Now you are ready to set your bead depth. This step will require some experimentation to get the
proper depth so it is recommended that you use a scrap piece of the same material you want to
bead roll.
5. Do not start with the rolls completely closed as you may find that the rolls are too close together
and find it difficult to feed the material.
6. Lightly step down on the foot pedal and feed the metal in from the desired side of the machine.
The foot pedal controls the speed.
7. Turn the bead depth adjustment clockwise until you get the desired bead depth. Now you are
ready to bead roll your panel.
8. If you find that you need to change the direction of the rolls during a bead, release the foot pedal
before changing from forward to reverse.

Assembly Drawing

Parts List
