USER'S QUICK REFERENCE GUIDE
WEATHER COMPENSATION
CONTROLLER
FW 100
Please keep this guide for
future reference.
6 720 612 220-00.1R
6 720 617 764 (2008/09)
Dear customer,
Thank you for choosing a top-quality product
from our company.
The FW 100 offers everything you can expect
from a modern heating control: It is both relia-
ble and energy efficient.
Like all Bosch Group products, the FW 100 has
been manufactured and tested in accordance
with the most stringent quality standards so
that you can enjoy the Worcester warmth for a
long time to come.

Controls
1Turning rotary selector in +direc-
tion: scrolls menu/information up or
increases setting value/room temperature
Turning rotary selector in – direc-
tion: scrolls menu/information down or
decreases setting value/room tempera-
ture
Pressing rotary selector : opens
menu or confirms setting/value or
switches heating circuit
2Mode selector for heating circuits:
Automatic mode
Continuous Comfort
Continuous Economy
Continuous Frost
3: Brings forward the next switching
point and the associated operating mode
= Comfort, = Economy, = Frost
for the heating circuit to now.
4: Activate DHW heating immediately.
The domestic hot water cylinder is heated
to the desired temperature for 60 minutes
or, with combination boilers, Comfort
mode is activated for 30 minutes.
5: Open/close menu
6: Show settings
7: Delete/reset setting
8: Return to next menu up
advance
advance
menu
info
Fig. 1 Controls
6 720 617 763-01.1O
3
34
1
menu info
1
2
35
6
7
8
4
912 h15
18
21
24 h
3
6
advance advance
Symbols
Current room temperature
(only when wall-mounted)
Flashing segment:
Time now (between 09:30
and 09:45)
Solid segments: time set for oper-
ating mode = Comfort today or
domestic hot water On (or ≥50 °C)
(1 Segment = 15 min)
Blank segments: time set for oper-
ating mode = Economy today or
domestic hot water Off (or > 20 °C
and < 50 °C) (1 segment = 15 min)
No segments: time set for operat-
ing mode = Frost today or
domestic hot water ≤20 °C
(1 segment = 15 min)
Operating mode Comfort for heat-
ing circuit
Operating mode Economy for heat-
ing circuit
Operating mode Frost for heating
circuit
Automatic mode for heating circuit
Holiday mode
Burner operating
Back Return to next menu up
Other display information (menu
options) is available. They can be
viewed by turning the rotary selec-
tor .
