Workite ergonomics CONF-BSE-CCG-S Programming manual

1 of 3 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
ADesk Base Set Qty: 1
CCable Management Clip Qty: 1 DM3×6 mm Screws Qty: 2 H2.5 mm Allen Wrench
Qty: 1
I4 mm Allen Wrench Qty: 1
J5 mm Allen Wrench Qty: 1
GGrommet Bolt, Wing Nut & M8 Steel Washer

Qty: 1
EU-Bracket

Qty: 1
FHole Cover Cap Qty: 1
Parts Included
Assembly & Installation Instructions:
Conform C-Clamp & Grommet Base CONF-BSE-CCG-S
A Phillips head screwdriver and included Allen Wrenches.
If a grommet mount hole is required, you'll need a
drill and .375" bit.
Conform Monitor Arm.
Note:
If you plan to use C-Clamp Mount, proceed to Step 2.
If you plan to use Grommet Mount, proceed to Step 3.
Attach Cable Management Clip
Use M3 × 6 mm screws (D) to attach the Cable Management Clip (C) to
the Conform Base (A) with Phillips head screwdriver.
Required Parts Sold Separately Tools Required
BAdhesive Pad Qty: 1
Do not use on hollow core tables.
Do not exceed 48 lb.
1
D
C
A

2 of 3 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
C-Clamp Installation
Using 5 mm Allen wrench (J), loosen the C-Clamp bolt on
the Desk Base (A) wide enough to fit over the edge of the
worksurface.
Remove the Adhesive Pad (B) backing. Apply the pad
to the bottom surface of the base, adhesive side up, so
that it aligns with the front edge of the base and sticks
in place.
Place C-Clamp over the rear edge of the worksurface
Tighten the clamp by turning the C-Clamp Bolt clockwise,
using 5 mm Allen wrench (J) until secure.
2
b
c
b
c
d
a
d
a
Loosen
Tighten
Tighten
Loosen
J
J
A
A
B

3 of 3 Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Grommet Mount Installation
Note: A grommet hole or small hole is required in your worksurface to install
the grommet mount.
Drill a .375hole in worksurface if needed. The minimum distance from
the edge of the worksurface to the center of the grommet hole is 2.125"
The grommet mount can accommodate existing holes up to 3" in diameter.
Using 5 mm Allen wrench (J), loosen the C-Clamp bolt on the Desk Base (A)
to remove C-Clamp from the Base. Also remove the C-Clamp bolt.
Remove the pad's pre-punched hole and remove the adhesive cover. Apply
the adhesive side to the bottom of the Desk Base, aligned with the front
edge of Base, and stick in place.
Insert Grommet Bolt (G) through the adhesive pad's hole and into the Desk
Base (A). Tighten with 4 mm Allen Wrench (I).
Insert the installed Desk Base Bolt (G) through the grommet hole of worksurface.
Make sure the mount does not overlap the edge of the worksurface.
From under the worksurface, place the U-Bracket (E) onto the Grommet Bolt (G)
then place the M8 Steel Washer (G) followed by the Wing Nut (G) onto the Bolt
and tighten Wing Nut to secure the base to the desktop.
Insert Hole Cover Cap (F) to cover the C-Clamp bolt hole.
Ready for Arm Installation
You are now ready to attach your selected Conform Monitor Arm (sold separately).
#1500250 Rev E
≤2.125"
≤2.125"
a
3
4
c
f
e
d
E
b
b
c
d
e
f
a
g
g
J
Tighten
Tighten
Remove
Remove
A
Loosen
Hole
I
G
G
F
