WorkPro MULTIPLAYER 10 WEB User manual

Rev. 12.04.02
User Manual / Instrucciones de Usuario
MULTIPLAYER 10 WEB

Table of contents
Safety Information
Front Panel
Remote Control
Rear Panel
OPERATION
1. System Setting
2. Connecting to a network
2.5 Manual setting
3. Internet Radio
4. Music Player
5. FM Radio
ESPAÑOL
Pag. 2
Pag. 5
Pag. 6
Pag. 7
Pag. 8
Pag. 9
Pag. 10
Pag. 12
Pag. 14
Pag. 16
Pag. 18
ENGLISH Pag. 1
EN
1 User Manual/Manual de Uso MULTIPLAYER 10 WEB

Thank you for deciding on purchasing this quality product. The user manual will give you a general idea how
this device operates, as well as provide you with information on cleaning and safety procedures. Please take
a few minutes to read and follow all safety and operating instructions found in this manual carefully, in order
to maintain this product condition and ensure safe operation.
Dear customer,
Please adhere to all of the safety information/instructions found in this instruction
manual!
Explanation of symbols
An exclamation mark is intended to inform the user of important information, operati-
on or maintenance instructions or that special attention is required.
This symbol is intended to alert you to the presence of unprotected, live parts or com-
ponents found within the product’s enclosure or of dangerous connections that upon
contact may be of suficient magnitude to constitute a risk of electric shock. Cables
intended for such connections should only be connected by qualifed personnel or you
should only use ready to connect cables. There are no user-serviceable parts found
inside the device, therefore the device is never to be opened.
Before use
Please read this instruction manual thoroughly before operating this device and retain it for further
reference, questions and use. Following and heeding all information found in this instruction manual
shall maintain this products condition and ensure safe operation.
Safety Information
2 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

› In order to completely cut of the power supply to the device, unplug the power
plug from the wall outlet. Merely turning the device of with the ON/OFF button is
not sufcient enough. Make sure that receptacles are easily accessible.
We assume no liability for personal or property damage resulting from the failure
to comply with the safety instructions, improper operation and handling. Under
such circumstances, all claims under warranty will become void.
The following safety and hazard warnings are not only for the protection of your device, but also
serve as a protection against potential health hazards. Please take time to read the following
instructions carefully.
› For safety and licensing (CE) reasons any unauthorized modifcation and/or change
on the device is forbidden and will void the warranty and all warranty claims.
› Any persons operating, installing, setting up, or servicing this device must be trained
and qualifed accordingly and observe these operating instructions.
› Ensure that the device has been set up accordingly by following all instructions
› This is a protection class II device. Make sure that the voltage supply of the power
outlet used meets the required voltage specifications (230 V/50 Hz).
› Power supply cables should be routed so that they are not likely to be walked on,
squished or pinched by items placed upon or against them, paying particular attention
to cords at plugs, convenience receptacles, and the point at which they exit from
the device. Avoid exposing the cable to extreme heat or cold. Ignoring the above
mentioned could result in cable damage and present the dangerous risk of electric
found in the instruction manual.
› Should any evident damage be seen on the device or on the connection cables, do
not come in contact with or touch these. Switch of the corresponding circuit breaker
in the power distribution panel frst, before carefully unplugging the power plug from
the wall outlet. Do not operate this device further! Please contact or take it to a
qualifed service technician/specialty workshop.
shock.
3 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

› Unplug the device from the power outlet, if it is not in use for a longer period of time.
› For safety reasons, always unplug the device from the power outlet during thunder
storms.
› Eliminate potential tripping hazards by routing cables in such a way that no one can
trip or stumble over them.
› Never use the device, if the power cable or device is damaged.
This device is not suitable for children.
Small children are unaware of the serious and immediate dangers involved
when exposing themselves to or handling electronic devices. Furthermore,
this product contains small parts that could be swallowed.
› Keep packaging and protective foil away from children at all times to a void the dan-
ger of sufocation.
› The device should never come in contact with water or moisture.
› To prevent the risk of fire or electric shock make sure that liquids, such as dripping or
splashing water, rain or moisture, do not come in contact with the device and power
supply plug
› Operate this device in a moderate climate and never expose it to extreme tempera-
tures, such as high humidity.
›
›
Condensation can build up suddenly, when this device is brought from a colder
Make sure the device is properly ventiled during operation and never operate it in
into a warmer area (e.g. when transporting). Should this happen, allow the device to
constricted arerad, such as for example in a bookcase or shelf. Never block ventilation
warm up to room temperature first before using.
openings with magazines, curtains or similar.
› Always pull on the plug’s grips and never on the cable to remove from a wall outlet.
4 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

2. WHEN PLAY MODE IS TUNER, PRESS TO AUTO SCAN PREVIOUS STATION
WHEN PLAY MODE IS MEDIA PLAYER, PRESS TO SKIP TO PREVIOUS TRACK.
1. WHEN PLAY MODE IS TUNER , PRESS TO AUTO SCAN NEXT STATION,
WHEN PLAY MODE IS MEDIA PLAYER ,PRESS TO SKIP TO NEXT TRACK.
3. WHEN PLAY MODE IS TUNER ,PRESS TO SEE INFORMATION OF FM RDS
WHEN PLAY MODE IS MEDIA PLAYER, PRESS TO PLAY, PRESS AGAIN TO PAUSE.
4. PLAY MODE CHANGE. PRESS TO SELECT ONE MODE WITHIN FM, INTERNET RADIO,
MEDIA PLAYER.
5. MENU: PRESS TO GO TO MENU SCREEN
6. BACK : PRESS TO GO TO PREVIOUS MENU SCREEN
7. POWER SWITCH
8. ENCODER:
PRESS & HOLD TO STORE STATION OR FILE IN A PLAYLIST.
WHEN IN MENU SCREEN, TURN LEFT OR RIGHT TO MOVE MENU ITEM.
PRESS TO CONFIRM THE SELECTION.
9. STEREO/MONO AUDIO MODE SETTING FOR FM
10. USB JACK
Front panel
1 2
3
4
6 5 8 7 10 9
5 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

Remote control
+
-
INFO STEREO MONO MUTE
MODE
STANDBY
1
4
7
2
5
8
3
6
9
P 10 scan
enter
MENU
PRESET
+
-
enter
PRESET
NAVIGATION: Use these buttons to control the highlight line
in the menu using UP and DOWN arrows.
Use the right and left arrows to navigate between submenus.
ENTER: Use this button to confirm.
PLAY/PAUSE: Use this button to start and pause playbacks in media player
mode.
Skip forward & Skip back: Skip to the next or previous item in the
playback list (it does not work with Internet Radio).
Stop: Stop all playback.
Browse through the preset stations
MODE Browse through the modes (Internet Radio, FM Radio and Music
Player).
INFO More information about the current station (title, time).
STEREO Switch to stereo playback ( when activated it apprears in the screen
the next icon
MUTE Mute all audio output
1-10 Allows to select directly the saved station. If you want to save a new
station, hold the desired button 5 seconds until the screen shows
Preset Stored.
P Open Playlist or the radio stations list.
SCAN Starts automatic scan in the FM radio mode.
STANDBY Switch ON/OFF the device.
The remote control requires two "AAA" batteries for operation. Remove the battery compartment
lid carefully. Remove the used batteries and insert the news ensurig the correct polarity
6 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

Rear panel
1 2 3 4 5 6 7 8
1. MAIN SUPPLY: Connect the included Mains cable to supply the device. Connect it to a correct
voltage value outlet.
2. FUSE: Protection fuse (500 mA). If it blows, change it for the same type. If it blows again, stop to
use the device and contact with a technical to repair it.
3. OPTICAL OUTPUT: It allows a connecting with an optical compatible device.
4. OUTPUT LEVEL: Turn it clockwise to increase the output level. Turn it anticlockwise to reduce the
output level.
5. OUTPUT: 2x RCA connectors for unbalanced output. Connect them to a mixer system.
6. LAN: Connect the device to a network through a Cat-5 cable in order to use the Internet Radio or
Music Player functions.
7. WiFi ANTENNA: Connect the attached antenna in order to use the Internet Radio and Music Player
functions through a WiFi connection.
8. FM ANTENNA: Connect the attached antenna in order to use the FM Radio function.
7 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

1. System Setting
This configuration appears in the three operation modes (Internet Radio, Music Player and FM radio).
The options are the followings:
Equalizer >
Network >
Time/Date >
Language >
Factory Reset >
Software Update >
Setup wizard >
Info >
1.1 Equalizer: It is possible to select 8 prefixed tone controls between: Normal, Flat, Jazz, Rock, Movie,
Classic, Pop, News. It is possible to select the tone value manually (My EQ profile setup)
and to store it to select in the future (My EQ).
1.2 Network: Allow to configure a network (Wired or Wireless for Internet radio and Music Player). See the
Connecting to a Network section in this user manual for more information.
1.3 Time/Date: Allows to:
- Configure the Time/Date manually.
- Select the update way (FM, Network, No update)
- Select the format (12/24)
- Select the Time Zone
- Enable or Disable Daylight saving
1.4 Language: Allows to select English/German language.
1.5 Factory Reset: Delete all configuration, stored stations, etc. allowing to setup the device as new.
1.6 Software update: It is possible to setup the autocheking function to update the device software.
1.7 Setup Wizard: The device will be configured automatically in the next starting process.
1.8 Info: Show the software version in the display.
8 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

2. Connecting to a network
- You will need a network connection for "Internet Radio" and "Music Player" operating modes.
- You will need either a router and RJ 45 cable or a WLAN router together with the required password
to establish a connection to your network.
- Your router must have a broadband internet connection for "Internet Radio" operation and to perform
software updates.
- When you select "Internet Radio" or "Music Player" modes, your device will try to connect to a network.
If this is the first time that a connection has been made or stored network are not accesible, the the
"Network Wizard" will start. To start the "Network Wizard" manually, select the following:
MENU > System settings > Network > Internet Wizard
Using this function, the device will search an operative network, asking us about:
- WLAN region ( select a country or region from the list)
- Network name (select the desired network)
- An encrypted wireless network will require a password.
Use the navigation button or the dial encoder to move the cursor through the displayed fuctions.
Inside Network function you can also select:
2.1 Internet Wizard
2.2 PBC Wlan setup: Allow to setup a PBC (Push Button Configuration) Wlan connection. Follow the
displayed instructions.
2.3 View setting: After setup the network, this function offers informations about Active connection, MAC,
DHCP state, SSID, etc.
2.4 Wlan Region: Allows to select a country/region
2.5 Manual setting: Allows to setup the network configuration manually. You can select Wired or Wireless
network, modifying all parameters. Follow the displayed instructions.
2.6 Network Profile: All configurated network can be stored here and to select it again without setup it
again.
9 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

2.5 Manual Setting
If you need to setup the network connection manually, please, follow the next instructions:
In MENU > System settings > Network > Manual Setting
1. Select the preferred connection type:
Wired (via cable) or Wireless (via wireless network).
The following options are common in both connection types.
2. Select if the Direct Host Configuration Protocol (DHCP) is to be used:
DHCP enable > Activates use.
DHCP disable > Desactivates use
.
6. SSID
Set the Network Host Name. Use the key or encoder to select the letters and to
compose the correct name. Select BKSP in the display to delete a mistake. When you finish select
OK in the display.
7. Authentication
Set the preferred method of authentication
Open, PSK (Pre-Shared Key), WPA (Wi-Fi Protectred Access) or WPA2. Press SELECT to
continue.
8. Encryptation Type
Set the appropriate type. It depends on the previous Authentication selection:
Disabled & Wired Equivalent Privacy (WEP) for Open and PSK type
Temporal Key Integrity Protocol (TKPI) or Advanced Encryption Standard (AES) for WPA & WPA2.
9. Key
Now, enter the wireless network code. Use the key or encoder to select the characters
and to compose the correct password. Select BKSP in the display to delete a mistake. When you
finish, select OK in the display.
NOTE: If you have any doubt about network configuration, please, contact with your network
administrator to choose the adequate configuration.
10 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

3. IP Setting
Set the IP address and the Subnet mask. Use the key or encoder to select the numbers
Select BKSP in the display to delete a mistake. When you finish select OK in the display.
4. Gateway address
Set the Gateway address and the Subnet mask. Use the key or encoder to select the
numbers. Select BKSP in the display to delete a mistake. When you finish select OK in the display.
5. DNS
Set the primary and secondary DNS address. Use the key or encoder to select the
numbers. Select BKSP in the display to delete a mistake. When you finish select OK in the display.
NOTE :The previous point will we requested to us in case of dynamic IP network configuration.
If the network has a static IP, the device will request also the following points.
NOTE : You can use the options MENU > System settings > Network > Network Profiles to
delete an unwanted network. Here you will see a list of previously used wireless
network. Select a profile with the keys or use the encoder. Press "YES" to
confirm.
11 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

3. Internet radio
3.2 Station List
After to setup a network connection, you can select internet radio stations. Press MENU and
select Internet radio. This function has the next menu:
Last listened >
Station list >
System setting >
Main menu >
3.1 Last Listened: show the last radio stations selected.Use the keys or encoder to select the station.
When you finish push SELECT to confirm.
3.2 Station list: With this menu and its submenus, it is possible to select a radio station according to several
criteria (genre, country, etc). Check below for additional information.
3.3 System setting: See System setting section for more information
3.4 Main menu: Allow to select the operating function: Internet radio, Media player, FM radio. Use the
keys or encoder to select the station. When you finish push SELECT to confirm.
With this menu and its submenus, it is possible to select a radio station according to several criteria.
This functions has the next menu:
My favourites >
Local xxxxxx >
Stations >
Podcast >
MAC >
3.2.1 My favourites: Show the added station by the user in order to create a personalized list of radio
stations. For add a radio station, with the station operating ,simply hold press the encoder several second
until the display shows “Favourite added”.
12 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

3.2.2 Local xxxxx: Where "xxxxx" is the searched country when network setup. Pressing it we can select
the Highlighted stations and the genres presents in the selected country for an easy and fast mode.
3.2.3 Stations: We can select the radio stations according to some criteria as:
- Location: It allows to select the country where the radio stations is allocated.
- Genre: It allows to select the radio station according to several genre (pop, jazz, metal, etc).
The number of genres depends on the selected country.
- Search stations: It allows to find a station manually typing its name.
- Popular stations: It shows the mosr rated stations.
- New stations: It shows the most recent stations in internet.
3.2.4 Podcasts: We can select podcast according to some criteria as:
- Location: It allows to select the country where the podcast is allocated.
- Genre: It allows to select the podcast according to several genre (pop, jazz, metal, etc).
The number of genres depending on the selected country.
- Search stations: It allows to find a podcast manually typing its name.
13 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

4. Music Player
This operating mode allows to use audio files placed in an external media device. The options are the
followings:
Shared media >
USB playback >
My Playlist >
Repeat play >
Shuffle play >
Clear My playlist >
System settings >
Main menu >
4.1 Shared Media: With this option, the device found any media server, PC or similar connected in the same
network in order to play its audio files. When the PC detects MULTIPLAYER 10 WEB, it requests us
permission to share files and which folder must be shared.
After this point, MULTIPLAYER 10 WEB detects the PC or Media server. Press SELECT to confirm.
The next menu will appears in the display.
4.1.1 Music >
All music
Genre
All authors
.
.
.
Composer
Album
Rating
Playlist
Folders
>Search>
NOTE: These selection fields are the default fields in the files allocated in the server. If they are
filled will be more easy to make a good search and selection.
NOTE: These selection fields will be showed in the OS language installed in the media server
or PC.
4.1.2 Playlist >
All playlist >
Folders >
It allows to select the playlist or folder in an easy way.
14 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

4.2 USB Playback:
MULTIPLAYER 10 WEB allows to play files from an external device connected in the USB port. When
you connect a device here, the display show this window:
USB attached
Open folder?
Yes No
If you press Yes, the device will open the folders present in the USB device allowing to select the audio
files.
If you press No, you can open the folders later selecting this function Music player > USB playback
and the process will be the same: you can select the folder and the audio file to be played.
4.3 My playlist
As much shared media as USB playback functions, you can create a playlist with quick access to your
favorite audio files. In both cases, press hold the encoder up to save the audio file. In the window will
show Added to playlist.
4.4 Repeat play
It can be switch between On or Off to repeat the current audio file. Press SELECT to change.
4.5 Shuffle play
It can be switch between On or Off to play the files in randomize way. Press SELECT to change.
4.6 Clear my playlist
Press to delete the direct access to stored files in the playlist. The device request us Remove all
from My playlist, select Yes or No and press SELECT to confirm.
4.7 System setting: See System setting section for more information
4.8 Main menu: Allow to select the operating function: Internet radio, Media player, FM radio. Use the
keys or encoder to select the station. When you finish push SELECT to confirm.
15 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

5. FM Radio
MULTIPLAYER 10 WEB allows to listen commercial FM radio stations. Connect the included FM antenna
in the rear connector.
Select the FM Radio mode using the MODE button:
Main Menu > Radio FM
Pressing the MENU button, appears the following options:
Scan setting >
Audio setting >
System settings >
Main menu >
5.1 Scan setting: Pressing SELECT will show the next message in the display: Strong stations only?
Yes/No. Selecting Yes, the device will scan the FM band choosing the stations with better reception level.
5.2 Audio setting: Pressing SELECT will show ihe next message in the display: Listen in mono only?
Yes/No. Selecting Yes, the device will work in mono mode. This feature can be changed after using frontal
buttons.
5.3 System setting: See System setting section for more information.
5.4 Main menu: Allow to select the operating function: Internet radio, Media player, FM radio. Use the
keys or encoder to select the station. When you finish push SELECT to confirm.
Selecting radio stations
Manually
Turn the encoder in clockwise sense to increase in 50 kHz the showed frequency and counterwise sense
to reduce the frequency in the same quantity.
If you want to select station from remote control, use the keys for increase or reduce the frequency
in the same way.
Auto scan
Use the key Tune + & - the search stations forwards and backwards. Depending on the configurated state
in scan setting function, the device will show radio stations with better reception level.
If you want to scan station from remote control, use the keys for increase or reduce the frequency
in the same way.
16 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

Storing & Saving radio stations
In the remote control, press & hold the number when you want to store the station until the display shows
Preset stored. It is possible to store up to 10 stations.
If you want to select any stored station, from remote control, use the keys where the chosen station is
stored.
If you want select any stored station from the device, first, press P button in the remote control. The display
will show all stored stating. Now, turn the enconder until the desired station and press SELECT.
This selection process can be make from the remote control using the keys after to press P button.
Info
Pressing the INFO button in the device or in the control remote, the display will show information concerning
to the station. This information depending on the station, therefore, it will we more extens in some stations
than others.
17 User Manual/Manual de Uso MULTIPLAYER 10 WEB
EN

Tabla de Contenidos
Información de Seguridad
panel Frontal
Control Remoto
Panel Trasero
FUNCIONAMIENTO
1. Configuración (System Setting)
2. Conectando a una red
2.5 Configuración Manual
3. Internet Radio
4. Music Player
5. FM Radio
Pag. 19
Pag. 22
Pag. 23
Pag. 24
Pag. 25
Pag. 26
Pag. 27
Pag. 29
Pag. 31
Pag. 33
ENGLISH
ESPAÑOL
Pag. 1
Pag. 18
18 User Manual/Manual de Uso MULTIPLAYER 10 WEB
ES

Estimado cliente,
Explicación de los símbolos
Antes de usarlo
Información de Seguridad
Gracias por su decisión de adquirir este producto de calidad. Este manual de usuario le proporcionará una idea
general del modo de funcionar de este dispositivo, así como proporcionar información sobre sus limpieza y
procedimientos de seguridad. Por favor, tómese unos minutos para leer y seguir todas las instrucciones de seguridad
y uso que se encuentran en el manual con el fin de mantener las condiciones del producto y asegurar un uso eficiente.
Por favor, siga todas las instrucciones/informaciones de seguridad que se encuentran en este manua.
Un signo de exclamación se usa para indicar al usuario de una información importante de uso o
mantenimiento o que se requiere una especial atención.
Este símbolo permite alertar al usuario de la presencia de elementos desprotegidos dentro del recinto del
producto o de conexiones peligrosas cuyo contacto puede significar un riesgo de descarga eléctrica. Los
cables para estas conexiones deben ser conectados por personal cualificado. No hay elementos de control
para el usuario en su interior, así pues nunca debe ser abierto.
Por favor, lea este manual de uso concienzudamente antes de hacer funcionar este dispositivo y consérvelas para
futuras referencias, preguntas y uso. Sigua y tenga presente toda la información que se encuentra en este manual de
instrucciones para conservar el dispositivo en buenas condiciones de uso y seguridad.
19 User Manual/Manual de Uso MULTIPLAYER 10 WEB
ES
