Workrite PA4000 User manual

Workrite Ergonomics | 800.959.9675 www.workriteergo.com
#1500155 - Rev C
PA4000 - Poise Twin Assembly Instructions
(PA3000 - Poise - Heavy Duty Arm + PATWIN-B Wing Bracket)
Use these instructions for the monitor attachment step on page 5 of the Poise Heavy Duty instructions.
AWing Bracket Qty: 1 CM4x10mm Screw Qty: 12
Attach Wing Bracket to Poise Arm
Remove Mounts (B) from Wing Bracket (A), then attach
Wing Bracket to the Poise - Heavy Duty forearm VESA 100
Mount using the four M4x10mm screws (C) (horizontal
orientation shown). Be sure to tighten securely. Attach
M4x8mm screw and washer (E) to lock pivot.
BMonitor Mount Qty: 2
DM4x6mm Screw Qty: 10
Note: It is strongly recommended to use the mounting screws provided by the monitor manufacturer. Due to the variety of monitor
mounting designs, the mounting holes at the back of the monitor might not be suitable for the M4 screws we have provided and could
cause damage to the Monitor.
!
1 2 Determine Mounting Conguration
There are ve possible recommended congurations for
mounting - three with a horizontal orientation and two with
a vertical orientation. Choose the conguration you wish to
use, then orient your Mounts accordingly.
EM4x8mm Screw and Washer
Qty: 1 each
Horizontal
Vertical
When using
horizontal
orientation, be
sure Mounts
are positioned with two
fasteners at the top.
!
FM4x18mm Screw Qty: 8
G ⅜" Nylon Spacer Qty: 8
Vertical
Horizontal
C
E
A
E

Workrite Ergonomics | 800.959.9675 www.workriteergo.com
Assembly Instructions for Workrite Poise™ Twin #1500155 - Rev C
Attach Monitors to Wing Bracket
Slide the Monitor Mounts on to the Wing Bracket (A) and
tighten the clamp knob. Adjust as needed to center the
monitors. Tighten
Loosen
Secure
Install two M4x6mm screws (D) into the ends of the Wing
Bracket (A) to prevent the monitors from sliding off the
Wing Bracket during use.
To adjust your monitor arm, see the section titled Arm
Adjustments in your Poise - Heavy Duty Assembly
Instructions.
4
5
3Secure Mounts to Monitors
Attach each Mount (B) to the monitors with four M4 screws
(C, D or F). Use parts F and G for Dell monitors or other
monitors with recessed mounting area. The tabbed side of
the mount should point toward the opposite monitor.
B
G
CDF
or or D
D
