Workzone Titanium WG20V User manual

Xfinity Li-ION 20V
Instruction Manual
IMPORTANT
Read carefully before use
Keep for future reference
MODEL NUMBER
* BATTERY NOT INCLUDED
WG20V
Version number: 005
Pressure Spray Gun Skin
• 1 x 20V Spray Gun Skin
•
1 x Extension Lance and
Nozzle Adapter
•
2 x Spray Nozzle(0ºand 25º)
• 1 x Hose Clip
• 1 x 6m Hose with Floater
and Hose Filter
• 1 x Carry Bag
• 1 x Instruction Manual
• 1 x Warranty Card

2
2
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
Welcome
Congratulations in choosing to buy a Workzone®Titanium 20V Spray
Gun (battery / charger not included).
All products bought to you by Workzone®Titanium are manufactured
to the highest standards of performance and safety and, as part of our
philosophy of customer service and satisfaction, are backed by our
comprehensive 5 Year Warranty. We hope you will enjoy your purchase
for many years to come.
When you open your packaging, rst remove all items and check there
are no parts damaged or missing. If you nd anything wrong, do not
operate the product until the parts have been replaced or the fault has
been rectied. Failure to do so could result in serious personal injury.

3
3
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
Contents
Application 4
Package Content List 4
Parts description 5
Description of symbols 6
Product Safety 7
Safety Warnings for battery pack 8
General Safety Warnings for Battery Charger 9
Important information – Product care 11
Operating instructions 12
Maintenance 16
Warranty 17
Troubleshooting 20
Technical Specications 22

4
4
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
1. Application
SPRAY GUN - WG20V
2. Package Content List
First time users or inexperienced operators pay particular attention to the
operation of the 20V Spray Gun, including details of starting and stopping
and correct use of the 20V Spray Gun on pages 13-16, as well as the
maintenance instructions on pages 17.
Intended use of the 20V Spray Gun(battery / charger not included)
NOTE: This product is for private domestic DIY use only.
It is not suitable for commercial or trade use.
This 20VSpray Gun is used for cleaning and watering / water spraying in a
domestic environment. Use the 20V Spray Gun only for intended applications.
1 x 20V Spray Gun Skin
1 x Extension Lance and Nozzle Adapter
2 x Spray Nozzle(0º and 25º)
1 x Hose Clip
1 x 6m Hose with Floater and Hose Filter
1 x Carry Bag
1 x Instruction Manual
1 x Warranty Card
• Remove all packing
materials
• Ensure all parts on the
contents list are present
• Check the appliance,
and all accessories for
transportation damages
WARNING! Please read and understand this instruction manual
before use and keep it for your future reference. Your product
should only be passed on together with this instruction manual.
WARNING! To reduce risk of injury, only use ALDI 20V Xnity Plus
battery packs. Other type of battery packs may burst causing personal
injury and damage. The battery pack must be recharged only with an
ALDI 20V Xnity Plus battery charger.

5
5
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
3. Parts description
1. Lock-o switch
2. On/o switch lever
3. Hose adapter
4. 20V Battery pack (not included;
shown only for illustrative and
instructional purposes only)
5. Battery pack release button
6. Power nozzle
7. Extension lance
8. Nozzle adapter
9. Spray nozzle (0ºand 25º)
10. Hose clip
11. Hose (6m)
12. Floater
13. Hose lter
14. Hose connector
15. Carry bag
16. Filter screen (Fig E2)
17. 20V Charger (not included; shown
only for illustrative and instructional
purposes only)
9
12 13
14
7
6
5 4
4
17
3
9
10
11
2
1
8
15

6
6
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
4. Description of symbols
The instruction manual, rating plate, or on the product itself, may
show these symbols. These represent important information about
the product or instructions on its use.
Caution/Warning:
Read all safety warnings and all instructions.
Read the instruction manual.
RCM marking. Conforms to relevant standards for electrical
safety and electromagnetic compatibility.
Remove battery pack from the spray gun before carrying out
any adjustment, servicing or maintenance.
60 Month Warranty Period.
Waste electrical products should not
be disposed of with household waste.
Machine not suitable for connection to the potable water
mains.
60

7
7
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
5. Product Safety
General safety warnings
WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
- Children should be supervised to ensure that they do not play
with the appliance.
- The appliance is only to be used with the power supply unit
recommended with the appliance.
- Liquid or steam must not be directed towards equipment
containing electrical components, such as the interior of ovens.
Safety warnings for battery-operated appliances
1. Non-rechargeable batteries are not to be recharged.
2. Rechargeable batteries are to be removed from the appliance
before being charged.
3. Different types of batteries or new and used batteries are not to
be mixed.
4. Batteries are to be inserted with the correct polarity.
5. Exhausted batteries are to be removed from the appliance and
safely disposed of.
6. If the appliance is to be stored unused for a long period, the
batteries should be removed.
7. The supply terminals are not to be short-circuited.
8. Use only compatible ALDI Xfinity 20V charger and batteries with
this appliance (not supplied).

8
8
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
6. Safety Warnings for battery pack
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery
packs haphazardly in a box or drawer where they
may short-circuit each other or be short-circuited by
conductive materials. When battery pack is not in use, keep it
away from other metal objects, like paper clips, coins, keys, nails,
screws or other small metal objects, that can make a connection
from one terminal to another. Shorting the battery terminals
together may cause burns or a fire.
c) Do not expose battery pack to heat or fire. Avoid storage
in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid
to come into contact with the skin or eyes. If contact has
been made, wash the affected area with copious amounts
of water and seek medical advice.
f) Seek medical advice immediately if a cell or battery pack
has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if
they become dirty.
i) Battery pack needs to be charged before use. Always
refer to this instruction and use the correct charging
procedure.
j) Do not maintain battery pack on charge when not in use.
k) After extended periods of storage, it may be necessary
to charge and discharge the battery pack several times to
obtain maximum performance.
l) Battery pack gives its best performance when it is
operated at normal room temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep battery packs of
different electrochemical systems separate from each

9
9
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
other.
n) Recharge only with the charger specified by
manufacturer. Do not use any charger other than that
specifically provided for use with the equipment.
A
charger that is suitable for one type of battery pack may create
a risk of fire when used with another battery pack.
o) Do not use any battery pack which is not designed for
use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future reference.
r) Remove the battery from the equipment when not in use.
s) Dispose of properly.
t) Use only compatible ALDI Xfinity 20V batteries with this
appliance (not supplied).
7. General Safety Warnings for Battery Charger
WARNING Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in
electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
- This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
- Children should be supervised to ensure that they do not play
with the appliance.
Additional safety instructions for your Battery Charger
1. Before charging, read the instructions.
2. For charging Li-ion battery pack only.
3. Do not charge a leaking battery.

10
10
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
4. Do not use chargers for works other than those for which they
are designed.
5. Before charging, ensure your charger is matching the local AC
supply.
6. The charging device must be protected from moisture.
7. Do not use the charging device in the open.
8. Do not short out the contacts of battery or charger.
9. Respect the polarity “+/-“ when charging.
10. Do not open the unit and keep out of the reach of children.
11. Do not charge the batteries of other manufactures or ill-suited
models.
12. Ensure that the connection between the battery charger and
battery is correctly positioned and is not obstructed by foreign
bodies.
13. Keep battery charger’s slots are free of foreign objects and
protect against dirt and humidity. Store in a dry and frost-free
place.
14. When charging batteries, ensure that the battery charger is in
a well-ventilated area and away from inflammable materials.
Batteries can get hot during charging. Do not overcharge
any batteries. Ensure that batteries and chargers are not left
unsupervised during charging.
15. Do not recharge non-rechargeable batteries, as they can
overheat and break.
16. Longer life and better performance can be obtained if
the battery pack is charged when the air temperature is
between 18ºC and 24ºC. Do not charge the battery pack in air
temperatures below 4.5ºC, or above 40.5ºC. This is important as
it can prevent serious damage to the battery pack.
17. Charge only battery pack of the same model recommended
by the manufacturer and of models recommended by
manufacturer.

11
11
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
18. Use only compatible ALDI Xfinity 20V chargers with this
appliance (not supplied).
8. Important information – Product care
NOTE: Xfinity Battery and Charger not included. For any issues
related directly to your purchased ALDI Xfinity Battery / charger,
contact the Customer Service of the manufacturer as listed on the
battery / charger packaging, manual or on the label on the battery /
charger.
This Spray Gun uses Lithium Ion Battery Cells. Care MUST be taken
to ensure both the safety and life of the pack is maintained. Ensure
you have read all of the safety notes in the previous pages before
using the Spray Gun. Treat the battery pack with care and within the
guidelines of this manual and the supplied manual included with
the purchase of ALDI Xfinity Batteries.
If the battery pack does become immersed in water or any fluids,
or is subject to a severe drop or it does not operate within the
guidelines of this manual or the supplied manual included with
the purchase of ALDI Xfinity Batteries, immediately STOP using the
battery pack and have it checked.

12
12
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
9. OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the instruction book
carefully.
BEFORE OPERATION
NOTE: The tool is compatible with ALDI 20V Xfinity batteries and
chargers. Xfinity Battery pack and charger is not included with this
product; it is shown only for illustrative and instructional purposes
only.
1. To attach the battery align the grooved guide rails of the
battery pack (4) with the raised guide rails on the bottom of
the spray gun. A click will be heard when the battery pack (4) is
engaged correctly (Fig A1).
2. Removing the battery pack (4). Press down the battery release
button and pull the battery pack (4) away from the unit (Fig A2).
3. Charging the battery pack (4) (Fig A3).
ASSEMBLY
1. Attaching extension lance (7) to the power nozzle (6) (Fig B).
NOTE: When attaching, align the two projections on the
extension lance (7) with the grooves of the power nozzle (6),
then push the nozzle in and rotate in a clockwise direction to
engage the lance securely.
2. Attaching the spray nozzle (9) (Fig C).
NOTE: When attaching, gently pull the spray nozzle (9) to make
A1 A2 A3
1
2REMOVE
INSTALL

13
13
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
sure it is locked into position securely.
NOTE: Choose a suitable nozzle according to your work. The 0°
spray nozzle is applicable for cleaning, and the 25° spray nozzle
is most suitable for watering.
3. Attaching the 6m hose (11) to the power nozzle (6) (Fig D1 D2).
NOTE: After the 6m hose (11) is attached, check the connection
by gently pulling the 6m hose (11). It should not be able to be
removed or pulled off from the power nozzle (6).
4. Attaching your own water hose (optional). Firstly, remove the
hose adapter (3) (Fig E1 E2), then attach your home garden hose
with suitable connectors (Fig E3).
WARNING: It is not recommended to connect the 6m hose
(11) to your garden hose or your home tap.
NOTE: Except for the 6m hose (11) supplied, you can also
connect the power nozzle to your own water hose with suitable
connectors.
B C
1
2
1
2
D1 D2

14
14
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
NOTE: Check whether the hose filter (13) screen is missing
before retightening the hose adapter (3) (Fig E2). When
retightening the hose adapter (3), tighten securely (using a
17mm spanner, not supplied). Otherwise, it may not draw any
water for proper operation.
OPERATION
1. Starting and stopping the Spray Gun (Fig F).
NOTE: At the first use, you need to remove any air in the 6m
hose (11) by placing the power nozzle (6) below waist level
(<1.5m), then attaching the extension lance (7) and starting the
spray gun by pressing in the Lock-off switch (1) firstly and the
On/off switch lever (2) Secondly. It will not start working until
the water goes up along the 6m hose (11) and sprays out. This
could take up to 30 seconds or more depending on the fresh
water source. To stop the spray gun, release the On/off switch
lever (2).
E1 E2 E3
F
2
1
Suitable
Connector
16

15
15
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
G H I
2. Watering (Fig G).
NOTE: It is recommended to use the 25° spray nozzle for
watering.
3. Cleaning (Fig H I).
WARNING: Do not connect the spray gun to water supplies
that are dirty, rusty, muddy, or corrosive. (Including window
cleaning liquids, plant foods, or fertilizers etc.)
NOTE: Not recommended for use with salt water; immediately
rinse with fresh water for proper maintenance.
4. Residual risk
Even if you use the 20v Spray Gun properly per the instructions
provided and following all safety notes, there are always
residual risks. The following risk may occur:
- Accidental Starting: Always remove the battery pack from the
spray gun before carrying out any adjustment, servicing or
maintenance. When not in use, store the battery in a safe, dry,
clean environment.
- Risk of fluid injection: Do not direct the output of the spray
gun at any person, the operator, or any animals. Never place
hands in front of nozzle, direct spray away from self or others,
and always operate in an area clear of all persons, pets and
obstacles. Do not operate the product when fatigued or under
the influence of alcohol or drugs, stay alert at all times.
Reduce residual risks by using the 20v Spray Gun with care and
following all safety notes as well as other instructions.

16
16
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
10. Maintenance
Cleaning
Clean the case only with a damp cloth. DO NOT use solvents when
cleaning plastic parts. Plastics are susceptible to damage from
various types of commercial solvents and may be damaged by their
use. Use a clean cloth to remove dirt, dust, oil, grease etc, then dry
well.
Battery Maintenance
To maintain battery capacity, always refer to the specific instructions
in the supplied manual included with the purchase of ALDI Xfinity
Batteries. It is recommended to recharge your battery every two
months. Store only fully charged batteries. They should therefore be
recharged from time to time. The place of storage must be dry.
CAUTION! Electrical and battery operated units that no longer work
should not be disposed of in the household waste! They are to be
collected separately, in accordance with your local waste disposal
regulations.
ATTENTION! Batteries must be removed from battery powered
tools and disposed of separately in accordance with relevant waste
battery regulations.
Batteries must never be disposed of with domestic waste!
Please discard power tools no longer usable at a local collection
point. Collection and disposal of packaging materials separately by
types complying with local rules and regulations. For details, please
contact your local council.

17
17
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
11. Warranty
Environmental protection
Your new WORKZONE®TITANIUM 20V Spray Gun will more than
satisfy your expectations.
It has been manufactured under stringent WORKZONE®TITANIUM
Quality Standards to meet superior performance criteria.
You will find your new 20V Spray Gun easy and safe to operate, and,
with proper care, it will give you many years of dependable service.
CAUTION. Carefully read through this entire instruction manual
before using your new WORKZONE®TITANIUM 20V Spray Gun.
Take special care to heed the Cautions and Warnings.
Your WORKZONE®TITANIUM 20V Spray Gun has many features
that will make your job faster and easier. Safety, performance, and
dependability have been given top priority in the development of
this 20V Spray Gun, making it easy to maintain and operate.
Use only WORKZONE®TITANIUM replacement parts for your
product.
Non-conforming parts or modifications made to parts will void your
warranty.
Recycle unwanted materials instead of disposing of them
as waste. All tools, hoses and packaging should be sorted,
taken to the local recycling centre and disposed of in an
environmentally safe way.

18
18
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
What your 5 year warranty means
Great care has gone into the manufacture of this product and it
should therefore provide you with years of good service when used
properly. In the event of product failure within its intended use over
the course of the first 5 years after the date of purchase, we will
remedy the problem as quickly as possible once it has been brought
to our attention. In the unlikely event of such an occurrence, or if
you require any information about the product please contact us via
our after sales support services, details of which can be found in this
manual and on the product itself.
After Sales Support TEL: [phone]
Service Support
If you have any issues with the operation of your product, please call
us on 1300 889 028 for advice, or email us at
[email protected]

19
19
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
1. 63349-EL and NA:
Extension Lance and
Nozzle Adapter
5. 63349-CB: Carry
Bag
4. 63349-6H and HF:
6m Hose with Floater
and Hose Filter
3. 63349-HC: Hose
Clip
2. 63349-SN: Spray
Nozzle (0º and 25º)
Accessories and After Sales Parts
The following is available for purchase by visiting https://help.tools/
or calling our customer service hotline on: 1300 889 028

20
20
AFTER SALESSUPPORT
1300 889 028 (toll free) e-mail:
MODEL No.:
[email protected]
WG20V • 63349 • 01/2019
12. Troubleshooting
Symptom Possible causes Solution
Spray Gun
turns on but
does not draw
any water,
or there is
not sufficient
pressure.
Power nozzle (6) is too
high from the water
source surface.
Lower the spray gun below
1.5m.
Hose filter (13) is blocked. Take out the hose filter (13) and rinse the parts with clean
water. (See Fig. J1, J2)
The garden hose is not
well connected to the
machine.
Check and reattach the
garden hose tightly. (See Fig.
D2)
Hose adapter (3) loose. Tighten the hose adapter (3) securely with a spanner (not
supplied).
The hose filter (13) screen
is missing or damaged.
(See Fig. E2)
Contact Customer Service on
1300 889 028 for replacement
or purchase of this filter.
Pump, hose, or other parts
are frozen due to outside
temperatures.
Wait for the pump, hose or
other parts to thaw.
Hose kinks. Straighten out the 6m hose (11).
Additional air be sucked
into the spray gun.
Remove the pressure
extension lance (7) to
eliminate the air, or remove
the spray nozzle (9) to drain
all the water completely. Then
reattach the extension lance
(7) or the spray nozzle (9).
J1 J2
