Worx Nitro LEAFJET WG543E User manual

SAFETY AND OPERATING MANUAL
ORIGINAL INSTRUCTIONS
20V Cordless Blower
WG543E WG543E.X

32
20V Cordless Blower
WG543E WG543E.X
ORIGINAL INSTRUCTION
PRODUCT SAFETY
WARNING: Read all
safety warnings and all
instructions. Failure to follow
the warnings and instructions
may result in electric shock, fire
and/or serious injury.
Save all warnings and
instructions for future
reference.
The appliance is only to be
used with the power supply unit
provided with the appliance.
GENERAL POWER TOOL
SAFETY WARNINGS
The term “power tool” in the
warnings refers to your mains-
operated (corded) power tool
or battery-operated (cordless)
power tool.
1)Work area safety
a)Keep work area clean and
well lit. Cluttered or dark
areas invite accidents.
b)Do not operate power
tools in explosive
atmospheres, such as in
the presence of flammable
liquids, gases or dust.
Power tools create sparks
which may ignite the dust or
fumes.
c)Keep children and
bystanders away while
operating a power tool.
Distractions can cause you to
lose control.
2)Electrical safety
a)Power tool plugs must
match the outlet. Never
modify the plug in any
way. Do not use any
adapter plugs with
earthed (grounded) power
tools. Unmodified plugs and
matching outlets will reduce
risk of electric shock.
b)Avoid body contact with
earthed or grounded
surfaces, such as pipes,
radiators, ranges and
refrigerators. There is an
increased risk of electric
shock if your body is earthed
or grounded.
c)Do not expose power tools
to rain or wet conditions.
Water entering a power
tool will increase the risk of
electric shock.
d)Do not abuse the cord.
Never use the cord for
carrying, pulling or
unplugging the power
tool. Keep cord away from
heat, oil, sharp edges or
moving parts. Damaged or

20V Cordless Blower
WG543E WG543E.X
32
entangled cords increase the
risk of electric shock.
e)When operating a power
tool outdoors, use an
extension cord suitable
for outdoor use. Use of a
cord suitable for outdoor use
reduces the risk of electric
shock.
f) If operating a power
tool in a damp location
is unavoidable, use a
residual current device
(RCD) protected supply.
Use of an RCD reduces the
risk of electric shock.
3)Personal safety
a)Stay alert, watch what
you are doing and use
common sense when
operating a power tool. Do
not use a power tool while
you are tired or under the
influence of drugs, alcohol
or medication. A moment of
inattention while operating
power tools may result in
serious personal injury.
b)Use personal protective
equipment. Always
wear eye protection.
Protective equipment such
as dust mask, non-skid
safety shoes, hard hat, or
hearing protection used for
appropriate conditions will
reduce personal injuries.
c)Prevent unintentional
starting. Ensure
the switch is in the
off-position before
connecting to power
source and/or battery
pack, picking up or
carrying the tool. Carrying
power tools with your finger
on the switch or energising
power tools that have the
switch on invites accidents.
d)Remove any adjusting key
or wrench before turning
the power tool on. A wrench
or a key left attached to a
rotating part of the power
tool may result in personal
injury.
e)Do not overreach. Keep
proper footing and
balance at all times. This
enables better control of the
power tool in unexpected
situations.
f)Dress properly. Do not
wear loose clothing or
jewellery. Keep your hair,
clothing and gloves away
from moving parts. Loose
clothes, jewellery or long
hair can be caught in moving
parts.
g)If devices are provided

54
20V Cordless Blower
WG543E WG543E.X
for the connection of dust
extraction and collection
facilities, ensure these are
connected and properly
used. Use of these devices
can reduce dust-related
hazards.
4)Power tool use and care
a)Do not force the power
tool. Use the correct
power tool for your
application. The correct
power tool will do the job
better and safer at the rate
for which it was designed.
b)Do not use the power tool
if the switch does not turn
it on and off. Any power tool
that cannot be controlled
with the switch is dangerous
and must be repaired.
c)Disconnect the plug from
the power source and/
or the battery pack from
the power tool before
making any adjustments,
changing accessories, or
storing power tools. Such
preventive safety measures
reduce the risk of starting the
power tool accidentally.
d)Store idle power tools out
of the reach of children
and do not allow persons
unfamiliar with the power
tool or these instructions
to operate the power tool.
Power tools are dangerous in
the hands of untrained users.
e)Maintain power tools.
Check for misalignment
or binding of moving
parts, breakage of parts
and any other condition
that may affect the
power tool’s operation. If
damaged, have the power
tool repaired before use.
Many accidents are caused
by poorly maintained power
tools.
f)Keep cutting tools sharp
and clean. Properly
maintained cutting tools with
sharp cutting edges are less
likely to bind and are easier to
control.
g)Use the power tool,
accessories and tool bits
etc. in accordance with
these instructions, taking
into account the working
conditions and the work
to be performed. Use of
the power tool for operations
different from those intended
could result in a hazardous
situation.
5)Battery tool use and care
a)Recharge only with the

20V Cordless Blower
WG543E WG543E.X
54
charger specified by the
manufacturer. A charger
that is suitable for one type
of battery pack may create
a risk of fire when used with
another battery pack.
b)Use power tools only with
specifically designated
battery packs. Use of any
other battery packs may
create a risk of injury and fire.
c)When battery pack is not
in use, keep it away from
other metal objects, like
paper clips, coins, keys,
nails, screws or other
small metal objects, that
can make a connection
from one terminal to
another. Shorting the
battery terminals together
may cause burns or a fire.
d)Under abusive conditions,
liquid may be ejected from
the battery; avoid contact.
If contact accidentally
occurs, flush with water.
If liquid contacts eyes,
additionally seek medical
help. Liquid ejected from the
battery may cause irritation
or burns.
6)Service
a)Have your power tool
serviced by a qualified
repair person using only
identical replacement
parts. This will ensure that
the safety of the power tool is
maintained.
ADDITIONAL SAFETY
WARNINGS FOR CORDLESS
BLOWER
- This appliance is not intended
for use by persons (including
children) with reduced physical,
sensory or mental capabilities,
or lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
- Children should be supervised
to ensure that they do not play
with the appliance.
The device is designed only
for the blowing of dry leaves
in private households and as
a hobby device in the garden.
Any other utilization, which is
not explicitly approved in these
directions, can lead to damage
to the device and represent a
serious danger to the user.
-The device is designed for use
by adults. Young people over 16
years may use the device under

76
20V Cordless Blower
WG543E WG543E.X
supervision only.
-The use of the device in the
rain or in a humid environment
is forbidden.
-The manufacturer is not liable
for damage which is caused
through inappropriate use or
incorrect operation.
Note: Do not employ and low
power machines for heavy
work. DO NOT use your device
for purposes for which it has
not been designed.
WARNING: To reduce
the risk of injury, user
must read and understand
instruction manual.
1) Training
a) Read the instructions
carefully. Be familiar with the
controls and the proper use
of the appliance;
b) Never allow children to use
the appliance.
c) Never allow people unfamiliar
with these instructions to
use the appliance. Local
regulations may restrict the
age of the operator;
d) Never operate the appliance
while people, especially
children, or pets are nearby;
e) The operator or user is
responsible for accidents or
hazards occurring to other
people or their property.
2) Preparation
a) While operating the
appliance, always wear
substantial footwear and
long trousers. Do not
operate the equipment when
barefoot or wearing open
sandals;
b)Do not wear loose clothing or
jewellery that can be drawn
into the air inlet. Keep long
hair away from the air inlets.
c) Wear protective goggles
while operating
d)To prevent dust irritation the
wearing of a face mask is
recommended
e)Never operate the appliance
with defective guards or
shields, or without safety
devices.
3) Operation
a) Take off the battery from the
appliance,
- when not in use;
- before clearing a blockage;
- before checking, cleaning or
working on the appliance;
- if the appliance starts to
vibrate abnormally.
b) Operate the appliance only
in daylight or in good artificial
light.
c) Do not overreach and keep
your balance at all times.

20V Cordless Blower
WG543E WG543E.X
76
d) Always be sure of your
footing on slopes.
e) Walk, never run;
f) Keep all cooling air inlets
clear of debris.
g) Never blow debris in the
direction of bystanders.
h) Do not put hands or feet near
or under rotating parts.
4) Maintenance and storage
a) Keep all nuts, bolts and
screws tight to be sure the
appliance is in safe working
condition;
b) Replace worn or damaged
parts.
c) Use only genuine
replacement parts and
accessories.
d) Store the appliance only in a
dry place.
IMPORTANT
READ CAREFULLY BEFORE
USE
KEEP FOR FUTURE
REFERENCE
Safe operating practices
1) Training
a) Read the instructions
carefully. Be familiar with the
controls and the correct use
of the machine.
b) Never allow children,
persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
or people unfamiliar with
these instructions to use the
machine, local regulations
may restrict the age of the
operator.
c) Never operate the machine
while people, especially
children, or pets are nearby.
d) Keep in mind, that the
operator or user is
responsible for accidents or
hazards occurring to other
people or their property.
2) Preparation
a) While operating the machine,
always wear substantial
footwear and long trousers.
Do not operate the machine
when barefoot or wearing
open sandals. Avoid wearing
clothing that is loose fitting
or that has hanging cords or
ties.
b) Do not wear loose clothing or
jewellery that can be drawn
into the air inlet. Keep long
hair away from the air inlets.
c) Obtain ear protection and
safety glasses. Wear them at
all times while operating the
machine.

98
20V Cordless Blower
WG543E WG543E.X
d) Operate the machine in a
recommended position and
only on a firm, level surface.
e) Do not operate the machine
on a paved or gravel surface
where ejected material could
cause injury.
f) Before using, always visually
inspect to see, that the
fasteners are secure, the
housing is undamaged and
that guards and screens
are in place. Replace worn
or damaged components
in sets to preserve balance.
Replace damaged or
unreadable labels.
3) Operation
a) Before starting the machine,
make certain that the
feeding chamber is empty.
b) Keep your face and body
away from the feed intake
opening.
c) Do not allow hands or any
other part of the body or
clothing inside the feeding
chamber, discharge chute, or
near any moving part.
d) Keep proper balance and
footing at all times. Do not
overreach.
e) Always stand clear of the
discharge zone when
operating this machine.
f) If the machine should start
making any unusual noise or
vibration, immediately shut
off the power source and
allow the machine to stop.
Remove the battery pack
from the machine and take
the following steps before
restarting and operating the
machine:
i)inspect for damage;
ii)replace or repair any
damaged parts;
iii)check for and tighten any
loose parts.
g) Do not allow processed
material to build up in the
discharge zone; this may
prevent proper discharge
and can result in kickback of
material through the intake
opening.
h) If the machine becomes
clogged, shut-off the
power source and remove
the battery pack from the
machine before cleaning
debris.
i) Never operate the machine
with defective guards or
shields, or without safety
devices.
j) Keep the power source
clean of debris and other
accumulations to prevent
damage to the power source

20V Cordless Blower
WG543E WG543E.X
98
or possible fire.
k) Do not transport this
machine while the power
source is running.
l) Always disconnect the
machine from the power
supply (e.g. remove the
battery pack from the
machine)
-whenever you leave the
machine,
-before clearing blockages
or unclogging chute,
-before checking, cleaning
or working on the machine.
m)Avoid using the machine
in bad weather conditions
especially when there is a
risk of lightning.
4)Maintenance and storage
a) keep all nuts, bolts and
screws tight to be sure the
appliance is in safe working
condition.
b) Replace worn or damaged
parts.
c) Use only genuine
replacement parts and
accessories.
d) Store the machine in a dry
place out of the reach of
children.
e) When the machine is
stopped for servicing,
inspection, or storage, or
to change an accessory,
shut off the power source,
disconnect the machine
from the supply and make
sure that all moving parts
are come to a complete
stop. Allow the machine
to cool before making any
inspections, adjustments,
etc. Maintain the machine
with care and keep it clean.
f) Store the machine in a dry
place out of the reach of
children.
g) Always allow the machine to
cool before storing.
h) Never attempt to override
the interlocked feature of the
guard.
SAFETY WARNINGS FOR
BATTERY PACK
a) Do not dismantle, open
or shred cells or battery
pack.
b)Do not short-circuit a
battery pack. Do not
store battery packs
haphazardly in a box or
drawer where they may
short-circuit each other
or be short-circuited by
conductive materials.
When battery pack is not
in use, keep it away from

1110
20V Cordless Blower
WG543E WG543E.X
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from one
terminal to another. Shorting
the battery terminals
together may cause burns or
a fire.
c) Do not expose battery
pack to heat or fire. Avoid
storage in direct sunlight.
d)Do not subject battery
pack to mechanical
shock.
e) In the event of battery
leaking, do not allow
the liquid to come into
contact with the skin or
eyes. If contact has been
made, wash the affected
area with copious
amounts of water and
seek medical advice.
f) Keep battery pack clean
and dry.
g)Wipe the battery pack
terminals with a clean dry
cloth if they become dirty.
h)Battery pack needs to
be charged before use.
Always refer to this
instruction and use
the correct charging
procedure.
i) Do not maintain battery
pack on charge when not
in use.
j) After extended periods
of storage, it may be
necessary to charge and
discharge the battery
pack several times
to obtain maximum
performance.
k) Recharge only with
the charger specified
by WorxNITRO . Do not
use any charger other
than that specifically
provided for use with the
equipment.
l) Do not use any battery
pack which is not
designed for use with the
equipment.
m)Keep battery pack out of
the reach of children.
n)Retain the original
product literature for
future reference.
o) Remove the battery from
the equipment when not
in use.
p)Dispose of properly.
q)Do not mix cells of
different manufacture,
capacity, size or type
within a device.
r) Keep the battery away
from microwaves and high
pressure.

20V Cordless Blower
WG543E WG543E.X
1110
SYMBOLS
Read the operator’s manual
Warning
Wear eye protection
Do not expose to rain
Do not use in the rain or leave
outdoors while it is raining.
Wear ear protection
Keep bystanders away
Warning of hazard
Waste electrical products must
not be disposed of with household
waste. Please recycle where
facilities exist. Check with your
local authorities or retailer for
recycling advice.
Remove battery from the socket
before carrying out any adjustment,
servicing or maintenance.
Li-Ion battery. This product has
been marked with a symbol relating
to ‘separate collection’ for all
battery packs and battery pack. It
will then be recycled or dismantled
in order to reduce the impact on
the environment. Battery packs can
be hazardous for the environment
and for human health since they
contain hazardous substances.
Li-I on
Li-I on
Do not burn
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
RCM marking
ABN: Australian Business
Number. By this number, business
information such as entity type,
status, business location etc. can be
found at website http://abr.business.
gov.au.
ABN of Positec Australia Pty Limited
is 14 101 682 357

9
10
8
7
6
1
2
3
4
5

CB
A2
A1
E
H
II
I
F
D
1
1
2
2
II
I
I
II
G1
I
II
100%
0%
2
1
ON
OFF
I1
I2
G3G2
G4
J

CB
A2
A1
E
H
II
I
F
D
1
1
2
2
II
I
I
II
G1
I
II
100%
0%
2
1
ON
OFF
I1
I2
G3G2
G4
J

CB
A2
A1
E
H
II
I
F
D
1
1
2
2
II
I
I
II
G1
I
II
100%
0%
2
1
ON
OFF
I1
I2
G3G2
G4
J

1716
20V Cordless Blower
WG543E WG543E.X
COMPONENT LIST
1. AIRSPEED SELECTOR NOZZLE
2. BLOWER TUBE
3. ONOFF SWITCH
4. HANDLE
5. BATTERY PACK RELEASE BUTTON *
6. BATTERY PACK *
7. MOTOR HOUSING
8. NOZZLE RELEASE BUTTON
9. WIDE NOZZLE 
10. BLOWER TUBE ADAPTOR 
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
Type Designation WG543E WG543E.X (520-559
- designation of machinery, representative of
blower)
WG543E WG543E.X**
Voltage 20 V Max.***
Maximum air volume I: 518 m3/h II: 696 m3/h
(Air volume mode)
Maximum air velocity I: 153 km/h II: 209 km/h
(Air speed mode)
Machine weight
(bare tool) 1.1 kg
** X=1-999, A-Z, M1-M9 there are only used for
different customers, there are no safe relevant
changes between these models
*** Voltage measured without workload. Initial
battery voltage reaches maximum of 20 volts.
Nominal voltage is 18 volts.
SUGGESTED BATTERIES AND
CHARGERS
Category Model Capacity
20 V Battery
WA3553 4.0 Ah
WA3551 2.0 Ah
WA3551.1 2.0 Ah
20 V Charger WA3880 2.0 A
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and
offer advice.
NOISE DATA
A weighted sound pressure LpA= 78.0 dB(A)
KpA 3.0 dB(A)
A weighted sound power LwA= 92.6 dB(A)
KwA 3.0 dB(A)
Wear ear protection.
VIBRATION INFORMATION
Typical weighted vibration ah< 2.5 m/s2
Uncertainty K = 1.5 m/s²
The declared vibration total value may be used for
comparing one tool with another, and may also be
used in a preliminary assessment of exposure.
WARNING: The vibration emission value
during actual use of the power tool can differ
from the declared value depending on the ways in
which the tool is used dependant on the following
examples and other variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained
Using the correct accessory for the tool and ensuring
it is sharp and in good condition.
The tightness of the grip on the handles and if any
anti vibration accessories are used.
And the tool is being used as intended by its design
and these instructions.

20V Cordless Blower
WG543E WG543E.X
1716
This tool may cause hand-arm vibration
syndrome if its use is not adequately managed.
WARNING: To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off and
when it is running idle but not actually doing the job. This
may significantly reduce the exposure level over the total
working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate)
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration tool
use across a number of days.
OPERATION
INTENDED USE
The blower is intended for residential use only. Use
the blower outdoors to move yard debris as needed.
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLY
Charging the battery pack
Your battery pack is UNCHARGED, you must
charge before use.
More details can be found in charger’s
manual.
WARNING! The charger and battery
pack are specially designed to work
together, so do not attempt to use any other
devices. Never insert or allow metallic
objects into your charger or battery pack
connections because of an electrical failure
and hazard will occur.
See Fig.
A1, A2
Installing & removing the battery pack
NOTE: Press the battery release button to
release battery pack from your tool. After
recharging, insert the battery pack into
tool’s battery port. A simple push and slight
pressure will be sufficient.
See Fig.
B, C
Air speed mode
NOTE: The blower is in the air speed mode
for default assembly.
NOTE: The blower has two working modes:
air speed mode and air volume mode. To
change modes, depress the nozzle release
button and slide backward for air speed
mode. Slide forward for air volume mode.
Choose a suitable mode according to your
work. Air speed mode is recommended
for cleaning in grass, as shown in Fig. I1.
While air volume mode is recommended for
cleaning on hard ground such as cement,
as shown in Fig. I2.
See Fig. D
Air volume mode See Fig.
E, F
Attach the wide nozzle See Fig.
G1-G4
OPERATION
Starting & Stopping
WARNING! The tool runs for a few
seconds after it has been switched
off.
Let the motor come to a complete standstill
before setting the tool down.
See Fig. H
Adjusting the blowing speed / air volume
with 2-speed switch
USER TIPS
- Hold the blower tube approximately 8’’
above the ground when operating the tool.
Use a sweeping motion from side to side.
Advance slowly keeping the accumulated
debris/leaves in front of you.
- After blowing the debris/leaves into a pile,
it is easy to dispose of the pile.
CAUTION!
- Do not blow hard objects such
as nails, bolts, or rocks.
- Do not operate the blower near
bystanders or pets.
- Use extra care when cleaning debris
from stairs or other tight areas.
- Wear safety goggles or other suitable
eye protection, long pants, and shoes.
See Fig.
I1, I2
Wide nozzle application See Fig. J
CLEANING THE TOOL
Clean the tool regularly.
WARNING! Keep your product dry. Under
no circumstances spray with water.
- To clean the tool, use only mild soap and a
damp cloth.
- Do not use any type of detergent, cleaner or
solvent which may contain chemicals that

1918
20V Cordless Blower
WG543E WG543E.X
could seriously damage the plastic.
- Self lubricating bearings are used in
your product, therefore lubrication is not
required.
ENVIRONMENTAL
PROTECTION
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with your
Local Authority or retailer for recycling advice.
Positec Australia Pty Limited
10 Corporate Blvd Bayswater , VIC
3153,Australia
DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
On behalf of Positec declare that the product
Description Battery-operated Blower
Type WG543E WG543E.X (520-559 - designation
of machinery, representative of battery-operated
Blower Vacuum)
Function Blowing
Complies with the following Directives:
2006/42/EC, 2014/30/EU,
2011/65/EU&(EU)2015/863,
2000/14/EC amended by 2005/88/EC
2000/14/EC amended by 2005/88/EC:
- Conformity Assessment Procedure as per Annex V
- Measured Sound Power Level 92.6 dB (A)
- Declared Guaranteed Sound Power Level 96 dB (A)
Standards conform to
EN 60335-1, EN 50636-2-100, EN 62233, EN ISO 3744,
EN 55014-1, EN 55014-2
The person authorized to compile the technical file,
Name Marcel Filz
Address Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
2022/01/25
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

20V Cordless Blower
WG543E WG543E.X
1918
DECLARATION OF
CONFORMITY
We,
Positec (UK & Ireland) Ltd.
PO Box 6242, Newbury, RG14 9LT, UK
On behalf of Positec declare that the product,
Description Battery-operated Blower
Type WG543E WG543E.X (520-559 - designation
of machinery, representative of battery-operated
Blower Vacuum)
Function Blowing
Complies with the following regulations:
Supply of Machinery (Safety) Regulations 2008
Electromagnetic Compatibility Regulations 2016
The Restriction of the Use of Certain Hazardous
Substances in Electrical and Electronic Equipment
Regulations
Noise Emission in the Environment by Equipment
for Use Outdoors Regulations
- Conformity Assessment Procedure as per
SCHEDULE 8
- Measured Sound Power Level 92.6 dB(A)
- Declared Guaranteed Sound Power Level 96 dB(A)
Standards conform to
BS EN 60335-1, BS EN 50636-2-100, BS EN 62233, BS
EN ISO 3744, BS EN 55014-1, BS EN 55014-2
The person authorized to compile the technical file,
Name Jim Kirkwood
Address Positec (UK & Ireland) Ltd.,
PO Box 6242, Newbury, RG14 9LT, UK
2022/01/25
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Copyright © 2022, Positec. All Rights Reserved.
AR01531803
www.worx.com
