Worx WG743E.X User manual

WG743E WG743E.X WP771E WP771E.X
P09
P20
P33
P45
P57
P69
P81
P93
P104
P115
P126
P139
P151
P163
P175
P187
P199
Cordless Lawn mower
Schnurloser Rasenmäher
Tondeuse à gazon sans fil
Tosaerba senza fili
Cortacésped a batería
Corta-relva sem fios
Snoerloze graasmaaier
Ledningsfri plæneklipper
Ledningsfri gressklipper
Sladdlös gräsklippare
Bezprzewodowa kosiarka do trawników
Vezetékmentes fűnyíró
Maşină de tuns iarba fără fir
Bezdrátová travní sekačka
Akumulátorová kosačka na trávu
Brezžična kosilnica
Аккумуляторная газонокосилка
EN
D
F
I
ES
PT
NL
DK
NOR
SV
PL
HU
RO
CZ
SK
SL
RU

Original instructions
Originalbetriebsanleitung
Notice originale
Istruzioni originali
Manual original
Manual original
Oorspronkelijke gebruiksaanwijzing
Original brugsanvisning
Opprinnelige Instruksjonene
Bruksanvisning i original
Instrukcja oryginalna
Eredeti használati utasítás
Instrucţiuni originale
Původní návod k používání
Pôvodný návod na použitie
Izvirna navodila
Оригинальное руководство по эксплуатации
EN
D
F
I
ES
PT
NL
DK
NOR
SV
PL
HU
RO
CZ
SK
SL
RU

5
7
6
10
16
11
12
13
14
2
3
4
1
8
9
15

2
1
A5 B1
A1 A2
A4
A3

3
2
1
1
2
1
2
C2 C3
B2 B3
C1
B4

1
2
100%
0%
17
D1 D2
EF
G1 G2

L2-1
L2-2
L2-3
19
18
L1-1
L1-2
L1-3
K2
K2
L
L1
M1
L2
O2
M2
K1

L2-1
L2-2
L2-3
19
18
L1-1
L1-2
L1-3
K2
K2
L
L1
M1
L2
O2
M2
K1

9
Cordless Lawn mower EN
PRODUCT SAFETY
GENERAL SAFETY WARNINGS
WARNING Read all
safety warnings and all
instructions. Failure to follow
the warnings and instructions
may result in electric shock,
fire and/or serious injury.
Carefully read the
instructions for the safe
operation of the machine.
Save all warnings and
instructions for future
reference.
- This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities,
or lack of experience
and knowledge, unless
they have been given
supervision or instruction
concerning use of the
appliance by a person
responsible for their safety.
- Children should be
supervised to ensure that
they do not play with the
appliance.
- The appliance is only to be
used with the power supply
unit provided with the
appliance.
IMPORTANT
READ CAREFULLY BEFORE
USE
KEEP FOR FUTURE
REFERENCE
Safe operation practices
Training
a)read the instructions
carefully. Be familiar with
the controls and the proper
use of the equipment;
b)never allow children or
people unfamiliar with
these instructions to
use the lawnmower. Local
regulations can restrict the
age of the operator;
c)never mow while people,
especially children, or pets
are nearby;
d)keep in mind that the
operator or user is
responsible for accidents or
hazards occurring to other
people or their property.
Preparation
a) While mowing, always
wear substantial footwear
and long trousers. Do not
operate the equipment
when barefoot or wearing
open sandals;
b) thoroughly inspect the
area where the equipment
is to be used and remove
all objects which can be
thrown by the machine;
c) Before using, always

10
Cordless Lawn mower EN
visually inspect to see that
the blades, blade bolts and
cutter assembly are not
worn or damaged. Replace
worn or damaged blades
and bolts in sets to preserve
balance. Replace damaged
and unreadable labels.
Operation
a)mow only in daylight or in
good artificial light;
b)avoid operating the
equipment in wet grass,
where feasible;
c)always be sure of your
footing on slopes;
d)walk, never run;
e)for wheeled rotary
machines, mow across the
face of slopes, never up
and down;mow across the
face of slopes, never up and
down.
f) exercise extreme caution
when changing direction on
slopes;
g)do not mow excessively
steep slopes;
h)use extreme caution when
reversing or pulling the
lawnmower towards you;
i) stop the blade(s) if the
lawnmower has to be tilted
for transportation when
crossing surfaces other
than grass, and when
transporting the lawnmower
to and from the area to be
mowed;
j) never operate the
lawnmower with defective
guards , or without safety
devices, for example
deflectors and/or grass
catchers, in place;
k)switch on the motor
carefully according to
instructions and with feet
well away from the blade(s);
l) do not tilt the lawnmower
when switching on the
motor, except if the
lawnmower has to be tilted
for starting. In this case,
do not tilt it more than
absolutely necessary and lift
only the part which is away
from the operator;
m)do not put hands or feet
near or under rotating parts.
Keep clear of the discharge
opening at all times;
n)not to touch the blades
before the disabling device
has been removed and
the blades have come to a
complete stop;
o)Do not start the lawnmower
when standing in front of
the discharge opening.
p)Do not transport the
lawnmower while the power
source is running.
q)Stop the lawnmower,and
remove the disabling

11
Cordless Lawn mower EN
device. Make sure that all
moving parts have come to a
complete stop.
– whenever leaving the
machine unattended,
– before clearing a blockage,
– before checking, cleaning or
working on the machine,
– after striking a foreign
object. Inspect the machine
for damage and make
repairs before restarting and
operating the lawnmower
If the lawnmower starts to
vibrate abnormally (check
immediately)
- inspect for damage.
- replace or repair any
damaged parts.
- check and tighten any loose
parts.
Maintenance and storage
a)keep all nuts, bolts and
screws tight to be sure the
equipment is in safe working
condition;
b)check the grass cacher
frequently for wear or
deterioration;
c)replace worn or damaged
parts for safety. Use only
genuine replacement parts
and accessories.
d)Be careful during adjusting
of the lawnmower to prevent
entrapment of the fingers
between moving blades
and fixed parts of the
lawnmower.
e)Always allow the
lawwnmower to cool down
before storing.
f) When servicing the blades
be aware that, even though
the power source is
switched off, the blades can
still be moved.
SAFETY WARNINGS FOR BAT
TERY PACK
a)Do not dismantle, open
or shred cells or battery
pack.
b)Do not short-circuit a
battery pack. Do not
store battery packs
haphazardly in a box or
drawer where they may
short-circuit each other
or be short-circuited by
conductive materials.
When battery pack is not
in use, keep it away from
other metal objects, like
paper clips, coins, keys,
nails, screws or other small
metal objects, that can
make a connection from one
terminal to another. Shorting
the battery terminals
together may cause burns or
a fire.
c) Do not expose battery

12
Cordless Lawn mower EN
pack to heat or fire. Avoid
storage in direct sunlight.
d)Do not subject battery
pack to mechanical
shock.
e) In the event of battery
leaking, do not allow
the liquid to come into
contact with the skin or
eyes. If contact has been
made, wash the affected
area with copious
amounts of water and
seek medical advice.
f) Keep battery pack clean
and dry.
g)Wipe the battery pack
terminals with a clean
dry cloth if they become
dirty.
h)Battery pack needs to
be charged before use.
Always refer to this
instruction and use
the correct charging
procedure.
i) Do not maintain battery
pack on charge when not
in use.
j) After extended periods
of storage, it may be
necessary to charge and
discharge the battery
pack several times
to obtain maximum
performance.
k)Recharge only with the
charger specified by
Worx. Do not use any
charger other than that
specifically provided for
use with the equipment.
l) Do not use any battery
pack which is not
designed for use with the
equipment.
m)Keep battery pack out of
the reach of children.
n)Retain the original
product literature for
future reference.
o) Remove the battery from
the equipment when not
in use.
p)Dispose of properly.
q)Do not mix cells of
different manufacture,
capacity, size or type
within a device.
r) Keep the battery away
from microwaves and
high pressure.
SYMBOLS
Read instruction handbook
before operation this machine

13
Cordless Lawn mower EN
Keep bystanders away.
Beware of sharp blades. Blades
continue to rotate after the motor
is switched off- Remove disabling
device before maintenance
Waste electrical products
must not be disposed of with
household waste. Please recycle
where facilities exist. Check with
your local authorities or retailer
for recycling advice.
Li-Ion battery This product has
been marked with a symbol
relating to ‘separate collection’
for all battery packs and battery
pack. It will then be recycled or
dismantled in order to reduce
the impact on the environment.
Battery packs can be hazardous
for the environment and for
human health since they contain
hazardous substances.
Do not burn
Batteries may enter water cycle if
disposed improperly, which can
be hazardous for ecosystem. Do
not dispose of waste batteries as
unsorted municipal waste.
Wear protective gloves.
Remove battery from the
socket before carrying out
any adjustment, servicing or
maintenance.
Blade continues to rotate after
the machine is switched off. Wait
until all machine components
have completely stopped before
touching them
Remove the key
COMPONENT LIST
1. SAFETY KEY
2. BAIL HANDLE
3. CABLE CLIP
4. UPPER HANDLE
5. LOWER HANDLE
6. BATTERY POWER INDICATOR
7. BATTERY PACK COVER
8. CUTTING HEIGHT ADJUSTMENT KNOB
9. CARRY HANDLE
10. HANDLE KNOB, LOWER
11. SAFETY FLAP
12. GRASS COLLECTION BAG
13. BAG HANDLE
14. GRASS BAG INDICATOR
15. HANDLE KNOB, UPPER
16. MULCHING INSERT
17. BATTERY PACK SEE FIG. E 
18. BLADE BOLT SEE FIG. M1
19. BLADE SEE FIG. M1
*Not all the accessories illustrated or described
are included in standard delivery.
TECHNICAL DATA
Type WG743E, WG743E.X WP771E WP771E.X
(740-789 - designation of machinery, represen-
tative of Cordless Lawn Mower)

14
Cordless Lawn mower EN
WG743E WG743E.X**
WP771E WP771E.X **
Voltage 40V Max.(2x20V Max.)***
No load speed 2800 / 3000 /min
Deck diameter 43cm
Cutting diameter 40cm
Front wheel
diameter 180mm
Rear wheel diameter 190mm
Cutting height 20mm-80mm
Cutting height
positions 7
Grass collection
capacity 45L
Battery type Lithium-ion
Machine Weight
(bare tool) 13.9kg
**X=1-999, A-Z, M1-M9 are only used for different
customers, there are no safe relevant changes
between these models.
***Voltage measured without workload. Initial battery
voltage reaches maximum of 20 volts. Nominal voltage
is 18 volts.
SUGGESTED BATTERIES AND
CHARGERS
Category Model Capacity
20V Battery WA3553 4.0 Ah
WA3014 4.0 Ah
20V Charger
WA3760 0.4 A
WA3860 2.0 A
WA3880 2.0 A
WA3772 2.0 A
WA3883 4.0 A
We recommend that you purchase your accessories
from the same store that sold you the tool. Choose the
type according to the work you intend to undertake.
Refer to the accessory packaging for further details.
Store personnel can assist you and offer advice.
NOISE DATA
A weighted sound pressure LwA = 75dB(A)
KpA 3 dB (A)
A weighted sound power LwA = 89.3 dB(A)
KwA 3 dB (A)
Wear ear protection
VIBRATION INFORMATION
Typical weighted vibration ah＜ 2.5 m/s
Uncertainty K = 1.5 m/s
WARNING The vibration emission value during
actual use of the power tool can differ from the
declared value depending on the ways in which the tool
is used dependant on the following examples and other
variations on how the tool is used:
How the tool is used and the materials being cut or
drilled.
The tool being in good condition and well maintained.
Using the correct accessory for the tool and ensuring it
is sharp and in good condition.
The tightness of the grip on the handles and if any anti
vibration accessories are used.
And the tool is being used as intended by its design and
these instructions.
This tool may cause hand-arm vibration syndrome
if its use is not adequately managed
WARNING To be accurate, an estimation of
exposure level in the actual conditions of use
should also take account of all parts of the operating
cycle such as the times when the tool is switched off and
when it is running idle but not actually doing the job. This
may significantly reduce the exposure level over the total
working period.
Helping to minimise your vibration exposure risk.
ALWAYS use sharp chisels, drills and blades.
Maintain this tool in accordance with these instructions
and keep well lubricated (where appropriate).
If the tool is to be used regularly then invest in anti
vibration accessories.
Plan your work schedule to spread any high vibration tool
use across a number of days.

15
Cordless Lawn mower EN
OPERATION INSTRUCTION
NOTE: : To reduce the risk of injury, user must
read instruction manual
Intended Use
This product is intended for domestic lawn mowing.
ASSEMBLY AND OPERATION
ACTION FIGURE
ASSEMBLY
Assembling the handle bar
NOTE: Choose one of the two holes in
the lower handle for desired handle’s
height.
See Fig. A1, A2,
A3, A4, A5
Assembling grass collection bag See Fig. B1, B2,
B3, B4
Fitting grass collection bag to the
lawn mower
NOTE: Depress the grass collection
bag slightly to ensure that it is
completely installed.
NOTE: Take the mulching insert out
of the lawn mower before fitting the
grass collection bag.
See Fig. C1,
C2, C3
Checking the battery charge condition
NOTE: Fig. D1 only applies for the
battery pack with battery indicator
light.
See Fig. D1
Charging the battery pack
NOTE: The batteries are shipped
uncharged. Each battery must be fully
charged before the first mow.
Always fully charge the two batteries at
same time. More details can be found in
charger’s manual.
See Fig. D2
Fitting/removing battery
NOTE: This machine will only run
when 2 batteries are installed. It
is recommended to use the same
two batteries and charge the two
batteries at the same time.
Using two different sized batteries
or if one battery isn’t fully charged
then the machine will only run to
the lowest common denominator.
See Fig. E
OPERATION
Battery power indicator on the machine
See details in BATTERY STATUS part
IMPORTANT
When only one light is illuminated,
at least one battery is depleted and
needs to be charged, even though the
mower may still be capable of cutting
grass. Continuing to operate your
lawnmower with the battery in this
discharged condition may reduce the
life and performance of your battery.
When no light is illuminated, at least
one battery is not fully installed or
battery may be defective, please
double check the batteries are fully
seated into position.
See Fig. F
Starting & stopping See Fig. G1, G2
Adjusting the Cutting Height See Fig. H
Grass bag filling indicator
Empty status: flap floats (a)
Fully status: flap falls down (b)
See Fig. I1
Removing/emptying grass collection
bag
WARNING! Always check the
safety flap close the discharge
outlet before using. Never lift the
safety flap when the lawn mower
is being used without fitted grass
collection bag.
See Fig. I2
Installing the mulching insert See Fig. J
Storage
WARNING Always remove the battery
and safety key when storage. See Fig. K1, K2
BATTERY STATUS (See Fig. F)
Before starting or after use, press the button beside
the power indicator light on the machine to check
the battery capacity. During operation, the battery
capacity will be indicated automatically by the
battery power indicator.
The indicator constantly senses and displays the
battery condition as follows.
For the machine with 2 battery packs with different
power, the power indicator light displays the battery
condition with the lower one of the two batteries.

16
Cordless Lawn mower EN
Battery power
indicator status Battery condition
Five green lights
() are
illuminated.
The two batteries are in a
highly charged condition.
Two, three or four
green lights are
illuminated.
The two batteries have a
remaining charge. The more
lights are illuminated, the
more battery capacity.
Only one green
light ( ) is
illuminated.
At least one battery is almost
depleted and needs to be
charged.
No light is
illuminated.
At least one battery is not fully
installed or battery may be
defective.
Only one light is
flashing twice per
cycle.
At least one battery is over
discharged (please refer to
the battery charge condition),
please recharge the two
batteries at once before use
again or storage.
Only one light is
flashing three times
per cycle.
At least one battery is hot,
wait for them cool down
before start again.
Only one light is
flashing four times
per cycle.
The machine is over load.
Raise the cutting height or
push slowly.
MOWING TIPS
NOTE: ALWAYS INSPECT AREA WHERE MOWER IS
TO BE USED AND REMOVE ALL STONES, STICKS,
WIRE, METAL AND OTHER DEBRIS WHICH MIGHT
BE THROWN BY THE ROTATING BLADE.
1. Mow across the face of slopes, never up-and-
down. Exercise extreme caution when changing
direction on slopes. Do not mow excessively
steep slopes. Always maintain good footing.
2. Release bail handle to turn mower “OFF” when
crossing any graveled area (stones can be
thrown by the blade).
3. Set mower at highest cutting height when
mowing in rough ground or in tall weeds.
Removing too much grass at one time can cause
circuit breaker to trip, which stops mower.
4. If a grass bag is used during the fast growing
season, the grass may tend to clog up at the
discharge opening. Release bail handle to turn
mower “OFF” and remove the safety key. Remove
the grass bag and shake the grass down to the
back end of the bag. Also clean out any grass
or debris which may be packed around the
discharge opening. Replace the grass collection
bag.
5. If mower should start to vibrate abnormally,
release bail handle to turn mower “OFF” and
remove safety key. Check immediately for cause.
Vibration is a warning of trouble. Do not operate
mower until a service check has been made.
6. ALWAYS RELEASE BAIL HANDLE TO TURN
MOWER “OFF” AND REMOVE SAFETY KEY
WHEN LEAVING IT UNATTENDED EVEN FOR A
SHORT PERIOD OF TIME.
CUTTING AREA
The cutting area can be affected by several factors,
such as cutting height, lawn humidity, grass length
and density. Besides, starting and stopping the
mower too many times during operation will reduce
the cutting area.
The below table provides the potential cutting areas
based on specific cutting conditions.
Cutting Height Recommend lot size
(maximum)
Cutting off 8cm to 6cm
With 2*20V / 4.0Ah
batteries
up to 500m
2
*
* Used with two fully charged battery packs.
TIPS:
1) It is recommended to mow your lawn more
frequently, walk at normal pace, and not to start/
stop the mower too often during operation.
Please always use the same two batteries and
charge the two batteries at same time.
2) For best performance, please ensure use a fully
charged battery pack and always cut off 1/3 or
less of the grass height.
3) Walk slowly when cutting long grass, so as
to have more effective cutting and properly
discharge the clippings.
4) Avoid cutting wet grass, otherwise it will stick
to the underside of the deck and the clippings
cannot be collected or discharged properly.
5) A higher cutting height shall be applied to new
or thick grass and it will extend the battery
duration.

17
Cordless Lawn mower EN
MAINTENANCE
WARNING: Stop the mower and remove the
safety key before removing the grass bag.
NOTE To ensure long and reliable service,
perform the following maintenance procedures
regularly. Check for obvious defects such as a
loose, dislodged or a damaged blade, loose fittings,
and worn or damaged components. Check that
the covers and guards are all undamaged and are
correctly attached to mower. Carry out any necessary
maintenance or repairs before operating mower.
If the mower should happen to fail despite regular
maintenance, please call our customer helpline for
advice.
BLADE SHARPENING
KEEP BLADE SHARP FOR BEST MOWER
PERFORMANCE.
WEAR PROPER EYE PROTECTION WHILE REMOVING,
SHARPENING, AND INSTALLING BLADE. ENSURE THAT
SAFETY KEY IS REMOVED.
Sharpening the blade twice during a mowing season
is usually sufficient under normal circumstances.
Sand causes the blade to dull quickly. If your lawn
has sandy soil, more frequent sharpening may be
required.
REPLACE BENT OR DAMAGED BLADE IMMEDIATELY.
WHEN SHARPENING THE BLADE:
1. Make sure blade remains balanced.
2. Sharpen blade at the original cutting angle.
3. Sharpen cutting edges on both ends of blade,
removing equal amounts of material from both ends.
NOTE
1. Be sure the mower is turned off and remove the
key.
2. Place the mower in stand up storage mode.
TO SHARPEN BLADE IN A VISE (SEE Fig.L1)
1. Be sure the bail handle is released, the blade has
stopped and the safety key removed before removing
the blade.
2. Remove blade from mower. See instructions for
removing and attaching blade.
3. Secure blade L1-1 in a vise L1-2.
4. Wear safety glasses and be careful not to cut
yourself.
5. Carefully file the cutting edges of the blade with a
fine tooth file L1-3 or sharpening stone.
6. Check balance of blade. See instructions for blade
balancing.
7. Replace blade on mower and tighten securely. Refer
to instructions below.
BLADE BALANCING (SEE Fig.L2)
Check balance of blade by placing center hole in blade
L2-1 over a nail or screwdriver shank L2-2, clamped
horizontally in a vise L2-3. If either end of the blade
rotates downward, file that end. Blade is properly
balanced when neither end drops.
BLADE MAINTENANCE (SEE FIG. M1, M2)
Renew your metal blade after 50 hours mowing or 2
years, which ever is the sooner-regardless of condition.
Follow these procedures to remove and replace the
blade. You will need garden gloves (not provided) and
a spanner wrench (not provided) to remove the blade.
Hold the blade (19) and unscrew the blade bolt (18)
counter-clockwise using a spanner wrench, and then
remove blade.
To re-assemble, position the blade (19) with the cutting
edges towards the ground. Then securely tighten the
blade bolt (18).
STORAGE (SEE Fig. K1, K2)
Stop the mower and always remove the safety key.
Clean the exterior of the machine thoroughly using
a soft brush and cloth. Do not use water, solvents or
polishes. Remove all grass and debris, especially from
the ventilation slots.
Turn the machine on its side and clean the blade area.
If grass cuttings are compacted in the blade area,
remove with a wooden or plastic implement.
Store the machine in a dry place. Do not place other
objects on top of the machine.
To aid storage, release the Lock Cam Lever, and fold the
upper handle as shown in Fig. K1, K2.
ENVIRONMENTAL
PROTECTION
Waste electrical products must not be disposed
of with household waste. Please recycle where
facilities exist. Check with your local authorities or
retailer for recycling advice.

18
Cordless Lawn mower EN
TROUBLE SHOOTING
Problem Solution
1. Mower doesn’t run when
bail handle is activated. A. Check to make sure safety key has been installed and is fully seated and that button on switch housing is being completely pushed.
B. Release bail handle to turn mower off. Remove safety key, turn mower
over and check that blade is free to turn. If not free, return to an authorized
servicer. Blade should turn freely.
C. Has battery been fully charged? Plug in charger and wait for green light to
come on.
2. Motor stops while mowing. A. Release bail handle to turn mower off. Remove safety key, turn mower over and
check that blade is free to turn. If not free, return to an authorized servicer. Blade
should turn freely.
B. Raise cutting height of wheels to highest position and start mower.
C. Has battery been fully charged? Plug in charger and wait for green light to
come on.
D. Avoid overloading the mower. Slow down the cutting pace by pushing mower
slower or raise the cut height. Or both.
3. Mower runs but
cutting performance is
unsatisfactory, or does not
cut entire lawn.
A. Has battery been fully charged? Plug in charger and wait for green light to
come on.
B. Release Bail handle to turn mower off. Remove safety key. Turn mower
over and check: Blade for sharpness - Keep blade sharp. Deck and discharge
chute for clogging.
C. Wheel height adjustment may be set too low for grass condition. Raise
cutting height.
4. Mower is too hard to push. A. Raise cutting height to reduce deck drag on grass. Check each wheel for
free rotation.
5. Mower is abnormally noisy
and vibrates.
A. Release bail handle to turn mower off. Remove safety key. Turn mower on
side and check blade to ensure it has not been bent or damaged. If blade is
damaged, replace with a replacement blade. If the underside of the deck is
damaged return mower to an Authorized service center.
B. If there is no visible damage to the blade and the mower still vibrates:
Release bail handle to turn mower off, remove safety key and remove blade.
Rotate blade 180 degrees and retighten. If mower still vibrates, return the
mower to an authorized service center.
6. Battery charger LED’s not
on. A. Check plug connection. B. Replace charger.
7. Battery charger LED does
not flip to green. A. Battery needs to be diagnosed. Take to authorized service center.
8. Mower not picking up
clippings with the Grass
Collection Bag.
A. Remove mulch plate when bagging.
B. Chute clogged. Release Bail handle to turn mower off. Remove safety key.
Clear chute of grass clippings.
C. Too much cut grass. Raise cutting height of wheels to shorten length of
the cut.
D. Bag full. Empty bag more often.
9. When mulching there are
clippings visible. A. Too much cut grass. Raise cutting height of wheels to shorten length of the cut. Do not cut off more than 1/3 of total length.
B. Check blade for sharpness. Always keep blade sharp.

19
Cordless Lawn mower EN
10. Low or diminished run-
time after many uses. A. Return to Authorized Service location - may need new battery.
11. The battery charger LED
flashes red and the battery
can’t be charged.
A. The battery overheats after continuous use. Remove battery from the
charger and allow it to cool to 42oC or less.
DECLARATION OF
CONFORMITY
We,
Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
Declare that the product
Description Worx Cordless Lawn Mower
Type WG743E, WG743E.X WP771E WP771E.X (740-
789 - designation of machinery, representative of
Cordless Lawn Mower)
Function mowing grass
Complies with the following Directives,
2006/42/EC, 2014/30/EU, 2011/65/
EU&(EU)2015/863, 2000/14/EC amended by
2005/88/EC
2000/14/EC amended by 2005/88/EC
Conformity assessment procedure as per Annex
VI.
Measured Sound Power Level 89.3 dB(A)
Declared Guaranteed Sound Power Level 92 dB(A)
The notified body involved
Name: Intertek Testing & Certification Ltd
(notified body 0359)
Address: Davy Avenue, Knowlhill, Milton Keynes,
MK5 8NL
Standards conform to,
EN 60335-1, EN 60335-2-77, EN 62233, EN ISO 3744,
EN 55014-1, EN 55014-2
The person authorized to compile the technical file,
Name: Marcel Filz
Address Positec Germany GmbH
Postfach 32 02 16, 50796 Cologne, Germany
2020/01/06
Allen Ding
Deputy Chief Engineer, Testing & Certification
Positec Technology (China) Co., Ltd
18, Dongwang Road, Suzhou Industrial
Park, Jiangsu 215123, P. R. China

Schnurloser Rasenmäher D
20
PRODUKTSICHERHEIT
ALLGEMEINE
SICHERHEITSHINWEISE
WARNING LESEN SIE
ALLE
SICHERHEITSHINWEISE UND
ANWEISUNGEN.
Versäumnisse bei der
Einhaltung der
Sicherheitshinweise und
Anweisungen können
elektrischen Schlag, Brand
und/oder schwere
Verletzungen verursachen.
Lesen Sie die
Bedienungsanleitung
zum sicheren Betrieb
des Gerätes aufmerksam
durch.
Bewahren Sie alle
Sicherheitshinweise und
Anweisungen für die
Zukunft auf.
- Dieses Gerät ist nicht dafür
bestimmt, durch Personen
(einschließlich Kinder)
mit eingeschränkten
physischen, sensorischen
oder geistigen Fähigkeiten
oder mangels Erfahrung
und/oder mangels Wissen
benutzt zu werden, es sei
denn, sie werden durch
eine für ihre Sicherheit
zuständige Person
beaufsichtigt oder erhielten
von ihr Anweisungen, wie
das Gerät zu benutzen ist.
- Kinder sollten beaufsichtigt
werden um Sicherzustellen,
dass sie nicht mit dem
Ladegerät spielen.
- Das Gerät darf nur mit dem
mitgelieferten Netzteil
verwendet werden.
WICHTIG
VOR GEBRAUCH BITTE
GENAU DURCHLESEN
FÜR SPÄTERE BEZUGNAHME
AUFBEWAHREN
Sicherer Betrieb
Training
a)Die Anweisungen
aufmerksam durchlesen.
Machen Sie sich mit den
Bedienelementen und
dem vorschriftsmäßigen
Gebrauch des Rasenmähers
vertraut.
b)Niemals Kindern oder
mit diesen Anweisungen
nicht vertrauten Personen
erlauben, den Rasenmäher
zu benutzen. Nationale
Vorschriften können das
Alter der Bedienperson
möglicherweise
beschränken.
c)Niemals mähen,
während sich Personen,
insbesondere Kinder, oder
Tiere in unmittelbarer Nähe
aufhalten.
