Wybron PS-600 User manual

PS-600
PS-300
PS-150
Power Supplies
User Manual

Power Supply User Manual
Updated March 2009
Page 2
PS-600 – Model 20600 (600 watts)
PS-300 – Model 20300 (300 watts)
PS-150 – Model 20150 (150 watts)
CONTENTS
Declaration of Conformity ..................................................... 3
Safety Information................................................................. 4
Introduction ........................................................................... 6
System Components............................................................. 7
PS Power Supply............................................................. 7
System Layout Diagram .................................................. 8
Equipment Compatibility......................................................... 9
Installing the Power Supply .................................................. 10
Head-Feet Restrictions......................................................... 11
Mounting and Installation Accessories ................................. 12
Infotrace ............................................................................... 13
Cables .................................................................................. 14
Specifications ....................................................................... 15
Parts List .............................................................................. 16
Exploded Parts Diagram ...................................................... 17
Warranty Information............................................................ 20

Power Supply User Manual
Updated March 2009
Page 3

Power Supply User Manual
Updated March 2009
Page 4
Safety Information
SAVE THESE INSTRUCTIONS
READ AND FOLLOW ALL INSTRUCTIONS
This manual gives step-by-step instructions for the preparation, setup, and operation of
the PS Power Supply.
There is a potential risk of fire, electric shock or injury to persons if the product is not
used as instructed.
WARNING: When using electrical appliances, use basic precautions, including:
•Read this manual before connecting power.
•Use supervision around children.
•Use in a dry location only.
The PS Power Supply is to be used in an indoor environment only and is not intended
for residential use.
For continued protection against risk of fire, replace only with same type and rating of
fuse.
Protection against electric shock is assured only if the mains connected power supply
cord set is connected to a properly earthed grounding type receptacle.
An all pole disconnect device must be located adjacent to the unit or, if the AC cord is
used as the main disconnect device, ensure that the socket-outlet is located/installed
near the equipment and is easily accessible.
THE MAINS LEADS ARE COLORED IN ACCORDANCE WITH THE FOLLOWING
CODE AND MUST BE CONNECTED IN THE FOLLOWING SCHEME:
-GREEN AND YELLOW: EARTH
-BLUE: NEUTRAL
-BROWN: LINE
WARNING: THIS EQUIPMENT MUST BE EARTHED.
For questions, contact Wybron at 1-800-624-0146 or visit www.wybron.com.
Product Modification Warning
Wybron, Inc. products are designed and manufactured to meet the requirements of
United States and International safety standards. Modifications to the products could
affect safety and render the product non-compliant to relevant safety standards.

Power Supply User Manual
Updated March 2009
Page 5
Notes de Sécurité
EPARGNER CES INSTRUCTIONS
LIRE ET SUIVRE TOUTES INSTRUCTIONS
Ce manuel donne des instructions pour la preparation, l’organisation, et l’opération du le
PS provision d'électricité.
Il y a un risqué de feu, décharge électrique, ou la blessure aux gens si le produit n’est
pas utilize comme instruit.
AVERTISSEMENT: En utilisant des appareils électriques utilise la prudence
fondamentale inclut:
•Lire ce manuel avant d'alimenter ou l'installation de l'accessoire.
•Utiliser la prudence près des enfants.
•Sécher l'emplacement seulement.
Le PS provision d'électricité va être utilize à la maison seulement et pas pour l’usage
residential. Pour la protection continuée contre le risque de feu, remplacer seulement
avec le même type et le même classement de fusible.
La Protection contre la décharge électrique est seulement assurée si la série de corde
connectée principale est connectée à un convenablement terre de type.
Un appareil débranchant doit être localisé à côté de l'unité ou, si la corde de courant
alternatif est utilisée comme le principal débranche l'appareil, S'assurer que la douille-
sortie localise/installé près de l'équipement et est facilement accessible.
LES AVANCES PRINCIPAUX SONT CONFORMEMENT COLORES AU CODE
SUIVANT ET DOIVENT ETRE CONNECTES DANS L'ARRANGEMENT SUIVANT :
vert et jaune– terre
bleu – neutre
marron – ligne
L'AVERTISSEMENT – CET EQUIPEMENT DOIT ETRE FONDE.
Pour les questions, Wybron de contact à 1-800-624-0146 ou visite www.wybron.com.
L’Avertissement de Modification de Produit
Les produits de Wybron, Inc. sont conçus et a fabriqué pour rencontrer les conditions
d’Etats-Unis et de norms de sûreté internationals. Les modifications aux produits
pourraient affecter la sûreté et rendent le produit non-conciliant aux normes de sûreté
pertinentes.

Power Supply User Manual
Updated March 2009
Page 6
Introduction
Wybron's 150-, 300- and 600-watt PS Power Supply units attach easily to a truss or can
be mounted into a 19-inch rack. A Power Supply unit can be controlled by one or
several DMX512 channels that send DMX signals from the lighting console to each
device along with 24 volts DC. Both the signal and the power travel along a single
cable, eliminating the need for a separate power cable for each device.
Each unit provides power for Wybron's feedback-compatible IT products, which send
feedback to their operators using Remote Device Management, an ESTA-standard two-
way communication protocol.

Power Supply User Manual
Updated March 2009
Page 7
System Components
Power Supply
The power supply accepts DMX512 from a lighting console and passes it along with
24VDC power to each device. This eliminates the need for separate control and power
cables to each device. The DMX512 control signal can also be daisy chained to other
PS power supplies or other DMX-controlled devices.
Caution: The PS Power Supply is compatible with Forerunner devices but
NOT the RAM/Coloram II family of devices (i.e. Coloram II, CXI, Goboram II,
etc.) DO NOT connect PS compatible devices to RAM/Coloram II Power
Supplies, or RAM/Coloram II compatible devices to PS Power Supplies.
Damage from such action will not be covered by the equipment warranties.
PS Compatible Devices
•Nexera LX
•Coloram IT
•CXI IT
•Forerunner
•Eclipse IT Iris
•Eclipse IT Shutter
Refer to the user manuals for detailed operating information on these products.
Power/Data Cable
The Power/Data Cable connects the Power Supply outputs to the connected devices
and provides them with power and control signal. The cable uses 4-pin XLR connectors
on either end and consists of two 14 AWG conductors and a 22 AWG twisted, shielded
pair. See the “Cable” section of this manual for the pin-out.

Power Supply User Manual
Updated March 2009
Page 8
PS Power Supply System Connection Diagram
5 pin DMX
Four Pin
Lighting Console

Power Supply User Manual
Updated March 2009
Page 9
Equipment Compatibility
The following is a chart of compatibility and capacity of the various models of PS Power
Supplies and their companion devices. This is current as of the print date of this
manual. As more products are added to the compatible line, an updated list will be
available on the Wybron Web site at www.wybron.com.
Power Supply
PS-150
PS-300
PS-600
Model Number
20150
20300
20600
Output Power
150 watts
300 watts
600 watts
Number of Units per Power Supply
Description
Model
Maximum
Head-Feet
PS-150
PS-300
PS-600
Nexera LX Tungsten
82560,
82570
82640
1500
8
16
32
Nexera LX CDM
2580,
2600
1500
6
12
24
Forerunner 4” / 7”
4540
7140
1500
16
32
64
Coloram IT 4” / 7.5”
84520
87110
1500
6
12
24
Coloram IT 10”
810100
1000
4
8
16
Coloram IT Lg Fmt
816090
1000
6
12
24
Coloram IT 15”
815010
1000
6
12
24
Coloram IT 8 Light
816080
1000
6
12
24
Aquaram IT 7.5”
87080
1000
5
10
20
Aquaram IT 6 Light
816120
1000
6
12
24
Aquaram IT 8 Light
816080
1000
6
12
24
Aquaram IT Lg Fmt
85000
1000
6
12
24
Eclipse IT Iris 1K
87250
1500
6
12
24
Eclipse IT Iris 2K
812020
1500
6
12
24
Eclipse IT Shutter
1K / 2K
89020
811020
1500
8
16
32
Eclipse IT Shutter
Lg Fmt (5K / 16”)
817010
1500
6
12
24
Eclipse IT Shutter 24”
82401
1500
6
12
24
Eclipse IT Iris 24”
823020
750
3
6
12
CXI IT 4” / 7.5”
87200
816120
1500
6
12
24
CXI IT Lg Format
81605
750
2
5
9
CXI 12”
812210
500
4
9
18
CXI Mariner
87220
1500
6
12
24
CXI MultiPar
87240
1000
4
9
18

Power Supply User Manual
Updated March 2009
Page 10
Installing the Power Supply
1. Mount the Power Supply
The Power Supply is designed to be freestanding, truss-mounted, or rack-
mounted.
The Power Supply comes with a mounting bracket that hooks over the pipe or
truss of your lighting rig and is locked into place with a thumb screw. If you use
this mounting method, connect the Power Supply's safety cable by clipping it
around the pipe or truss.
The Power Supply can also be mounted into a 19" rack using the optional rack
mount kit. The rack mount kit will accommodate two units side-by-side.
2. Connect the Device to the Power Supply
Connect the device to the Power Supply using Wybron’s 4-pin power/data cable.
Refer to the HEAD-FEET RESTRICTION section of the manual for details of the
length of cable runs.
Note: The Wybron Power/Data Cable has been specially designed to minimize
voltage drop. Use only Wybron-supplied cable.
3. Connect the Power Supply to AC Power
Plug the AC cord into a non-dimmed power circuit. The power supply
automatically accommodates 100 – 240V ~ 50/60 Hz.
Caution: Do not power the Power Supply from a dimmed circuit.
Severe damage will result and is not covered by product warranty.
A red LED (viewable from the stage) indicates power.
4. Connect and Set the DMX512 Source
Connect the DMX512 signal source to the DMX input connector on the front of
the power supply using standard DMX cable. The presence of a valid DMX signal
will be indicated by a flashing green LED.

Power Supply User Manual
Updated March 2009
Page 11
Head-Feet Restrictions
The HEAD-FEET parameter is a method of accounting for the voltage drop in the
power/signal cable caused by the current drawn by each device.
To help understand this issue, think of it as water pressure (voltage) in a hose (cable)
where there are multiple water sprinkler heads (color changers). If the hose (cable) is
too long, or there are too many sprinkler heads (color changers), the water pressure
(voltage) will be too low.
HEAD-FEET is defined as "the sum of cable lengths from each device to a single power
supply output.”
For Head-Feet information on a specific Wybron product, please refer to that product’s
user manual.

Power Supply User Manual
Updated March 2009
Page 12
Mounting and Installation Accessories
The following sections describe how to install and replace mounting accessories.
Power Supply Hanger Brackets
The Power Supply units are shipped with hanger brackets to allow pipe or truss
mounting.
Follow these steps to install the hanger bracket.
1. Disconnect AC power from the power supply.
2. Place the power supply on its side on a flat surface.
3. Position the brackets as shown on the next page.
4. Attach the bracket using a 3/16" Allen wrench and the supplied screws.
Note: Use the supplied thumb screws to clamp the hanger brackets to the desired pipe
or truss.
Power Supply Rack Mounting
The rack mount accessory can be used with up to two Power Supplies and allows them
to be mounted into a 19-inch rack.
Power Supply Hanger Brackets

Power Supply User Manual
Updated March 2009
Page 13
Infotrace
Imagine checking your lighting equipment and diagnosing any problems without
grabbing a ladder or strapping on a harness. It's possible with Wybron's award-winning
Infotrace Control and Management System, which gives you the tools to manage
your rig without leaving your computer. Using the feedback protocol Remote Device
Management, or RDM, Infotrace enables you to inspect and address everything in your
lighting system, managing it and knowing that it works.
The diagram above outlines Infotrace’s key components, which include:
Infogate – The software and hardware required to facilitate the transfer and display of
information.
Infochip – A conversion chip that can be used with non-RDM equipment to allow
communication with the Infogate software.
Infostore – An Internet-based application that aggregates data captured by Infogate
and allows for the accumulation of historical information related to the equipment
performance in the installation.
IT Products – Coloram IT, CXI IT, Eclipse IT Iris, and Eclipse IT Shutter all have
updated electronics to support RDM communication plus additional product
improvements, including sensors to detect a variety of conditions.
The heart of the Infotrace system is Infogate — specialized software that uses RDM to
facilitate remote addressing and diagnostics for potentially every piece of equipment
mounted on a rig. Infogate works with all Wybron-manufactured IT products as well as
RDM-compatible equipment from any other manufacturer.

Power Supply User Manual
Updated March 2009
Page 14
Cables
Power/Data Cable
The power/data cable uses 4-pin XLR connectors on either end and consists of two 14
AWG conductors and a 22 AWG twisted, shielded pair. The shells of the two XLR
connectors are not electrically connected together, preventing large power currents from
flowing from chassis to chassis of the equipment. The twisted pair shield is connected at
the male XLR connector end only.
XLR Pin # Wire Color Function Size
1 White Ground 14 AWG
2 Green Data - 22 AWG
3 Red Data + 22 AWG
4 Black 24VDC 14 AWG
DMX512 Control Cable
The DMX control cable from the lighting console to the power supply is a five-conductor
cable with 5-pin XLR connectors on each end. The wiring pin-out is specified by the
USITT DMX512/1990 standard.
XLR Pin # Function
1 Common
2 Data -
3 Data +
4 Talkback -
5 Talkback +

Power Supply User Manual
Updated March 2009
Page 15
Specifications
Connectors:
DMX in: Male 5-pin XLR
DMX out: Female 5-pin XLR
Output: Female 4-pin XLR
DMX512 termination: None – DMX signal pass thru
Fuse:
PS-600 (model 20600):
Input voltage: 100-240V ~ 50/60 Hz 10-5A
250V 7A Slo Blo for 100-120V~
250V 4A Slo Blo for 220-240V~
PS-300 (model 20300):
Input voltage: 100-240V ~ 50/60 Hz 5-3A
250V 4A Slo Blo for 100-120V~
250V 2A Slo Blo for 220-240V~
PS-150 (model 20150):
Input voltage: 100-240V ~ 50/60 Hz 3-1.5A
250V 2A Slo Blo for 100-120V~
250V 1A Slo Blo for 220-240V~
Input Power: Automatically accepts 100-240V ~ 50/60 Hz
Input Signal: 1990 USITT standard DMX512
Red LED: Indicates power
Green LED: Indicates DMX signal
Size:
PS-600:
14”/356mm L x 7.8”/198mm W x 4.1”/104mm H
Weight: 7.9 lbs/3.6 kg
PS-300:
14"/356mm L x 7.8"/198mm W x 3"/76mm H
Weight: 5.4 lbs/2.4 kg
PS-150:
12.7"/323mm L x 7.6"/193mm W x 2.9"/74mm H
Weight: 3.9 lbs/1.8 kg

Power Supply User Manual
Updated March 2009
Page 16
Parts List
Callout
Quantity
Part Number
Description
(1)
4
SCRFH632150
Flat head screw
(2)
8
Z-2287
Grommet
(3)
1
F0825
Fan 600W
1
F6025S
Fan 300W/150W
(4)
1
2060-01-02
Board bracket 600W only
(5)
4
SCHRFHM4X8
Flat screw head 4mmX8mm
(6)
4
SCRPH440025P
Pan head black with patch
(7)
4
SCRFHM4X8
Flat screw head 4mmX8mm
(8)
2
SCRFH832037
3/8 Flat head black stainless
(9)
1
2024-01-06
24 way power supply fan plate
(10)
2
67-1160-ND
5mm green LED
(11)
2
2060-01-03
LED bracket
(12)
2
67-1162-ND
5mm red LED
(13)
1
2060-02-0011
Circuit card
(14)
1
NC5MP
5-pin chasis MT male
(15)
8
NC4FD-L1
4-pin chasis MT female (600W)
(16)
20
SCRFH440037
Flat head screw
(17)
1
NC5FP
5-pin chasis MT female
(18)
1
031-1666
Fuse cap round
(19)
1
313-007
Fuse 7 amp
(20)
1
031-1693
Fuse holder body
(21)
2
SCRFH632037
3/8 Flat head
(22)
1
10EEA1
Power connector filter
(23)
4
SCRPH440037
Pan head screw
(24)
1
2060-01-04
Top Chassis (600W)
(25)
8
SCSRFH632025
Flat head screw
(26)
4
704-08-03
Rubber feet
(27)
4
SCRPH832037P
Pan head machine black

Power Supply User Manual
Updated March 2009
Page 17
13
14
15
16
17
18
19
20
21
22
23
12
10
9
1
1
2
11
3
4
5
Exploded View of a PS-600 Power Supply:
Part Numbers

Power Supply User Manual
Updated March 2009
Page 18
27
26
25
24

Power Supply User Manual
Updated March 2009
Page 19
Model Numbers
Power Supply Units
20600 ...........................................................PS-600
20300 ...........................................................PS-300
20150 ...........................................................PS-150
Mounting Accessories
715-01-03P...................................................PS-600, PS-300, and PS-150 hanger bracket
SCRWC252075............................................Wing screw for power supply hanger
bracket to pipe
SCRSC2520037...........................................Socket cap screw for hanger bracket to
power supply
Power/Data Cable
7042-3 ..........................................................3' power/signal cable
7042-5 ..........................................................5' power/signal cable
7042-10 ........................................................10' power/signal cable
7042-15 ........................................................15' power/signal cable
7042-25 ........................................................25' power/signal cable
7042-50 ........................................................50' power/signal cable
7042-75 ........................................................75' power/signal cable
7042-100 ......................................................100' power/signal cable

Power Supply User Manual
Updated March 2009
Page 20
Warranty Information
WYBRON, INC. warrants to the original owner or retail customer that for a period of one
year from date of delivery of a portable system or energization of a permanently
installed system (up to a maximum of 18 months from delivery) its products will be free
from defects in materials and workmanship under normal use and service.
Warranty does not cover any product or part of a product subject to accident,
negligence, alteration, abuse, misuse or any accessories or parts not supplied by
WYBRON, INC. Warranty does not cover "consumable" parts such as fuses, lamps, or
color media. WYBRON, INC.'s warranty does not extend to items not manufactured by
us. Freight terms on warranty repairs are FOB WYBRON, INC. factory or designated
repair facility. Collect shipments or freight allowances will not be accepted.
WYBRON, INC.'s sole responsibility under this warranty shall be to repair or replace at
WYBRON, INC.'s option such parts as shall be determined to be defected on
WYBRON, INC.'s inspection. WYBRON, INC. will not assume any responsibility for any
labor expended or materials used to repair any equipment without WYBRON, INC.'s
prior written authorization. WYBRON, INC. shall not be responsible for any incidental,
general or consequential damages to property, damages for loss of use, time, profits or
income, or any other charges.
The owner's obligations during the warranty period under this warranty are to notify
WYBRON, INC. at WYBRON, INC.'s address within one week of any suspected defect,
and return the goods prepaid to WYBRON, INC. at their factory or authorized service
center.
This warranty is contingent on the customer's full and timely compliance with the terms
of payment set forth in said purchase order. This warranty is expressly in lieu of any and
all other warranties expressed or implied including the warranties of merchantability and
fitness for a particular purpose and of other obligations and liabilities on our part. The
owner acknowledges that no other representations were made to him or relied upon him
with respect to the quality and function of the goods sold.
This written warranty is intended as a complete and exclusive statement of the terms
thereof. Prior dealings or trade usage shall not be relevant to modify, explain or vary this
warranty. Acceptance of, or acquiescing in, a course of performance under this warranty
shall not modify the meaning of this agreement even though either party has knowledge
of the performance and a chance to object
Software version 1.0
Manual revision: March 19, 2009
