WIS4200/WIS4300 (WIS4x00) Quick Start Guide
Location
For optimal performance with a particular access point, the WIS4x00 should be located
between 3-6 feet from the access point.!The unit
may be mounted on a wall, ceiling or above the
ceiling.
Wall Mounting
Download a full-size printable version of the
template and instructions from!
http://support.wyebot.com/help/Wyebot-WIS4x00-
wallmount-template.pdf
Suspended Ceiling Mount
Select the pair of ceiling rail clips which match the
width of your ceilings T-bar rails.!The provided
clips support both 9/16” and 15/16” ceiling rails.
Using the two 8mm lock screws provided, attach the respective clips to the bottom of the
WIS4x00.!Ensure clips are aligned with the indented areas on the bottom of the WIS4x00 (See
Fig. 1).
Attach the WIS4x00 to a secure ceiling rail by attaching one clip at a time to the rail (See Fig. 2).
Verify the WIS4x00 fits securely on the ceiling tile rail for the most secure mounting.!
NOTE: the included wall anchors are NOT
suitable for use in a drywall ceiling.!Toggle
bolts or other anchors intended for ceilings
and capable of supporting 5lbs or more should
be purchased separately.
Above Ceiling (Plenum Space)
The WIS4x00 is suitable for use in
environmental air space in accordance with
Section 300-22(C) of the National Electrical
Code.!Use above a suspended ceiling is
permitted in a horizontal mounting position
only.!The optimal orientation of the unit is with
the top cover (logo) facing down toward the floor.!Avoid placing the unit near electrical wiring
or ductwork in order to reduce the impact these items may have on RF signals.
[email protected] 2020 Wyebot, Inc. WIS4x00 Quick Start Guide

WIS4200/WIS4300 (WIS4x00) Quick Start Guide
Powering the Unit
The WIS4x00 may be powered with PoE (802.3at required for WIS4300) or an optional AC/DC
power adapter (available separately).!Insert the Ethernet LAN cable into the port marked
“1G/PoE”.!If using the AC/DC adapter, insert the adapter plug into the port labeled
“12VDC” then plug adapter into AC outlet.
Network Configuration
The WIS4x00 is a plug-and-play solution that requires no configuration in order to get started.!
The sensor defaults to DHCP on ethernet to obtain an IP address.
Connecting to the Cloud
Plug the Sensor into a PoE port for power and Internet connectivity.
Wait for the Cloud LED to turn solid green.
Login to the Wyebot cloud dashboard (https://cloud.wyebot.com) with your username and
password.
"
If the Cloud LED does not turn green within 60 seconds, verify the sensor’s traffic is not being
blocked by a firewall.!See the Troubleshooting section of the Wyebot Getting Started Guide for
more information at:
http://support.wyebot.com/help
If you need further assistance, please do not hesitate to contact us at [email protected].
