WYLMAN PEGASUS User manual
FILLINGTHEGAPSINTECHNOLOGY
QuickStartGuide
PATENTPENDING
Dec2020
Rev.0
Definitions…………………………….…………………………………………………………...3
SafetyInstructions…..………………………………………………………………………...4
ComplianceStatements……………………………………………………………………..5
Contents………………………..…………………………………………………………………..6
Overview…………………………………………………………………………………………...8
GettingStarted………………………………………………………………………………...10
StartingaSession……………………………………………………………………………..11
TABLE OF CONTENTS
2
FILLINGTHEGAPSINTECHNOLOGY
DEFINITIONS
!
NOTE: A NOTE indicates important information that helps make better use of the
product.
CAUTION: A CAUTION indicates either potential damage to hardware or lossofdata
andtellshowtoavoidtheproblem.
WARNING:AWARNINGindicatesapotentialforpropertydamage,personalinjury,or
death.
3
SAFETY INSTRUCTIONS
4
UsethefollowingsafetyguidelinestoprotectyourPEGASUSfrompotentialdamage
and to ensure your personal safety. Unless otherwise noted, each procedure
includedinthisdocumentassumesthatthefollowingconditionsexist:
•Youhavereadthesafetyinformationincluded.
•Acomponentand/orattachmentcanberemovedbyperformingthe installation
procedureinreverseorder.
•Ifathirdpartyattachmentwasused,youhavereadthesafety instructions that
camewithit.
!
NOTE: Forbestperformance,onlyusetheprovidedaccessoriesandcables. Please
contactusifcable(s)replacementorcable(s)differentlengthis/areneeded.
CAUTION:HandlePEGASUSandaccessorieswithcare.AlthoughPEGASUSenclosureis
veryrigid,strongimpactfromdropscancauseinternalelectronics to malfunction.
Suchdamagewillnotbecoveredunderwarranty.
WARNING:ToavoiddamagetoPEGASUS,useonlythepowersupplyprovided.Donot
usepowersuppliesdesignedforotherdevices.
CAUTION:Repairsmayonlybedonebyacertifiedservicetechnician.Endusershould
onlyperformtroubleshootingandsimpleaccessory/cablereplacement as authorized
inthisproductdocumentation,orasdirectedbytheonlineortelephoneserviceand
supportteam.DamageduetoservicingthatisnotauthorizedbyWYLMANisnot
coveredunderwarranty. Readandfollowthesafetyinstructionsthatcamewiththe
product.
CAUTION:Whendisconnectingacable,pullonitsconnectororonitspull‐tab,noton
the cable itself. As pulling connectors apart, keep them evenlyalignedtoavoid
bending any connector pins. Also, before connecting a cable, ensure that both
connectorsarecorrectlyorientedandaligned.
!
WARNING: This product is designed to be used indoors and in non‐hazardous areas.
Donotusethisproductinahazardousclassifiedareasasthismayresultinfiresand/or
explosions.
CAUTION: PEGASUSissecuredwithhighsecuritytamperproofscrews,thescrews
mustbecheckedfortamperingmarksbeforeeveryuse.Ifanytampering marks are
noticed,DONOTusePEGASUSandcontactWYLMANforsupport.
5
COMPLIANCE STATEMENTS
FCCComplianceStatement:
This device complies with part 15 of the FCC rules. Operation is subject to the
followingtwoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)
this device must accept any interference received, including interference that may
causeundesiredoperation.
Note:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClass
Adigitaldevice,pursuanttopart15ofthe FCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferencewhentheequipmentis
operated in a commercial environment. This equipment generates, uses and can
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththe
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in aresidentialareaislikelytocause harmful
interferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceathis
ownexpense.
RoHSComplianceStatement:
All components and solder alloys used in this product comply with the RoHS
Directive. The RoHS Directive prevents all new electrical and electronic equipment
placed on the market in the European Economic Area from containing more than
agreed levels of lead, cadmium, mercury, hexavalent chromium, poly‐brominated
biphenyls(PBB)andpoly‐brominateddiphenylethers(PBDE).
CONTENTS
PEGASUS PowerSupply
PEGASUSShield HDMICable(6.6ft)
DVI‐DDualLinkVideo
Cable(6.6ft) SVGACable(6ft)
USB2.0Cable(6.6ft) VGAtoDVIAdapter
6
7
CONTENTS
USBEthernetAdapter USBWi‐FiAdapter
NOTE:Ifanyofthecontentsismissing,pleasecontactWYLMANforsupport.
NOTE:Toensurethemaximumsecurityforourcustomers,onlytheprovidedexternal
networkadapterswillbeacceptedbyPEGASUS.
8
OVERVIEW
2 3 4 5 61
8 9 107
9
OVERVIEW
DESCRIPTION
1.GroundingScrew
It is recommended to connect the grounding screw to a clean/instrument ground
bus.
2.12VDCPowerInput
Powerinputport;onlyuserprovidedpowersupply.
3.AudioOutput(3.5mm)
Optionalaudiooutput.
4.USB2.0Ports(x2)
OptionalexpansionUSBports,canbeusedtoconnectexternalnetwork adapters,
Keyboard, mouse, etc. It does not support using any type of storage read and/or
writedevices;USBflashdrive,externaldiscdrive,etc.
5.NetworkPort(RJ45)
OptionalwirednetworkconnectiontoconnecttoLANand/ortotheinternet.
6.HDMIOutput
Optionalvideooutput,canbeusedforPEGASUSconfigurationand/ormonitoring.
7.HDMIInput
OptionalHDMIinput,canbeusedtoreceivevideosignalfromTargetcomputer.
8.DVIInput
OptionalDVIinput/VGAinput withtheDVI‐VGA adapter (included),canbeusedto
receivevideosignalfromTargetcomputer.
9.Keyboard&MousePort(MicroUSBTypeB)
Used to transfer the Keyboard & Mouse Commands from PEGASUS to Target
Computer.
10.PowerSwitch
Usedasthemasteron/offswitchforPEGASUS.
10
GETTING STARTED
Initialconfiguration
1.Makesuretheboxincludeallcontentsmentioned.
2. Connect PEGASUS to its power supply. It is recommended to connect the
groundingscrewtoaclean/instrumentgroundbus.
3.ConnectamonitortoPEGASUSHDMIOutput,monitornotincluded.
4.ConnectKeyboardandMousetoPEGASUSusingtheavailableUSB2.0ports.
5.PowerupPEGASUS.
6.Loginscreenwillbedisplayed,“WYLMAN”isthedefaultpassword.
7.AfterPEGASUSboots,loginasadministrator,“WYLMAN”isthedefaultpassword.
8.DetailedUserManualisavailableonthePEGASUSShieldUSBDriveandavailable
onlineatwww.wylman.com
NOTE: Allpasswordsinthesystemaresetto“WYLMAN”asdefault.Itis
stronglyrecommendedtochangethepasswordsonthefirstuseand
frequently.
NOTE:Ifwirelessconnectionisrequired,connecttheWi‐Fiadapterincludedto
PEGASUSusingoneoftheavailableUSB2.0ports.
NOTE: If communication redundancy is required, connect the USB Ethernet
adapterincludedand/orWi‐FiadapterincludedtotheavailableUSB2.0ports.
NOTE: Default passwords can be restored in case administrator password is
lost.Pleasecontactsupport@wylman.comforassistancewithpasswordsreset.
NOTE:IfauthenticationbetweenPEGASUSandTargetmachineusingPEGASUS
Shield fails, this may be due to unsynchronized time, please make sure that
PEGASUSsystemtimeandTargetmachinetimearesynchronized.
NOTE:IfahardwarechangewasdonetotheTargetmachineorassigninganew
Target machine, PEGASUS Shield must be reconfigured. Please contact
[email protected]forassistance.
NOTE: Before Launching PEGASUS Shield software, make sure PEGASUS is
connected to Target machine using the provided USB cable, otherwise
PEGASUSShieldwillnotwork.
11
STARTING A SESSION
InstructionsbelowexplaintheneededconnectionstobeabletostartaViewora
Controlsession:
1. Assign Target Machine, Activate PEGASUS and PEGASUS Shield. Refer to user
manualfordetails.
2. Connect PEGASUS to its power supply. It is recommended to connect the
groundingscrewtoaclean/instrumentgroundbus.
3.ConnectvideocablefromTargetmachinetoaPEGASUSvideoinput.
4.ConnectTargetmachinetoPEGASUSkeyboardandmouseport;thisconnectionis
requiredevenifthesessionisaviewonlysession.
5. If using wired connection to connect PEGASUS to LAN/internet, connect the
networkcable(s).
6.ConnectPEGASUSShieldtoTargetmachine.
7.PowerupPEGASUS,giveenoughtimetoPEGASUStobootandgetonline.
8. Remote user shall connect to PEGASUS using configured means of remote
connection.
9.RemoteusershallloginaseitherControllerorViewer.
10.Remoteusershallselect start session from the menu.Asessionauthentication
willpopup.
11. PEGASUS session authentication code shall be transferred over non‐PEGASUS
meanstolocaluser,exampleviaphonecallortextmessage.
12. Local user shall start PEGASUS Shield and enter the PEGASUS session
authenticationcode.Ifcorrect,Shieldsessionauthenticationcodewillbedisplayed,
otherwiseremoteusershallwaitfortheanewPEGASUSsessionauthentication
code.Codesautomaticallychangeevery1minute.
13.Shield sessionauthentication codeto betransferred over non‐PEGASUS means
toremoteuser,exampleviaphonecallortextmessage.
14. Remote user shall enter the Shield session authentication code. If correct,
sessionwillstart,otherwiseremoteusershallrestart the authenticationprocedure
andwaitforanewPEGASUSsessionauthenticationcode.
TypicalSystemConfigurationforaremotesession
Target
Machine
PEGASUS
LAN or Internet
RemoteUser
LocalUser
WYLMANLLC
TEL:+1‐832‐632‐4400
Email:[email protected]
www.wylman.com
©2020WYLMANLLC.ALLRIGHTSRESERVED
PATENTPENDING
