X-Vision XIR504 Guide

CCTV
Model: XIR504
Colour Vandal Resistant
IR Dome Camera
CCTV
Model:
XIR504
Colour Vandal Resistant Dome
Camerawith 15m Nightvision
Manufactured exclusively for:
Xvision (Europe) Group,
Head Office: London, U.K.
Email: [email protected]
Web: www.x-vision.co.uk
TECHNICAL SUPPORT:
For Technical Support for any Xvision product please contact your local
distributor.
LIMITED WARRANTY:
This product is supplied with a 2 Year warranty.The Warranty excludes
products that have been misused, (including accidental damage) and
damage caused by normal wear and tear. In the unlikely event that you
encounter a problem with this product, it should be returned to the
place of purchase.
Before you begin
•Please unpack the box carefully and identify that all the parts are present.
•Do not cut the camera cables, this will void the warranty.
•Make sure you use only the recommended power supply. Damage caused to the camera by
incorrect voltage or wiring is not covered by the warranty.
The camera is suitable for indoor or outdoor use. Please bear in mind the following points when
choosing a mounting position.
•The camera must be positioned so that it will not point directly into the sun (sunrise and
sunset) or any bright light, as this may cause damage to the camera.
•Avoid viewing areas where half the area is in bright sunlight and the other half is dark,
such as in the shadow of a building. All types of cameras have difficulty in ‘seeing’ with
such a large lux level variation.
Specification
Model: XIR504
Picture Type: Day/Night (B/W & Colour)
Image Sensor: Sony 1/3” Super HAD CCD
DSP: Xvision IXC1DN
Resolution: 480TVL
Lens Viewing Angle: 78°
Infra Red Nightvision: 15 metres
Minimum Illumination: 0.1 Lux
Audio: No
Operating Voltage: 12V DC 750mA Regulated
Suggested Power Supply: 12V DC 1250mA
Mounting: Ceiling
Weatherproofing: No
Dimensions: Ø136x99mm
STEP 4: When the camera focus adjusment has been completed, use the
Allen key provided to fasten the vandal proof housing to the main
body (as shown in Figure 3).
STEP 5: When the camera focus adjusment has been completed, use the
Allen key provided to fasten the vandal proof housing to the main
body (as shown in Figure 4).
STEP 6: When using the side conduit cabling, it is suggested to use a
metal cover over the cables to prevent external damage and for
waterproofing. wind the adhesive tape (PTFE Thread Seal Tape)
onto the metal cover before instalation (as shown in Figure5).
Description
Package Contents Installation & Operation
THANK YOU VERY MUCH FOR PURCHASING OUR PRODUCT
The XIR504 colour vandal resistant dome camera is designed for medium to high
risk applications and is designed to withstand a blow from a 10 pound
sledgehammer.It offers very high resolution 480 TVL images from its Sony 1/3"
Super HAD CCD sensor and will provide images in complete darkness up to 15
metres and beyond 15 metres in light levels above 0.1 lux. The camera is designed
for internal or external use and ceiling mounting.
STEP 1: Using the L wrench provided, loosen the vandal resistant housing
cover screws (with screws still attached on the cover). The unit
has a factory installed side conduit entry and you can adjust the
cables to the back conduit entry according to installation
requirement (as shown in Figure1).
STEP 2: Set the mounting base onto the wall or ceiling and center it over
the mounting hole,using the four retaining screws for the main
body supplied in the accessory package (as shown in Figure2).
STEP 3: Set the proper image by moving the camera body (some model
types limit the PCB board to 180° rotational adjustment) and set
focus by turning the lens to the left or to the right.
Main Features
•Sony 1/3" Super HAD CCD image sensor for 480 TVL resolution images and 0.1
lux low light sensitivity
•Dual mode High Resolution CCD sensor provides very good quality Colour images
in low light conditions of 0.1 lux or above and B/W images in low light conditions
below 0.1 lux and in complete darkness.
•Integrated Long Life Infra Red LEDs turn on automatically when the camera
switches to B/W mode and provide up to 15 metres nightvision
•Vandal resistant for use in areas where the camera is vulnerable to vandalism,
can withstand a blow from a 10 pound sledgehammer
•Durable Corrosion Proof Metal Casing designed for internal or external use and
ceiling mounting
1. Instruction Manual
2. XIR504 Dome Camera 3. L wrench
1 2 3
Figure 1
Figure 2
Figure 3
Figure 4
Figure 5
