X10 IR543 User manual

X10(USA)Inc.LimitedOneYearWarranty
X10(USA)Inc.(X10)warrantsX10productstobefreefromdefectivematerial
andworkmanshipforaperiodofone(1)yearfromtheoriginaldateofpurchase
atretail.X10agreestorepairorreplace,atitssolediscretion,adefectiveX10
productifreturnedtoX10withinthewarrantyperiodandwithproofofpurchase.
Ifserviceisrequiredunderthiswarranty:
Call1-800-442-5065,visitwww.x10.com,ore-mail[email protected].
Forhelpormoreinformationonsetup,pleasevisit:
http://www.x10.com/support
CommandCenter,ModelIR543SetupandOperatingInstructions
The IR543 Command Center sends commands over your existing house wiring to control
lights and appliances around your home. You plug lights and appliances into X10 Modules
(soldseparately).TheCommandCenteralsoworkswithmanyX10UniversalRemoteControls
so you can use the same remote that controls your TV, VCR, etc., to control your lights and
appliances.TheCommandCenteralsoworkswiththeCK11AActiveHomesystemtoinitiate
macros (routines) so you can set up a “coming home” routine which is initiated when you
pressabuttonontheCommandCenter.Formoreinformation,seetheActiveHomeOwner’s
Manual which can be downloaded at: http://www.x10.com/support
1. Set the Command Center’s Housecode dial to match the X10 Modules you want it to
control.
2. SettheCommandCenter’sslideswitchforthegroupofX10Modulesyouwanttocontrol
fromits buttons(1-4or 5-8).
3. Plug the Command Center into any convenient AC outlet.
4. Plug a lamp or appliance into an X10 Lamp or Appliance Module (sold separately).
TocontrolModulesfromtheCommandCenter’sbuttons:
1. Press the corresponding number button(s) for the X10 Module(s) you want to control.
E.G.,1,2,3,or4(or5,6,7,or8).
2. Press the ON or OFF button to turn the X10 Module(s) on and off.
3. TobrightenordimlightsconnectedtoX10LampModulesandWallSwitchModules(sold
separately), first press the corresponding number button(s), then press and hold the
Bright or Dim button until the desired brightness level is reached.
4. PresstheAllLightsOntoturnonALLlightsconnectedtoLampModulesandWallSwitch
Modules (set to the same Housecode as the Command Center).
5. Press the All Units Off to turn off ALL X10 Modules (set to the same Housecode as the
CommandCenter)includingApplianceModules. Note,AllLights OnandAll UnitsOff
affect all 16 Unit Codes (not just 1 to 4 or 5 to 8).
Youcan controlModules in groupsby pressing1, 2,3, and4 (or 5,6, 7,and 8), followedby
On,Off, Bright,or Dim.Modules setto 1,2,3, and4 (or5, 6,7, and 8) willthen turnon and
off, or brighten and dim at the same time (as a group).
TocontrolModulesfromanX10UniversalRemote:Followthesetupprocedureintheowner’s
manual for the Universal Remote to set it up to work with the IR543 Command Center. IR543-1/03
Troubleshooting
IfX10Modulesdon’trespondtotheCommandCenter:
• Check the Housecode on the Command Center is set to the same Housecode as your
Modules.
• Check the position of the 1-4/5-8 switch on theCommand Center.
Ifsomemodulesworkbutothersdon't:
• Try plugging the Module or theCommand Center into a different outlet.
Intercomsystems
Intercom systems which send voice signals over existing electrical wiring may interfere
with the operation of the Command Center when the intercom is in use. If the Intercom
system has its own separate wiring it will not cause a problem.
