XAVi EG102 User manual

I
User Manual
EG102
Ethernet IAD with VoIP
Wireless LAN
and Ethernet Switch
Issue 1.0
18th July. 2008

EG102 User’s Guide
II
XAVi Technologies Corporation
Tel: [phone]
9F, No. 129, Hsing Te Road, Sanchung City,
Taipei County 241,
Taiwan
Copyright © 2008, XAVi Technologies Corporation
Information in this manual is subject to change without notice. No part of this manual may be reproduced
or transmitted in any form or by any means, electronic or mechanical, including photocopying or scanning,
for any purpose, without the written permission of XAVi Technologies Corporation.
XAVi Technologies Corporation provides this documentation without warranty of any kind, implied or
expressed, including, but not limited to, the implied warranties of merchantability and fitness for a particular
purpose.

EG102 User’s Guide
III
T
Ta ab bl le e o of f C Co on nt te en nt ts s
1Introduction.................................................................................................1
Features................................................................................................................................1
Device Requirements...........................................................................................................2
2Getting to know the device........................................................................3
Parts Check...........................................................................................................................3
Front Panel............................................................................................................................4
Rear Panel............................................................................................................................5
3Connecting your device.............................................................................6
Connecting the Hardware.....................................................................................................6
Step 1. Connect the WAN port to the broadband device like DSL modem, cable modem or fiber
modem...........................................................................................................................................7
Step 2. Connect the Ethernet cable ..............................................................................................7
Step 3. Attach the power connector..............................................................................................7
Step 4. Configure your Ethernet PCs............................................................................................7
Or, step 5. Install a Wireless card and connect Wireless PCs if the device is with wireless
interface .........................................................................................................................................7
Next step........................................................................................................................................7
4Getting Start with the Web pages.............................................................8
Accessing the Web pages....................................................................................................8
Commonly used buttons.....................................................................................................10
Testing your Setup..............................................................................................................11
Default device settings........................................................................................................11
5Device Information ...................................................................................13
Summary.............................................................................................................................13
WAN....................................................................................................................................13
Statistic................................................................................................................................14
Route...................................................................................................................................14
ARP.....................................................................................................................................15
DHCP..................................................................................................................................15
6Advanced Setup........................................................................................16
WAN....................................................................................................................................16
Bridging........................................................................................................................................18
PPP over Ethernet (PPPoE)........................................................................................................19
IP over Ethernet...........................................................................................................................20
LAN......................................................................................................................................22
NAT (Network Access Translation)....................................................................................23
Virtual Server...............................................................................................................................23
Port Triggering.............................................................................................................................24

EG102 User’s Guide
IV
DMZ.............................................................................................................................................25
Security ...............................................................................................................................26
IP Address Filter ..........................................................................................................................26
Parental Control..................................................................................................................29
Quality of Service................................................................................................................30
QoS Classification .......................................................................................................................30
Routing................................................................................................................................32
Default Gateway..........................................................................................................................32
Static Route .................................................................................................................................33
Policy Routing..............................................................................................................................33
RIP...............................................................................................................................................34
DNS.....................................................................................................................................35
DNS Server..................................................................................................................................35
Dynamic DNS..............................................................................................................................35
Print Server.........................................................................................................................36
Port Mapping.......................................................................................................................37
7Wireless Setup..........................................................................................39
Basic....................................................................................................................................39
Security ...............................................................................................................................40
MAC Filter...........................................................................................................................44
Wireless Bridge...................................................................................................................45
Advanced............................................................................................................................46
Station Information..............................................................................................................47
8Voice Setup ...............................................................................................48
Interface Setup....................................................................................................................48
Provisioning Setup..............................................................................................................49
SIP Setup............................................................................................................................49
Line 1 or Line 2 Setting.......................................................................................................50
RTP/Codec Setup...............................................................................................................51
Operational Setup...............................................................................................................53
9Voice Supplementary Service.................................................................55
Call Forward........................................................................................................................55
Call Forward Unconditional .........................................................................................................55
Call Forward No Response.........................................................................................................55
Call Forward on Busy..................................................................................................................55
Secret Number, Calling Line Identification Restriction (CLIR)..........................................55
Static Configuration .....................................................................................................................56
On per call basis..........................................................................................................................56
Call Waiting.........................................................................................................................56
Call Waiting customer configuration............................................................................................56
Force Busy...................................................................................................................................56
Pickup and Release old...............................................................................................................56

EG102 User’s Guide
V
Pickup and put old on hold..........................................................................................................56
Switch between 2 active calls......................................................................................................56
Timeout........................................................................................................................................57
Three Parties Conference..................................................................................................57
Call Transfer........................................................................................................................57
Enquiry service....................................................................................................................57
Call Back Busy Subscriber (Busy).....................................................................................58
Call Back last number called (Call Return)........................................................................58
10 Diagnostic..................................................................................................59
Diagnostic............................................................................................................................59
11 Management..............................................................................................60
Settings ...............................................................................................................................60
System Log.........................................................................................................................61
TR-069 Client......................................................................................................................62
Internet Time.......................................................................................................................63
Access Control....................................................................................................................63
Service.........................................................................................................................................63
IP Address ...................................................................................................................................64
Password.....................................................................................................................................64
Update Software.................................................................................................................66
Save / Reboot.....................................................................................................................66
Appendix A - Configuring the Internet Settings...............................................67
Configuring Ethernet PCs...................................................................................................67
Before you begin..........................................................................................................................67
Windows® XP PCs......................................................................................................................67
Windows 2000 PCs.....................................................................................................................67
Windows Me PCs........................................................................................................................68
Windows 95, 98 PCs...................................................................................................................68
Windows NT 4.0 workstations.....................................................................................................69
Assigning static Internet information to your PCs .......................................................................70
Configuring Wireless PCs...................................................................................................71
Positioning the wireless PCs.......................................................................................................71
Wireless PC cards and drivers....................................................................................................71
Configuring PC access to your Wireless device......................................................................... 71
Appendix B - Troubleshooting...........................................................................72
Troubleshooting Suggestions.............................................................................................72
Diagnosing Problem using IP Utilities................................................................................73
Ping..............................................................................................................................................73
Nslookup......................................................................................................................................74
Appendix C – Glossary........................................................................................75
Appendix D - Specification .................................................................................82

EG102 User’s Guide
VI
Appendix E - Warranties .....................................................................................84
Appendix F - Regulation......................................................................................86
Appendix G - Contact information.....................................................................89

EG102 User’s Guide
1
1 Introduction
Congratulations on becoming the owner of the EG102, Ethernet IAD. You will now be
able to access the Internet using your high-speed connection.
The EG102 is an IAD integrating wireless, VoIP, and Ethernet interfaces into one
device which provides the most flexibility and efficiency way to you. You could
connect devices like PCs, Set-Top-Box, servers, phone, and so on easily by Ethernet,
wireless, and VoIP interfaces to enjoy data, voice, and video services immediately
through high speed connection.
This User Guide will show you how to connect your EG102 Ethernet IAD and how to
customize its configuration to get the most out of your new product.
Features
The list below contains the main features of the device (EG102) and may be useful to
users with knowledge of networking protocols. The chapters throughout this guide will
provide you with enough information to get the most out of your device.
The features include:
zEthernet interface automatic speed-sensing and crossover correction supports
up to 100 Mbps downstream and 100 Mbps upstream rates
zIntegrated four-port 10/100BaseTX Ethernet switch with speed-sensing and
crossover detection automatically
z802.11b/g WLAN supports up to 54 Mbps transmission rate
zProvides wireless secure transmitting encryption by either 802.1x; WEP; WEP2;
WPA; WPA2; TKIP; AES; 802.11i
zSupports 2 FXS ports for VoIP application including call waiting, call forward, call
transfer and so on
zSupport voice CODECs like G.711, G.726, G.729AB, BV16, ILBC, T.38 etc.;
programmable G.168 echo cancellation, adaptive jitter buffer and packet loss
concealment
zSupports Voice activity detection (VAD), comfort noise generation (CNG) and
caller ID
zSupports DTMF tone detection and generation; Fax / Modem detection and
pass-through
zSupport SIP signaling protocol and bonus services like call forwarding, call
waiting, call transfer, call busy, call return, enquiry service, CLIP/CLIR and three
way conference
zSupport Networking protocols such as PPP, Routing, DHCP server / relay / client
zNetwork address translation (NAT) functions to provide security for your LAN and
multiple PCs surfing Internet simultaneously.
zConfiguration and management by Web-browser through the Ethernet interface
and remotely through WAN interface
zFirmware Support TR-069
zUpgradeable through HTTP / TFTP

EG102 User’s Guide
2
Device Requirements
In order to use the EG102, you must have the following:
High speed broadband service
Instructions from your ISP on what type of Internet access you will be using, and
the IP addresses needed to set up access
One or more computers, each containing an Ethernet card (10Base-T/100Base-T
network interface card (NIC)).
For system configuration using the supplied web-based program: a web browser
such as Internet Explorer v4 or later, or Netscape v4 or later. Note that version 4
of each browser is the minimum version requirement – for optimum display
quality, use Internet Explorer v5, or Netscape v6.1
Note
You do not need to use a hub or switch in order to connect more than one
Ethernet PC to the device. Instead, you can connect up to four Ethernet
PCs directly to the device using the ports labeled LAN1 to LAN4 on the
rear panel.

EG102 User’s Guide
3
2 Getting to know the device
Parts Check
In addition to this document, your package should arrive containing the following:
The device (EG102)
Ethernet cable
Standard phone line cable
Power adapter
Figure 1: Package Contents
One of EG102 devices
RJ-45 Cable
RJ-11 Cable
Power adapter

EG102 User’s Guide
4
Front Panel
The front panel of this device will be described here which cover all front panel
definitions of other models.
Figure 2: Front Panel and LEDs
Connector and LED definitions from left to right:
Label Color Function
Power Green
or Red GREEN off: No power
GREEN on: Power on
RED on: Self-test fails
WAN Green On: Physical layer sync up successfully.
Off: No connection or no signal
Blink: Physical sync up progress
Internet Green
or Red GREEN off: No connection to Internet
GREEN on: The device gets an IP address
successfully in router mode
GREEM blinking: Data being transmitted.
RED on: The device is set as a BRIDGE or can not get
an IP address in ROUTER mode.
TEL1 Green On: make or receive a phone call
Off: disconnect the phone call
Blink: incoming call (ringing)
TEL2 Green On: make or receive a phone call
Off: disconnect the phone call
Blink: incoming call (ringing)
LAN Green
On: LAN link established and active
Off: No LAN link
Blink: Data being transmitted
WLAN Green
On: WLAN service is enabled
Off: WLAN service is disabled
Blink: Data being transmitted
