XDrum DD-450 User manual

00039164
Version 09/2015
XDrum
DD
-
450
Digital Drum Set
Users manual

2
INFORMATION FOR YOUR SAFETY!
THE FCC REGULATION WARNING (for USA)
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules.
These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician
for help.
Unauthorized changes or modification to this system can
void the user's authority to operate this equipment.
PRECAUTIONS
PLEASE READ CAREFULLY BEFORE PROCEEDING
Please keep this manual in a safe place for future reference.
Power Supply
Please connect the designated AC adaptor to an AC outlet
of the correct voltage.
Do not connect it to an AC outlet of voltage other than that
for which your instrument is intended.
Unplug the AC power adaptor when not using the
instrument, or during electrical storms.
Connections
Before connecting the instrument to other devices, turn off
the power to all units. This will help prevent malfunction and
/ or damage to other devices.
Location
Do not expose the instrument to the following conditions to
avoid deformation, discoloration, or more serious damage:
Direct sunlight
Extreme temperature or humidity
Excessive dusty or dirty location
Strong vibrations or shocks
Close to magnetic fields
Interference with other electrical devices
Radios and televisions placed nearby may experience
reception interference. Operate this unit at a suitable
distance from radios and televisions.
Cleaning
Clean only with a soft, dry cloth.
Do not use paint thinners, solvents, cleaning fluids, or
chemical-impregnated wiping cloths.
Handling
Do not apply excessive force to the switches or controls.
Do not let paper, metallic, or other objects into the
instrument. If this happens, remove the electric plug from
the outlet. Then have the instrument inspected by qualified
service personnel.
Disconnect all cables before moving the instrument.
CAUTION
The normal function of the product may be disturbed
by Strong Electro Magnetic Interference. If so, simply
reset the product to resume normal operation by
following the owner's manual. In case the function
could not resume, please use the product in other
location.
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 2 2015/5/13 16:09:46

3
Connects
Main Features.............................................................4
Panel & Display Description
Front Panel...................................................................5
Side Panel (Connecting)..............................................6
LCD Display..................................................................7
Setup
Connecting Pads and Pedals.......................................8
Getting Ready to Play
Setting Up the Power Supply........................................9
Turning the Power On/Off.............................................9
Quick Play
Drum Kits and Voices.................................................10
Playing Techniques.....................................................10
Select a Preset Drum Kit and Create a User Drum
Kit
About the Preset and User Drum Kit..........................12
Edit the Drum Kit Parameters.....................................12
Edit the Voice Parameters..........................................12
Save User Drum Kit....................................................13
Playing Along with a Song
Playing Along with a Song..........................................14
Metronome.................................................................14
Record
Preparing Record.......................................................15
Start / Stop Recording................................................15
Auto Fill In（AFI）
Turn the AFI Function On/ Off.....................................16
Rules of AFI trigger.....................................................16
Coach
About Coach Mode.....................................................17
Coach Mode Control..................................................17
Qut Cnt (Quiet Count)................................................17
Change Up.................................................................18
Beat Check.................................................................19
DBT (Double Bass Trigger)
Turn the DBT Function On..........................................20
Tempo........................................................................20
Utility Mode (Utility)
The Drum Pad Trigger Settings..................................21
The Drum Module Settings.........................................22
Download AFI Midi Styles from a Computer...........23
Troubleshooting.......................................................24
Prompt Messages.....................................................24
Specifications...........................................................24
Appendix
Drum Kit List...............................................................25
Drum Voice List ..........................................................26
Song List....................................................................28
GM Drum Kit List........................................................29
GM Melody Voice List.................................................30
MIDI Implementation Chart........................................31
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 3 2015/5/13 16:09:46

4
Bring the Professional Experience to Your Performance
Natural and Realistic Voices
This digital drum has equipped with all new voices, which vastly improved sound quality and will reach a super natural and
realistic sense for your ears. No matter playing the stroke roll or striking pads with velocity dynamic, all of these let you enjoy
delicate nuances and natural voice, capture the unique characteristics of acoustic drum kit.
Fashionable Appearance
Compact, elegant appearance, only occupy a little place when fold it up. Except for a perfect learning assistant, it also can be
exquisite furniture decorated in your house.
Interesting AFI Function
There is an interesting way to suddenly become a master drummer. AFI means the auto fill in function, use this function you
can play a professional cool solo without any difficulties. What’s more, you can download your own AFI style solos to your
module through specified user software.
Amazing DBT Function
Easy to achieve double bass pedal techniques here. The frequency is adjustable.
Scientific COACH Practicing
Provide three coach modes with dozens of common beat practice. Automatically score function intuitively reflects practice
condition.
USB MIDI Output
This digital drum equipped with an USB MIDI output, it is available to connect with smart devices, such as an iPad, through a
Camera kit.
Main Features
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 4 2015/5/13 16:09:46

5
Panel Description
1. [VOLUME] Knob
Adjust the phone volume level.
Note:
Rotate the [VOLUME] knob anticlockwise to the minimum
position before power on.
2. [POWER] Button
Press this button to power on/ off the module.
3. [DBT] (DOUBLE BASS TRIGGER) Button
Turn DBT function on/ off.
*Turn DBT function on. It can generate two or three
continuous kick sounds when you step on the bass drum
only once. Easy to achieve double bass pedal techniques.
4. [COACH] Button
Enter learning mode.
5. [AFI] (AUTO FILL IN) button
Turn AFI function on/ off.
*Turn AFI function on when play a song. Strike specified
AFI trigger to play intro/ ending or fill drum solos without
striking a pad.
6. [CLICK] Button
Start/Stop the metronome; enter the metronome
parameter setting mode.
7. [KIT/VOICE] Button
Shortly press: enter drum kit mode.
Press and hold: enter voice mode.
8. [SONG/REC] Button
Shortly press: enter the song mode.
Press and hold: enter the quick record mode.
9. [UTILITY] Button
Enter the utility mode.
10. [TEMPO] Button
Adjust the tempo value.
11. [SAVE/ENTER] Button
Save the drum kit / pad settings.
12. [START/STOP] Button
Start / Stop playing songs.
13. [PAGE] Button
Switch between the settings of different functions.
14. [+]/ [-] Button
Gradually increasing or decreasing the value of settings.
15. LCD Display
Shows the name and parameter settings of Kit, Voice,
Song and so on.
Front Panel
1
2 3 45
6 7 8 9
10 11 12 13
14
15
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 5 2015/5/13 16:09:46

6
Panel Description
Side Panel (Connecting)
16. USB MIDI Terminal
Connect the PC/USB host with audio devices.
Note:
Only transmit MIDI data.
17. AUX IN jack (1/8”)
For connecting an extra audio player, for example, MP3
and so on via a stereo plug. You can enjoy playing the
drum along with your favorite songs.
18. AFI Terminal
Connect the AFI trigger.
19. PHONES jack (1/8”)
Connect stereo headphones here.
20. DC IN jack
Connect the AC adaptor here. Plug the AC adaptor cable
into the DC IN jack.
Note:
To prevent malfunction and equipment failure, always turn down the volume, and turn off all the units before making any
connections.
16 18 19 20
17
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 6 2015/5/13 16:09:46

7
Panel Description
1. Mode
Display the current mode, such as KIT, VOICE, SONG,
and UTILITY and so on.
2. Coach Mode
Display current beat accuracy and rhythm type.
3. The Second Level Mode
When the mode is turned on, the LCD displays current
mode.
4. External Device and Strike Strength
Display the connected external device and current
striking strength.
5. Pad Name
Display the current selected pad name.
6. Parameter Type
Display current parameter type, for instance, Volume,
Curve and so on.
7. Parameter Value
Display the value which corresponding to the parameter
or the number of Song/Kit/Voice.
LCD Display
1
2
2
3 3
4
5
6 7
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 7 2015/5/13 16:09:46

8
Ride
Crash
Hi-Hat
Drum Module
Hi-Hat Control
Kick
Snare
Tom1 Tom2
Tom3
AFI Trigger AFI Trigger
Setup
Caution!
To prevent electric shock and damage to drum module or other devices, always turn off the power of all devices
before making any connections.
Connecting Pads and Pedals
Standard configuration: KICK, SNARE (Double trigger), TOM 1~3, CRASH 1 (Choke), RIDE (Choke), HI-HAT,
HI-HAT CONTROL PEDAL, AFI Triggers.
Note:
1. Using the cables provided, connect each Trigger input jack on the rear panel of the module, and make sure
each pad is connected to its corresponding trigger input jack.
2. For details on assembling the drum stand, attaching the digital drum and connecting pads, refer to the
Installation Manual description.
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 8 2015/5/13 16:09:47

9
Setting up the Power Supply
1. Connect the DC plug of the AC power adaptor to the DC IN jack on
the rear panel.
2. Connect the other end of the power cord to the AC outlet.
Note:
1. Only use the voltage specified as correct for the drum module.
2. Even when the module is turned off, electricity is still flowing to the
module at the minimum level. When you are not using the drum
module for a long time, make sure to unplug the AC power adaptor
from the wall AC outlet.
Turning the Power On/Off
Turning the power on
1. Please make sure that the volume has been adjusted minimize.
2. Press the [POWER] button.
3. Listen through the headphone.
4. Striking the pads and adjust the volume by slowly turning the
[VOLUME] knob toward the right direction. Keep turning until you
get an appropriate value.
Note:
1. Make sure that you have made all necessary connections right
(trigger, audio and so on), turn down all volume controls of the
module and other audio equipments.
Turning the power off
1. Minimize the volume of the module and connected audio devices.
2. Turn the connected external audio device off.
3. Press the [POWER] button again.
Note:
The drum module automatically saves all current settings before it
turns off, you can also restore the factory setting by the following steps:
a) Press the [+] and [-] buttons simultaneously.
b) Press the [POWER] button.
c) When the LCD displays “FAC SET”, it indicates the factory setting is
finished.
About the Auto Power Off Function
To prevent unnecessary power consumption, this function automatically
turns the power off if no buttons or keys are operated for
approximately 30 minutes. If desired, you can disable or enable this
function. Refer to Utility Settings.
Getting Ready to Play
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 9 2015/5/13 16:09:47

10
KIT xx
KICK
Head
SNARE TOM1 TOM2
Head Head Head
TOM3
Head
HI-HAT CRASH
Head Head
Rim
RIDE
Head
Drum Kits and Voices
An acoustic drum has only a fixed kit, but the digital has a lot. It is a
particular characteristic of digital drum.
The structure of a drum kit is shown on the right:
Drum Kits and Voices
1. Shortly press the [KIT/ VOICE] button, enter the drum kit menu.
The screen is shown on the right:
2. Press the [+]/ [-] button to select your desired drum kit. (Refer to
Drum Kit List)
Selecting a voice
While striking the pads, you can enjoy the ensemble sound effect. If
you are not satisfied with the voice of any pads, change the voice as
you want.
1. Press the [KIT/ VOICE] button for 2 seconds to enter the voice
menu.
The screen displayed is shown on the right:
2. Strike the pad you want.
The screen will display the name of current pad.
3. While striking the pad, press the [+] / [-] button until you get an
appropriate voice for your pads. (Refer to Voice List)
Quick Play
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 10 2015/5/13 16:09:47

Head
Head
Rim
11
Playing Techniques
This section introduces various performance functions to make your
performance professional. Similar to an acoustic drum kit, the digital
drum responds differently to various playing techniques and dynamics.
All the pads are velocity sensitive. And some voices change timbre
depending on the striking force.
Pad
Only the snare drum can detect both head shot and rim shot.
Head Shot
Strike only the head of the pad.
Rim Shot
Strike the head and the rim of the pad simultaneously. Or you can only
strike the rim of the pad.
Cymbal
Cymbal Bow shot
Playing the middle area of the cymbal.
Choke Play
Both Ride and Crash cymbals have cymbal choke. But hi-hat don't
have the cymbal choke.
Choking the crash/ride edge with the hand immediately after hitting the
crash/ride mutes the crash/ride sound.
Hi-Hat
Hi-Hat Pedal Change
With different positions the pedal pressed down, the voice of pad
varied while you are striking the Hi-Hat pad. And this is similar to an
acoustic drum.
Open Hi-Hat
Strike the Hi-Hat pad without pressing the pedal.
Closed Hi-Hat
Strike the Hi-Hat pad with the pedal pressed completely down.
Hi-Hat Pedal
Press down the hi-hat controller’s pedal to create a foot-close sound
without having to strike the hi-hat pad.
Splash
Playing the hi-hat with the pedal fully pressed and then instantly
opening it.
Quick Play
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 11 2015/5/13 16:09:47

12
About the Preset and User Drum Kit
From No.1 to 20 are preset drum kits, and the drum kits from No.21 to
25 are user drum kits. You can edit the parameters of drum kit (from
No.1-20), and save them into user drum kits (from No.21-25).
Note:
Please save your own parameter or voice after edited, otherwise, all
data will lost.
Edit the Drum Kit Parameters
Change the drum kit volume, the overall effect of drum kit will be
affected. It means if you increase the volume of drum kit, all volume of
the pads will be increased.
1. Press the [KIT] button, the LCD will display the kit menu.
2. Repeatedly press the [PAGE] button to select the item that you want
to edit.
3. Press the [+] / [-] button to adjust parameter value.
Edit the Voice Parameters
Edit parameters of one pad will not affect others. For example, if you
increased the volume of snare, the other pads wouldn’t change.
1. Press the [KIT/VOICE] button for 2 seconds and the LCD will display
the voice menu.
2. Strike the pad that you want to edit.
3. Repeatedly press the [PAGE] button to select an item you want.
4. Press the [+]/ [-] button to adjust parameter value.
Select a Preset Drum Kit and Create a User Drum Kit
Parameter
KIT NAME
VOLUME
Value
Preset: 1~20
User: 21~25
0~8
LCD Display
NUM XXX
VOL XXX
Description
Drum kit selection.
Adjust the volume of drum kit;
the volume of each pad will be
changed.
Parameter
VOICE NAME
VOLUME
Value
1~226
0~8
LCD Display
NUM XXX
VOL XXX
Description
Select a voice.
Adjust the volume
of voice.
Triggers：
K (KICK)
Sn (Snare)
SnR (Snare Rim)
T1 (Tom1)
T2 (Tom2)
T3 (Tom3)
HH (Hi-hat)
C1 (Crash1)
Rd (Ride)
Pd(Hi-hat Pedal)
PS (Hi-hat Splash)
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 12 2015/5/13 16:09:47

13
Save User Drum Kit
1. While in the drum kit and voice edit menu, press the [SAVE/ ENTER]
button to save all changes.
2. Use the [+] / [-] button to select a user drum kit (From No.21 to 25).
The number of kit starts flashing at the same time.
3. Press the [SAVE/ ENTER] button again; the LCD will display “OK”,
which indicates all data has been saved successfully.
Select a Preset Drum Kit and Create a User Drum Kit
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 13 2015/5/13 16:09:47

14
In order to have a better performance experience, a variety of styles can
be selected. Each one offers you to practice. (Refer to the Song List)
You can play the drums while listening to one of these songs.
A song contains Drum part and Accompaniment part. Drum part means
the rhythm you played on the pads; the Accompaniment part means
percussion and melody. The volume of each part can be adjusted.
Playing Along with a Song
1. Press the [SONG] button to enter the selection menu.
2. Repeatedly press the [PAGE] button to select the parameter that you
want to edit.
3. Use the [+] / [-] button to adjust the parameter value.
Press the [+] / [-] buttons simultaneously to mute songs.
4. Press the [START/STOP] button to play/stop songs.
Metronome
Practicing with the metronome is the best way to follow the beats.
Choose a right tempo for your learning/ performance require.
Starting/ Stopping the Metronome and Its Feature
1. Press the [CLICK] button.
The metronome will start playing, and the light of the [CLICK] button
will blink with the tempo.
2. Repeatedly press the [PAGE] button to select the parameter you
want to edit. Adjustable parameters are shown below:
3. Use the [+] / [-] button to change the parameter value.
4. Press the [CLICK] button again to stop the metronome, the light will
be off.
Parameter
SONG SELECT
ACC VOLUME
DRUM VOLUME
Value
1~61
0~8
0~8
LCD Display
NUM XXX
ACC XXX
DRM XXX
Description
Select a song.
Adjust the background volume.
Adjust the drum volume.
Parameter
TIME
SIGNATURE
INTERVAL
VOLUME
NAME
Value
0-9/2, 0-9/4,
0-9/8, 0-9/16
1/2,3/8,1/4,
1/8,1/12,1/16
0~5
1~6
LCD Display
SIG XXX
INT XXX
VOL XXX
NUM XXX
Description
Adjust the time signature.
Adjust the rhythm interval.
Adjust the volume of
metronome.
Select the metronome voice.
Playing Along with a Song
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 14 2015/5/13 16:09:48

15
This digital drum offers you easily record your own performance.
Maximize 5000 notes could be recorded in one user song.
Preparing and starting record, refer to the details bellow:
Preparing Record
1. Press the [REC] button for 2 seconds to enter the Record-prepare
mode, the light of the [REC] button starts flashing, and it means the
record is standby. The “REC” icon on the LCD lights up and displays
“RDY---”.
2. If you want to exit the record-prepare mode, press the [SONG]/ [KIT]
button.
Start / Stop recording
1. You can start recording in real time while in the preparing record
menu, there are two ways to start record:
Press the [START/STOP] button.
Strike one pad.
2. Recoding begins after 4 beats count-in.
3. While recording, the light of the [REC] button keeps lighting all the
time, and the LCD will display “ING xxx”, the “xxx” means measure
number.
4. Press the [START/STOP] button again to stop recording, and the
light of the [REC] button will be off.
5. The system returns to the last option automatically. The LCD will
display “NUM 061”. Press the [START/ STOP] button to play back
the recorded song.
Note:
While the record storage capacity is full, the LCD will temporarily display
“REC FUL”, the recording stops automatically.
Record
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 15 2015/5/13 16:09:48

16
There are 10 preset AFI styles, and each style contains 5 Intros, 10 Fills
and 5 Endings which triggered at random. When the AFI function is off,
the splash and cowbell will be triggered when strike the AFI trigger. Edit
voice in the voice menu. When the AFI function is on, strike the AFI
triggers to automatically play an intro, fill or ending.
There are 2 AFI triggers, one for triggering intro/ending, and one for fill.
Turn the AFI Function On/ Off
1. Press the [AFI] button to turn AFI function on. The light of [AFI] keeps
lighting.
The light of the [CLICK] button starts flashing, but only indicates you
the current tempo value. Press the [CLICK] button, you can hear the
click voice.
2. Press the [PAGE] button to switch between the menu of solo type
and accompaniment type, and use the [+]/ [-] button to select an
appropriate setting for each of them.
Trigger the intro, sync start accompaniment. Trigger the ending, sync
stop accompaniment.
3. The light of the [AFI] button starts flashing when playing the intro, fill,
or ending.
4. Press the [AFI] button again to turn AFI function off.
Rules of AFI trigger
When the accompaniment is off:
1. Real-time respond current trigger.
2. Alternate trigger intro/ ending.
When the accompaniment is on:
1. Real-time respond the fill when the accompaniment is not playing.
2. When the accompaniment is playing and AFI is not playing, real-time
respond fill expect triggered at the last beat.
When triggered the fill at the last beat, start playing fill at the next bar.
3. When the accompaniment and AFI is playing, only triggered the fill at
the last beat, start playing fill at the next bar.
4. When trigger the intro, accompaniment automatically start playing.
5. Ending always responded at the next bar after triggered.
6. When trigger the ending, accompaniment playing will fade out and
stop.
Note:
Users can load their own AFI styles (MIDI format) into module and use
them in AFI function. Please refer to “Download AFI MIDI Styles from a
Computer” for more details.
AUTO FILL IN (AFI)
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 16 2015/5/13 16:09:48

17
The Coach mode is a unique set of exercises. Specifically designed for
those learners who want to build a better tempo, accuracy and
stamina, as well as developing a better drum playing skills.
About Coach Mode
There are three types of exercises in Coach Mode: Quiet Count,
Change Up and Beat Check. Each exercise has its special practicing
characteristics. Automatic grading function is available for Change Up
and Beat Check types. Try to get a perfect score of 100!
Coach Mode Control
1. Press the [COACH] button to enter coach mode. Then repeatedly
press the [PAGE] button to shift coach type among Quiet Count,
Change Up and Beat Check. In the meantime, you can set the
accent beat prompt for MEA.
According to your present playing skills, select an appropriate coach
type to practice.
2. Press the [ENTER] button to enter the selected coach type.
3. Use the [PAGE] button to select relevant parameters.
Throughout the Coach modes, you will discover that some of them
have programmable parameters, allowing you to adapt the functions
to your specific needs.
4. Press the [TEMPO] button to adjust practice speed at any time.
5. Pay attention to the LCD indicators of hitting accuracy when you are
practicing.
Note:
1. Set the automatic grading function to “ON”, only playing with
metronome guidance without bell.
2. Set the automatic grading function to “OFF”, playing with
conventional metronome sound with bell.
6. Press the [COACH] button to exit the Coach Mode.
QUT CNT (QUIET COUNT)
Practice with auto metronome on/ off circularly with several measures
to help you develop a good sense of time and tempo.
1. Repeatedly press the [PAGE] button to select quiet count mode.
2. Press the [ENTER] button to enter quiet count mode.
3. Use the [PAGE] button switch between QUT and CNT parameters,
press the [+]/ [-] button to select a suitable quiet and count type.
Coach
Coach Type
Quiet Count
Change Up
Beat Check
Display
QUT CNt
CHG UP
BEA CHE
Description
This helps to develop a good sense of time/
tempo. There are 3 types of quiet mode and
5 selectable rhythm types.
3 types of rhythm pattern to train your beat
accuracy. The rhythm type will change every
two measures.
Only metronome accuracy practice. There
are 15 selectable rhythm types.
Try to play fast
Good hit
Try to play slowly
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 17 2015/5/13 16:09:48

18
4. Press the [START/ STOP] button to start practicing.
There is a count-in about 1 measure length before starting. Metro
nome sound automatically on/ off, you have to catch up with every
beat you ought to play, come on!
5. If you want to change another QUT/CNT parameter or just exit
coach mode. Firstly, press the [START/ STOP] button again to stop
practicing.
Change Up
In change up mode, system will automatic change the style every two
measures. The note value gradually becomes shorter from half note,
and then will return to half note in the end. This change will be
repeated. The icon on the LCD will flash for times when the rhythm
type is ready to change.
1. Repeatedly press the [PAGE] button to select change up mode.
2. Press the [ENTER] button to enter change up mode.
3. Use the [+]/ [-] button to select a suitable rhythm pattern.
4. Use the [PAGE] button to switch to score editing, press the [+]/ [-]
button to turn score function on/ off.
The default score setting is “OFF”.
5. Press the [START/ STOP] button to start practicing.
There will play a length of one measure count-in before starting.
This system automatic change the style every two measures. In
addition to, the next rhythm will flash for times on the LCD when the
rhythm type is ready to change.
6. If the score setting is “ON”: Auto stops practicing and displays your
score after circularly playing several times. Or, Press the [START/
STOP] button to stop practicing and back to the main page of
change up without display your score.
If the score setting is “OFF”: Press the [START/ STOP] button to
stop the practicing mode.
Coach
Chang Up
CHG
SCO
Range
1~3
ON/ OFF
Description
Use the [+]/ [-] button to select a
suitable rhythm type.
ON: The score setting is on.
OFF: The score setting is off.
Display
CHG XXX
SCO XXX
Parameters
QUT
CNT
Range
1~5
1-1/2-2/1-3
Display
QUT XXX
CNT XXX
Description
Use the [+]/ [-] button to select a
suitable quiet type.
Use the [+]/ [-] button to select a
suitable count type.
1-1: 1 measure counts, 1
measure quiets.
2-2: 1 measure counts, 2
measure quiets.
1-3: 1 measure counts, 3
measure quiets.
hq
q qq
3
qqq
qqq
3
hq q
qq
3
qqq
qqq
3
hq q
qq
3
qqq qq qq
6
Rhythm
Pattern
P-1
P-2
P-3
Display
CHG 001
CHG 002
CHG 003
Description
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 18 2015/5/13 16:09:48

19
Beat Check
In order to improve playing accuracy of beat, practice with the
metronome basic beat type. If the score function is on, system will
display your practicing score after you have finished.
1. Repeatedly press the [PAGE] button to select beat check mode.
2. Press the [SAVE/ ENTER] button to enter beat check mode.
3. Use the [+]/ [-] button to select a beat type to practice. There are 15
beat types to choose from.
4. Use the [PAGE] button to switch to score editing, press the [+]/ [-]
button to turn score function on/ off.
The default score setting is “OFF”.
5. Press the [START/ STOP] button to start practicing.
There will play a length of one measure count-in before starting.
6. If the score setting is “ON”: Auto stops practicing and displays your
score after circularly playing several times. Or, Press the
[START/ STOP] button to stop practicing and back to the main page
of beat check without display your score.
If the score setting is “OFF”: Press the [START/ STOP] button to
stop the practicing mode.
Coach
Beat check
BEA
SCO
Range
1-15
ON, OFF
Description
Use the [+]/ [-] button to select a
suitable beat type.
ON: The score setting is on.
OFF: The score setting is off.
Display
BEA XXX
SCOXXX
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 19 2015/5/13 16:09:48

20
Normally, it is too hard for beginners to play double bass, almost
impossible, but we make it possible now. Turn on DBT function on; it
can generate two or three continuous kick sounds when you step on
the bass drum only once. Easy to achieve double bass pedal
techniques.
Turn the DBT Function On
1. Press the [DBT] button to turn DBT function on. The [DBT] button
lights up.
The screen will display “DBT 1-x”.
2. Use [+]/ [-] to adjust the second trigger time. This setting can be
remained even turn the module off.
Press the [TEMPO] button to adjust the tempo value of metronome and
song playback.
1. Press the [TEMPO] button.
2. Use the [+] / [-] button to adjust tempo value.
3. Without any operation within 3 seconds, the system will be back to
previous menu automatically.
3. As you play the bass drum, it can produce a double bass technique.
4. Press the [DBT] button again, turn DBT function off.
DBT (Double Bass Trigger)
Tempo
Parameter
BEA
Range
1-1/1-2/
1-3/1-4
Display
DBT XXX
Description
1. Press the [+]/ [-] button to select a
rhythm type.
2. 1=original beat, trigger once.
2=original beat/ 2, trigger once.
3=original beat/ 3, trigger twice.
4=original beat/ 4, trigger once.
3. Power off protection. This setting can
be remained even turn the module off.
Parameter
Tempo
Value
30-280
LCD Display
TMP xxx
Description
Both metronome and song playback
are based on this tempo value.
C
M
Y
CM
MY
CY
CMY
K
AW_DD620_manual_G04_150508.pdf 20 2015/5/13 16:09:48
