XDrum DD-30 User manual

000
2
5211
Version 01/2013
DD
-
30 Digital Drum
Users manual

INFORMATION FOR YOUR SAFETY!THE FCC REGULATION WARNING (for USA)This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: Reorient or relocate the receiving antenna. Increase the separation between the equipment and receiver. Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help.Unauthorized changes or modification to this system can void the user’s authority to operate this equipment.CAUTIONThe normal function of the product may be disturbed by Strong Electro Magnetic Interference. If so, simply reset the product to resume normal operation by following the owner’s manual. In case the function could not resume, please use the product in other location.PRECAUTIONSPLEASE READ CAREFULLY BEFORE PROCEEDINGPlease keep this manual in a safe place for future reference.Power SupplyPlease connect the designated AC adaptor to an AC outlet of the correct voltage.Do not connect it to an AC outlet of voltage other than that for which your instrument is intended.Unplug the AC power adaptor when not using the instrument, or during electrical storms.ConnectionsBefore connecting the instrument to other devices, turn off the power to all units. This will help prevent malfunction and / or damage to other devices.LocationDo not expose the instrument to the following conditions to avoid deformation, discoloration, or more serious damage: Direct sunlight Extreme temperature or humidity Excessive dusty or dirty location Strong vibrations or shocks Close to magnetic fieldsInterference with other electrical devicesRadios and televisions placed nearby may experience reception interference. Operate this unit at a suitable distance from radios and televisions.CleaningClean only with a soft, dry cloth.Do not use paint thinners, solvents, cleaning fluids, or chemical-impregnated wiping cloths.HandlingDo not apply excessive force to the switches or controls.Do not let paper, metallic, or other objects into the instrument. If this happens, unplug the AC adaptor from the wall outlet. Then have the instrument inspected by qualified service personnel.Disconnect all cables before moving the instrument.2

ContentsPanel DescriptionFront PanelRear Panel.....................................................................................................................................4SetupPower Supply.................................................................................................................................5ConnectionsUsing Headphones........................................................................................................................5Playing the Demo Song...............................................................................................................6Playing a Rhythm.........................................................................................................................7Playing the pads..........................................................................................................................8Learning a Lesson.......................................................................................................................8Specifications..............................................................................................................................9AppendicesPercussion kit List........................................................................................................................10Rhythm kit List.............................................................................................................................11Demo List.....................................................................................................................................11....................................................................................................................................43

Panel DescriptionFront Panel1. POWER ON/OFF Start or stop playing.2. VOLUME +/- Increase/decrease volume.3. KIT +/- Increase/decrease kit number.4. 1~7 Number buttons [1~7] for rhythm selection.5. [+/-] Increase/decrease rhythm number.4123456789106. DEMO Start or stop playing the demo song.7. TEMPO+/- Increase/decrease tempo value.8. START Start rhythm play.9. STOP Stop rhythm play.10. LESSON Go into lesson mode.Rear Panel11. Headphone jack This stereo jack is used to connect headphone.12. DC jack Connect the included DC 9V power adaptor.1112

SetupPower SupplyYour Digital Drum will run either from batteries or power adaptor. Follow the instructions below according to the power source you intend to use.Using an AC-AdaptorConnect the power adaptor to the DC IN jack located on the rear panel of the unit, and plug the AC power adaptor into an AC power outlet.Using Batteries1. Open the battery compartment cover on the underside of the unit.2. Insert six “C” size, R-14, SUM-2 or equivalent batteries. When inserting the batteries, be careful to follow the polarity marking in the illustration.3. Close the battery compartment securely.Note:Power will be automatically drawn from the AC adaptor if an optional AC adaptor is connected while batteries are installed in the instrument.Caution:It is recommended that you replace worn batteries as soon as possible. When battery voltage drops, the display will dim and/or the sound will become distorted. When this occurs, replace the batteries with a complete set of six new batteries of the same type.NEVER mix old and new batteries, different types of batteries (alkaline, magnesium, etc ), batteries by different makers, or batteries from the same maker but of different types. Misuse may cause the instrument to become hot, result in fire, or battery leakage.Also, to prevent damage due to battery leakage, remove all the batteries from the instrument when it is not to be used for an extended period of time. Batteries left in an unused instrument will also loose their power overtime.5ConnectionsUsing HeadphonesAn optional set of stereo headphones can be connected to the Headphones jack located on the rear panel. When a pair of headphones is connected to the jack, the internal speakers of the unit will switch off automatically, perfect for private practice or late night playing. If you want to use an external sound system, the headphone jack can also be used to connect the digital drum to a stereo system or mixing console.

Playing the Demo SongYour Digital Drum comes with a demo song for showing you the possibilities of drum. To playback the demo song, follow instructions below : 1. Turn on the power Turn the [POWER] switch on. Then indicator [Tempo] lights on.2. Start the DEMO song Press [ DEMO] button, then the demo song starts playing immediately. Meanwhile indicators of drum pads flash following demo playing , and the [Tempo] indicator flashes once per measure.3. Volume adjusting Volume of the demo song can be adjusted by pressing buttons [VOLUME+] and [VOLUME-]. The default volume value is 5. It can be adjusted from 0 to 8. Volume increases or decreases 1 level when [VOLUME+] or [VOLUME-] pressed once.4. Tempo adjusting Tempo of the demo song can be adjusted by pressing buttons [TEMPO+] and [TEMPO-]. It can be adjusted from 40BPM to 240BPM. When [TEMPO+] and [TEMPO-] pressed at the same time, the demo song would play at its default tempo.5. Stop the DEMO song Press [ DEMO ] or [STOP] button to stop the DEMO song. 6123455

7Playing a RhythmYour Digital Drum features 49 different rhythms that can be used to provide accompaniment. Select one of the rhythms and listen to it.1. Selecting a Rhythm There are two methods for selecting a rhythm. Method1: Press buttons [ ] and [ to select rhythms. In this method, rhythms are selected in circle. Method2: Use the Number buttons to type the two-digit code of the Rhythm within 2 seconds , then the corresponding rhythm will be selected. On upper front panel, each song's number and name can be found. The Rhythm's default Kit will return once you select a different . Rhythm 2. Press [START] button The selected rhythm starts playing. Indicators of drum pads flash following rhythm playing. The [Tempo] indicator flashes once per measure.3. Volume adjusting Volume of rhythm can be adjusted by pressing buttons [VOLUME+] and [VOLUME-]. Volume can be adjusted from 0 to 8.4. Tempo adjusting Tempo of the rhythm can be adjusted by pressing buttons [TEMPO+] and [TEMPO-]. Tempo can be adjusted from 40BPM to 240BPM. If [TEMPO+] and [TEMPO-] pressed at the same time, the rhythm would play at its default tempo.5. Stop rhythm playing Press [STOP] button to stop rhythm playing.+- ]12345

Playing the PadsThis Digital Drum has 26 kits.1. Selecting a kit Press buttons [KIT+] or [KIT-] to increase or decrease kit number in 1~26 range. A warning voice sounds when kit number reaches bottom number (1) or top number (26).2. Volume adjusting Volume of pads can be adjusted by pressing buttons [VOLUME+] and [VOLUME-]. It can be adjusted from 0 to 8. Then you can play pads with selected kit freely.8Learning a LessonThis Digital Drum’s lesson function let the player learn and play a rhythm by following drum indicators flashing. Starting a New Lesson1. Press the [LESSON] button The LESSON indicator light on.2. Selecting a rhythm Select a rhythm you want to learn. Its corresponding kit is also selected automatically. Note1: Refer to page 7 for rhythm selecting method Note2: Refer to page 11 kit link about current selected rhythm.3. Selecting a kit Press buttons [ KIT+ ] or [ KIT- ] to select a kit you want to play with. You can also make no change and use a rhythm’s default kit.4. Start learning Press [START] button. Rhythm’s drum part is muted, but the indication lights of each pad start flashing. You can strike the pads with indication lights.5. Stop learning Press [STOP] button to stop learning. Press [LESSON] button to exit LESSON mode. 12345512

SpecificationsPads4 Touch Sensitive Drum Pads with Indication LightsDrum Kits26 drum kitsRhythms49Demo Song1Panel ControlsPOWER ON/OFF, VOLUME[+/-], KIT[+/-], [+/-], number button [1~7], [DEMO], TEMPO[+/-], [START], [STOP], [LESSON] ConnectorsHEADPHONES9V ( AC Adaptor )Power SourceSix “C” size, SUM-2, R-14, or equivalent batteriesDimensions398(L)X278(W)X95.6(H)MMWeight 1400g9

Percussion Kit List10No0102030405060708091011121314151617181920212223242526NameAcoustic Kit 1Acoustic Kit 2Standard Kit 1Standard Kit 2Room Kit 1Room Kit 2Rock Kit 1Analog Kit 1Electronic Kit 1Jazz KitLatin KitSFX Kit 1SFX Kit 2SFX Kit 3SFX Kit 4Acoustic Kit 3Bass Drum & Stick KitBass Drum & Snare Kit 1Analog Kit 2Bass Drum & Snare Kit 2Analog Kit 3Rock Kit 2Electronic Kit 2Rock Kit 3Electronic Kit 3Analog Kit 4

Rhythm kit ListSong Num01020304050607080910111213141516171819202122232425Song Name8 Beat 8 Beat Ballad8 Beat Pop8 Beat RockRock 1Rock 2Hard RockHeavy Metal 1Heavy Metal 216 Beat 16 Beat Ballad16 Beat Pop16 Beat FunkFunk Funk PopBlues FunkDance PopDiscoHouseHip HopRapShuffle Slow RockSoul Cool JazzKits Num41111177711111118111911110Song Num262728293031323334353637383940414243444546474849Song NameJazz SwingBlues 1Blues 2Fusion 1Fusion 2BounceReggae 1Reggae 2Bossa Nova SambaLatin RockCha ChaMamboRhumbaCountryCountry RockMarchPolkaWaltz 1Waltz 2SFX 1SFX 2SFX 3SFX 4Kits Num101141211511411442614412121314Demo ListSong Num01Song NameFunk Live11
