Xenarc P104MR Installation and operating instructions

1

U
Us se er r M Ma an nu ua al l / / I In ns st ta al ll la at ti io on n G Gu ui id de e 
M
Mo od de el l N No o. . 1 10 04 4O OT TS S

Warning!Malfunctionsarepossibleifthemonitorisoperatedwithanunspecifiedpowersupply
adaptororincorrectpowervoltage.Donotexposethisunittorainoramoistenvironmenttoreduce
theriskoffireorelectricshock.
PRECAUTIONS
Donotusethemonitornearwater.
Donotplacethemonitoronanunstablecart,stand,ortable.Ifthemonitorfalls,itcaninjurea
personandcauseseriousdamagetotheappliance.Useonlyacartorstandrecommendedbythe
manufacturerorsoldwiththemonitor.Ifyoumountthemonitoronawallorshelf,useamounting
kitapprovedbythemanufacturerandfollowthekit’sinstructions.
Themonitorshouldbeoperatedwiththetypeofpoweradaptorindicatedonthelabel.
Normallyitispackedwithmonitor,oruseanadaptorapprovedbythemanufacturer.
Unplugtheunitduringalightningstormorwhenitwillnotbeusedforlongperiodsoftime.This
willprotectthemonitorfrombeingdamagedduetopowersurges.
Neverspillliquidsonthemonitor.
Donotattempttoservicethemonitoryourself;openingorremovingthecovercandamagethe
monitororpanel.Pleasereferallservicingtoqualifiedservicepersonnel.
ForWallmountadaptors,thewallsocketshallbeinstalledneartheequipmentandshouldbe
easilyaccessible.


2

Index:
I. Introduction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3
Features‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 3
Unpackthemonitor‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 3
CheckAccessories‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 3
II. Installation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 4‐6
PowerSupply&Signalconnection‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 4
CapacitiveTouchKeyControl‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 4
StructureofOSDsettings‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 5
III. Foryoursafety‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 6
IV. Supporttiming‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 6
V. ResistiveTouchPanel‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐6~10
TouchDriverinstallation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐6~10
VI. Mechanicaldimension‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 11
VII. EMCWarningStatement‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 12
FCCClassAWarning‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 12
CISPR22classAWarning‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 12
VIII. ProductGeneralSpecification‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐ 13



3
I. Introduction
‐ThismonitorproducesclearimageswithvividcolorsatresolutionsfromVGAupto
XGA.Itusesagraphicsadapterofscanningfrequencyfrom30KHzto82KHzinhorizontalsweep
whileverticalrefreshrateis56Hzto76Hzcontinuously.
‐OnScreenDisplayprovidesflexibilitywithsimple&user‐friendlycontrols.
‐IntegratedD‐subandHDMIinputsprovideflexibleconnectivityforhigh‐definitionmultimedia
devicesandgamingconsoles
‐Optionalbuilt‐in2Wx2Speakers
‐USBinterface5‐WireResistiveTouchPanel
‐1040TS:10.4”panelwithVGA&HDMIinput,and5‐WireResistivetouchscreen.


Features
-10.4inchdiagonalscreenwithnativedisplayresolution800*600
-Dual Video input: VGA, HDMI
-Full flat front panel with high quality resistive touch panel
-Rimless front bezel design;IP54 spill &dust proof
-Cable management down routing through the mounting stand
-Light weight, only 1320g physically
-5Wire Resistive Touch Panel Control Function 
-Mitsubishi PMMA cover lens for P104MG

Unpackthemonitor
-Putthemonitoronacleansurface;makesuretheboxisinanuprightposition.
-Removepackingmaterialsfrominsideofbox.

Checkaccessories
Pleasemakesuretheallaccessoriesareincluded:
 
1.8 meter VGA 15 pin Power Adaptor 
D‐sub Video cable


USB cable for P104MR 


4
II. Installation:
PowerSupply&Signalconnection:
Powersupply:UseDC12Vdcpower.
HDMIsignal:ApplyHDMIsignal

CapacitiveTouchKeyControl/Connectors


Power
()
Use the power switch to turn the power ON or OFF. We recommend turning
your system power on first, then the LCD monitor.
Presspower key to turn on and Press again for 2~3sec. to power off monitor
AutoAdjust
(AUTO)
a. PresstoexecuteAUTO‐Adjustingfunction.Thisfunctionwilloptimizethe
displayimage.
b. Sometimesthisfunctioncan'tachievetheoptimaleffects.Pleasefollowthe
manualadjustingprocedure.
c. AftertheOSDmenuisactivated,pressingthiskeycanturnofftheOSD
menu.

5
Menu
(MENU)
a. PressMenukeytoactivateOSDMenu
b. Thiskeyalsoregisters“OK”;
Press“Up,Down”keytomovetheindicatortothedesireditem,thenpress
Menukeytoselectandreadtoadjust.
Afteradjustment,pressthiskeytoreturntothepreviousMenu.
Up
(▲)
a. WhenOSDmodeisactivated(When“MENU”keyispressed),thesetwokeys
areusedtoselecttheadjustmentitems.
b. Whenadjustmentitemisselected,thesetwokeysaredefinedtodecrease
orincreasethevalueofeachselecteditem.
c. Directaccess“Up”KeywillrevealBrightnessOSDforadjustment.
Directaccess“Down”keywillrevealVolumeOSDforadjustment.
Down
(▼)
OSDLock/Unlock:
Pressingthe“Menu”Keyformorethan7secondsshalllockallcontrolkeysfunction.
Afterkeyslocked,press“Menu”keyagainformorethan7secondtounlockthekeyfunction.
StructureofOSDsettings
Man Menu:
Main
Menu


Level1Level2Level3OperatingProcedure
AutoAdjust  Press“UP”or“DOWN”toadjustH‐phase&H‐position&V‐position
clockautomatically.
Luminance
Brightness

Contrast

Sharpness

Exit

Press“UP”keytoincreasebrightness,“DOWN”keytodecrease
brightness.
Press“UP”keytoincreasecontrast,“DOWN”keytodecrease
contrast.
Press“UP”keytoincreaseimagesharpness,“DOWN”keytodecrease
imagesharpness.
ExittopreviousMenu
Management
H.Position
V.Position

PixelClock


Phase

Exit

Press“UP”keytoshiftscreenleft,“DOWN”keytoshiftscreenright.
Press“UP”keytoshiftpictureupward,“DOWN”keytoshiftpicture
downward.
Reducesanyverticalbarsorstripsvisibleonthescreenbackground.
AdjustingtheClockwillalsochangethehorizontalscreenimage
width
Removesanyhorizontalnoiseandclearsorsharpenstheimageof
characters.
ExittopreviousMenu
Color
9300K
6500K
5400K
Press“UP”or“DOWN”tochoosethreetypesofcolortemperature
9300°k,6500°k,sRGBanduserdefine.
UserPreset
Red
Green
Blue
Exit
SelectUserPresettoenterColorAdjustMenu,
Selectdesiredcolortoadjust
Exit−ExittoMainMenu
OSD
H.Position
−
AdjustOSDMenuhorizontalposition,press“UP”keytoshiftMenu
right,“DOWN”keytoshiftMenuleft
V.PositionAdjustOSDMenuverticalposition,press“UP”keytoshiftMenu
upward,“DOWN”keytoshiftMenudownward
OSDTimeSetsthetimedurationinsecondsthattheOSDisvisibleafterthelast
buttonispressed.
ExitExittopreviousMenu
Language
English
Francais
Deutsch
Italino
−
PressUp/DownkeytomoveOSDbartodesiredlanguage,
Thenpresstoconfirm,theOSDMenuwillchangetodesiredlanguage
andreturntoMainMenu.

6
Espanol
日本語
繁體中文
简体中文
Portuguese
한국어
русский
Main
Menu
Recall
Recallcolor

RecallAll


Exit
Yes
No

Yes
No
Press”Yes”toresetColortofactorysetting

Press“Yes”tosetallsettingsbacktofactorysetting,exceptlanguage

Press“Ext”toreturntoMainMenu
Information
Display
information

Exit
−
PressDisplayinformationtodisplayresolutionandrefreshrate
Press“Exit”toreturntoMainMenu
Ext−−Pressing“Exit”keywillcloseOSDMenuandsavethesettings
SourceSelectMenu:Directpressing“Down”keycanselectvideosource
VGA
HDMI


III. Foryoursafety
1. Whenmovingthemonitor,alwaysswitchoffpoweranddisconnectallcablestoavoidanydanger.
2. Pleaseusethepowerandsignalcablescorrectlywheninstalling.
3. Incaseofanyabnormalsmellornoise,pleasestopoperationandcallthenearestdealerorservice
center.

IV. Supporttimingchart:
Timing
Mode
Reference
StandardResolutionPixel
MHzFHKHzFVHzInterlaceH
Polarity
V
Polarity
Mode1VESA800×60036.000 35.156 56.250 NO ++
Mode2VESA800×60040.000 37.879 60.317 NO ++
Mode3VESA800×60050.000 48.077 72.188 NO ++
Mode4VGA640x48025.1731.4759.94NO− −
Mode5VGA720x40028.3231.4770.08NO−+
Mode 6VESA 1024 x768 65.000 48.363 60.004 N O−−

V. ResistiveTouchPanel: 
P a n e l :
Type:Five‐Wire Analog Resistive
Input Mode:Five‐Wire Analog Resistive
Transparency:80% +/‐5%
Build‐in Touch Control
Modu l e 
(Note: For Panel Touch Control, user needs to connect upstream cable to System PC)
Control type:USB
Touch Control Driver   :eGalax Touch Drivers

7
Touch Driver installation:



1.0 Screen display as below, please click Next>.



8
2.0 Select the set up type; don’t tick the box if PS2 interface is not required, Click “Next>
3.0 RS232 interface driver install is default, please click Next>

9
4.0 You can select to do Touch screen calibration after system boot up or not;Default setting is” None”
5.0 Select to use Multi‐Monitor system, then press Next>

10
6.0 Choose destination location; default folder location shown as below.
Press Next>
7.0 Figure shown below, please press Next> to complete installation

11
VI. Mechanicaldimension

12

VII. EMCWarning:
FCC ClassA Warning


ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassAdigitaldevice,
pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotection
againstharmfulinterferencewhentheequipmentisoperatedinacommercialenvironment.This
equipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandused
inaccordancewiththeinstructionmanual,maycauseharmfulinterferencetoradio
communications.Operationofthisequipmentinaresidentialareaislikelytocauseharmful
interferenceinwhichcasetheuserwillberequiredtocorrecttheinterferenceathisown
expense.

13

VIII. ProductGeneralSpecification:
ModelP104MR/P104MG
LCDpanel
Displaysize
DisplayArea
OptimalResolution
Brightness
ContrastRatio
ResponseTime
ViewingAngle
10.4"
211.2mmx158.4mm
800*600/1024*768
300cd/m²(typ)
500:1(typ)
30ms(typ)
V:50/60,H:75/75
Video VGA Signal input connector
HDMI Signal connector
15pin Miniature
D‐sub 
19 pin HDMI 
Signal cable 1.8meter VGA cable
HDMI cable(Optional)
Powersupply Adaptor
InputFrequency
Wall mount type power
adaptor 
Input:100~240AC0.9A,Output:12Vdc1.5A
H:30‐62kHz;V:55‐76Hz
CoverLens
P104VGOnly
MitsubishiPMMAHardness>5H
(JISD0202),T>90%
Resistive Touch Panel (P104MR only) Type
Input Mode
Touch Control type
Touch Control Driver
Touch control cable
ive‐Wire Analog Resistive 
Stylus or Finger 
USB 
eGalax Touch 
1.8 meter cable; one end with Mini USB B
type connect to
monitor, the other end is USB A
type connect to Host PC 
TemperatureOperating:0℃~40℃ ;Storage:‐10℃~50℃
Weight1320g(net)
PhysicalDimension248.9 x236.9 x140 (mm)
ApprovalsCE,FCC
WallMounttypeVESA75*75mm
Optional item 
Color White
*Productspecificationsmaybechangedwithoutpriornotice
*MadeInTaiwan
