Xerox 721 User manual

XEROX
Xerox 4635 Laser Printing System
Message Guide
April 1995
721P83040

Xerox Corporation
701 S. Aviation Boulevard
El Segundo, CA 90245
© 1994, 1995 by Xerox Corporation. All rights reserved.
Copyright protection claimed includes all forms and matters of
copyrightable material and information now allowed by statutory
or judicial law or hereinafter granted, including without limitation,
material generated from the software programs which are
displayed on the screen, such as icons, screen displays, looks,
etc.
Printed in the United States of America
Xerox® and all Xerox products mentioned in this publication are
trademarks of Xerox Corporation. Products and trademarks of
other companies are also acknowledged.
WARNING: This equipment has been tested and found to
comply with the limits for a Class A digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
Changes are periodically made to this document. Changes,
technical inaccuracies, and typographic errors will be corrected in
subsequent editions.
This document was created on the Xerox 6085 Professional
Computer System using VP software. The typeface is Optima.

Related publications
The Xerox 4635 Laser Printing System Message Guide Guide is
part of the ten-manual reference set for your laser printing
system. The entire reference set is listed in the table below.
Several other related documents are also listed for your
convenience. For a complete list and description of available
Xerox documentation, refer to the Xerox Documentation Catalog
(Publication number 610P17417) or call the Xerox
Documentation and Software Services (XDSS) at 1-800-445-5554.
Publication Number
Xerox Dynamic Document Interface
Operator Guide 720P13670
Xerox Dynamic Document Interface
Command Summary 720P13680
Xerox 4635 Laser Printing System
Operator Guide 721P83010
Xerox 4635 Laser Printing System
Operations Reference 721P83020
Xerox 4635 Laser Printing System
Sysgen Guide 721P83030
Xerox 4635 Laser Printing System
Message Guide 721P83040
Xerox 4635 Laser Printing System
PDL/DJDE Reference 721P83050
Xerox 4635 Laser Printing System
Forms Creation Guide 721P83060
Xerox 4635 Laser Printing System
Product Reference 721P83070
Xerox 4635 Laser Printing System
Installation Planning Guide 721P83080
Xerox 4635 Laser Printing System
Operator Command Summary Card 721P83090
Xerox 4635 Laser Printing System
PC UI Reference 721P83100
Xerox Laser Printing Systems
Tape Formats Manual 600P86175
Xerox Laser Printing Systems
Standard Font Library Font User Guide 600P86174
Xerox 4850 HighLight Color and 4135
Laser Printing Systems Font User Guide 720P87340
Helpful Facts About Paper 721P82490
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE iii

Notice
This publication may contain descriptions of concepts and
features not currently available for your Xerox Laser Printing
System. Consult your Xerox sales representative or your
operating system software program description for additional
information.
iv XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE

Table of contents
Related publications iii
Notice iv
Introduction vii
About the reference set vii
4635 Laser Printing System document set vii
What the message guide contains x
How the message guide is organized xi
The conventions used in this guide xii
1. CP (COMPRESS command) messages 1-1
2. DSR (disk save and restore command) messages 2-1
3. FD (forms compilation) messages 3-1
4. HIP (host interface processor) messages 4-1
5. IFU (Interpress font utility) messages 5-1
6. OSS (operating system software) messages 6-1
OS Level 0: Confirmation 6-1
OS Level 1: Information 6-9
OS Level 2: Routine maintenance 6-41
OS Level 3: Printer problem 6-65
OS Level 4: System or tape problem 6-71
OS Level 6: Job integrity 6-75
OS Level 7: System problem 6-95
OS Level 8: Probable severe software error 6-100
OS Level 9: Probable severe hardware error 6-107
7. PDL (job source library compilation) messages 7-1
8. PG (PURGE command) messages 8-1
9. PR (HARDCOPY graphics printing command) messages 9-1
10. PSC (printer subsystem controller command) messages 10-1
11. SCALE command messages 11-1
12. SFS (status file services command) messages 12-1
13. System verification error messages 13-1
14. Summary sheet error messages 14-1
XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE v

TABLE OF CONTENTS
Appearance warning messages 14-4
Appearance warning 14-4
Appearance warning (page n) 14-6
Fatal error messages 14-8
Fatal error 14-8
Fatal error (page n) 14-8
Informational messages 14-11
Informational messages 14-11
Master error messages 14-13
Master error (page n) 14-13
Master warning messages 14-18
Master warning (page n) 14-18
System problem messages 14-18
System problem 14-18
System problem (page n) 14-19
15. 4635 LPS additional messages 15-1
Numbered 4635 LPS messages 15-2
Messages 7 through 36 15-2
Messages 41 and 42 15-2
Messages 44 through 48 15-2
Message 538 15-2
Messages 540 and 541 15-2
Messages 544 through 574 15-3
Messages 1538 through 1572 15-7
Messages 3538 through 3579 15-11
Messages 4037 through 4145 15-13
Messages 4500 through 4506 15-14
Messages 9038 through 9068 15-15
Messages 9537 through 9542 15-18
Unnumbered 4635 LPS messages (in alphabetical order) 15-19
Appendix A. Xerox support services A-1
Glossary GLOSSARY-1
Index INDEX-1
vi XEROX 4635 LASER PRINTING SYSTEM MESSAGE GUIDE

Introduction
The Xerox4635 Laser Printing Systems Message Guide is one of
the ten manuals which make up your 4635 Laser Printing System
(LPS) Reference Set.
The LPS Message Guide provides an easy to use reference tool
for quickly determining why messages appear on your system
controller display or printed summary sheet, and the appropriate
action(s), if any, to take.
This message guide does not contain detailed explanations of
tasks. Throughout the guide, you are referred to the appropriate
reference manual for detailed information.
About the reference set
This document is part of a reference set designed to help you
receive maximum benefit from your 4635 laser printing system.
To help you select the appropriate document for your needs, the
following section identifies the documents in the set and
describes the information contained in each.
4635 Laser Printing System document set
• Product overview
• Hardware and software
• LPS connections
• User considerations
• LPS comparisons
4635 LPS
Product
Reference
