The Manual of Wireless Handle for Engraving machine
Model：WHB03
Version：V
1.0
ChengduXingHongChang Wireless Technology Co., Ltd.
www.cdxhctech.com

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 2 -
1. Structure Description
Note：When the Low voltage indicator LED light；the battery is completely；Proposed to replace the battery
2．Packing Parts
1．Wireless USB Receiver：one
2．Wireless Handle：one
3．Manual：one

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 3 -
DC Description
Name Voltage Current Note
Wireless USB Receiver 4．5V—5．0V Less than 50ma
Wireless Handle 1．5V—3．0V Average Current
Less than 2ma
Use of time More than 2
months USE Two
2000MAH Battery
Note: Wireless Handle Need Two AA Battery；When the Low voltage indicator LED light；the battery is
completely；Proposed to replace the battery
3. RF Performance Description
No. Performance or Parameters Description
1 The RF is Standard with 2.4G ISM ,the Tx power is 0DB and the RX sensitivity is -98DB.
2 The RF has 64 channels,the channel gap is 1Mhz
3 The transmission distance is further than 15 meters with no barrier
4 The protocol Designed with high performance；Low power consumption；Automatic
learning ID Number
5 To jump frequency Adaptively when noised ,which can work with 2.4G wireless Mic ,Wlan
and Bluetooth etc. devices.
6 32 sets Wireless Handle work fine at the same time in one room ,with no-interference
each other
4. Use the steps Description
Step 1
Set up the Driver Software ，and flished Set up：
Please send CD into the CD-ROM；Please follow the computer prompts，Set up the Driver
Software Until flished Set up

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 4 -
Double click the icon to begin installing the driver
Please follow the computer prompts，Set up the Driver Software Until flished Set up
Step 2
OPEN The Driver Software，then Open The NcStudio Software
From the Start menu to open just installed the driver inside

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 5 -
Open the driver soft, will appear in the task bar icon。
Step 3
Please Insert Wireless USB Receiver into USB Jack
If this is the 1st use, the computer will be prompted to find a new hardware device；Automatically install the USB
driver to wait for success
Step 4
Installing 2 AA Batteries into Wireless Handle； Press red Power switch； LCD will display properly, the handle
started to work
Note：The battery positive and negative direction, can not install the wrong
5. Features Description
A．Button Features Description

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 6 -
B．LCD Display Features Description
Coordinates of the window
Feed and speed display window
Key function description
Corresponding
icon Name Key function description
Stop button Press the button to stop machine; If the machine does not stop, long
press for 3 seconds, reset the motion controller, the machine stops.

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 7 -
Start / Pause button
Machine is running, press the button, the machine to suspend
processing
Machine is paused, press this button, the machine continues to run
Breakpoint Continue
button
Power or cutting knife for machine tools, heavy power, press the
button, the machine continues to work from the breakpoint
Floating on the knife
start or stop or reset
Button
When you press the button, the machine Operating the knife
YES and NO LED flashing lights, requires the user to reconfirm the
need for the knife；
If you press YES key, the start of the knife, LCD's on the knife
flashing; said the ongoing Operating of the knife. Press NO, then exit
to the knife
When the machine is processing running, press the button, the
machine reset, and stop processing
Back to the origin
Button Press this key piece back to the origin of the implementation machine
X Coordinates 1 / 2
Button X Coordinates 1 / 2
Y Coordinates 1 / 2
Button Y Coordinates 1 / 2
Z Coordinates 1 / 2
Button Z Coordinates 1 / 2
X oordinates=0
Button X coordinate is set to the current Workpiece coordinates axis

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 8 -
Y oordinates=0
Button Y coordinate is set to the current Workpiece coordinates axis
Z oordinates=0
Button Z coordinate is set to the current Workpiece coordinates axis
Back mechanical
origin button
Press this key, the mechanical return origin Operating。
When you press the key, YES and NO light flashes and LCD display
flashes back to the mechanical origin of the chart; indicates the
current state of the state machine back to the mechanical origin
If the user pressed YES, then all axis machine origin return; if the user
presses the X, the X-axis back to the mechanical origin, if the user
press the Y, the Y-axis back to the mechanical origin, if the user press
the Z, the Z-axis back to the machine Origin;
If the user presses NO, then exit back to the mechanical origin
Step adjustment
button
Press this key to adjust the machine to move step
0X：Continuously moving
1X：move step 0．01mm 5X：move step 0．05mm
10X：move step 0．1mm 50X：move step 0．5mm
100X：move step 1mm 500X：move step 5mm
1000X：move step 10mm
Fine adjustment
button
Fine-tune the Operating of the machine, with Hand wheel, you can
fine-tune the X, Y, Z axis movement
When in fine-tuning mode, LCD display fine-tune the icon flashes and
YES and NO lights flashing, to withdraw from fine-tuning, need to
press YES or NO key
the spindle start or
stop button Start and stop the spindle from the control action
Band switch Functional Description

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 9 -
Band switch control opponents play a round of functional role of the various functions of Hand wheel, gear
change through the band switch, and switch accordingly
display icons Icon name Functional Description
OFF stalls
Off Hand wheel function, usually do not hand wheel, needs to be the band
switch is in OFF state to prevent false triggering round opponents and
saving power consumption and extend battery life
X-axis
When fine-tuning or manual adjustment of the time, shake the hand wheel
on the X axis motion control
Y-axis
When fine-tuning or manual adjustment of the time, shake the hand wheel
on the Y axis motion control
Z-axis When fine-tuning or manual adjustment of the time, shake the hand wheel
on the Z axis motion control
Hand wheel
Lead
When the machine is in running state (corresponding to run on the LCD
screen flashing); shake the hand wheel to control the processing speed
and the suspension of operational control.
The machine is stopped state, and pause state, the Hand wheel Lead
does not work
Feed speed
control
When the feed speed control, LCD screen displays the default value of
the feed and the actual values, shaking the hand wheel can adjust the
feed speed control
the spindle
speed control
When the spindle speed control mode, LCD screen displays the default
value of spindle speed and the actual values, shaking the hand wheel to
control the speed of the spindle speed setting.
Description of the function LCD display icons

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 10 -
Display Icons The icon name Functional Description
Back to the
mechanical
origin
LCD display back to the mechanical origin of the icon that represents the
state machine in the mechanical origin
Back to the
workpiece
origin
LCD displays the icon back to the origin of the workpiece, said state
machine is back to the origin of the workpiece
Fine tuning Fine-tune the LCD display icons, said state machine is in fine-tuning
Calibration the
knife
LCD displays the icon that represents the state machine is on Calibration
the knife
runing The chart flash, running machine
pause The icon flashes to indicate that machine is suspended
idel The icon flashes to indicate that machine is idle
Moving step
value
That regulate the machine X, Y, Z coordinates when moving step show
0X：Continuously moving；1X：move step 0．01mm
5X：move step 0．05mm；10X：move step 0．1mm
50X：move step 0．5mm；100X：move step 1mm
500X：move step 5mm；1000X：move step 10mm
YES and NO
display light
flashing
Some important operations, prompting the user need to press YES or NO
key to re-key to confirm or cancel the order for the corresponding
operation
Displays status descriptions in common

成都新宏畅无线科技有限公司www.cdxhctech.com
Chengdu Xin hong chang Wireless Technology Co.,Ltd
- 11 -
Displays status Functional Description
Show All 0 ：Engraving machine motion control software
（NcStudio）that is not open Or engraving machine motion control
software（NcStudio）crash
Blinking 2 times, then close the LCD display
Instructions：USB wireless receiver is not connected to
the computer's USB port If the receiver is connected to a
computer USB port, wireless controller so that the signal is not
good, connection quality is poor
Application instructions：Start driver software, it will drive in the computer taskbar icon
Icon Functional Description Operation Description
Working properly
Close engraving machine motion
control software（NcStudio）or
engraving machine motion control
software（NcStudio）has crashed
Lock the handle or is not inserted USB
wireless receiver
The mouse into the computer task bar
icon, right click inside the pop-up menu,
select the lock handle.
If the handle is locked, pressing any key
will not work the handle
