XHC WHB04B-4:4 User manual

WHB04B-4:4
WHB04B-6:6
WHB04B-4:4 axis,wireless handwheel
WHB04B-6:6 axis,wireless handwheel

,support 10 macro function button

RESET button
Stop button
Start/Pause button:When machine stops,press
the button,machine starts to work;When
machine is working, press the button,machine
stop working
Macro-1/Feed+ button:When press the button
alone,macro function-1 works; When press the
+ ,Processing speed increase.
Macro-2/Feed- button:When press the button
alone,macro function-2 works; When press the
+ ,Processing speed decreases.

Macro-3/Spindle- button:When press the
button alone,macro function-3 works; When
press the + ,Spindle speed increases.
Macro-4/Spindle- button:When press the
button alone,macro function-4 works; When
press the + ,Spindle speed reduction.
Macro-5/M-HOME button:When press the
button alone,macro function-5 works; When
press the + ,refer all home.
Macro-6/M-HOME button:When press the
button alone,macro function-6 works; When
press the + ,Return to the safe height
of the Z axis

Macro-7/W-HOME button:When press the
button alone,macro function-7 works; When
press the + ,go to zero work.
Macro-8/S-ON/OFF button:When press the
button alone,macro function-8 works; When
press the + ,Spindle on or off.
Macro-9/ probe-Z button:When press the
button alone,macro function-9 works; When
press the + ,probe Z
Macro-10 button:press the button,macro
function-10 works.
Function button:When you press the button,
then press the other button to achieve the
combination function.

-7-
MPG button:press the button,Hand wheel
into Continuous mode.
Step button: press the button,Hand wheel
into Step mode
0.001（2
0.01(5%)
0.1(10%)
1.0(30%)
60%
100%
Lead:
MPG
)
%

Selection speed：
0.001（2%）:When handwheel in
Step mode,move unit 0.001;when in
Continuous mode,move speed is 2%
0.01(5%):When handwheel in step
mode,move unit 0.01;when in
Continuous mode,move speed is 5%
0.1(10%):When handwheel in step
mode,move unit 0.1;when in
Continuous mode,move speed is 10%
1.0(30%):When handwheel in step
mode,move unit 1.0;when in
Continuous mode,move speed is 30%
60%:When handwheel in Continuous
mode, move speed is 60%
100%:When handwheel in Continuous
mode,move speed is 100%

Mode：
CON：Continuous
Step:Step

Explantion：
Key success indication:When you press the button,the receiver
receives the key value,the indicator flashes about,indicating
successful key operation.
Speed indicator:When you press MPG button,band switch to
select 2%,5%...,LCD display CON and different speed.When
you press Step button,band switch to select 0.001,0.01...,LCD
display Step and different speed.
Axis selected location:Axis selection switch position,LCD
display axis selected. X: X axis workpiece coordinate axis,
X1: X axis mechanical coordinate

Plugin instructions
Open Mach3 and go to the “Config”menu choice and select
“Config Plugins”.You should see “ShuttlePro-V3xx-XHC-
HB04BX-FOR-MACH3”,Click the “CONFIG” in yellow and
macro button function as you wish.
-12-

Plugin instructions
1
2
3
2.After Click the yellow"CONFIG",there will be plug-in settings
interface,According to the following method set.
-13-

Plugin instructions
First step:Click the Macro-1 drop-down menu button,choice
“Custom Macro#1”, Macro-2 choice "Custom Macro#2",
And so on.Click Macro-9 drop-down menu button,choice
“OEM Custom Code#1”, Macro-10 choice “OEM Custom
Code#2”.
Second step:In the following “Macro Number” input M
code you need.Macro-1 corresponds to Macro number 1.
and so on. Macro-9 corresponds to OEM Custom Code#1,
Macro-10 corresponds to OEM Custom Code#2.
(The M code you entered must be copied to the Mach3>
macro>Mach3Mill folder)
-14-
