Xiamen VK-6089AW User manual

VK-6089AW
User Manual
PLEASE READ AND SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
A r Purifieri

Contents
1. Important safety instructions ……………………………………01
2. Product Structure……………………………………………………03
3. Before first use ………………………………………………………04
4. Using the appliance… … ……………………………………………06
5. Filter Replacement …………………………………………………11
6. Clean air purifier ……………………………………………………13
7. Storage …………………………………………………… … … … … …13
8. Environment … … … … … … … … … … … … … … … … … …………… 13
9. Troubleshooting… ……………………………………………………14
10. Warranty Terms … … … … … ………………………………………15

1. Important safety information
Read this user manual carefully before you use the appliance and save it for future
reference.
● Do not let water or any other liquid or flammable detergent enter the appliance to avoid electric shock
and/or a fire hazard.
● Do not clean the appliance with water or any other liquid or a (flammable) detergent to avoid electric
shock and/or a fire hazard.
● Check if the voltage indicated on the appliance corresponds to the local mains voltage before you
connect the appliance.
● If the mains cord is damaged, you must have it replaced by distributor, or a service centre authorised by
distributor or similarly qualified persons in order to avoid a hazard.
● Do not use the appliance if the plug, the mains cord or the appliance itself is damaged.
● This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
● Children should be supervised to ensure that they do not play with the appliance.
● Do not block the air inlet and outlet, e.g. by placing items on the air outlet or in front of the air inlet.
● To reduce the risk of fire or electric shock,DO NOT use the appliance with any solid-state speed control
device.
● This appliance is not a substitute for proper ventilation, regular vacuum cleaning or use of an extractor
hood or fan while cooking.
● If the wall socket used to power the appliance has poor connections, the plug of the appliance becomes
hot. Make sure you plug the appliance into a properly connected wall socket.
● Always place and use the appliance on a dry, stable, level and horizontal surface.
● Leave at least 40cm free space behind and on both sides of the appliance and leave at least 40cm free
space above the appliance.
● Do not place anything on top of the appliance and do not sit on the appliance.
● Do not place the appliance directly below an air conditioner to prevent condensation from dripping onto
the appliance.
● Make sure all filters are properly installed before you switch on the appliance.
● Only use the original filters specially intended for this appliance. Do not use any other filters.
● Avoid knocking against the appliance (the air inlet and outlet in particular) with hard objects.
● Always lift or move the appliance by the handle at the back of the appliance.
● Do not insert your fingers or objects into the air outlet.
● Do not use this appliance when you have used indoor smoke-type insect repellents or in places with oily
residues, burning incense or chemical fumes.
● Do not use the appliance near gas appliances, heating devices or fireplaces.
● Always unplug the appliance after use and before you clean it.
● Do not use the appliance in a room with major temperature changes, as this may cause condensation
inside the appliance.
● The appliance is only intended for household use under normal operating conditions.
● Do not use the appliance in wet surroundings or in surroundings with high ambient temperatures, such
as the bathroom, toilet or kitchen.
● The appliance does not remove carbon monoxide (CO) or radon (Rn). It cannot be used as a safety
device in case of accidents with combustion processes and hazardous chemicals.
● To prevent is interference , should be kept at least 2 meters distance between the product and the use
of radio waves electrical.
01
Danger
Warning
Caution

02
To satisfy FCC RF exposure requirements,a separation distance of 20 cm or more
should be maintained between the antenna of the device and persons during device
operation.
To ensure compliance, operations at closer than this distance is not recommended.

03
2. Product Structure
Welcome using our company air purifier ,before use please read this
manual carefully to operate the product correctly.
1 Touch-Control Panel
2 Night Light
3 Air Outlet
4 Upper Body
5 Power Cord
6 Air Inlet
7 True HEPA 4-stage Filter
8 Base Cover
2
3
4
5
7
8
6
1

04
3. Before first use
Placing the filters
The appliance comes with all filters fitted inside, but you have to remove
the packaging of the filters before you can use the appliance. Remove all
filters, unpack them and place them back into the appliance as described
below.
Note: Make sure you insert the filters in the correct position.
1. Put the appliance upside down on a soft cloth to avoid scratching, to
open the base cover, you need to find an arrow point on the base cover
corresponding the LOCK position, turn the base cover counterclockwise
from LOCK to OPEN position, then the lock released.
2. Remove the base cover and take out the new filter.
3. Remove the Plastic Packaging from the filter.

05
4. Put the filter back into the appliance.
5. Turn the base cover clockwise from OPEN position to LOCK position,
you will hear a "click" sound, the base cover is fastened.

4. Using the appliance
4.1 About the control panel
06
1). Put the plug in the wall socket
All lights will be ON for 1 second and you hear a beep,
all lights then stay OFF .
2). Press the power button to switch on the appliance.
Press button, Night light turns on and Speed at level 2 (Med) .
3). Fan speed adjustment
The fan speed light indicates at which fan speed the appliance is operating.
Press Speed button to adjust fan speed level, there are four levels
1~4 refers to Low, Medium, High and Turbo.
4). Sleep mode
When you use the appliance in Sleep Mode, it works very quietly. Only the and
buttons (If setting the timer) will be at half brightness, all other buttons light off.
Press any other buttons(except and buttons ) to exist the sleep mode.
5). Auto mode
At Auto mode, the fan speed will be automatically adjusted according to AQ level as
below:
On/Off Speed
Sleep
mode
Filter
Reset
AQ/Night
Light
Timer
Time
indicator
Fan speed
indicator
Lock
Auto
mode
WiFi
indicator
4(Turbo)

6). Air Quality Sensor Light / Night Light
There is an air quality sensor inside the air purifier.
Note: Compared with professional instrument, the detecting resut of this
air quality sensor may has tolerance in accuracy, we suggest you regard
the sensor detecting result as a reference only.
Air Quality Sensor Light (AQ Light)
Air Quality Light Color will automatically change according to the air
quality being detected.
RED = POLLUTED ; ORANGE = BAD ; GREEN = GOOD ; BLUE = VERY
GOOD
1. Press the once to enter air quality display mode, and press again
to exit.
2. Long press button 3 seconds, turn on the breathing mode, and
long press 3 seconds, turn off it.
Night Light Mode (Machine Standby Status)
Enter the Night Light Mode:
Night color is orange and cold-white. Press button turn on night light,
the light is orange, half-light, and hear a “beep” sound. Then press
button again, night light is cycle in order by fully bright-cold white, half
bright-fully bright-turn off-orange, half bright…
7). Setting timer
1. Press to turn on or off the timer, and to cycle through timer options
(2 hours, 4 hours, 6 hours, or 8 hours).
2. The air purifier will automatically power off once the timer is finished.
NOTE: Pressing or unplugging the air purifier will cancel the timer.
8). Keylock mode
1. Press button to activate Keylock mode , all buttons are locked at this
mode; If your house has young child, we suggest use this mode.
2. To cancel the keylock mode, just press and hold button for 3 seconds.
9). Filter replacement light
When indicator lights, it means that you should check the filter if it
need to be cleaned or replaced.
Note: The filter’s lifetime is based to your house air quality and using time.
Using the appliance in a humid environment will reduce the lifetime of the filter.
10). Memory Function
When the air purifier is plugged in, it will remember its previous fan speed
setting.
07

11). Connect to WiFi
At the standby mode, long press for 5
seconds, when indicator light flashes ,
then enter WiFi network pairing mode.
Please connect your smart phone to WiFi
and operate it according to following steps.
Note: If purifier has been successfully connected
to WiFi, indicator will stay on. Scan QR code to
download the APP.
01
02
01
02
Register account or Log in with
existing account.
Add device.
08

09
03
03 Click “Small Home Appliances”,
Then choose “Air Purifier”.
04
05
04 Input wifi password.
05 Click Finish network configuration.

06
06 Connecting.
10
07 Device added
successfully.
07

5. Filter Replacement
11
How to replace the Air Filter?
1. Switch off the appliance and unplug it. (a)
2. Put the appliance upside down on a soft cloth to
avoid scratching, to open the base cover, you need
to find an arrow point on the base cover
corresponding the LOCK position, turn the base
cover counterclockwise from LOCK to OPEN
position, then the base cover released. (b)
（b）
（a）
When Should I Replace the Air Filter?
It is recommended to change the air filter every 6–8 months. However, you
may need to change your filter sooner or later depending on how often you
use your air purifier. It is important to watch out for the following signs of
expired filter:
● Increased operating noise
● Decreased airflow
● Clogged filter
● Increased presence of odors
NOTE:
● The environment in which the air purifier being used may also extend or
shortenthe lifetime of the the air filter. Using your air purifier in an
environment ofrelatively high pollution may mean you will need to
change the air filter more often.
● If the air pollution in your environment is very high, there is a possibility
that the filters may not be completely effective and may need to be
replaced before lights up.
● Remember to reset the air purifier after changing the air filter.

3.
4. Remove the packaging material of the new
filter. (d)
5. Put the new filter back into the appliance. (e)
Remove the old filter. (c)
12
（c）
（d）
（e）
6.
position to LOCK position, you will hear a "click"
sound, the base cover is fastened. (f)
7.Put the plug in the wall socket and switch
on the appliance again. (g)
Turn the base cover clockwise from OPEN
（f）
（g）

8.Reset Filter's lifetime.
The filter lifetime should be reset if lights up, after
replacing the new filter, you need to reset filter lifetime.
1). Plug in the air purifier and turn it on.
2). Press and hold for 3 seconds.
3). Release and the light will turn off, indicating
that the reset is complete.
Filter replacement force mode
When using the air purifier in an environment of heavy pollution, the
lifespan of the air filter may be significantly reduced. You can change the
filters even if does not light up. Follow the steps below to perform a
hard reset.
1). Replace the air filters as mentioned in the Filter Replacement section.
2). Plug in the air purifier and keep in standby mode.
3). Press and hold for 3 seconds, and it will light up.
4). Press and hold again for 3 seconds, and it will turn off. The reset
is now complete.
13
3 seconds
（h）
6. Clean air purifier
In order to keep your purifier working with more efficiency and life-time,
clean the filter (pre-filter side only) every 2 weeks with the Instruction
Below:
1). Clean out any dust, hair, or furs remain on the pre-filter by using the
vacuum hose.
2). Clean out any dust, hair, or furs remain on the bottom cover by using
the vacuum hose.
3). DO NOT wash the filter with any water or liquid.
7. Storage
Unplug the power cord, then wipe the machine clean, put the appliance in
the packing bag ,then put it in a dry place away.
8. Environment
Do not throw away the appliance with the normal household waste at the
end of its life, but hand it in at an official collection point for recycling. By
doing this, you help to preserve the environment.

14
9. Troubleshooting
This chapter summarises the most common problems you could
encounter with the appliance. If you are unable to solve the problem with
the information below, contact the Consumer Care Centre in your country.

1) This product is warranted for one year from the date of purchase (12 months, 365
days); the warranty is limited to defects in the materials of the product and manufacturing
defects.
2) The following conditions are not in the scope of maintenance:
a) This product has exceeded the "12-month warranty".
b) Failure to provide valid purchase receipts; or alter valid purchase receipts without
authorization; or the model and serial numbers on the product in purchase receipt
do not match the actual product.
c) The label or serial number of the product is damaged or has been tampered, and
the identity of this product can't be proved effectively.
d) Due to unexpected factors, improper use or other human factors (including water
ingress, moisture, fall down, user operation errors, transportation, bumps, etc.)
cause a defect or damage ; Failure or damage caused by natural disasters and force
majeure so on (such as earthquakes, fires, etc.)
e) Disassembled, refitted or repaired by user or an unauthorized third party.
f) Not follow the instructions in this manual, or damage caused by not using the
original parts of the product.
g) The purchaser has clearly be informed that the product is a disposed product, or
samples that serve as commercial listings, or products that have been subjected to
performance overload tests.
h) Wear of any part, or damage to plastics and other accessories.
3) All air freight and transportation costs are not covered by the warranty and must be
borne by the customer.
4) In any case, the company or its authorized distributors will not grant any guarantee on
time if it is beyond the control, or any special or indirect damage occurs, the company or
its authorized distributors will not responsible for it. In addition to the above-mentioned
clear warranty provisions, the company is not required to assume other forms of
warranty responsibilities.
The electronic manual can be downloaded from the following website：
www.vorktech.com
15
10. Warranty Terms
