Xiaomi Mi Smart Air Fryer User manual

Mi Smart Air Fryer (3.5L)
User Manual

Read this manual carefully before use, and retain it for future reference.
Thank you for choosing the Mi Smart Air Fryer (3.5L). This product is for household use only.
Illustrations of product, accessories, and user interface in the user manual are for reference
purposes only. Actual product and functions may vary due to product enhancements.
Safety Instructions
Hereby, Ningbo Careline Electric Appliance Co., Ltd. declares that the radio equipment type Air Fryer MAF02 is in
compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
For detailed e-manual, please go to www.mi.com/global/service/userguide
internet address: http://www.mi.com/global/service/support/declaration.html
Do not modify the internal wiring of the air fryer.
Do not block the air fryer's air inlet and outlets, nor the heat dissipation vents during use to avoid aecting
its normal heat dissipation.
Do not use charcoal or other similar fuel sources to heat the basket, frying plate, or grill.
Do not place the basket on any other heat sources, such as an induction cooker or gas stove.
Do not plug or unplug the power cord with wet hands to avoid the risk of an electrical shock.
Do not use a power cord with a loose connection or poor contact.
Do not let the power cord cross through sharp objects to avoid damage to the power cord.
Do not use the air fryer to store any items, especially flammable, explosive, or corrosive items.
The air fryer cannot be started without the basket being in place.
Do not let children near the air fryer during or right after use to avoid them from getting scalded.
Do not use any plastic utensils or any wrapping materials which may melt or poison/aect the food to wrap
food for cooking.
Stop using the air fryer immediately and unplug it from the power source if it doesn't function normally or
malfunctions.
Do not excessively pinch, bend, twist, or place heavy objects on the power cord to prevent from exposing or
breaking its core.
Do not allow children to play with the plastic packaging bag to avoid suocation accidents.
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless
they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children less than 8 years.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
The temperature of accessible surfaces may be high when the appliance is operating.
The surfaces are liable to get hot during use.
Household use only.
The appliances are not intended to be operated by means of an external timer or separate remote control
system.
Keep a distance of 30 cm or more between the air outlets and other devices, during use.
Please ensure that the electrical outlet the air fryer is plugged into, is well grounded to avoid an electrical
shock or other safety hazards.
Do not move or shake the air fryer during use.
Do not insert any foreign objects into the safety switch, to avoid any danger.
When placing the air fryer in a kitchen cabinet, etc., please ensure that it is well ventilated.
Ensure that the air fryer is unplugged before cleaning or repairing it.
This product must be used on a level, heat-resistant surface to avoid damage to the product or accidents.
Ensure that the silicone parts of the air fryer do not come into contact with ethanol or solutions that contain
more than 50% of alcohol.
Do not use any accessories that are not recommended by the manufacturer.
Do not drop this air fryer or bump it against hard objects to avoid damage or malfunction.
Do not insert pins, wires or other objects into any of the openings of the air fryer to avoid an electrical
shock or injury.

Control Knob
Product Overview
How to Use
1. Turning on
Note: Press the power button to turn on the air fryer for the first time, „Enable Wi-Fi“ will be displayed, if you do not operate it
for 30 seconds or select No, the Wi-Fi will remain disabled, and if you select Yes, the Wi-Fi indicator will blink and Wi-Fi will be
enabled.
Notes:
2. Ingredients that are too small are not suitable for use on the grill. Please make sure that ingredients don't fall through t he
gaps in the grill.
1. The silicone rubber used in the air fryer is made of high temperature resistant food grade materials to prevent the edges of
the frying plate from scratching the coating of the basket and to improve the stability of the frying plate. Do not remove the
silicone rubber from the frying plate.
2. Turning o
21 43
Connect the power cord and press the
power button to turn on the air fryer.
Connect the power cord and press the power button to turn on the air fryer.
Press the power button to turn off the air
fryer, regardless of the state it is in.
Grill
Frying Plate
Silicone Rubber
Handle
Basket
Heat
Dissipation Vent
Power Plug
Control Knob
Display Screen
Air Inlet
Power button
Safety Switch
Air Outlet
Air Fryer
Press to confirm
selection.
Press and hold
for 0.5 seconds
to return to the
previous menu.
to change
Turn left/right
functions.
Press the power
button
to turn on/o.

3. Configuring the Wi-Fi
The ingredients can be marinated to
taste before cooking.
Preparations
How to Use
4. Connecting with Mi Home/Xiaomi Home App
This product works with the Mi Home/Xiaomi Home app*. Use the Mi Home/Xiaomi Home app
to control your device, and to interact with other smart home devices.
Updating…
Wi-Fi indicator
blinks twice
Connected
successfully
Wi-Fi indicator
is on continuously
Wi-Fi Status
Awaiting
connection…
Wi-Fi indicator
blinks slowly
Reconnecting
after a disconnection...
blinks quickly
Wi-Fi indicator
Note: If it does not connect to the Wi-Fi for 30 minutes, the Wi-Fi indicator will turn o.
Press the control knob to enter “Reset Wi-Fi” while in the “Wi-Fi” screen, then press the
control knob to select Yes to reset the Wi-Fi, or turn the control knob to select No to abandon
resetting the Wi-Fi.
Press the control knob to enter “Enable/Disable Wi-Fi” while in the ”Wi-Fi” screen, then
press the control knob to select Yes to enable or disable the Wi-Fi, or turn the control knob
to select No to abandon the change.
2. Enabling/Disabling the Wi-Fi
1. Resetting the Wi-Fi
Scan the QR code to download and install the
app. You will be directed to the connection
setup page if the app is installed already. Or
search “Mi Home/Xiaomi Home” in the app
store to download and install it.
Open Mi Home/Xiaomi Home app, tap ”+” on
the upper right, and then follow prompts to add
your device.
Note: In order to improve the user's experience, the device's
firmware and the Mi Home/Xiaomi Home app interface will be
updated from time to time, so if you encounter any interface
experience that is not consistent with this manual, please refer to
the actual product.

4. Some ingredients need to be turned over
during cooking, please follow the air fryer's
instructions and pull out the basket to turn
over the ingredients, then place the basket
completely back into the air fryer and press
the control knob to continue cooking.
2. Place the frying plate into the basket and
add the ingredients one by one. If there are
more ingredients, use the grill to place them
in two layers.
Note: Stacking ingredients without using the grill will aect
the cooking.
reyalelbuoDreyalelgniS
1. Place the air fryer on a stable, level surface
and ensure that there is air circulation
around the air fryer.
Starting a cooking program
3. Once the basket is completely inserted into
the air fryer, press the power button to turn it
on, and turn the control knob to select the
menu for the corresponding cooking program
and press the control knob to confirm. Then
press the control knob to select the amount
of ingredients (single layer/half/full/double
layer), and finally press the control knob to
confirm and start cooking.
Notes:
2. Once you turn the control knob to adjust the cooking
time or temperature, you need to press the control knob
to confirm, otherwise it will continue to cook at the
original time and temperature after five seconds.
1. The cooking time and temperature can be adjusted by
turning the control knob during cooking.
Half
Full
Quantity

Other Operations
Caution: When cooking is completed, the basket is very hot,
so do not touch it to avoid from getting scalded.
2. Manual mode
1. Language settings
While standby, turn the control knob and
select the manual mode, press it to set the
temperature and turn it to adjust to the
desired cooking temperature, then press it to
set the time and turn it to adjust to the
desired cooking time, and press it to start the
above set program.
3. Turning over the food
If the cooking time is more than 8 minutes
(except for cake and dried fruits), the air fryer
will remind you to turn over or shake the food.
"Please shake the food" will blink on the
display screen, and it will beep three times.
Please pull out the basket, turn over or shake
the food, and then completely insert the
basket back into the air fryer.
4. Scheduled cooking
While standby, turn the control knob and
select the schedule function, set the
completion time, cooking program, cooking
temperature and time, and press the control
knob to confirm and start the scheduled
cooking program.
Once the scheduled time is over, the air fryer
has completed the scheduled cooking
program.
Note: The scheduled time here is the scheduled completion
time, for example six hours, which means cooking will be
completed in six hours, and the scheduled time cannot be
shorter than the cooking time.
5. The air fryer will beep and "Program
completed" will appear on the display to
indicate that the cooking program has
been completed. Carefully take out the
basket and use clamps to remove the food.
English
Language
Manual
Shake
Schedule
the control knob to enter the language
selection screen.
Turn the control knob to the desired language
Turn the air fryer, go to settings, and press
and press it to confirm.

Maintenance Tips
Only professionally trained and qualified technicians should repair the air fryer.
Others should not repair the air fryer without permission to avoid serious consequences.
When the air fryer is acting abnormally, please refer to Troubleshooting before contact-
ing the customer service.
If the issue cannot be resolved, please unplug the power cord and disconnect it and
contact after-sales service.
Cleaning & Maintenance
The surface of the air fryer can be wiped with a dry, soft cloth or a sponge moistened with a
neutral cleaning detergent.
1. Air fryer surface
Unplug the power cord before cleaning and maintaining the air fryer, and wait for it to cool
down to room temperature or a safe temperature before operating it. Please remove the
basket when cleaning the inside of the air fryer.
2. Cavity
Clean the air fryer after each use. The basket of the air fryer is coated, so do not use any
steel wool or other abrasive cleaning materials to clean it as they may damage the coating.
3. Basket
You can use a soft, cotton cloth or sponge moistened with neutral detergent to wipe it clean,
then moisten it with water to wipe away the detergent residue.
4. Frying plate/Grill
Note: The basket, frying plate, and grill can be separated and placed in the dishwasher for cleaning, but the air fryer cannot be
washed in water or cleaned in the dishwasher.
To remove stains from the inside of the air fryer, apply a suitable amount of detergent
diluted in hot water to its surface and let it sit for about 10 minutes, then use a soft sponge
moistened with water to wipe away the detergent residue.
5. Pausing
Press the control knob to pause the cooking
program while cooking.
Press the control knob to continue the
cooking program while it is paused.
Press and hold the control knob for 0.5
seconds, the display screen indicates to
confirm the cancellation of the current
cooking program, turn the control knob and
select yes or no. Once cancelled, it will enter
standby mode.
6. Stopping program
Paused

The air fryer doesn't
function.
The air fryer is not connected
to a power supply.
Plug the power cord into a
grounded electrical outlet.
Possible Causes SolutionsIssue
The fan blade is stuck.
The motor is damaged or other
components have a broken circuit
The sensor has a broken circuit.
Contact after-sales service.
Contact after-sales service.
Contact after-sales service.
Contact after-sales service.
The sensor has a short circuit.
The OLED display shows E1.
The OLED display shows E2
The fan doesn't rotate.
Pull out the basket and push
it back into place.
When you fry ingredients
containing more fat, there will
be a lot of smoke, which is
normal.
Ensure that you clean the air
fryer after each cooking
program.
The air fryer still contains
grease residue from the
previous cooking program.
Can't insert the basket
into the air fryer
smoothly.
Cooking oily ingredients.
White smoke is
coming out.
The scheduled time is shorter
than the cooking time.
The schedule function
doesn't function as
requested.
The ingredients in the basket
can't exceed the maximum mark.
Properly insert the basket.The basket is not properly inserted.
Troubleshooting
Cleaning Precautions
Note: Regular cleaning and maintenance of the air fryer will help to extend its service life.
near a source of fire nor immerse it in water. Do not place the power plug directly on the air
1. After using the air fryer, please unplug the power plug in time and do not place the air fryer
fryer to prevent the plug from scratching its surface.
2. Cleaning and maintenance should only be done after the air fryer has cooled down.
3. Do not use any corrosive or abrasive cleaning materials or detergents.
The basket is not pushed
Wi-Fi can't be connected.
Update the Mi Home/Xiaomi
Home app to the latest version.
Move to a location where the
signal is strong enough.
Check whether the Mi Home
/Xiaomi Home app is up to date.
Check whether the Wi-Fi's
signal is strong enough.
Unable to connect the
air fryer.
Check whether the Wi-Fi is
connected normally or reset the
Wi-Fi to reconnect.
Check whether the Wi-Fi
functions normally.
The scheduled time is saved
and carried out by pressing
the control knob.
The scheduled time
is not saved.
The scheduled time
is too short.
Too many ingredients
in the basket.

Electrical Diagram
L
E
N
3
4
Control Panel
3
5
1
2
OLED Display
1
2
Low-speed Motor
66
7
8
9
Power Board
8
Fuse
9
Heating Element
7
High-speed Motor
4
Fuse
5
Safety Switch
Package Dimensions: 370 × 295 × 345 mm
Net Weight: 3.9 kg
Gross Weight: 5.2 kg
Color: White
Rated Voltage: 220–240 V~
Rated Frequency: 50–60 Hz
Rated Capacity: 3.5 L
Maximum Output Power : ＜20 dBm
Under normal use of condition, this equipment should be kept a separation distance of at least 20 cm between the antenna
and the body of the user
Specifications
Name: Air Fryer
Model: MAF02
Rated Power: 1500 W
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Operation Frequency : 2412–2472 MHz
Operating Temperature: -10°C to 40°C
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Ningbo Careline Electric Appliance Co., Ltd.
Address: 558#, Wei'er Road, Andong Industrial Zone, Andong Town,
Cixi, Ningbo, Zhejiang, China
For further information, please go to www.mi.com
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
User Manual Version: V1.0
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/EU) which
should not be mixed with unsorted household waste. Instead, you should protect human health and the environment by
handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic
equipment, appointed by the government or local authorities. Correct disposal and recycling will help prevent potential
negative consequences to the environment and human health. Please contact the installer or local authorities for more
information about the location as well as terms and conditions of such collection points.
