Xiaomi Smart Air Fryer 6,5 User manual

Smart Air Fryer 6,5 l User Manual

01
Read this manual carefully before use, and retain it for future reference.
Thank you for choosing Xiaomi Smart Air Fryer 6.5L. This product is for household use only.
Illustrations of product, accessories, and user interface in the user manual are for reference
purposes only. Actual product and functions may vary due to product enhancements.
Safety Instructions
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capa-bilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are
older than 8 and supervised.
Please keep the air fryer and the power cord out of the reach
of children aged under 8.
For household use only.
If the power cord is damaged or broken, it must be replaced by
the manufacturer or after-sales service department to avoid
safety hazards.
The temperature of the accessible surface may rise while the
air fryer is working.
The surface will heat up easily while the air fryer is in use.
The air fryer should not be operated via an external timer or a
separate remote control.
Do not block the air fryer's air inlet and outlet, nor the heat
dissi-pation vents during use to avoid affecting its normal heat
dissipa-tion.
Any non-professionally trained technicians should not modify
the internal wiring of the air fryer.
Do not use charcoal or other similar fuel sources to heat the
basket, frying plate, or grill.
Do not place the basket on any other heat sources, such as
an induction cooker or gas stove.
Do not plug or unplug the power cord with wet hands to avoid
the risk of an electrical shock.
Do not use a power cord with loose connection or poor
contact.
Do not let the power cord cross through sharp objects to
avoid damage to the power cord.
Do not use the air fryer to store any items, especially
flammable, explosive, or corrosive items.

CAUTION：Hot surfaces.
Do not excessively pinch, bend, twist, or place heavy
objects on the power cord to prevent from exposing or
breaking its core.
Stop using the air fryer immediately and unplug it from the
power source if it doesn't function normally or malfunctions.
The air fryer cannot be started without the basket being in
place.
Do not touch the basket directly with your hands during or
right after use to avoid getting scalded.
Do not allow children to get close to or play with the cling wrap
and packaging to avoid suffocation accidents.
Do not use any plastic utensils or normal paper wrapping
materials to wrap food for cooking.
Do not drop this air fryer or bump it against hard objects to
avoid damage or malfunction.
Do not insert pins, wires or other objects into any of the
openings of the air fryer to avoid an electrical shock or injury.
Do not use any accessories that are not recommended by the
manufacturer.
The normal operating altitude range of this product is 0–2000
meters.
Keep a distance of 30 cm or more between the air outlet and
other devices during use.
Do not move or shake the air fryer during use.
Do not insert any foreign objects into the safety switch to
avoid causing any danger.
When placing the air fryer in a kitchen cabinet, etc., please
ensure that it is well ventilated.
Please be sure to unplug the air fryer before cleaning or
repairing it.
This product must be used on a level, heat-resistant surface to
avoid damage to the product or accidents.
Ensure that the silicone parts of the air fryer do not come into
contact with ethanol or solutions that contain more than 50% of
alcohol.
Please ensure that the electrical outlet the air fryer is plugged
into is well grounded to avoid an electrical shock or other
safety hazards.
02

03
Product Overview
How to Use
Notes:
1
Turning on
Connect the power cord and press the
power button to turn on the air fryer.
Turning off
Press the power button to turn off the
air fryer, regardless of the state it is in.
Notes:1. The silicone rubber on the frying plate is made of high temperature resistant food-grade materials to
prevent the edges of the frying plate from scratching the coating of the basket and to improve the stability of
the frying plate. Do not remove the silicone rubber from the frying plate.
2. Ingredients that are too small are not suitable for use on the grill. Please make sure that ingredients don't fall
through the gaps in the grill.
Control Knob
Press to confirm
selection.
turn the control knob to the desired language, then press the control knob to confirm the selection.
2. The air fryer may give off a minor odor on first use. It is recommended to run the air fryer with an empty
basket at the maximum temperature (220°C) for five minutes to remove the odor. The air fryer may emit a
small amount of white smoke or an odor while running with an empty basket, which is normal.
Handle
Basket
Heat
Dissipation Vent
Air Outlet
Air Fryer
Power Plug Display
Air Inlet
Safety Switch
Frying Plate
Grill
Control Knob
2 3 4
Press and hold
for 1 second to
return to the
previous menu.
to change
functions.
Press the power
on/off.
Power button

04
Cooking
Preparations
The ingredients can be marinated to taste before
cooking.
Wi-Fi is disconnected. Other operations cannot be performed when the firmware update is in progress.
Connecting with the Mi Home/Xiaomi Home App
This product works with the Mi Home/Xiaomi Home app*. Control your device
with Mi Home/Xiaomi Home app.
Configuring the Wi-Fi
Press the control knob to enter "Reset Wi-Fi" while in the "Wi-Fi" screen, then press the
control knob to select Yes to reset the Wi-Fi, or turn the control knob to select No to
abandon resetting the Wi-Fi.
Enabling/Disabling the Wi-Fi:
Press the control knob to enter "Enable/Disable Wi-Fi?" while in the "Wi-Fi" screen, then
press the control knob to select Yes to enable or disable the Wi-Fi, or turn the control knob
to select No to abandon the change.
Updating…
Connected
successfully
Wi-Fi indicator
stays on
Wi-Fi Status Indicator
Awaiting fast
connection…
Wi-Fi indicator
blinks slowly
Reconnecting after
a disconnection…
Wi-Fi indicator
blinks quickly
Note: If the air fryer does not connect to the Wi-Fi for 30 minutes, the Wi-Fi indicator will turn off.
Firmware update
When you update the firmware through the Mi Home/Xiaomi Home app, the display will
show that an update is in progress, and the air fryer will automatically restart when the
update is completed.
Note: The Mi Home/Xiaomi Home app will be able to update the firmware unless the air fryer or its display is turned off,
or the
Wi-Fi indicator
blinks quickly
Scan the QR code to download and install
the app. You will be directed to the
connection setup page if the app is installed
already. Or search for "Mi Home/Xiaomi
Home" in the app store to download and
install it.
Open the Mi Home/Xiaomi Home app, tap
"+" on the upper right, and then follow the
instructions to add your device.
* The app is referred to as Xiaomi Home app in Europe
(except for Russia). The name of the app displayed on your
device should be taken as the default.
Note: The version of the app might have been updated,
please follow the instructions based on the current app
version.
Resetting the Wi-Fi:

05
Starting a cooking program
1. Place the air fryer on a stable, level surface and ensure that there is air circulation
around the air fryer.
2. Place the frying plate into the basket and add ingredients one by one. If there are
more ingredients, use the grill to place them in layers.
Note: Layering ingredients without using the grill will affect the cooking.
3. When the basket is completely pushed into the air fryer, turn and press the control
knob to select the manual mode or the preset recipe (yogurt, chicken wings, fries,
etc.), turn and press the control knob to set the mode (crispy grill/defat, supported
by certain recipes), quantity of ingredients (single layer/double layer), temperature
and time, and press the control knob to start the cooking program and the cooking
time countdown. For a scheduled cooking program, the air fryer will automatically
start cooking at a proper time to ensure that the cooking is completed at the
scheduled time.
Notes:
1. The cooking time and temperature can be adjusted by turning the control
knob during cooking, except for cooking yogurt. When cooking in the defat
mode, you can only adjust the cooking time, not the cooking temperature.
2. Once you turn the control knob to adjust the cooking time or temperature,
you need to press the control knob to confirm, otherwise the air fryer will
continue to cook as per the original settings after five seconds.
3. You cannot change the recipe while cooking.
4. Ingredients do not need to be turned over during cooking (unless you are
cooking fries). When you have selected over 500 g of fries, there will be a
prompt to turn over the ingredients halfway. Follow the prompt to pull out
the basket to turn over the ingredients, then place the basket completely
back into the air fryer and press the control knob to continue cooking.
5. The air fryer will beep and "Completed" will appear on the display to
indicate that the cooking program has been completed (for some recipes,
the air fryer will enter the keeping warm state and display "Keeping warm…").
Carefully take out the basket and use clamps to remove the food.
CAUTION: When cooking is completed, the basket is very hot, so do not touch it to avoid getting scaled.

06
2. Manual mode
When the air fryer is turned on, press the control knob to enter the manual
mode, then turn the control knob to the desired cooking temperature, press
the control knob to set the time and turn the control knob to the desired
cooking time, and finally press the control knob to start the manual cooking
program.
3. Temperature/Time adjustment
4. Scheduled cooking
Press the control knob to select the schedule function, turn the control knob to
select the scheduled recipe, then set the cooking time and scheduled time. The air
fryer will automatically start cooking at a proper time to ensure that the cooking is
completed at the scheduled time, then enter the keeping warm state or finish
cooking once done. Notes:
1. The scheduled time must be longer than the cooking time, but less than 24 hours.
2. The scheduled time here is the scheduled completion time. For example, when the screen displays 02:40,
it means that cooking will complete within 2 hours and 40 minutes.
3. The schedule function is not supported in yogurt, dried fruit, and defrost modes.
The temperature can be adjusted between 40°C and 220°C. The time can be
adjusted between 0–24 hours.
When adjusting the cooking time or scheduled completion time, pay attention to
thespeed in which you turn the control knob. When the adjusted time range is ≥60
minutes, turning the control knob quickly will adjust the time by 60 minutes, while
turning the control knob slowly will adjust the time by 1 minute. When the adjusted
time range is <60 minutes, turning the control knob quickly will adjust the time by
10 minutes, while turning the control knob slowly will adjust the time by 1 minute.
The cooking temperature is adjusted by 5°C for each turn of the control knob.
If you adjust or modify the time parameters in recipe cooking program, when the
cooking temperature is between 80°C and 220°C, the adjustable cooking time is ≤1
hour; when the cooking temperature is <80°C, the adjustable cooking time is ≤24
hours.
Other Operations
Turn on the air fryer, go to settings, and press the control knob to enter the
language selection screen.
Turn the control knob to the desired language and press it to confirm.
1. Language settings

07
6. Pause/Cancel cooking
When the air fryer is in cooking mode, press the control knob to pause cooking.
When the air fryer is cooking or paused, press and hold the control knob for one
second to enter the canceling cooking screen. Select Yes to cancel cooking and enter
the manual mode screen.
CAUTION: During cooking, you can turn the control knob to adjust the temperature and time parameters.
The corresponding numbers will blink during adjustment. Once adjustment is completed, press the control knob to
confirm the new parameters.
If you select and execute a cloud recipe with the Mi Home/Xiaomi Home app, the
will cook automatically according to the recipe. After cooking, the air fryer will enter
the air fryer manual mode screen.
7. Cloud recipe mode
Notes:
1. When executing cloud recipes, you can select the schedule function.
2. You cannot execute cloud recipes in the following situations:
1) The air fryer or its display is turned off. 2) There is no Wi-Fi connection. 3) The air fryer is cooking,
keeping warm, or in scheduled mode. 4) The basket has been pulled out.
8. Error message
When the air fryer detects an error, the display will show "E1" or "E2", and the air
fryer will emit three brief beeps.
5. Keeping warm function
The keeping warm time is 30 minutes, while the keeping warm temperature is
80°C. Keeping warm and its timing will be suspended if the basket is pulled out.
If you place the basket back in within 3 minutes, keeping warm will continue at
the retained time settings. If the basket is not placed back within 3 minutes,
keeping warm will end, and the air fryer will return to the home screen of the
corresponding recipe.
CAUTION: When keeping warm is on and the cooking temperature is set to ≥80°C, the keeping warm
operation will be performed after the cooking is completed. Otherwise, the air fryer will directly finish
cooking by entering the cooking completed screen.
Cleaning & Maintenance
Unplug the power cord before cleaning and maintaining the air fryer, and wait for it to
cool down to a safe temperature before proceeding. Please remove the basket from
the air fryer when cleaning the air fryer.
The keeping warm function is enabled by default. You can disable it in the settings.

08
Note: The frying plate and grill can be separated and placed in the dishwasher for cleaning; the basket can be washed
in water, and can be cleaned in dishwasher; however, the air fryer can neither be washed in water nor be cleaned in
dishwasher.
Cavity:
To remove stains from the inside of the air fryer, apply a suitable amount of detergent
diluted in hot water to its surface and let it sit for about ten minutes, then use a soft
sponge moistened with water to wipe away the detergent residue.
Basket:
Clean the air fryer after each use. The basket of the air fryer is coated, so do not use any
steel wool or other abrasive cleaning materials to clean it as they may damage the
coating.
Frying plate and grill:
You can use a soft, cotton cloth or sponge moistened with neutral detergent to wipe it
clean, then moisten it with water to wipe away the detergent residue.
Air fryer surface:
Cleaning Precautions
1.After using the air fryer, please unplug the power plug in time and do not place the
air fryer near a source of fire nor immerse it in water. Do not place the power plug
directly on the air fryer to prevent the plug from scratching its surface.
2. Cleaning and maintenance should only be done after the air fryer has cooled
down.
3. Do not use any corrosive or abrasive cleaning materials or detergents.
Note: Regular cleaning and maintenance of the air fryer will help extend its service life.
Maintenance Tips
Only professionally trained and qualified technicians should repair the air fryer.
Others should not repair the air fryer without permission to avoid serious consequences.
When the air fryer is acting abnormally, please refer to the Troubleshooting before
contacting after-sales service team.
If the issue cannot be resolved, please unplug the power cord and disconnect it
and contact after-sales service team.
The surface of the air fryer can be wiped with a dry, soft cloth or a sponge moistened with
a neutral cleaning detergent.

09
The air fryer
doesn't function.
The air fryer is not connected
to a power supply.
Plug the power cord into
a grounded electrical outlet.
Possible Causes Solutions Issue
The fan blade is stuck.
The motor is damaged or other
components have a broken
circuit.
The sensor has a broken circuit.
The sensor has a short circuit.
Display shows E1.
Display shows E2.
The fan doesn't rotate.
Pull out the basket and
push it back into place.
When you fry ingredients
containing more fat, there
will be a lot of smoke, which
is normal.
Ensure that you clean the
air program.
The air fryer still contains
grease residue from the
previous cooking program.
Can't insert the
basket into the air
fryer smoothly.
Cooking oily ingredients.
White smoke is
coming out.
The scheduled time should be
longer than the cooking time.
The schedule
function doesn't
function as
requested.
The ingredients in the basket
can't exceed the maximum mark.
Properly insert the basket. The basket is not properly inserted.
Troubleshooting
The basket is not
pushed into place.
Wi-Fi can't be connected.
Update the Mi Home/Xiaomi
Home app to the latest version.
Move to a location where the
signal is strong enough.
The Mi Home/Xiaomi Home
app is not the latest version.
The Wi-Fi signal is weak.
Unable to connect
the air fryer.
Check whether the Wi-Fi is
connected normally or reset
the Wi-Fi to reconnect.
Wi-Fi cannot be connected.
The scheduled time should be
saved and carried out by
pressing the control knob.
The scheduled
time is not saved.
The scheduled
time is too short.
Too many ingredients in
the basket.
Contact the after-sales service
team.
Contact the after-sales service
team.
Contact the after-sales service
team.
Contact the after-sales service
team.

10
Package Dimensions: 425 × 330 × 355 mm
Net Weight: 5.4 kg
Gross Weight: 6.5 kg
Color: White
Rated Voltage: 220–240 V~
Rated Frequency: 50–60 Hz
Capacity: 6.5 L
Specifications
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Operating Frequency: 2412–2472 MHz
Name: Oven (Air Fryer)
Model: MAF10
Rated Power: 1800 W
Maximum Output Power: < 20 dBm
Operating Temperature: -10°C to 40°C
Under normal use of condition, this equipment should be kept a separation distance of at least 20 cm between the antenna and the body of
the user.
EU) which should not be mixed with unsorted household waste. Instead, you should protect human health and
the environment by handing over your waste equipment to a designated collection point for the recycling of
waste electrical and electronic equipment, appointed by the government or local authorities. Correct disposal and
recycling will help prevent potential negative consequences to the environment and human health. Please
contact the installer or local authorities for more information about the location as well as terms and conditions
of such collection points.
Hereby, Ningbo Careline Electric Appliance Co., Ltd. declares that the radio equipment type Oven (Air Fryer) MAF10 is
in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
internet address: http://www.mi.com/global/service/support/declaration.html
For detailed e-manual, please go to www.mi.com/global/service/userguide
All products bearing this symbol are waste electrical and electronic equipment (WEEE as in directive 2012/19/
Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Ningbo Careline Electric Appliance Co., Ltd.
(a Mi Ecosystem company)
Address: No.558, Wei’er Road, Andong Industrial Zone,
Hangzhou Bay New Area ,
Ningbo, 315327, Zhejiang, China
For further information, please go to www.mi.com
User Manual Version: V1.0
Importer:
Beryko s.r.o.
Pod Vinicemi 931/2, 301 00 Plzeň
www.beryko.cz
