Xilica Audio Design DCP-3060 User manual

DCP-3060
LoudspeakerManagementSystem
UserManual
XILICA Audio Design

Important Safety Instructions
1. READ THESE INSTRUCTIONS
All the safety and operating instructions should be read before the product is operated.
2. KEEP THESE INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
3. HEED ALL WARNINGS
All warnings on the product and in the operating instructions should be adhered to.
4. FOLLOW ALL INSTRUCTIONS
All operating and use of instructions should be followed.
5. DO NOT USE THIS APPARATUS NEAR WATER
Do not use the product near water. For example, near a bathtub, washbowl, kitchen sink,
or laundry tub, in a wet basement, or near a swimming pool, and the like.
6. CLEAN ONLY WITH DRY CLOTH
Unplug the unit from the wall outlet before cleaning. Do not use liquid cleaners or
aerosol cleaners. Use a damp cloth for cleaning.
7. DO NOT BLOCK ANY VENTILATION OPENINGS
Slots and openings in the cabinet back or bottom are provided for ventilation, to ensure
reliable operation of the limit and to protect it from overheating. These openings must
not be blocked or covered. The openings should never be blocked by placing the product
on a bed, sofa, rug, or similar surface. This product should never be placed near or over
a radiator or heat source. This product should not be placed in a built-in installation such
as a bookcase or rack unless proper ventilation is provided or the manufacture's
instructions have been adhered to.
DCP-3060 User's manual - Page 2

8. DO NOT INSTALL NEAR ANY HEAT SOURCES
This Product should be situated away from heat sources such as radiators, stoves, or
other products (including amplifiers) that produces heat.
9. DO NOT DEFEAT THE SAFETY PURPOSE OF THE POLARIZED OR GROUNDING-TYPE
PLUG
A Polarized plug has two blades with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The wide blade or the third prongs are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. PROTECT THE POWER CORD FROM BEING WALKED ON OR PINCHED
PARTICULARLY AT PLUGS, CONVENIENCE RECEPTACLES, AND THE POINT WHERE
THEY EXIT FROM THE APPARATUS.
11. ONLY USE ATTACHMENTS/ACCESSORIES SPECIFIED BY THE MANUFACTURER.
12. USE ONLY WITH CART, STAND, TRIPOD, BRACKET, OR TABLE SPECIFIED BY THE
MANUFACTURER, OR SOLD WITH THE APPARATUS. WHEN A CART IS USED, USE
CAUTION WHEN MOVING THE CART/APPARATUS TO AVOID INJURY FROM TIP-OVER.
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The unit may
fall, causing serious injury to someone, and serious damage to the appliance. A unit and
cart combination should be moved with care. Quick stops, excessive force, and uneven
surfaces may cause the product and cart combination to overturn.
13. UNPLUG THIS APPARATUS DURING LIGHTNING STORMS OR WHEN UNUSED FOR
LONG PERIODS OF TIME.
For added protection for this unit during a lightning storm, or when it is left unattended
and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna or cable system. This will prevent damage to the unit due to lightning and power
line surges.
14. REFER ALL SERVICING TO QUALIFIED SERVICE PERSONNEL. SERVICING IS
REQUIRED WHEN THE APPARATUS HAS BEEN DAMAGED IN ANYWAY, SUCH AS
WHEN THE POWER SUPPLY CORD OR PLUG IS DAMAGED, LIQUID HAS BEEN SPILLED
OR OBJECTS HAVE FALLEN INTO THE APPARATUS, THE APPARATUS HAS BEEN
EXPOSED TO RAIN OR MOISTURE, DOES NOT OPERATE NORMALLY, OR HAS BEEN
FROPPED.
15. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPARATUS TO RAIN OR MOISTURE.
16. APPARATUS SHALL NOT BE EXPOSED TO DRIPPING OR SPLASHING AND NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES, SHALL BE PLACED ON THE
APPARATUS.
DCP-3060 User's manual - Page 3

Table of Contents
Table of Contents ................................................................... 4
1.0 Introduction .................................................................... 5
2.0 Features .......................................................................... 6
3.0 Front Panel Functions ................................................... 7
4.0 Rear Panel Functions .................................................... 9
5.0 Powering Up the Device .............................................. 10
6.0 Operating the Device ................................................... 11
6.1 Input menus............................................................. 11
6.2 Output Menus.......................................................... 13
6.3 System Menus......................................................... 17
7.0 Quick Reference........................................................... 20
8.0 PC Control Software .................................................... 21
9.0 Specifications............................................................... 22
10.0 Warranty........................................................................ 24
DCP-3060 User's manual - Page 4

1.0 Introduction
The DCP-3060 is a complete 3 input - 6 output digital loudspeaker
management system designed for the touring or fixed sound installation
markets. The absolute latest in available technology is utilized with 32-bit
(40-bit extended) floating point processors and high performance 24-bit
Analog Converters. The high-bit DSP prevents noise and distortion induced
by truncation errors of the commonly used 24-bit fixed-point devices. A
complete set of parameters include I/O levels, delay, polarity, 6 bands of
parametric EQ per channel, multiple crossover selections and full function
limiters. Precise frequency control is achieved with its 1 Hz resolution.
Inputs and outputs can be routed in multiple configuration to meet any
requirements. The DCP-3060 can be controlled or configured in real time
on the front panel or with the intuitive PC GUI accessed via the RS-232
interface. Software upgrade for CPU and DSP via PC keeps the device
current with newly developed algorithms and functions once available.
Multiple setup storage and system security complete this professional
package.
Shipped contents:
- DCP-3060 unit
- User Manual
- XLink Software CD
DCP-3060 User's manual - Page 5

2.0 Features
> 3 Inputs and 6 Outputs with flexible routing
> 32-bit (40-bit extended) floating point DSP
> High Performance 24-bit A/D Converters
> 1 Hz Frequency Resolution
> 6 Parametric Equalizers for each Input and Output
> Multiple Crossover types with Full Function Limiters
> Precise Level, Polarity and Delay
> CPU and DSP upgrade via PC
> Individual Channel Buttons with Linking capability
> 2-Line x 16 Character Backlit LCD Display
> Full 5-segment LED’s on every Input and Output
> Storage of up to 30 Program Setups
> Security Lock
> RS-232 Interface for PC Control and Configuration
> Future options available
DCP-3060 User's manual - Page 6

3.0 Front Panel Functions
3 6 54
1
2
1. Mute keys - Mute/Unmute input and output channels. When an input
channel is muted, a red LED will come on for indication.
2. Gain/Menu keys - Selects the corresponding channel for the LCD menu
display and is acknowledged by a green LED. The last modified menu
will be displayed on the LCD. Linking multiple channels is accomplished
by pressing and holding the first channel key, then pushing the other
desired channels. This eases programming for same parameters across
multiple channels. Multiple Inputs can be linked together and multiple
outputs can be linked together. Inputs and Outputs are linked separately.
3. Peak Level LED - Indicates the current peak level of the Signal:
Signal, -12dB, -6dB, -3dB, Over/Limit. The Input Over LED references to
the device's maximum headroom. The Output Limit LED references to
the threshold of the limiter.
4. LCD -Shows all the necessary information to control the unit.
5. Rotary Thumb Wheel - Changes parameter data values. The wheel
has travel velocity sensing which ease large incremental data
modifications. For modifying delay and frequency (1 Hz resolution),
pressing the Speed key simultaneously will increment/decrement the
data value by 100X.
6. Menu Control keys - There are 6 menu keys: <<Menu (Menu Down),
Menu>> (Menu Up), <<Cursor (Cursor Down), Cursor>> (Cursor Up),
Enter/Sys/Speed and Exit. The functions of each key is explained
below:
DCP-3060 User's manual - Page 7

<<Menu: Previous menu screen
Menu>>: Next menu screen
<<Cursor: Previous cursor in the menu screen
Cursor>>: Next cursor in the menu Screen
Enter/Sys/Speed: Enter is used only in the System Menu to proceed
with selected actions
Sys enters the System Menu from the main menu
Speed modifies delay and frequency (1 Hz
resolution mode) data values by 100X.
Exit: Exit to the Main Menu
DCP-3060 User's manual - Page 8

4.0 Rear Panel Functions
1,2,3 54 6
1. Main Power - Connects via a standard IEC socket. A compatible power
cord is supplied with the unit. The voltage input is either 115VAC or
230VAC and is clearly specified on the unit. Voltage requirement has to
be stated upon ordering.
2. Main Fuse - T200mA-250V. Slow blow type.
3. Power switch - Controls power On/Off.
4. RS232 - a standard female DB9 socket. A straight through cable is
required for PC connection.
5. Option slot - Option slot for future use.
6. XLR input and outputs - Separate 3-pin XLR connectors are provided
for each audio input and output. The device's output stage employs the
balanced impedance topology. All I/O connectors have pin 1 as ground
(shield), pin 2 as + and pin 3 as -.
DCP-3060 User's manual - Page 9

5.0 Powering Up the Device
•After powering up the unit, the following initialization screen is displayed
on the LCD:
•The initialization process takes about 8 seconds and during that period
the unit boots and displays the DCP-3060 firmware version.
•After the initialization process is finished the DCP-3060 displays its main
screen:
XILICA DCP-3060
-INITIALIZING -
XILICA DCP-3060
P01 XXXXXXXXXXXX
•The screen shows the current program number and program name
assigned to the unit. The program assigned is always the last program
the user recalled or stored before powering down the unit.
•Now the DCP-3060 is now ready to operate.
DCP-3060 User's manual - Page 10

6.0 Operating the Device
Tips: Channel Linking - If the user presses one of the Input or Output Menu
keys, holds it down and press any other Menu key(s) in the same group
(Input or Output group), then the channels are linked together. The green
menu LEDs for the linked channels are lit. Any modification of the data for
the selected channel will be applied to the linked channels as well. To
cancel the linking, just press any other Menu key or the Sys key after
releasing the held key.
6.1 Input menus
Each of DCP-3060 input channels has a separate Menu key. There are 3
menus for each input channel.
Signal - Signal parameters
•LEVEL - Gain, -40.00dB to +15.00dB in 0.25dB steps.
I1:XXXXXX Signal
LEVEL:0.00dB
•POL - Polarity, can be normal (+) or inverted (-).
I1:XXXXXX Signal
POL:+
•DELAY - Delay in 21us steps. Can be displayed in ms, ft or m. The
time unit of the delay can be changed in the System menu. The
maximum delay permitted is 2,400 steps (50ms).
I1:XXXXXX Signal
DELAY:000.000ms
DCP-3060 User's manual - Page 11

EQ - EQ parameters
•EQ# - Selects one of the 6 available Equalizers.
I1:XXXXXX EQ
EQ#:1
•LEVEL - EQ level gain. Ranges from -30.00dB to +15.00dB in
0.25dB steps.
I1:XXXXXX EQ
LEVEL:0.00dB
•FREQ - EQ center frequency. Ranges from 20 to 20,000Hz in either
1Hz steps or 1/36 octave steps. The sampling rate and the
frequency steps can be selected in the System Menu.
I1:XXXXXX EQ
FREQ:1000Hz
•BW - EQ Bandwidth. Ranges from 0.02 to 2.50 octaves in steps of
0.01 octave steps for PEQ. The Q value is automatically shown
beneath the octave value. For Lo-Slf or Hi-Shf, it is either 6 or
12dB/Oct.
I1:XXXXXX EQ
BW:0.33 Q=4.36
•Type - Type of EQ. The types can be parametric (PEQ), Lo-shelf
(Lo-shf) and Hi-shelf (Hi-shf).
I1:XXXXXX EQ
T
yp
e:PEQ
Ch-Name - Channel Name
I1:XXXXXX ChName
NAME:XXXXXX
•Name - Channel name. It is 6 characters in length.
DCP-3060 User's manual - Page 12

6.2 Output Menus
Each output channel of the DCP-3060 has a separate menu key. There are
6 menus for each output channel.
Signal - Signal parameters
•Refer to the Input Menus for details
EQ - EQ paramters
•Refer to the Input Menus for details
DCP-3060 User's manual - Page 13

XOver - Crossover parameters
•FTRL - Filter Type of low frequency crossover point (high pass).
Types can be Butterworth, Linkritz Riley or Bessel.
O1:XXXXXX XOver
FTRL:Off
•FRQL - Filter cut-off Frequency of low frequency crossover point
(high pass). Ranges from 20 to 20,000Hz in either 1Hz steps or
1/36 octave steps. The frequency steps can be selected in the
System Menu.
O1:XXXXXX XOver
FRQL:1000Hz
•SLPL - Filter Slope of low frequency crossover point (high pass).
Ranges from 6 to 48dB/octave. If the selected Filter Type is
Linkritz Riley, the available slopes are 12 / 24 / 36 / 48 dB/octave.
O1:XXXXXX XOver
SLPL:24dB
•FTRH - Filter Type of high frequency crossover point (low pass).
O1:XXXXXX XOver
FTRH:Off
•FRQH - Filter cut-off Frequency of high frequency crossover point
(low pass).
O1:XXXXXX XOver
FRQH:1000Hz
•SLPH - Filter Slope of high frequency crossover point (low pass).
O1:XXXXXX XOver
SLPH:24dB
DCP-3060 User's manual - Page 14

Filter
configuration
Low crossover
point
High crossover
point
None FTRL Off FTRH Off
Highpass FTRL not Off FTRH Off
FRQL
Lowpass FTRL Off FTRH not Off
FRQH
Bandpass FTRL not Off FTRH not Off
FRQL FRQH
Limit - Output Limter
•THRESH - Limit Threshold. Ranges from -20 to +20dBu in 0.5dB
steps.
O1:XXXXXX Limit
THRESH:+20.0dB
•ATTACK - Attack time. Ranges from 0.3 to 1ms in 0.1ms steps,
then ranges from 1 to 100ms in 1ms steps.
O1:XXXXXX Limit
ATTACK:10ms
•RELEASE - Release time. Can be set at 2X, 4X, 8X, 16X or 32X
the attack time.
O1:XXXXXX Limit
RELEASE:8X
DCP-3060 User's manual - Page 15

Source - Input Source
•1,2,3 – Input channel source for the current output channel. Can
be set to enable the input source (On) or disable it (Off). If more
than one input source are enabled, they will be added together as
the source for the current output channel.
O1:XXXXXX Source
In1:On
O1:XXXXXX Source
In2:Off
O1:XXXXXX Source
In3:Off
Ch-Name - Channel Name
•Refer to the Input Menus for details
DCP-3060 User's manual - Page 16

6.3 System Menus
The System Menus allow the user to control and change parameters that
are related to the system behavior and general operation. It can be
accessed by pressing the Sys key in the main menu (when no Input/Output
or System Menu is activated). All System Menus require the Enter key to
be pressed for the selected action.
Recall - Program Recall
The DCP-3060 has a built in non-volatile memory that can store up to 30
different program setups. A program can be recalled using this menu.
•PROG - Program Number to be recalled. Only first 8 characters of
the program name is displayed.
O1:XXXXXX Recall
PROG:01 XXXXXXXX
Store - Program store
The DCP-3060 has a built in non-volatile memory that can store up to 30
different program setups. A program can be stored using this menu. The
old program with the same program number will be replaced. Once the
program is stored in the flash memory, it can be recalled at a later time,
even after power down.
•PROG - Program Number for the current data to be stored.
O1:XXXXXX Store
PROG:01
•NAM - Program Name, allows a maximum length of 12 characters.
O1:XXXXXX Store
NAM:XXXXXXXXXXXX
DCP-3060 User's manual - Page 17

Config - Device Configuration
SYSTEM-SETUP MENU:Config
MODE:2-Way
•MODE - configures the mode of operation.
Mode: Out 1 Out 2 Out 3 Out 4 Out 5 Out 6
None Any Any Any Any Any Any
Stereo 2-Way In1 In1 In2 In2 Any Any
Stereo 3-Way In1 In1 In1 In2 In2 In2
The unit assigns the Input source for the corresponding outputs when the
Mode of Configuration is selected. The crossover point parameters like the
filter type, cut-off frequency and slope have to be configured manually in
the Xover Menu in each Output menu.
*Note: The configuration mode configures the input sources when selected.
The user can change the source afterwards if desired. It does not keep the
configuration in memory.
Copy - Copy channels
Copy Channels from the source to the target. When the Source and
Targets are both Inputs or Outputs, all audio parameters will be copied.
When one of the Source or the Target is an input while the other is an
output, only the Level, Polarity, Delay and EQ are copied.
•SOURCE - Channel to be copied from.
O1:XXXXXX Copy
SOURCE:In1
•TARGET - Channel to be copied to.
O1:XXXXXX Copy
TARGET:In2
DCP-3060 User's manual - Page 18

General - General system parameters
SYSTEM-SETUP MENU:General
FREQ MODE :All Freq
DELAY UNIT:01
DEVICE# :1
•FREQ MODE - Selects the frequency control mode for EQ and
crossover filters. Can be 36 steps/octave or All Frequencies (1 Hz
resolution).
O1:XXXXXX Generl
FREQ MODE:All
•DELAY UNIT - ms, ft or m.
O1:XXXXXX Generl
DELAY UNIT:ms
•DEVICE# - Assigns the device ID from 1 to 16. This ID is useful
when a network of more than 1 unit is present.
O1:XXXXXX Generl
DEVICE#:1
Security - Security Lock
The DCP-3060 enables the user to secure the unit and prevent undesired
changes in the setup. In order to lock/unlock the unit the user must enter
the correct password.
•PASSWORD – The password of the DCP-3060 is 4 characters in
length. The user can change it via the PC application software.
The factory default of a new unit does not require a password.
O1:XXXXXX Secure
PASSWORD:XXXX
DCP-3060 User's manual - Page 19

7.0 Quick Reference
Parameters Menu
<<Menu>>
Field
<<Cursor>> Min Max Steps Units
Level Signal LEVEL -40 +15 0.25 dB
Polarity Signal POL + / -
Delay Signal DELAY 0 2,400 1 21us steps
EQ Number EQ EQ# 1 6 1
EQ Level EQ LEVEL -30 +15 0.25 dB
EQ Frequency EQ FREQ 20 20,000 1 Hz
EQ Bandwidth EQ BW 0.0
2 2.50 0.01 Octave
Crossover Low XOver FTRL Off / Butterworth / Linkwitz-Riley / Bessel
Crossover Low XOver FRQL 20 20,000 1 Hz
Crossover Low XOver SLPL 6 48 6 dB/octave
Crossover High XOver FTRH Off / Butterworth / Linkwitz-Riley / Bessel
Crossover High XOver FRQH 20 20,000 1 Hz
Crossover High XOver SLPH 6 48 6 dB/octave
Out Limit Thresh Limit THRESH -20 +20 0.5 dBu
Out Attack Time Limit ATTACK 0.3 100 0.1/1 ms
Out Release Time Limit RELEASE 2 / 4 / 8 / 16 / 32X Attack time
Source Source 1, 2, 3 Off / On
Channel Name Ch-Name NAME 6 characters
DCP-3060 User's manual - Page 20
