Chapter 1
VC7222 Board Features and Operation
This chapter describes the components, features, and operation of the Virtex®-7 FPGA
VC7222 GTH and GTZ Transceiver Characterization Board. The VC7222 board provides
the hardware environment for characterizing and evaluating the GTH and GTZ
transceivers available on the Virtex-7 XC7VH580T-G2HCG1155E FPGA. The VC7222
board schematic, bill-of-material (BOM), layout files, and reference designs are available
online at the Virtex-7 FPGA VC7222 Characterization Kit documentation website.
VC7222 Board Features
• Virtex-7 XC7VH580T-G2HCG1155E FPGA
• Onboard power supplies for all necessary voltages
• Terminal blocks for optional use of external power supplies
• Digilent USB JTAG programming port
•SystemACE™SDcontroller
• Power module supporting Virtex-7 FPGA GTH transceiver power requirements
• Power module supporting Virtex-7 FPGA GTZ transceiver power requirements
• A fixed, 200 MHz 2.5V LVDS oscillator wired to multi-region clock capable (MRCC)
inputs
• Two pairs of differential MRCC inputs with SMA connectors
• SuperClock-2 module supporting multiple frequencies
• Six Samtec BullsEye connector pads for the GTH transceivers and reference clocks
• Two Samtec BullsEye connector pads for the GTZ transceivers and two pairs of SMA
connectors for GTZ transceiver reference clocks
•PowerstatusLEDs
• General purpose DIP switches, LEDs, pushbuttons, and test I/O
• Two VITA 57.1 FPGA mezzanine card (FMC) high pin count (HPC) connectors
• USB-to-UART bridge
• I2C bus
• PMBus connectivity to onboard digital power supplies
• Active cooling for the FPGA
Send Feedback

6www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
The VC7222 board block diagram is shown in Figure 1-1.
Detailed Description
Figure 1-2 shows the VC7222 board described in this user guide. Each numbered feature
that is referenced in Figure 1-2 is described in Table 1-1 and later sections.
The VC7222 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
prevention measures when handling the board.
Caution! Do not remove the rubber feet from the board. The feet provide clearance to prevent short
circuits on the back side of the board.
Note: Figure 1-2 is for reference only and might not reflect the current revision of the board.
X-Ref Target - Figure 1-1
Figure 1-1: VC7222 Board Block Diagram
UG965_c1_01_070313
Push Buttons,
DIP Switches,
and LEDs
SuperClock-2 Module
Interface
GTH Transceivers
Virtex-7 FPGA
XC7VH580T-G2HCG1155E
Select I/O Termination
and VTT Jacks
Analog/Digital
Converter (XADC)
FMC1 Interface
High-Performance I/O
USB to UART
Bridge
FMC2 Interface
High-Performance I/O
I2C Bus
Management
7 Series
GTH Power Module
Interface
12V
PMBus
5V
3.3V
User Clocks
System ACE SD
Controller
Power In
12VDC
PMBus
FPGA Power Source
On-board Regulation:
VCCINT 1.0V, 20A
VCCBRAM 1.0V, 10A
VCCAUX 1.8V, 10A
VCCAUX_IO 1.8V, 10A
VCCO_HP 1.8V, 10A
VCCO_0 1.8V, 7.5A
Board Utility Power
On-board Regulation:
5.0V, 10A
3.3V, 18A
2.5V, 18A
GTH and GTZ
Power Monitoring
VCCO_HP
5V
3.3V
2.5V
QUAD 113
QUAD 114
QUAD 115
QUAD 213
QUAD 214
QUAD 215
7 Series
GTZ Power Module
Interface
12V
PMBus
5V
3.3V
GTZ Transceivers
OCTAL 300A
OCTAL 300B
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 7
UG965 (v1.4) February 11, 2015
Detailed Description
X-Ref Target - Figure 1-2
Figure 1-2: VC7222 Board Features. Callouts Listed in Table 1-1
UG965_c1_02_070313
2
3
32
1
29
3534
5 4
14
10
28 12 119
13
25
26
33
30
31
19
27
22 24
23
17
16
18
6
6
7
15 36
36
37
8
20
21
Table 1-1: VC7222 Board Feature Descriptions
Figure 1-2
Callout
Reference
Designator
Feature
Description
1 U1 Virtex-7 XC7VH580T-G2HCG1155E FPGA
2 SW1 Power switch
3 J2 12V Mini-Fit connector
4 J131 12V ATX Connector
5 J12 12V Euro-Mag Connector
6J28, J85, J86,
J158, J159, J241
GTH transceiver connector pads
Q113, Q114, Q115, Q213, Q214 and Q215
7 J18, J25 GTZ transceiver connector pads O300A and O300B
8 J46, J47, J56, J57 GTZ transceiver reference clock SMAs
9 U57 USB JTAG connector (micro-B receptacle)
10 J1 JTAG connector (alternate access for programming
cables)
11 J30 System ACE SD card connector (back-side of board)
12 SW8 System ACE SD configuration address DIP switches
Send Feedback

8www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
13 SW7 System ACE SD RESET button
14 SuperClock-2 module
15 U35 200 MHz 2.5V LVDS oscillator
16 DS21 FPGA DONE status LED
17 DS25 FPGA INIT_B status LED
18 SW3 FPGA PROG_B pushbutton
19 DS11 12V power status LED
20
DS1, DS2, DS3, DS4,
DS5, DS6, DS7, DS8,
DS9, DS10, DS26,
DS27, DS28, DS29,
DS30
Status LEDS for FPGA logic, transceiver and utility
power
21 SW10 Core power regulation enable switches
22 J75 Core power terminal block
23 J72 GTH transceiver power terminal block
24 J73 GTZ transceiver power terminal block
25 GTH transceiver power supply module
26 GTZ transceiver power supply module
27 J26 PMBUS connector
28 J79 Connector for USB to UART bridge (mini-B receptacle)
29 J121 Power connector for active heatsink
30
DS13, DS14, DS15,
DS16, DS17, DS18,
DS19, DS20
User LEDs (active high)
31 SW4, SW5 User pushbuttons (active high)
32 SW2 User DIP switches (active high)
33 J125 User I/O header
34 JA2 FMC1 connector
35 JA3 FMC2 connector
36 J98, J99, J100, J101 SMA connectors to differential MRCC pins on FPGA
37 J141, J142, R233 Jumpers and potentiometer for XADC reference
and analog supply set-up
Table 1-1: VC7222 Board Feature Descriptions (Cont’d)
Figure 1-2
Callout
Reference
Designator
Feature
Description
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 9
UG965 (v1.4) February 11, 2015
Detailed Description
Power Management
Board 12V Input Power
VC7222 board receives 12V main power through J2 (callout 3, Figure 1-2) using the 12V AC
adapter that ships with the board. J2 is a 6-pin (2 x 3), right angle, Mini-Fit connector.
Caution! When supplying 12V through J2, use only the power supply provided for use with this
board (Xilinx part number 3800033).
Caution! Do NOT use a 6-pin, PC ATX power supply connector with J2. The pinout of the 6-pin, PC
ATX connector is not compatible J2 and the board will be damaged if an attempt is made to power it
from a PC ATX power supply connector.
12V power can also be provided through:
• Connector J131 which accepts an ATX hard drive, 4-pin, power plug
• Euro-Mag terminal block J12 which can be connected to a bench-top power supply
Caution! Because terminal block J12 provides no reverse polarity protection, use a power supply
with a current limit set at 6A max.
Caution! Do NOT apply 12V power to more than a single input source. For example, do not apply
power to J2 and J131 at the same time.
Power Switch
Main board power is turned on or off using switch SW1 (callout 2, Figure 1-2). When the
switch is in the ON position, power is applied to the board and green LED DS11
illuminates (callout 19, Figure 1-2).
Onboard Power Regulation
Figure 1-3 shows the onboard power supply architecture.
Send Feedback

10 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
The VC7222 board uses power regulators and PMBus compliant digital PWM system
controllers from Texas Instruments to supply the FPGA logic and utility voltages listed in
X-Ref Target - Figure 1-3
Figure 1-3: VC7222 Board Power Supply Block Diagram
UG965_c1_03_070313
MGTZVCCH
MGTZVCCL
MGTZAVCC
VCCAUX
VCCINT
VCCAUX_IO
VCCBRAM
VCCO_0
VCCO_HP
Power Supply
12V PWR IN
J2 or J12
or J131Power Controller 1
UCD9248PFC
U9
Switching Regulator (2 Phases)
1.0V at 40A max
U5, U51
Switching Regulator
5.0V at 10A max
U2
Switching Regulator
3.3V at 18A max
U13
UTIL_5V0
UTIL_3V3
Switching Regulator
2.5V at 18A max
U52 UTIL_2V5
Switching Regulator
1.8V at 10A max
U6
Switching Regulator
1.0V at 10A max
Power Controller 2
Switching Regulator
1.8V at 10A max
U46
Switching Regulator
1.8V at 10A max
U50
Switching Regulator
1.8V at 10A max
U10
UCD9248PFC
7 SeriesGTH Power Module
MGTAVCC: 1.05V at 12.0A max
MGTAVTT: 1.2V at 8.0A max
MGTVCCAUX: 1.8V at 2.6A max
7 SeriesGTZ Power Module
MGTZAVCC: 1.075V at 6.0A max
MGTZVCCL: 1.075V at 1.3A max
MGTZVCCH: 1.8V at 0.3A max
MGTVCCAUX
MGTAVTT
MGTAVCC
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 11
UG965 (v1.4) February 11, 2015
Detailed Description
Table 1-2. The board can also be configured to use an external bench power supply for each
voltage. See Using External Power Sources.
Table 1-2: Onboard Power System Devices
Device Reference
Designator(s) Description Power Rail Net Name Voltage
Core Power
UCD9248PFC U9 PMBus compliant digital PWM system controller (address = 52)
PTD08A020W U5, U51 Adjustable(1) switching regulator, 40A (two phases at 20A/phase),
0.6V to 3.6V VCCINT 1.0V
PTD08D210W
(VOUTA)
U6
Adjustable(1) switching regulator, Dual 10A, 0.6V to 3.6V VCCAUX 1.8V
PTD08D210W
(VOUTB)
Adjustable(1) switching regulator, Dual 10A, 0.6V to 3.6V VCCBRAM 1.0V
UCD9248PFC U10 PMBus compliant digital PWM system controller (address = 53)
PTD08D210W
(VOUTA)
U50
Adjustable(1) switching regulator, Dual 10A, 0.6V to 3.6V VCCAUX_IO 1.8V
PTD08D210W
(VOUTB)
Adjustable(1) switching regulator, Dual 10A, 0.6V to 3.6V VCCO_HP 1.8V
PTD08A006W U46 Adjustable(1) switching regulator, 10A, 0.6V to 3.6V VCCO_0 1.8V
GTH Transceivers (monitoring only)
UCD9248PFC(2) U11 PMBus compliant digital PWM system controller (address = 54)
GTZ Transceivers (monitoring only)
UCD9248PFC(3) U18 PMBus compliant digital PWM system controller (address = 55)
Utility
PTH12060W U2 Fixed switching regulator, 10A UTIL_5V0 5.0V
PTH12020W U13 Fixed switching regulator, 18A UTIL_3V3 3.3V
PTH12020W U52 Fixed switching regulator, 18A UTIL_2V5 2.5V
XADC((4)
ADP123 U43 Fixed LDO regulator VCCADC_ADP 1.8V
REF3012 U45 Fixed LDO regulator VREFP_3012 1.25V
System ACE SD
ADP123 U21 Fixed LDO Regulator VCC1V2 1.2V
Notes:
1. The output voltages of regulators controlled by a UCD9248 can be reprogrammed using the Texas Instruments Fusion Digital Power
Designer application (www.ti.com/tool/fusion_digital_power_designer). However, extreme caution must be taken when
attempting to modify any of the onboard regulators. An incorrectly programmed regulator can damage onboard components.
2. The UCD9248PFC (U11) at Address 54 monitors MGTAVCC, MGTAVTT, and MGTVCCAUX rail voltage and current levels which can be
observed in real time using the Texas Instruments Fusion Digital Power Designer application (see Monitoring Voltage and Current,
page 13). Transceiver supply voltages cannot be changed from this controller.
3. The UCD9248PFC (U18) at Address 55 monitors MGTZAVCC, MGTZVCCL, and MGTZVCCH rail voltage and current levels
which can be observed in real time using the Texas Instruments Fusion Digital Power Designer application (see Monitoring Voltage
and Current, page 13). Transceiver supply voltages cannot be changed from this controller.
4. For information on XADC see 7 Series FPGAs and Zynq-7000 All Programmable SoC XADC Dual 12-Bit 1 MSPS Analog-to-Digital
Converter User Guide (UG480) [Ref 1].
Send Feedback

12 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
Using External Power Sources
The maximum output current rating for each power regulator is listed in Table 1-2. If a
design exceeds this value on any core power rail, power for that rail must be supplied
externally through the 14-position core power terminal block J75 shown in Figure 1-4
(callout 22, Figure 1-2) using a supply capable of providing the required current.
Caution! The SW10 power regulator enable switch (callout 21, Figure 1-2) (see Disabling Onboard
Power) must be set to the OFF position before turning ON the main power switch (SW1) and applying
external power to the corresponding rail input pin on the core power terminal block J75 (callout 22,
Figure 1-2).
Caution! The core power terminal block J75 has a maximum load current contact rating of 24A.
X-Ref Target - Figure 1-4
Figure 1-4: Core Power Terminal Block J75
UG965_c1_04_121812
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 13
UG965 (v1.4) February 11, 2015
Detailed Description
Disabling Onboard Power
Each core power regulator can be disabled through the 8-position regulator enable DIP
switch, SW10 as shown in Figure 1-5. A switch in the ON position means the rail is
supplied by an onboard regulator. Setting a switch in the opposite (OFF) position disables
onboard power for that rail. SW10 is shown in Figure 1-2 as callout 21.
Default Jumper and Switch Positions
A list of jumpers and switches and their required positions for normal board operation is
provided in Appendix A, Default Jumper and Switch Settings.
Monitoring Voltage and Current
Voltage and current monitoring and control are available for FPGA core and transceiver
power rails through Texas Instruments' Fusion Digital Power graphical user interface
(GUI). The four onboard TI power controllers (U9 at PMBUS address 52, U10 at PMBUS
address 53, U11 at PMBUS address 54, and U18 at PMBUS address 55) are wired to the
same PMBus. The PMBus connector, J26 (callout 27, Figure 1-2), is provided for use with
the TI USB Interface Adapter PMBus pod and associated TI GUI.
References
More information about the power system components used by the VC7222 board are
available from the Texas Instruments digital power website [Ref 2].
7 Series GTH Transceiver Power Module
The 7 series GTH transceiver power module (callout 25, Figure 1-2) supplies MGTAVCC,
MGTAVTT and MGTVCCAUX voltages to the FPGA GTH transceivers. Two 7 series GTH
power modules from third-party vendors are provided with the VC7222 board for
evaluation, Texas Instruments PMP6577 and Bellnix BPE-37. Either of the two GTH
modules can be plugged into connectors J29 and J102 in the outlined and labeled power
module location shown in Figure 1-6.
X-Ref Target - Figure 1-5
Figure 1-5: Core Power Regulator Enable Switches SW10
UG965_c1_05_121812
Send Feedback

14 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
Caution! To ensure proper operation, do not plug a GTZ power module into the GTH power module
location shown in Figure 1-6. Pay close attention when connecting the GTH or the GTZ power
modules to the board. Both power modules have the same mechanical footprint and can be plugged
into either the GTH or GTZ board interface.
Table 1-3 lists the nominal voltage values for the MGTAVCC, MGTAVTT and
MGTVCCAUX power rails. It also lists the maximum current rating for each rail supplied
by 7 series GTH modules included with the VC7222 board.
X-Ref Target - Figure 1-6
Figure 1-6: Mounting Location, 7 Series GTH Transceiver Power Module
Table 1-3: 7 Series GTH Transceiver Power Module
GTH Transceiver Rail
Net Name Nominal Voltage Maximum Current Rating
MGTAVCC 1.05V 12A
MGTAVTT 1.2V 8A
MGTVCCAUX 1.8V 2.6A
UG965_c1_06_070313
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 15
UG965 (v1.4) February 11, 2015
Detailed Description
The GTH transceiver power rails also have corresponding inputs on the GTH transceiver
power terminal block J72 as shown in Figure 1-7 to supply each voltage independently
from a bench-top power source. J72 is shown in Figure 1-2 as callout 23.
Caution! The 7 series GTH module MUST be removed when providing external power to the
GTH transceiver rails.
Information about the 7 series GTH power supply modules included with the VC7222
Characterization Kit is available from the vendor websites [Ref 3].
7 Series GTZ Transceiver Power Module
The 7 series GTZ transceiver power module (callout 26, Figure 1-2) supplies MGTZAVCC,
MGTZVCCL and MGTZVCCH voltages to the FPGA GTZ transceivers. Two 7 series GTZ
power modules from third-party vendors are provided with the VC7222 board for
evaluation, Texas Instruments PMP6577 and Bellnix BPE-37. Either of the two GTZ
modules can be plugged into connectors J5 and J71 in the outlined and labeled power
module location shown in Figure 1-8.
X-Ref Target - Figure 1-7
Figure 1-7: GTH Transceiver Power Terminal Block J72
UG965_c1_07_121912
Send Feedback

16 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
Caution! To ensure proper operation, do not plug a GTH power module into the GTZ power module
location shown in Figure 1-8. Pay close attention when connecting the GTH or the GTZ power
modules to the board. Both power modules have the same mechanical footprint and can be plugged
into either the GTH or GTZ board interface.
Table 1-4 lists the nominal voltage values for the MGTZAVCC, MGTZVCCL and
MGTZVCCH power rails. It also lists the maximum current rating for each rail supplied by
7 series GTZ modules included with the VC7222 board.
X-Ref Target - Figure 1-8
Figure 1-8: Mounting Location, 7 Series GTZ Transceiver Power Module
Table 1-4: 7 Series GTZ Transceiver Power Module
GTZ Transceiver Rail
Net Name Nominal Voltage Maximum Current Rating
MGTZVCC 1.075V 6A
MGTZVCCL 1.075V 1.3A
MGTZVCCH 1.8V 0.300A
UG965_c1_08_121912
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 17
UG965 (v1.4) February 11, 2015
Detailed Description
The GTZ transceiver power rails also have corresponding inputs on the GTZ transceiver
power terminal block J73 as shown in GTZ Transceiver Power Terminal Block J73
Figure 1-9 to supply each voltage independently from a bench-top power source. J73 is
shown in Figure 1-2 as callout 24.
Caution! The 7 series GTZ module MUST be removed when providing external power to the GTZ
transceiver rails.
Caution! The GTZ transceiver power terminal block J73 has a maximum load current contact rating
of 24A.
Information about the two 7 series GTZ power supply modules included with the VC7222
kit is available from the vendor websites [Ref 3].
Active Heat Sink Power Connector
Callout 29, Figure 1-2
An active heat sink (Figure 1-10) is provided for the FPGA. A 12V fan is affixed to the heats
ink and is powered from the 3-pin friction lock header J121 (Figure 1-11).
X-Ref Target - Figure 1-9
Figure 1-9: GTZ Transceiver Power Terminal Block J73
UG965_c1_09_121912
X-Ref Target - Figure 1-10
Figure 1-10: Active FPGA Heatsink
UG965_c1_10_070313
Send Feedback

18 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
The fan power connections are detailed in Table 1-5:
Figure 1-11 shows the heats ink fan power connector J121.
Virtex-7 FPGA
The VC7222 board is populated with the Virtex-7 XC7VH580T-G2HCG1155E FPGA at U1
(callout 1, Figure 1-2). For further information on Virtex-7 FPGAs, see 7 Series FPGAs
Overview (DS180) [Ref 5].
FPGA Configuration
The FPGA is configured via JTAG using one of the following options:
• USB JTAG connector (callout 9, Figure 1-2)
• System ACE SD (callout 11, Figure 1-2)
• JTAG cable connector (callout 10, Figure 1-2)
The VC7222 board comes with an embedded USB-to-JTAG configuration module (U57)
which allows a host computer to access the board JTAG chain using a standard A to
micro-B USB cable. Alternately, the FPGA can be configured via System ACE from a Secure
Digital (SD) memory card installed in J30 (see System ACE SD Configuration Address DIP
Switches, page 20). Finally, a JTAG connector (J1) is available to provide access to the JTAG
chain using one of Xilinx's configuration cables—Platform Cable USB, Platform Cable USB
II or Parallel Cable IV (PCIV).
Table 1-5: Fan Power Connections
Fan Wire Header Pin
Black J121.1 - GND
Red J121.2 - 12V
Blue J121.3 - NC
X-Ref Target - Figure 1-11
Figure 1-11: Heatsink Fan Power Connector J121
UG965_c1_11_070313
Send Feedback

VC7222 Transceiver Characterization Board www.xilinx.com 19
UG965 (v1.4) February 11, 2015
Detailed Description
The JTAG chain of the board is illustrated in Figure 1-12. By default only the Virtex-7 FPGA
and the System ACE SD controller are part of the chain (J112 jumper OFF). Installing the
J112 jumper adds the FMC interfaces as well.
PROG_B Pushbutton
Pressing the PROG pushbutton SW3 (callout 18, Figure 1-2) grounds the active-Low
program pin of the FPGA.
DONE LED
The DONE LED DS21 (callout 16, Figure 1-2) indicates the state of the DONE pin of the
FPGA. When the DONE pin is High, DS21 lights indicating the FPGA is successfully
configured.
X-Ref Target - Figure 1-12
Figure 1-12: JTAG Chain
UG965_c1_12_070313
FMC1_PRSNT_M2C_L
FMC2_PRSNT_M2C_L
FMC1 HPC
Connector
TDI
TDO
JA2
FMC2 HPC
Connector
TDI
TDO
JA3
U23
Virtex-7
FPGA
TDI
TDO
U1
U57
Digilent
USB-JTAG
Module
TDI
TDO
System Ace SD
Controller
TDI
TDO
U32
CFGTDO
CFGTDI
U59
U58
FMC_JTAG_EN_B
U7
3.3V1.8V
UTIL_3V3
10.0 K
J112
FMC_JTAG_EN_B
Send Feedback

20 www.xilinx.com VC7222 Transceiver Characterization Board
UG965 (v1.4) February 11, 2015
Chapter 1: VC7222 Board Features and Operation
INIT LED
The dual-color INIT LED DS25 (callout 17, Figure 1-2) indicates the FPGA initialization
status. During FPGA initialization the INIT LED illuminates RED. When FPGA
initialization has completed the LED illuminates GREEN.
System ACE SD Controller
The onboard System ACE SD controller U32 allows storage of multiple configuration files
on a Secure Digital (SD) card. These configuration files can be used to program the FPGA.
The SD card connects to the SD card connector J30 (callout 11, Figure 1-2) located directly
below the System ACE SD controller on the back side of the board.
System ACE SD Controller Reset
Pressing the SASD RESET pushbutton SW7 (callout 13, Figure 1-2) resets the System ACE
SD controller. The reset pin is an active-Low input.
System ACE SD Configuration Address DIP Switches
DIP switch SW8 shown in Figure 1-13 selects one of the eight configuration bitstream
addresses in the SD memory card. A switch is in the ON position if set to the far right and
in the OFF position if set to the far left. The MODE bit (switch position 4) is not used and
can be set either ON or OFF. SW8 is shown in Figure 1-2 as callout 12.
The switch settings for selecting each address are shown in Table 1-6.
X-Ref Target - Figure 1-13
Figure 1-13: Configuration Address DIP Switch (SW8)
Table 1-6: SW8 DIP Switch Configuration
Configuration Bitstream Address ADR2 ADR1 ADR0
0ONONON
1ONONOFF
2ONOFFON
3ONOFFOFF
4 OFF ON ON
5OFFONOFF
6OFFOFFON
7 OFF OFF OFF
UG965_c1_13_070313
ADR0
ADR1
ADR2
234
SW8
1
MODE
ON
SYSACE-2 CFG
Send Feedback
