Xintex G-1BB-24-R Original instructions

1
Part Number 18141, H, 01/28/2020
Gasoline Fume Detection System
With Blower Control
Single Channel Systems
G-1BB-R (Black, Round, Blower Control, 12V Solenoid)
G-1BB-24-R (Black, Round, Blower Control, 24V Solenoid)
G-1CB-R (Chrome, Round, Blower Control, 12V Solenoid)
G-1CB-24-R (Chrome, Round, Blower Control, 24V Solenoid)
Dual Channel System
G-2BB-R (Black, Square, Blower Control, 12V Solenoid)
G-2BB-24-R (Black, Square, Blower Control, 24V Solenoid)
Owner’s Manual
&
Installation Instructions
Read and comply with all instructions, warnings and limitations before
installing, servicing or removing this device.

2
Part Number 18141, H, 01/28/2020
Additional copies of this manual are available on the Fireboy-Xintex website. Fireboy-Xintex
reserves the right to change features without notice.
General Information
3
Specifications
3
Operation of Xintex Gasoline Fume Detector(s)
4
Installation
6
Installing the Display Unit (G1BR-B01-D/G1CR-B01-D or G2BS-B01-D)
6
Routing Sensor Cable(s) (FS-X01 CABLE XX’)
6
Installing Gasoline Fume Sensor(s) (FS-T01)
6
Electrical Connections (G1BR-B01-D/G1CR-B01-D or G2BS-B01-D)
7
Testing the System Operation
7
Testing the Gasoline Fume Sensors
7
Maintenance
8
In the Event of an Alarm
8
Repairing Xintex Gasoline Detection Components
8
Returning Xintex Gasoline Detection Components
8
1 Year Limited Warranty
9

3
Part Number 18141, H, 01/28/2020
General Information
WARNING
GASOLINE FUME DETECTORS ARE MEANT TO SERVE AS A SUPPLEMENTAL WARNING SYSTEM. IT
IS NOT MEANT TO REPLACE STANDARD SAFETY PRACTICES WHICH SHOULD BE CARRIED OUT
AROUND EXPLOSIVE GASES.
The G-1BB-R, G-1CB-R, and G-2BB-R Gasoline Fume Detectors are an effective means to monitor
gasoline fumes in an engine compartments, leaking fuel tanks, or fumes from un-burnt
hydrocarbons emitted from faulty exhaust systems. In addition, these units automatically actuate
your bilge Blower to purge the space of fumes. The systems use sensors, located in a place of
interest, and a central display unit that notifies you of the state of the system.
Specification
System Specifications (G-1BB-R / G-1CB-R)
Operating Voltage: 9-30V DC
Nominal Current Draw: 55mA @ 12V DC
Maximum Current Draw: 95mA @ 9V DC
Maximum Blower Output Current: 2A
Operating Temperature: -40°F (-40°C) to 185°F (85°C)
Alarm Horn: ≈ 68 dB
System Specifications (G-1BB-24-R / G-1CB-24-R)
Operating Voltage: 18-30V DC
Nominal Current Draw: 34mA @ 24V DC
Maximum Current Draw: 46mA @ 18V DC
Maximum Blower Output Current: 2A
Operating Temperature: -40°F (-40°C) to 185°F (85°C)
Alarm Horn: ≈ 68 dB
System Specifications (G-2BB-R)
Operating Voltage: 9-30V DC
Nominal Current Draw: 95mA @ 12V DC
Maximum Current Draw: 150mA @ 9V DC
Maximum Blower Output Current: 2A
Operating Temperature: -40°F (-40°C) to 185°F (85°C)
Alarm Horn: ≈ 68 dB
System Specifications (G-2BB-24-R)
Operating Voltage: 18-30V DC
Nominal Current Draw: 47mA @ 24V DC
Maximum Current Draw: 62mA @ 18V DC
Maximum Blower Output Current: 2A
Operating Temperature: -40°F (-40°C) to 185°F (85°C)
Alarm Horn: ≈ 68 dB

4
Part Number 18141, H, 01/28/2020
Operation of Xintex Gasoline Fume Detector(s)
There are 3 LEDs located on the Display Unit for each channel on the system, as well as an LED for
the Blower status. The Green LED, located at the top, indicates that the system is operational.
The Yellow LED, located in the center, indicates that there is a Fault in the system. This is to notify
the user to check the connections and wire runs of the sensors. There may be a break in the
wiring or a disconnected sensor on that channel. The Red LED, located at the bottom, indicates a
fume buildup of 20% of the LEL (Lower Explosive Limit) which is considered an alarm. The Blower
status LED and alarm horn will actuate when the Red LED is illuminated. Whenever the Blower
status LED is illuminated, the Blower is active.
The alarm status will continue as long as the fume level remains at an elevated level. The alarm
horn may be silenced by pressing the “Check/Reset” button, but the Blower will remain active
until the alarm status has ended. The alarm will reactivate after 30 seconds as long as the
Detector remains in alarm status. The problem should never be considered corrected as long as
the Red LED is illuminated.
G1BR-B01-D
G1CR-B01-D
G2BS-B01-D

5
Part Number 18141, H, 01/28/2020
FS-X01 CABLE XX’
FS-T01
FS-T01
G2BS-B01-D
RED –Power (+) 1.0 Amp Fuse from Circuit
Breaker
LACK –Ground (-)
Blower
Ground
Blower Switch
YELLOW –Switching Ground 2A Fuse Included
Positive (+) voltage from
Blower Circuit Breaker
MB30RLY
30
85
87
86
G1BR-B01-D
G1CR-B01-D
FS-X01 CABLE XX’
FS-T01
RED –Power (+) 1.0 Amp Fuse from Circuit Breaker
BLACK –Ground (-)
Blower
Ground
YELLOW –Switching Ground 2A Fuse Included
Positive (+) voltage from
Blower Circuit Breaker
MB30RLY
30
85
87
86
Blower Switch

6
Part Number 18141, H, 01/28/2020
Installation
Installing the Display Unit (G1BR-B01-D/G1CR-B01-D or G2BS-B01-D)
The Display Unit should be located at the instrument panel, so that the visible and audible
indicators may be easily observed.
Drill a 2-1/16” hole to accommodate the G1BR-B01-D/G1CR-B01-D Display Unit.
Drill a 2-1/8” hole to accommodate the G2BS-B01-D Display Unit.
Insert Display Unit into hole and secure with the provided threaded mounting nut. A Trim Ring is
available if needed.
NOTE
DO NOT MAKE ELECTRICAL CONNECTIONS AT THIS TIME. THEY WILL BE ADDRESSED IN A LATER
SECTION.
Routing Sensor Cable(s) (FS-X01 CABLE XX’)
A 20 FT Sensor Cable is provided for each Gasoline Fume Sensor. The Sensor Cables should be
routed starting at the Display Unit, then to the pre-determined location of the Gasoline Fume
Sensor. Connect to the Display Unit using the attached quick-disconnect connectors. Take care
not to pinch, break, or cut the Sensor Cable or put too much stress on the connectors while
routing the cable. Secure the Sensor Cable with the appropriate hardware for the application.
NOTE
DO NOT CUT EXTENSION CABLE FOR ANY PURPOSE. DOING SO VOIDS THE PRODUCTS
WARRANTY. LONGER CABLES ARE AVAILABLE FROM 20 FT TO 100 FT.
Installing Gasoline Fume Sensor(s) (FS-T01)
The Gasoline Fume Sensor should be located in the Bilge, just above the “Slosh Line”. A good rule
of thumb is to install no lower than the height of the starter solenoid. Avoid locating sensors near
manifold or exhaust systems, as high heat may damage the sensor.
Use the appropriate #8 mounting hardware to mount the Gasoline Fume Sensor in the desired
location. The rubber gasket should be installed between the sensor and the mounting surface.
Connect to the Extension Cable using the attached quick-disconnect connectors.

7
Part Number 18141, H, 01/28/2020
Electrical Connections (G1BR-B01-D/G1CR-B01-D or G2BS-B01-D)
The Display Unit operates on 9-30V DC. A Red and a Black 16 GA wire are provided for connecting
to the power source. Connect the Red wire to Power (+) with an inline 1.0 Amp fuse. Connect the
Black wire to Ground (-).
A 2A fused Yellow 16 GA wire is provided for connecting the Display Unit to the Bilge Blower
system. Connect the Yellow wire to terminal 85 of MB30RLY/MB30RLY-24. Connect the positive
(+) voltage to terminals 30, 86, and the Manual Blower Switch. Connect the Ground to the Blower
System.
NOTE
UNITS MANUFACTURED PRIOR TO JANUARY 01, 2018 DO NOT INCLUDE THE 2A FUSE. A
DEDICATED 2A FUSE OR BREAKER SHOULD BE USED TO POWER THE BILGE BLOWER SYSTEM.
NOTE
IMPROPER CONNECTIONS WILL DAMAGE THE DISPLAY UNIT AND WILL VOID WARRANTY.
Testing the System Operation
The Gasoline Fume Detectors can be tested by pressing the “Check/Reset”button on the face of
the Display Unit. The Display Unit will cycle through the LEDs and the alarm horn will activate
while the LEDs cycle.
Unplug the Gasoline Fume Sensor from each channel of the Detection System one at a time. The
Yellow “Fault” LED should illuminate. If the Yellow LED does not illuminate, remove Display Unit
and return direct to manufacturer following the instructions at the back of this manual.
Press the Blower button on the Display Unit. The Blower system should turn on until the button is
released.
Testing the Gasoline Fume Sensors
WARNING
DO NOT USE A GASOLINE SOAKED RAG OR A PARTIALLY FULL CONTAINER OF GASOLINE TO TEST A
SENSOR. THE RAW GASOLINE COULD IGNITE, RESULTING IN SERIOUS INJURY.
Test the Sensors by holding an unlit Butane lighter to the sensor. Within a few seconds, the Red
“Danger” LED should illuminate, Blower will activate, and the alarm horn will sound. Remove the
lighter from the Sensor and mute the alarm horn. After approximately one minute, the Red LED
will shut off.

8
Part Number 18141, H, 01/28/2020
Maintenance
The system should be tested periodically in the fashion described in the previous sections. Due to
the harsh environmental conditions in marine applications, it is recommended to replace the
Gasoline Fume Sensors every 3-4 years.
In the Event of an Alarm
Immediately have all passengers and crew exit the passenger compartment and vessel if possible.
Ventilate the space being monitored.
Carefully check all fuel lines and other potential sources of gasoline fume leaks. If leaks are
identified, shut off fuel supply and make any necessary repairs.
Repairing Xintex Gasoline Fume Detection Components
Xintex Gasoline Fume Detection Components are not field serviceable. Components must be
returned to the factory for any repairs.
Returning Xintex Gasoline Detection Components
No product may be returned for credit or repair without a written “Returned Material
Authorization” (RMA) form. Purchaser must call or email Fireboy-Xintex 616-735-9380 or
[email protected] for a RMA. If due to extenuating circumstances a product is to be
returned, after approval it must be received in 100% new/resalable condition. Products stored by
the buyer for more than 26 weeks may not be returned for any reason. Maintaining fresh and
current inventory is the responsibility of the buyer.

9
Part Number 18141, H, 01/28/2020
1 Year Limited Warranty
This Warranty is in lieu of all other expressed or implied Warranties
Seller warrants title, materials, and workmanship on equipment, except components
manufactured by others for which the Seller assigns, as permitted, the original manufacturer’s
warranty. Seller’s warranty shall be for a period of (1) one year from the date of sale to the
ORIGINAL CONSUMER PURCHASER, during which non-conforming equipment returned to the
Seller at Buyer’s expense and risk, be repaired or replaced at the Seller’s option. Fireboy-Xintex
LLC will repair or replace products found to be defective in materials or workmanship within the
period set forth above, provided that: (a) the product has not been subjected to abuse,
contamination, neglect, accident, incorrect wiring not our own, improper installation or servicing,
or used in violation of instructions furnished by Fireboy-Xintex LLC and (b) as to any prior defects
in materials or workmanship covered by this warranty, the product has not been repaired or
altered by anyone except Fireboy-Xintex LLC and (c) the serial number has not been removed,
defaced or otherwise changed, and (d) examination discloses, in the judgment of Fireboy-Xintex
LLC, does not assume the costs of removal and/or installation of the product or any other
incidental costs of removal and/or installation of the product or any other incidental costs which
may arise as a result of any defect in material or workmanship, and (e) upon discovery of defect,
Buyer shall immediately cease use of and notify Fireboy-Xintex LLC.
Any warranty implied by law, including warranties of merchantability or fitness, is in effect only
for the duration of the expressed warranties set forth above, no person is authorized to give any
other warranty, or to assume for Fireboy-Xintex LLC any other liability in connection with the sale
of its products; Fireboy-Xintex LLC shall not be liable for the loss of use, revenue, or profit or for
any injury, or for any other consequential or incidental damages, buyer is not relying on seller’s
judgment regarding his or her particular requirements, and has had an opportunity to inspect the
product to his or her satisfaction.
This warranty gives you specific legal rights, and you may also have other rights, which vary, from
state to state.
