XL displays 3m x 3m Printed Gazebo User manual

FOR ATTENTION 1 2
3
45
67
CAUTION
Scissor sections
of frame are a
pinching hazard
Remove frame from bag. Extend the
frame partially by pulling outwards. Apply canopy loosely over the frame.
Continue to extend frame
by pulling outwards until
corner snap button“clicks”
into position
While standing on triangular
foot, extend the tent legs by
pulling up until snap button
“clicks into place.
Pull canopy down tightly
over the corners of the frame
Secure all interior velcro fastenings
• Take Shelter Down in
Heavy Wind
• Allow fabric to dry before
putting away
• Store in cover bag when
tent is not in use
2 wood grain finishes.
3m x 3m Printed Gazebo
Assembly Instructions
www.xldisplays.co.uk
01733 511030

A
SECURING TENT
COLLAPSING TENT
Secure using Guy Ropes
and Pegs through Canopy Loops
Secure using Pegs through
the Holes in Tent Feet
option
B
option
Depress Snap Buttons on all
legs and retract lower
section of the leg inside the
upper section.
Slowly collapse frame by
pushing in on itself. Remove
Canopy as it starts to slacken
Release Frame Corner
Auto Slider by pressing
Snap Button
Collapse frame entirely
1 2
3 4 5
Note: Hammer/Mallet required for pegs
2 wood grain finishes.
3m x 3m Printed Gazebo
Assembly Instructions
www.xldisplays.co.uk
01733 511030
